Afiladoras de bandas

CARACTERÍSTICAS TÉCNICAS: Área de trabajo: 2400 x 800 mm Ajuste de altura: 550 mm Potencia instalada: 3 Kw Velocidad de desplazamiento vertical Longitud máx. de la correa: 6650 mm Poleas: Ø 200 mm

Código: 0021 Marca: BOHR - AUSTRIA Modelo: 150/330 Lijadora para lijadora de banda Lijadora universal para lijadoras de banda en grafito para madera maciza y chapa - mm 330 x 150 Dimensiones total mm 330 x 150 x 100 h Peso kg 4

CARACTERÍSTICAS TÉCNICAS: Potencia instalada: 5,5 kW 2 volantes de inercia Ø 450 mm Longitud de la correa de lijado: 4900 mm 2 ajustes de velocidad

anchura de las tiras: 150 mmfila de banda: 2000 mmvelcidad de banda: 30 m/scargo total de potencia: 3,6 kWpeso de la máquina ca.: 138 tdimensiones de la máquina ca.: 995 x 490 x 890 mm

ancho de las tiras: 75 mmfiler de banda: 2000 mmvelcidad de banda: 30 m/s: 75 x 540 mmcargo de potencia total: 3 kWpeso de la máquina aprox.: 90 kgdimensiones de la máquina ca.: 995 x 415 x 890 mm

Número de unidades de lijado: 2 st.Ancho de lijado: aprox. 180 mm Altura de lijado máx.: 12 - 140 mm

Number of sanding units: 4 Stsanding width: 190 mmSanding height max.: 4-180 mmweight: 4200 kgHess Expert 4-belt single wood sanding machine--------------------------------------Ø Grinding at the bottom/topØ With 2 offset grinding units each (bottom and top)Ø Grinding units (bottom and top) connected in series according to theDressing principleØ Pre-sanding with coarse grit (calibrate)Ø Regrinding with fine grit (finish)Ø Central motorized height adjustment of the lower grinding unitsØ Central motorized and synchronous height adjustment of the entire upperGrinding and brushing units including the upper transport unitsØ Oscillating sanding belt utilization (during the sanding process)Ø Absolute power connection thanks to 5.5 KW motors and large dimensionsdrive drumsØ Oxide ceramic grinding shoe for- exact surface geometry- no adjustment work- permanent dimensional accuracy- comp ...

Number of sanding units: 2 st.sanding width: 190 mmSanding height max.: 4-150 mmHess Junior single wood sander---------------------------------basic structure:Stable, heavy welded construction made of thick-walled rectangular hollow profileswith additional, statically calculated bracing for optimalvibration damping.Staggered grinding units with large dimensionedBelt drive drums for slip-free belt travel. Two-point suction for directand airborne dust extraction with integrated blow-off device. grinding unitsin heavy steel plate construction as the basis for vibration-damped,quiet belt run. All guides as a ball linear set on hardened andpolished waves. Lasting precision thanks to protection against dust and dirtof the sphere linear sets. Contact roller and sanding pad in a balanced ratioto the grinding belt grain load. The large dimensioned drive drumsguarantee the full transmission of the ...

Number of sanding units: 2 st.sanding width: 190 mmSanding height max.: 4-150 mmHess Junior single wood sander---------------------------------basic structure:Stable, heavy welded construction made of thick-walled rectangular hollow profileswith additional, statically calculated bracing for optimalvibration damping.Staggered grinding units with large dimensionedBelt drive drums for slip-free belt travel. Two-point suction for directand airborne dust extraction with integrated blow-off device. grinding unitsin heavy steel plate construction as the basis for vibration-damped,quiet belt run. All guides as a ball linear set on hardened andpolished waves. Lasting precision thanks to protection against dust and dirtof the sphere linear sets. Contact roller and sanding pad in a balanced ratioto the grinding belt grain load. The large dimensioned drive drumsguarantee the full transmission of the ...

Number of sanding units: 2 st.sanding width: 190 mmSanding height max.: 4-150 mmHess Junior single wood sanding machine--------------------------------Machine in checking process at the moment!Basic structure:Stable, heavy welded construction made of thick-walled rectangular hollow profiles with additional, statically calculated reinforcements for optimalVibration dampening.Staggered grinding units with large dimensionsBelt drive drums for slip-free belt running. Two-point suction for directand airborne dust extraction with integrated blow-off device. grinding unitsin heavy steel plate construction as the basis for vibration-damped,quiet tape running. All guides as a ball linear set on hardened andpolished waves. Permanent precision thanks to dust and dirt protectionthe ball linear sets. Contact roller and sanding pad in a balanced ratiofor sanding belt grain load. The large-sized drive  ...

anchura de las tiras: 75 mmlargo de banda: 2000 mmvelcidad de banda: 37 m/mincargo total de potencia: 3 kWpeso de la máquina ca.: 110 Kgdimensiones de la máquina ca.: 1x0,5x1 m

Lijadora de banda de banco Höfer Motor 4.2KW formato 2.50 x 1.20 metros

Máquina de molienda de correa para madera y metal, espaciado de rodillos aprox. 3000 mm

Working width: 300 mmNumber of sanding units: 6 st.Workpiece thickness max.: 8-230 mmWeight: 3100 kgLöwer double-sided grinding machine DSM 3304 GDR---------------------------------Manufacturer short description:Double-sided single wood sander for sandingof solid wood such as window wood orFurniture components made of MDF etc. Stable top designwith electronic articulated pressure shoes for fine grindingwell-planed or veneered surfaces.Sanding units arranged one after the otherFine grinding, disc aggregates for defibering grinding,Cleaning brush, from above and below as follows:1. Belt sanding unit with articulated pressure shoe2. Belt sanding unit with articulated pressure shoe3. Disc unit with brush sanding flaps diameter 320mm4. Cleaning brush with Tempicofibre trim diameter 120mm---------------------------------detailed long text of the manufacturers description as well as theInstall ...

Number of sanding units: 8 st.sanding width: 180 (260) mmSanding height max.: 160 mmDimensions (length / width): 3065x1600x1900 mmweight of the machine ca.: 1500 kgLöwer Leistomad SDWindow single wood intermediate sanding machine---------------------------------Machine factory tested by Löwer!Automatic fine grinding machine for wood grinding (smoothing, defibering andEdge breaking) or intermediate sanding of profiled window bars. With soft discTechnology for the visible surfaces as well as automatically safe profile andWidth adjustment.- 2 lamella roller units on the side, each 0.37kW, L=100mm, D=200mm- 1 softisc unit Ø=200mm above 0.75kW,- 1 slat roller unit L=200mm above 0.75kW- 1 soft disc unit Ø=200mm below 0.75kW,- 1 lamella roller unit L=200mm below 0.75kW,- 2 lamella roller units on the side, each 0.37kW, L=100mm, D=200mm- Linear guidance of all grinding units via linear ball  ...

Number of sanding units: 8 st.sanding width: 150 mmMachine can be inspected during production!Leistomat - Finisch and intermediate leveling machine Löwer LZ 8-------------------------------------------------- -------------------for finish sanding (smoothing, defibering and edge breaking)or intermediate sanding profiled window latch- Finish and intermediate sanding machine with eight sanding blade aggregates,2 surface units at the top (synchronism / counter-rotation)2 surface units below (synchronism / counter-rotation)4 profile units with angled arrangement top right,bottom right, top left, bottom left, all mating- linear guidance of all grinding units overLinear ball bearing sets on hardened shafts- Timed immersion of all in the opposite directionrotating grinding units directly above the incomingWorkpiece edges to avoid looping through thePrimer in the front edge area. By theIt is pos ...

Number of sanding units: 1 st.sanding width: 150 mmSanding height max.: 150 mmLöwer edge finishing machine MiniSpin NMachines for finishing and intermediate sandingEdges and profiles with a grinding spindlehorizontal or vertical.Motor 0.75 KWSpindle in vertical position for processing edgesSpindle in horizontal position, swung out to the sidefor processing longer profile bars or similar or inConnection with a combination grinding head for grindingof edges with a sanding flap discGrinding head can be swiveled +/- 20° for processingof slanted edgesWorking height / width 150 mmmax. diameter roller / brush < 300 mmFrequency converter for continuous adjustment of theSpindle speed 200 - 800 rpmTable size 400 x 800 mmtwo directions of rotation selectableOperating voltage 110 / 240 V, 50 / 60 HzSuction connection D=100 mmWeight approx. 100 kgincluding grooved base body D=180, L=150with Smartfl ...

Código: 0198 Marca: MABO - ITALIA Modelo: DELTA Lijadora de banda con doble cuello de cisne para madera, metal, aluminio, materiales compuestos Longitud de la mesa mm 3000 Ancho de la mesa mm 800 Elevación automática de la mesa - Carrera vertical mm 550 Motor 2 velocidades rpm 1400/2800 - Hp 3/4 Diámetro de la polea mm 200 Motor de aspiración Hp 0,5 Cuerda de emergencia Diámetro de la boca de aspiración mm 120 Dimensiones totales mm 4400 x 1100 x 1550 h Peso kg 420

CARACTERÍSTICAS TÉCNICAS: Rectificadora de banda horizontal Ancho de mesa mm: 800 Longitud de la mesa mm: 2.900 Ancho de la banda de lijado mm: 1.500 Longitud de la correa de lijado mm: 8,000 Altura máxima de trabajo mm: 600 Potencia del motor principal HP: 4 Con zapato de lijado

ancho de las tiras: 75 mmlongitud de banda: 2000 mmvelocidad de banda: 30 m/s: 75 x 540 mmpotencia total requerida: 3 kWpeso de la máquina aprox.: 90 kgdimensiones de la máquina ca.: 995 x 415 x 890 mm

Se vende lijado de segunda mano maschine steinemann. Papel arriba y abajo, súper ancho, 200kw. 1990 yc. Corto usado.
