Tijeras de las pizarras de los motores

sheet width: 1050 mmplate thickness: 3.0 mmthickness at Niro-steel: 1.5 mmno. of strokes: 35 Hub/mincutting angle: 2°30 °engine output: 3.0 kWtable height: 810 mmweight of the machine ca.: 1150 kg.range L-W-H: 1300 x 1520 x 1170 mm from a maintenance workshop ()Furnishing:- robust electro-motorized metal sheet shears- manual backgauge- adjustable up to 610 mm, using the handwheel from the back- 1x side stop including mm scale- 2x table sheet metal support arms- Piece counter- freely movable foot switch- rear sheet metal slide- EMERGENCY stop button at the front Machine link:https://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machinen o=1008-9325126The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

1) Cizalladura mecánica de guillotina COLGAR mod. 3006 Año 1997 longitud 3050 mm ancho 32000 mm pasaje entre montantes 250-500 espesor de cuchillas afiladas 7 mm 2) Cizalladura mecánica de guillotina COLOGAR mod. CS 1520 Longitud= 1550 mm Longitud de la hoja = 1580 paso entre montantes = 1600 Hueco 250 mm. Capacidad de corte con cuchillas afiladas de 22 mm. 3) Cizalladura mecánica de guillotina COLGAR CM 3020 Año 1997 Longitud de corte útil 3050 mm Longitud lamw 3550 mm Paso entre montantes 3465 mm Espesor 22 mm.

sheet width: 2550 mmplate thickness: 4,0 mmdistance between columns: 2600 mmback stop - adjustable: 750 mmno. of strokes: 42 Hub/mincutting angle: 1°30 table width: 450 mmtable height: 800 mmtotal power requirement: 7,5 kWweight of the machine ca.: 3230 kgdimensions of the machine ca.: 3200 x 2300 x 1350 mm Current new price with special accessories ~ 33.000 euros from a maintenance workshop / good condition ()Furnishing:- robust / powerful mechanical guillotine shears- electric backgauge, with ball screws- with DURMA NC control - model D-Touch 7 Control unit with touchscreen function 128 MB internal memory (programming possible) Multilingual (English, Turkish, German) INCH/metric conversion- manual cutting gap adjustment, from the front analogue display of the material thickness- 1x extra long side stop 2.000 mm, with support foot & T-slot- 2x support arms- Ball casters in the support  ...

sheet width: 2540 mmplate thickness: 3.25 mmthroat: 100 mmno. of strokes: 60.0 Hub/minback stop - adjustable: 530 mmvoltage: 400 Vengine output: 7.5 kWweight: 2450 kgrange L-W-H: 3600 x 1000 x 1560 mmFurnishing:- robust electric motorized guillotine shears- stable, front support/work table- Front control panel - including emergency stop button- manual back gauge up to approx. 700 mm- adjustable by handwheel, with analogue mm scale display- 1x front side stops- 3x front support arms- manual cutting gap adjustment- Cut/lift confirmation by foot pedal- 1x freely movable foot switch- rear sheet metal slide- User manual (PDF) Machine link:http://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machineno =1008-9325320The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 1050 mmplate thickness: 3,0 mm STcutting angle: 2,0 °stroke max.: 38 p. Min.total power requirement: 5,5 kWweight of the machine ca.: 1690 kg.range L-W-H: 1800 x 1800 x 1250 mm from a maintenance workshop ()Furnishing:- Motorized / electric guillotine shears- manual backgauge, adjustment by hand crank Travel range max. 700 mm with analogue position display (scale) manual adjustment from behind- rear protection- rear sheet metal slide- free-moving footswitchThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 605 mmplate thickness: 1.50 mmdistance between columns: 605 mmback stop - adjustable: 300 mmtable width: 605 mmoperating pressure: max 6.0 barwork height max.: 1025 mmwork table:: 605 x 250 weight of the machine ca.: 268 kgdimensions of the machine ca.: 1200 x 950 x 1300 mmFurnishing:- pneumatically driven sheet metal shears- manual backgauge- Pneumatic pressure gauge- 2x side table stops including mm scale- 1x movable table stop- Piece counter- mechanical sheet metal hold-down device- Machine light- freely movable foot switch Machine link:https://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machinen o=1008-9325334The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 2100 mmplate thickness: 3.0 mmthickness at Niro-steel: 1.5 mmblade length: 2110 mmno. of strokes: 34 Hub/minback stop - adjustable: 1000 mmcutting angle: 1.5 °work height max.: 880 mmControl: DIGI engine output: 6.25 kWweight: 2650 kgrange L-W-H: 2750 x 2350 x 1550 mm Machine from a maintenance workshop maintained condition ()Furnishing:- robust electro-mechanical sheet metal shears- Machine body in a closed design as an all-steel welded construction- heavy / robust drive motor (5.5 KW)- electro-motorized backgauge, including digital control unit Adjustment range max. 1.000 mm Input of target / actual value possible- manual cutting gap adjustment, adjustable from the front- 1x table side stop- Ball rollers in the support table- 1x freely movable foot switch, including EMERGENCY stop button- front finger protection- original instruction manual Machine link:http://mhp.logotec ...

sheet width: 1040 mmplate thickness: 4,0 mmthickness at Niro-steel: 2,5 mmblade length: 1100 mmno. of strokes: ca. 38 Hub/minback stop - adjustable: ca. 500 mmControl: konv. table height: 820 mmNumber of working hours: ca. 610 hengine output: 5,0 kWweight: 2250 kgrange L-W-H: 1650 x 1900 x 1300 mm Machine from a maintenance workshop with only approx. 610 operating hours ()Furnishing:- heavy / robust electro-mechanical sheet metal shears- Machine body in a closed design as an all-steel welded construction- heavy / robust drive motor (5.0 KW)- manual back gauge, adjustable from the rear Adjustment by handwheel, with mm scale- 1x side stop- 2x front support arms with T-slot- manual central lubrication- Operating hours counter- Special accessories: 1x set of LOTZE replacement knives Machine link:http://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machineno =1008-9325309The data for this  ...

sheet width: 1040 mmplate thickness: 2,50 mmno. of strokes: 63 Hub/mincutting angle: 1,66 °column arm: 100 mmtable height: ca. 750 mmtotal power requirement: 3,0 kWweight of the machine ca.: 750 kgrange L-W-H: 1470 x 1550 x 1020 mm Refurbished - shear blades sharpened like New ()Furnishing:- manual backgauge 0-550 mm- with analogue measuring scale and magnifying glass- adjustable in front, by adjusting lever- 1x long side stop 850 mm- free-moving footswitch- Scratch protection on support tableThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 2040 mmplate thickness: 2.00 mmthickness at Niro-steel: 1.25 mmno. of strokes: 63 Hub/mincutting angle: 1.10 Gradtable height: 750 mmdistance between columns: 2120 mmback stop - adjustable: 0 - 550 mmcolumn arm: 100 mmControl: manuell engine output: 2.8 kWweight of the machine ca.: 1100 kg.range L-W-H: 2650 x 1980 x 1400 mmFurnishing:- robust / motorized swing-cut guillotine shears- Shatterproof, torsion-free steel welded construction- compact and clear mechanical design- manual backgauge, with analogue position display adjustable from the front Continuous adjustment over the entire travel range Adjustment range 0.0 - 550 mm- Machine side stand with projection .. 100 mm- 1x hold-down bar- 1x long side stop with mm scale- 2x support arms- 1x freely movable foot switch- rear sheet metal slide- Connection cable including plug- original instruction manual Machine link:http://mhp ...

sheet width: 2040 mmplate thickness: 3.0 mmthickness at Niro-steel: 1.5 mmno. of strokes: 50 Hub/mincutting angle: 1.4 Gradtable height: 750 mmdistance between columns: 2120 mmback stop - adjustable: 1.0 - 550 mmcolumn arm: 100 mmControl: manuell engine output: 5.5 kWweight of the machine ca.: 2050 kg.range L-W-H: 2600 x 1980 x 1400 mmFurnishing:- robust / motorized swing-cut guillotine shears- Shatterproof, torsion-free steel welded construction- compact and clear mechanical design- manual backgauge, with analogue position display adjustable from the front Continuous adjustment over the entire travel range Adjustment range 1.0 - 550 mm- Machine side stand with projection .. 100 mm- manual cutting gap adjustment- 1x hold-down bar- 1x long side stop- 2x support arms- 1x freely movable foot switch- rear sheet metal slide- 2x EMERGENCY stop buttons at the front- Connection cable including p ...

sheet width: 2540 mmplate thickness: 2,0 mmthickness at Niro-steel: 1,25 mmno. of strokes: 34 Hub/mincutting angle: 1,4° table height: 820 mmdistance between columns: 2600 mmControl: konv. engine output: 4,0 kWweight of the machine ca.: 1330 kg.range L-W-H: 2892 x 1865 x 1430 mmFurnishing:- robust / motorized swing-cut guillotine shears- Shatterproof, torsion-free steel welded construction- compact and clear mechanical design- All-steel knife, double-edged- 1x hold-down bar- Support/work table with 10 mm gaps- extended, extendable support table- freely movable foot switch- Operation manual Special accessories included:- electro-motorized back gauge with analogue position display Fine adjustment via handwheel at the front- Sheet metal holding device for thin sheet metal cuts Machinelink : http://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machineno=1008 -9325306The data for this ad  ...

sheet width: 2030 mmplate thickness: 4,0 mmthickness at Niro-steel: 2,5 mmno. of strokes: 34 Hub/mincutting angle: 2,5 Gradtable height: 820 mmdistance between columns: 2340 mmControl: POS 100 back stop - adjustable: max. 750 mmengine output: 6,8 kWweight of the machine ca.: 2860 kg.range L-W-H: 2870 x 2070 x 1400 mm Machine from a maintenance workshop very well maintained condition - hardly used ()Furnishing:- robust / motorized swing-cut guillotine shears- Shatterproof, torsion-free steel welded construction- compact and clear mechanical design- Electric back gauge, with SCHRÖDER POS 100 NC control Digital position display from the backgauge adjustable from the front right with target/actual value input Continuous adjustment over the entire travel range Protection of limit values with limit switches 9-fold programming possible- Duo-Cut drive with two dynamic, powerful geared motors- S ...

sheet width: 2030 mmplate thickness: 4,00 mmthickness at Niro-steel: 2,50 mmno. of strokes: 34 Hub/mincutting angle: 2,5 Gradtable height: 820 mmdistance between columns: 2340 mmControl: POS 100 back stop - adjustable: max. 750 mmengine output: 6,8 kWweight of the machine ca.: 2860 kg.range L-W-H: 2870 x 2070 x 1400 mm Machine from a maintenance workshop very well maintained condition - hardly used ()Furnishing:- robust / motorized swing-cut guillotine shears- Shatterproof, torsion-free steel welded construction- compact and clear mechanical design- Electric back gauge, with SCHRÖDER POS 100 NC control Digital position display from the backgauge adjustable from the front right with target/actual value input Continuous adjustment over the entire travel range Protection of limit values with limit switches 9-fold programming possible- Duo-Cut drive with two dynamic, powerful geared motors- ...

Ancho de la chapa: 2.040 mm Espesor de la chapa: 3,0 mm Distancia entre columnas: 2.210 mm Tope trasero - ajustable: 540 mmTensión: 400 VPeso de la máquina aprox.: 2,5 tDimensiones de la máquina aprox.: 2,50 x 2,10 x 1,25 mCizalla de placa motorizada - interruptor de pie - Tope trasero ajustable

sheet width: 2060 mmplate thickness: 04,0 mmdistance between columns: mmtable width: 455 mmwork height max.: 880 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3060 mmplate thickness: 04,0 mmdistance between columns: mmtable width: 455 mmwork height max.: 880 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Ancho de la hoja: 2000 mm Grosor de la placa: 3 mm Distancia entre columnas: 2080 mmPotencia total requerida: 5 kWPeso de la máquina aprox.: 2,5 TDimensiones de la máquina aprox.: m
