Máquinas dobladoras de anillos KLAEGER BR 71

I - beam section - flat steel: 120 x 20 (d 750) mm
I-beam section - upend: 60 x 10 (d800) mm
L-beam: 50 x 5 (d 1200) mm
bar material - diameter: 35.0 (d 800) mm
bar material dia. max.: 70 x 3.0 (1200) mm
: 50.0 mm
diameter of upper rolls: 155 mm
diameter of lower rolls: 155 mm
Stroke length: 150 mm
Rotating speeds: 9.0 U/min
total power requirement: 1.3 kW
weight: 305 kg
range L-W-H: 900 x 700 x 1500 mm
Features:
- Robust electric-motor-driven ring/profile bending machine
- Machine base frame with rear storage shelf
- Capable of horizontal and vertical operation
- Equipped with a wide variety of roller sets
Split roller segments
Pipe rollers
- Manual feed of the upper roller
- Analog position indicator for the upper rollers (scale)
- Manually adjustable side/aligning rollers
- Base frame with forklift pockets
For easy transport
