Máquinas de pulido doble disco (5)

Rectificadora de doble disco

CONTROLS  conventional WORKING RANGE (DOUBLE DISC GRINDER)  Grinding wheel diameter: 750 mm  grinding width max. - throughfeed grinding: 150 mm  material thickness max. - throughfeed grindin: 70 mmGRINDING SPINDLE 1  spindle revolutions (max): 610 /minGRINDING SPINDLE 2  spindle revolutions (max): 610 /minCOMPONENT-FEEDER  Feeder Design: rotary Feeder DIMENSIONS / WEIGHTS  space requirements -left/right-: 5230 mm  space requirements -front/back-: 4460 mm  total height: 3600 mm  total weight approx.: 11000 kgMachine is dismantled and stored

CONTROLS  CNC controls SIEMENS 840 C WORKING RANGE (DOUBLE DISC GRINDER)  Grinding wheel diameter: 457 mm  grinding width max. - throughfeed grinding: 80 mm  material thickness max. - throughfeed grindin: 20 mm  grinding width max. - plunge cut grinding: 205 mm  material thickness - plunge cut grinding: 80 mmGRINDING SPINDLE 1  drive power: 23 kWGRINDING SPINDLE 2  drive power: 23 kWCOMPONENT-FEEDER  Feeder Design: rotary Feeder   feeder velocity max.: 240 mm/min  feeder velocity min.: 20 mm/minScope of delivery:- Machine- emulsion tank new in 2012Measuring control IONIC 17A

CONTROLS  CNC controls SIEMENS 840 D WORKING RANGE (DOUBLE DISC GRINDER)  Grinding wheel diameter: 750 mm  grinding width max. - throughfeed grinding: 180 mm  material thickness max. - throughfeed grindin: 30 mm  grinding width max. - plunge cut grinding: 300 mm  material thickness - plunge cut grinding: 80 mmGRINDING SPINDLE 1  drive power: 48 kWGRINDING SPINDLE 2  drive power: 48 kWCOMPONENT-FEEDER  Feeder Design: rotary Feeder   feeder velocity max.: 20 mm/min  feeder velocity min.: 240 mm/minDIMENSIONS / WEIGHTS  space requirements -left/right-: 4900 mm  space requirements -front/back-: 5000 mm  total height: 3100 mm  total weight approx.: 13000 kgwith inline measuring system DISKUS IONIC 17AEmulsion treatment system HÜTTNER F6-157 ...

CONTROLS  CNC controls SIEMENS 810 T WORKING RANGE (DOUBLE DISC GRINDER)  Grinding wheel diameter: 750 mm  grinding width max. - throughfeed grinding: 180 mm  material thickness max. - throughfeed grindin: 30 mm  grinding width max. - plunge cut grinding: 180 mm  material thickness - plunge cut grinding: 30 mmCOMPONENT-FEEDER  Feeder Design: rotary Feeder ELECTRICAL SPECIFICATIONS  total power consumption: 95 kWScope of delivery:- Machine- div. flanges and used grinding wheels- Measuring control IONIC 17AOptional:- 270 pcs. grinding segments 22A 100 S 6 B20- 289 pieces grinding segments 14C 80 L 10 B30Machine is dismantled and stored
