Máquinas para fabricar ventanas de plástico ROTOX EPA 472

Corner cleaning machine ROTOX
Type EPA 472 6605
Year of construction 2010

CNC Corner Cleaning Machine
Fully automatic plastering of visible surfaces, outer corners,
Sealing grooves/areas, inner corners on PVC window frames and sashes, also with radii, curves and slopes.

Automatic profile feeding
Integrated reversible arm for turning frame elements
Variable tool loading with up to 12 tool positions
Tool diameter 170/190 mm

Machinable profile width 50 mm – 130 mm
Machinable profile height 50 mm – 115 mm

Revolutions 5500 rpm.
Current consumption 22.8 amps
Voltage 400 volts
Frequency 50 Hz
Compressed air 6-7 bar

Weight 1,980 kg
Machine dimensions approx.
6000 mm x 4000 mm x H 2000 mm


seller offer No. resale 9771
