rectificadoras madera usadas para la venta (637)

Datos técnicos: Construcción de acero soldado antivibración Accionamiento de cadena continuo de 86 mm de ancho, piezas de cadena de acero y plástico, cojinetes autolubricantes, cambio a guía prismática Velocidad de la correa infinitamente ajustable 5-25 m / min Mesa de trabajo de altura mínima 870 mm (ajustable) La unidad de presión superior con ruedas de goma ajustables rodamientos de bolas de 60 mm Unidad de presión lateral con ruedas de goma rodamientos de bolas de 40 mm Workshoehe Mín. / Máx. 10/100 mm Longitud mínima 50 mm Ancho de trabajo mínimo de 30 mm La anchura máxima es de 200 mm Potencia del motor de alimentación 3 kW 1 unidad de frause kW/2800 2,4 rpm 4 bucles Geraete con motores oscilantes Leistunj cada 4 x 1,7 kW 2800ot/min Consumo total de energía 12,5 kW Máquina de primer año 3000 kg Muy buen estado, probado en el taller ...

Máquina de molienda de banda larga pintura de molienda intermedia Datos técnicos: Ancho de molienda: máx. 2.300 mm, mín. 200 mm Tueckhoehe de fábrica 8 - 200 mm 1.Masa de la correa de molienda 100-120 mm x 9000 mm 2.Masa de la correa de molienda 150 mm x 9000 mm Masa de siband listón de lamas a presión 10 mm x 7280 mm Velocidad de la cinta 4 - 12,5 m/min Adecuado para lijado de pintura intermedio Potencia del motor de molienda 10/16 kW Potencia total: 20 kW Dimensiones de la máquina aprox. W 4590 x L 2344 x H 1640 mm Peso de la máquina 2150 kg Generalmente anticuado

Brushing machine brand: Ecoline Type: Rustikmat 2-1000 New machine 2 brushes More stability due to the lower brush position Length of the brushes 1000 mm; Diameter 270 mm. Power 4 kW per brush. Each brush can rotate in synchronism and counter-rotation. Working width: 1000 mm Working thickness: 120 mm. Workpiece dimensions: Min. length: 350mm Max. Width: 1000mm Max. Thickness: 120mm Electric adjustment of thickness, speed and feed with digital display. Spindle diameter 50 mm. Infinitely variable feed: 0 - 12 m/min. The speed of the brushes and the feed speed are controlled by frequency converters. The heavy machine bed allows deep structuring of the plates.

Brush grinding machine Brand: Ecoline Type: B Sand 5 New machine The B Sand 5 as a high-quality solution for your production. The individual equipment offers many possibilities. In addition to panels and profiled doors, sash surfaces can also be processed, for example. A perfect result for different types of materials and surfaces: - Solid wood, MDF, veneered parts... - impregnated, primed surfaces... Technical data: Workpiece dimensions: Min. length: 550 mm Min. thickness: 10mm Max. Width: 1550 mm Max. Thickness: 120 mm Power: 11 kW Air pressure: 6-8 bar Suction nozzle: 6 x Ø120mm unit - vertical swiveling brushes for grinding the edges. diameter 400mm per brush, 2 motors á 1,1 kW - Horizontal sanding lamellar roller diameter 420mm, length 1600mm, 3 kW motor - Cross brush for sanding the wood fibers diameter 40mm, 1,5 kW motor - 2 round b ...

Profile grinding machine Brand Ecoline Type: Profilsand 6 New machine The customized solution for sanding individual parts such as for window profiles or moldings. Flexibility also in the choice of material and surface to be sanded: The Profilsand 6 can process different surfaces (impregnated, primed...) and types of wood (solid wood, veneered parts, MDF, etc.). The machine is equipped according to your specifications. Basic machine - Machine bed made of steel frame to ensure high stability. - Ground and therefore absolutely flat surface of the machine bed. - All movements of the aggregates are carried out on linear guides with recirculating ball bearings to ensure durability, precision and strength. - Feed via a driven conveyor belt. - Adjustable support rollers for supporting the parts between the lower units - Pressure rollers are positioned at the top alo ...

Brushing machine Brand: Ecoline Type: Rustikmat 2-600 New machine - Upper feeding belt with grip, power 0,75 kW frequency controlled. - Controlled lift of feed belt via ball bearing guidances for precision and a long product life. - Manual height adjustment - Additional pneumatical and self-regulating pressure of brushes via lower pressure pistons to process as well slight convex / concave formed surfaces to get an even finish. - Additional verticale and independant adjustment of the bruhes up to 20 mm via regulator to have a similar wear and tear and to change the depth of the structuration (stronger / slighter). - Transmission of the motors via v-belt. That is the cause of the low weight, minimal maintenance work and in relation a high trasmission. Suctiong housing for each brush. - Additional rollers at infeed and outfeed for more supporting space. 2 Brushes More ...

Ancho de trabajo: 800 mm; altura de trabajo: 300 mm; min. Longitud de la pieza: 250 mm; total: 2 unidades ajustables por separado; 1. cepillo: Diámetro del cepillo metálico 220mm; 2. cepillo: Tynexbrush, grano 80, diámetro 220mm; ajuste de altura: manual; Lee el grosor de la pieza: contador mecánico; velocidad de avance: 4 - 12 m/min; escobillas de potencia del motor: 2 x 5,5 kW; alimentación de potencia del motor: 0,37 kW; Longitud de máquina: 1400mm; Ancho de máquina: 1500mm; Peso: 950 kg;

working width: 1100 mm; min. workpiece height: 4 mm; max. workpiece height: 170 mm; height adjustment: electrically; workpiece thickness display: digital; aggregates: 2; 1. aggregat: angular grooved steel roller Ø 120 mm, fine adjustment for calibration, pneumatic on/off of the roller; 2. Aggregat: Combination unit with finely adjustable working height for calibrating and fine grinding: rubber-coated roller Ø 120 mm (45 Sh), hard grinding shoe with graphite coating on replaceable insert and pneumatic on/off of roller; Link grinding shoe: elastic, sector distance 56; Electronic control: FOX 500 KTR; dust brush: no; motor power: 15 kW; suction connection: 2 x 140 mm; machine length: 1650 mm; machine width: 1820 mm; machine height: 1960 mm; weight: 1170 kg; The LIBRA 35 calibration and fine grinding machine is an extremely versatile machine that can be used in differ ...

working width: 950 mm; min. workpiece height: 4 mm; max. workpiece height: 170 mm; height adjustment: electrically; read out height: digital; electronic control: Fox 500 KTR; aggregates: 1; 1. aggregat: Combination unit for calibrating and sanding / Slant-grooved steel roller Ø 120 mm with height fine adjustment / Hard sanding pad with graphite pad; dust brush: no; motor power: 7,5 kW; suction connection: 140 mm; machine length: 1388 mm; machine width: 1545 mm; machine height: 1668 mm; weight: 660 kg; - Also for smaller craft shops for occasional use- Combination sanding unit with sanding shoe for fine sanding- Standard with diagonally grooved steel roller Ø 120 mm for calibration- Fine adjustment of the working height- Clear control panel on the front- Robust tube-stiffened monobloc steel machine body, robot welded, high-mounted working units for maximum rigidity-  ...
