Linha de bobinas DREHER BHE-45-520-H-BSH/BRME-7-60-400-F

Decoiler Coil weight: 4,5 ton Material width max.: 520 mm Coil exterior diameter: 1600 mm Expansion range: 460 - 530 mm Leveller / Straightener Material width : 20 - 400 mm Number of levelling rolls: 7 pcs. Diameter of the levelling rolls: 60 mm Number of pull out rolls: 4 pcs. Diameter of the pull out rolls: 60 mm Material thickness: 0,4 - 3,5 mm Feeding speed: 2 - 10 m / min Roll feeder Material width max.: 310 mm Material thickness: 3,0 mm Material thickness at max. width: 2,8 mm Material thickness at max. cross section: 850 sq mm Number of feeding rolls: 2 pcs. Diameter of feeder rolls : 80 mm Feeding speed: 104 m / min Required power: 1,5 kW
seller offer No. resale 1131-0475
