Description: Saw blade 250mm Connection voltage 400 volts Power 0.8 KW Cutting diameter 70mm Miter right max. 45°weight approx.: 150 kg, Approx. Onsite Dimension. (l x w x h): 700 x 700 x 1,500 mm
Description: Motor power 1.8/2.5 kW Belt opening 190 mm Belt dimensions 350x32x2.5 Speed 15/30/45/90 1/min Cutting surface 0° 115 / 95 /180x95 Cutting surface 45° right 110 / 95 / 125x95 Cutting surface 45° left 110 / 95 / 125x95 Cutting surface 60° right 90 / 90 / 90x90weight approx.: 380 kg, Approx. Onsite Dimension. (l x w x h): 2,050 x 1,050 x 1,120 mm
Description: Saw blade diameter: approx. 200 mmweight approx.: 150 kg, Approx. Onsite Dimension. (l x w x h): 1,000 x 600 x 1,200 mm
Semi-automatic circular sawing machine with radial cut for cutting aluminium, non-ferrous metals, wood and various plastics Clean, burr-free cut edges as if polished. Saw blade diameter Ø 600 mm Saw blade drive power 4 kW Saw blade travel forward for sawing - backward for empty stroke Mitre adjustment range infinitely variable from 20° to 125° Digital display for mitre angle Sawing range 90° - approx. 230 x H 180mm or 300 x H 120 mm Sawing range 45° - approx. 160 x H 180 mm or 210 x H 120 mm Saw blade feed speed infinitely variable by means of a handwheel. Automatic spray mist lubrication Compressed air requirement 6 to 8 bar Dimensions approx. 1.55 m x 0.96 m x H 1.65 m Weight approx. 670 kg
Semi-automatic undercounter circular sawing machine for cutting aluminum, non-ferrous metals, wood and various plastics Clean, burr-free cut edges as if polished. Saw blade diameter Ø 600 mm Saw blade drive power 3 kW Saw blade path upwards for sawing - downwards for empty stroke Mitre adjustment range infinitely variable from 10° to 170° - with grid dots at + 45° and – 45° Pneumatic saw table clamping Digital display for mitre angle Sawing range 90° - approx. 400 x H 135mm or 460 x H 100 mm Sawing range 45° - approx. 190 x H 60 mm or 120 x H 150 mm Saw blade feed speed infinitely variable by means of a handwheel. Adjustment range material stop forward and backward approx. 180 mm Automatic spray mist lubrication Compressed air requirement 6 to 8 bar Dimensions approx. 1.1 m x 1.2 m x H 1.65 m Weight approx. 310 kg
OBRIEN ALUMINIUM - COLD SAWS TYPE 400 VEGA I -Zaagblad 400 mm -Verstek Dubbel -Materiaalklem -Materiaalaanslag -Beschermkap -Documentatie -400V DUTCHMACH Metal working machinery ENSCHEDE - NETHERLANDS (3 km from the German border)
Description: Underfloor aluminum circular saw - Hydropneumatic semi-automatic - pneum. Workpiece clamping device - Roller conveyor with material stop - Machine feet Saw blade diameter 420 mm Cutting range at 90 degrees: around 130 mm Cutting area at 90 degrees: flat 160 x 100 mm Cutting range at 45 degrees: around 110 mm Cutting area at 45 degrees: square 130 x 80 mm Speed 3000 rpm Motor power 2.0 KW Total power requirement 3.0 kW Machine weight approx. 190 kg Dimensions L x W x H 3,0 x 1,0 x 1,3 mweight approx.: 190 kg, Approx. Onsite Dimension. (l x w x h): 3,000 x 1,000 x 1,300 mm
Description: Aluminum miter saw - Miter left/right 45° - pneumatic double clamping device - with mist spray device - with machine base - Roller conveyor 3m with material stop - Machine feet Saw blade diameter 400 mm Cutting range at 90 degrees: around 130 mm Cutting area at 90 degrees: flat 160 x 130 mm Cutting range at 45 degrees: around 110 mm Cutting area at 45 degrees: flat 110 x 125 mm Saw blade speeds 3000 rpm Total power requirement 1.75 kW Machine weight approx. 140 kg Dimensions L x W x H 3,0 x 0,8 x 1,4 mweight approx.: 140 kg, Approx. Onsite Dimension. (l x w x h): 3,000 x 800 x 1,400 mm
Plate Saw for Iron Plates Saw blade dia. 350mm, stroke: approx. 500mm, mitre and swivel possible To be visited under electricity
Manufacturer: Pressta Eisele Type: 501 angle punch Overhaul year: 2020 Built in 2010 Saw blade carbide: 500 mm Drive power saw motor: 5.5 KW Speed Saw Motor: 2860 min-1 Cutting speed Saw blade: 4500 m/min Saw blade feed: infinitely adjustable 0-70 mm/s Tool area 90 max approx.: 20 x 250 mm Punching cylinder: 1 pcs vertical top diameter 100 mm ,1st st horizontal front diameter 100 mm Punching force power: 4.0 KW Pressure max. 280 bar Pressure in KN at 280 bar approx.: 210 KN Volume flow at 280 bar approx.: 6.8 L/ min Pressure in KN at 200 bar approx.: 150 KN Volume flow at 200 bar approx.: 9.5 L/ min Supply length pneumatic: single stroke max. 600 mm Servo controlled: single stroke max. 600 mm Multiple stroke max. 9999mm Replenishment. servo-controlled replenishment unit max. 500 mm/s Compressed air connection on the side: 6 bar Weight (s ...
Underfloor aluminium circular sawing machine Specifications: - Saw blade dimension 300 mm - Saw blade speed 2800 rpm - Cutting range - at 90° 160 x 20 mm - 100 x 80 mm - at 45° 100 x 40 mm - Drive 400 V / 1.5 kW - Space requirement approx. W 400 x H 1200 x D 700 mm - Weight approx. 80 kg - Machine stand - Parallel stop
Description: Surface grinding machine Grinding length 600 mm Grinding width 300 mm Workpiece height 340 mm Magnetic plate size 500 x 300 mm Grinding wheel diameter max. 355 mm Grinding wheel width max. 38 mm Machine weight approx. 1.8 t Space requirement approx. 2.3 x 1.6 x 1.8 mweight approx.: 1,800 kg, Approx. Onsite Dimension. (l x w x h): 2,300 x 1,600 x 1,800 mm
Description: Fabrication number: 63.103/84 Operating voltage: 3 x 380 V Frequency: 50 Hz Control voltage: 24 V Working length: approx. 1300 mm Saw blade diameter: approx. 250 mm Incl. hydraulic unit from the manufacturer REXROTH Incl. batch of different saw bladesweight approx.: 500 kg, Approx. Onsite Dimension. (l x w x h): 2,300 x 1,100 x 1,800 mm
Saw blade diameter: 500 mm profile height: 250 mm profile width: 400 mm jack height: 215 mm jack depth: 185 mm Material stop swivel between 22.5° and 157.5° Jack height can be adjusted by motor with digital display Motor adjustment of the angles with digital display Depth stop motor adjustable with digital display Automatic sawing sequence via control with preselection of the cutting angles Pneumatic material clamps Coolant lubrication
Description: Saw blade diameter: 350 mm Cutting diameter: 130 mm Saw blade dimensions: 350 x 3 x 40 mm Cutting range at 90 degrees: round: 110 mm Cutting range at 90 degrees: flat: 170 x 105 mm Cutting range at 90 degrees: square: 100 mm Cutting range at 45 degrees: round: 110 mm Cutting range at 45 degrees: flat: 130 x 105 mm Cutting range at 45 degrees: square: 100 mm Working height: 900 mm Total power requirement: 1.9/2.6 kW Control: conventionalweight approx.: 400 kg, Approx. Onsite Dimension. (l x w x h): 800 x 700 x 1,700 mm
Saw blade: ø 350 mm Saw Capacity: 110 mm Round / 100 mm Square Saw angle: 45º Left/Right Sawing speed: 18 / 36 rpm Equipped with: - Coolant system - Pneumatic clamping - Variable feed -Saw blade Country of origin: Germany Motor power: 1.8 kW Machine LxWxH: 800 x 1000 x 1850 mm Machine weight: 800 kg
Description: 'SINICO' TR90/2-550 TOP 2000 CNC automatic transfer machine, suitable for tube cutting, facing and beveling operations. N° 1491 Specifications: , Machinable diameter: 12 - 90 mm Range of machinable lengths: 50 - 550 mm Cut-off unit power rating: 9kW Log saw unit speed range: 35 -230 rpm Machine equipped with: , Rapid jaw change rotary table Four vise units rotary table No. 2 machining units for facing, chamfering and centring Bar loader with beam magazine Complete with chip conveyor Use and maintenance manual Harmonisation to CE standards Machine components: , Loader: 6000x2300mm - 2500 Kg Electrical cabinet: 800 x 2400 - 900 Kg Cutting unit: 5000 x 1600mm - 6100 Kgweight approx.: 9,500 kg, Approx. Onsite Dimension. (l x w x h): 11,800 x 2,400 x 1,800 mm
Saw blade Diameter 400 mm Saw capacity 150 mm round Suitable for: - Plastic pipe - Air clamping Country of origin Netherlands Engine power 2.2 kW Machine Weight 750 kg
Qty. 1 Second-hand hot circular saw Mfc.: TBA Built – Bj.: 1950 overhauled 1972 Saw blade dia. – Sägeblattdurchm.: 1,600 mm Saw blade feeding with hydraulic drive Sägeblattvorschub mit hydr. Antrieb Hydraulic station Hydraulikstation Dimensions of piece for cut: min./max. 70 / 185 mm square Abmessungen des zu schneidenden Materials: min./max. 70 / 185 mm
The circular saw is in used condition and is functional. Condition see pictures. Visit and demonstration possible. The prices quoted are net prices for collection ex works. A chargeable transport within Germany can be arranged.
Saw motor, pole-switchable approx. 1.0 / 1.8 kW Saw blades 360 mm 6 cutting speeds : 16 / 20 / 25 m/min 32 / 40 / 50 m/min Cutting range 90 degrees with blade size 360 mm : round 110 mm flat 200 x 80 mm Weight approx. 560 kg
Technical data: Saw blade diameter: 520mm Mitre: 90° / 45° / 30° Drive capacity: 1.6 / 2.8 kW Dimensions: WxDxH 1520x1520x1560mm Working height: 900 mm Weight: 1250kg
TUGRA ALU - COLD SAWS TYPE AC-450 -Zaagblad 450 mm -Verstek Dubbel -2 pneumatic clamp -Check of the hydraulic system -Nevelsmeerssysteem -Rollenbaan met lengteaanslag -Blaaspistool -Beschermkap -Documentatie -400V DUTCHMACH Metal working machinery ENSCHEDE - NETHERLANDS (3 km from the German border)
Description: Saw blade diameter: 300 mm Table dimensions: 470 x 450 mmweight approx.: 250 kg, Approx. Onsite Dimension. (l x w x h): 700 x 700 x 1,700 mm
Description: • Metal cut-off saw • Motor 4 KW-2880 rpm • Saw blade diameter 300 mm • Swiveling jaw is included, maximum jaw opening approx. 90 mmweight approx.: 200 kg, Approx. Onsite Dimension. (l x w x h): 510 x 1,140 x 1,270 mm
UKM 600 DG High quality semi-automatic under-table double miter circular sawing machine, for cutting profiles and solid material made of aluminum – non-ferrous metal – plastics – wood and other soft materials Largest saw blade diameter 600 mm Cutting range - 0° - 400 x H 135 mm, 245 x H 100 mm, 190 x 190 mm - 45° - 160 x H 100 mm, 145 x 145 mm Saw blade speed 2,800 rpm Stepless miter adjustment + 10°/-170° with grid points at +/- 45° and 0° Saw blade drive power 3 kW Dimensions approx. 1.1 x 1.2 m x H 1.65 m Weight approx. 310 kg
Very high quality under-table double miter circular saw machine with manual saw blade feed – for cutting profiles and solid material made of aluminium – non-ferrous metal – plastics – wood and other soft materials Optionally available with roller conveyor and manual measuring stop with digital display. Largest saw blade diameter 620 mm Cutting Area - Examples - 90° - 130 mm x H 125 mm 90° - 80 mm x H 145 mm 45° - 100 x H 130 mm Infinitely variable miter adjustment +/- 20° Saw blade drive power 2.2 kW Dimensions approx. 0.9 x 1.2 m x H 1.6 m (with open protective cover) Weight approx. 350 kg
Description: Roller shutter tool cabinet for SK50 tool holders with 17 pcs. recordings Dimensions 950 x 600 x 1950mm Weight approx. 200kgweight approx.: 200 kg, Approx. Onsite Dimension. (l x w x h): 950 x 600 x 1,950 mm
- technically efficient, ready to work – after full service - disc diameter: 350 mm
Description: Aluminum saw Saw blade 300mm Double miter +45 / -60 degrees 2 speeds 1500/3000 rpm see picturesweight approx.: 150 kg, Approx. Onsite Dimension. (l x w x h): 800 x 600 x 1,500 mm
Description: Demonstration machine Machine for cutting tubes and profiles made of steel, light metal, plastic, non-ferrous metal and composite materials. Saw blade diameter 355 mm Cutting area at 90 degrees: around 115 mm Cutting area at 90 degrees: square 120 x 106 mm Cutting area at 90 degrees: flat 102 x 197 mm Saw blade holder diameter 25.4 mm Connection voltage 230V Total power requirement 2,3 kW Machine weight approx. 28 kg Dimensions LxWxH 0.6 x 0.35 x 0.45 mweight approx.: 28 kg, Approx. Onsite Dimension. (l x w x h): 600 x 350 x 450 mm
Description: Table circular saw with base Saw blade diameter 255 mm Saw blade swivels 45° Cutting height 75 mm Table size 640 x 920 mm (extended) Saw blade bore 30 mm Motor power 1.6 kW Connection voltage 230 V Machine weight approx. 32 kg Dimensions (length/width/height) 720 x 1080 x 920 mmweight approx.: 32 kg, Approx. Onsite Dimension. (l x w x h): 720 x 1,080 x 920 mm
Saw blade diameter: 255 mmSawblade tiltable: 45 °Cutting height: 75 mmTable dimensions: 640 x 920 (ausgezogen) mmSaw blade: 30 mmMotor output: 1,6 kWconnected load frequency: 230 Vmachine weight ab.: 32 kgDimensions (L/W/H): 720 x 1080 x 920 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
