13 BLOHM máquina utilizada para venda

grinding length: 1025 mm grinding width: 520 mm workpiece height: - mm Control: SINUMERIK 840 D tool taper: HSK-A 63 A - axis: + 110 / - 5 ° workpiece weight: 30 kg distance grinding spindle - table min./max.: 473,5 - 1023,5 mm x-axis: 520 mm y-axis: 550 mm z-axis: 1000 mm V-axis: 166 mm feed x-axis: 4 - 6.000 mm/min feed y- axis: 4 - 4.000 mm/min Feed z- axis: 30 - 25.000 mm / min. table dimensions: 1.400 x 874 mm spindle speeds (infinitely variable): 0 - 12.000 U/min power capacity - grinding motor: 35,00 kW grinding wheel diam. min/max.: 100 / 300 grinding wheel width: 60 mm total power requirement: 100,00 kW weight of the machine ca.: 11,00 t dimensions of the machine ca.: 8,60 x 7,25 x H3,80 m 5 Axis Profile grinding machine, with SIEMENS SIN840D, double dividing head (B-C axis), V-axis (coolant nozzles), EROWA tool changing device (machine can also be operated without a tool chang ...

grinding length: 1025 mm grinding width: 520 mm workpiece height: - mm Control: SINUMERIK 840 D tool taper: HSK-A 63 A - axis: + 110 / - 5 ° workpiece weight: 30 kg distance grinding spindle - table min./max.: 473,5 - 1023,5 mm x-axis: 520 mm y-axis: 550 mm z-axis: 1000 mm V-axis: 166 mm feed x-axis: 4 - 6.000 mm/min feed y- axis: 4 - 4.000 mm/min Feed z- axis: 30 - 25.000 mm / min. table dimensions: 1.400 x 874 mm spindle speeds (infinitely variable): 0 - 12.000 U/min power capacity - grinding motor: 35,00 kW grinding wheel diam. min/max.: 100 / 300 grinding wheel width: 60 mm total power requirement: 100,00 kW weight of the machine ca.: 11,00 t dimensions of the machine ca.: 8,60 x 7,25 x H3,80 m 5 Axis Profile grinding machine, with SIEMENS SIN840D, double dividing head (B-C axis), V-axis (coolant nozzles), EROWA tool changing device (machine can also be operated without a tool chang ...

magnetic table diameter: 400 mm x-travel: 550 mm weight of the machine ca.: 1,5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

comprimento de moagem: 800 mm largura de moagem: 600 mm altura de moagem: 500 mm peso da máquina ca.: 4,9 t dimensões da máquina ca.: 3,20 x 2,90 x 2,55 m

grinding length:900 mm grinding width:400 mm workpiece height:450/530 mm table clamping surface LxW:1.320 x 300 mm magnetic plate size:880 mm x 280 mm mm Finimatic Creep speed Add-on for Diaform Rectifier system Coolant device Infinitely variable grinding clamping drive

Surface grinding machine, grinding machine, surface grinding machine-horizontal, surface grinding machine, magnetic grinding machine -Manufacturer: Blohm, surface grinding machine-horizontal -Table size: 770 x 140 mm, swiveling -Travel paths: x 490 mm / y 200 mm / z 220 mm -Dimensions: 1030/870/H1510mm -Total weight: 403 kg

Table dimensions X/Y: 900mm/300mm, max. grinding length: 900mm, max. grinding width: 350mm, max. table to spindle center distance: 575mm, max. table load: 670kg, max. table longitudinal movement/cross movement: 859mm/300mm, grinding spindle speed: 2800rpm, grinding wheel outer diameter min./max.: 400mm/165mm, bore diameter for 400mm: 127mm. Machine dimensions X/Y: approx. 1100mm/1100mm, weight: approx. 3100kg. Documentation available. On-site inspection is possible.

Comprimento de moagem 500 mm Largura de moagem 230 mm Tamanho da mesa: 760 x 200 mm Entrega automática Disco magnético Sistema de filtragem

Dimensões da mesa X/Y: 760mm/200mm, comprimento máximo de lixamento: 500mm, largura máxima de lixamento: 230mm, distância central do eixo da mesa: 520mm, movimento longitudinal da mesa: 30m/min, movimento transversal da mesa: 16mm/curso. Diâmetro da roda de moagem: 225mm, largura da roda de moagem: 25mm, furo: 51mm, potência: 5kW. Dimensões da máquina X/Y/Z: aprox. 2500mm/2000mm/1950mm, peso: aprox. 2100kg. É possível uma inspeção no local.

grinding length: 1600 mm grinding width: 600 mm workpiece height: 500 mm total power requirement: 50 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 600 mm grinding width: 300 mm workpiece height: mm total power requirement: kW weight of the machine ca.: 2,9 t dimensions of the machine ca.: 2,9 x 2,8 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Specification: Tangential
