Cargadoras de ruedas JCB 3CX-ECO

Ground Clearance 1.22ft in
Cab Roof Height 9.95ft in
Axle Centreline Distance 7.12ft in
Stabiliser Feet Clearance 1.22ft in
Steering Wheel Centre Height 6.37ft in
Total Travel Length 221.26in
Travel Clearance 142.13in
Width 92.52in
Kingpost Clearance 1.71ft in
Rear Frame Width 7.71ft in
Slew Centre To Rear Axle Center Distance 4.47ft in
Reach At Max Dump Height 21.4ft in
Dig Depth 0.18in
Dump Height 8.99ft in
Load Over Height10.5ft in
Loader Hinge Pin Height_Long Arms11.32ft in
Electrical SystemGauges
Tachometer, engine coolant temp, fuel level, hourmeter, clock
Pre-Wire
Radio speakers (cab), beacon (all)
Front Working Lights4 adjustable
Rear Working Lights4 adjustable
Battery 1000 CCA (120 amp)
Alternator 95amps
Emissions Certification Tier IV
Number Of Cylinders 4
Cooling Method
Hot climate specification, pressurized 1.0 bar suction fan. Pressurised recovery tank with integral filler neck
Rated Engine Speed 2200rpm
Engine Model 3CX ECO SITE MASTER
Gross Power 73.8hp
Net Power 536.5hp
Air Cleaner
Dual, dry element type, with self cleaning internal air intake cleaner
Fuel Type Diesel
Net Max Torque 295.1lb ft
Aspiration Turbocharged
Displacement 268.6cu in
Bore 4.1in
Stroke 5.2in
Operating Weight 17861.9lb
Fuel Capacity 39.7gal
Max Weight 17934.7lb
Hydraulic System Fluid Capacity 43.6gal
Cooling System Fluid Capacity 4.9gal
Front Axle Fluid Capacity 4.3gal
Rear Axle Fluid Capacity 4.3gal
Transmission Max Speed 4.7mph
Transmission Type Syncroshuttle
