131 KRAUSS MAFFEI máquina utilizada para venda

This Krauss Maffei 200-1000 C2 was manufactured in 2006. A hydraulic injection moulding machine featuring a tie bar distance of 560 x 560 mm and an opening stroke of 700 mm. It includes a screw diameter of 55 mm and is equipped with 1 core valve, 3 air valves, and an EU 12 connector for robot integration. A solid choice for expanding production capabilities. For more information about this hydraulic injection moulding machine, please reach out to us.

This Krauss Maffei 600 - 3500 C3 hydraulic injection moulding machine was manufactured in 2006. It features a tie bar distance of 1000 x 930 mm and an opening stroke of 1150 mm. Equipped with 1 core valve, 3 air valves, and a screw diameter of 80 mm, it also includes an EU 12 connection for robot integration. For more information about this hydraulic injection moulding machine, please reach out to us.

This Krauss Maffei 80-340 C2 was manufactured in 1998. It features a MC3F controller, Euromap Interface 12, and hydraulic and air units. With a screw diameter of 35 mm, it offers a maximum pressure of 2156 bar and an injection volume of 156 cm³. Consider the opportunity to buy this Krauss Maffei 80-340 C2 hydraulic injection moulding machine. Contact us for more information.

This Krauss Maffei 110-520 C1 was manufactured in 2000. It features a MC4 controller, Euromap Interface 12, and a hydraulic unit. With a screw diameter of 45 mm, it offers a maximum pressure of 1878 bar and an injection volume of 275 cm³. Consider the opportunity to buy this Krauss Maffei 110-520 C1 hydraulic injection moulding machine. Contact us for more information.

This Krauss Maffei 125-520 C1 was manufactured in 2001. It features a MC4 controller, Euromap Interface 12, and a screw diameter of 50 mm. With a maximum pressure of 1521 bar and an injection volume of 340 cm³, it is ideal for precision moulding tasks. Contact us for more information.

REFERÊNCIA B&A: 9128 TONELADA: 110 DIÂMETRO DO PARAFUSO: 40MM PESO DO LANÇAMENTO: 183 VOLUME DO TRAÇO: 201CM3 PRESSÃO DE INJEÇÃO: 1860AR TAMANHOS DAS PLACAS: 745 X 770MM DBTB: 470 x 470MM ALTURA MÍNIMA DO MOLDE: 300MM CURSO DE ABERTURA DO MOLDE: 600MM LUZ MÁXIMA DO DIA: 900MM CURSO DO EJETOR: 150MM CONTROLOS: MC5 PUXÃO DO NÚCLEO: 1 VÁLVULAS DE AR: 1 MOTOR: 22 CAPACIDADE DE AQUECIMENTO: 10,97KW INTERFACE ROBÓTICA: EUROMAP 67 ACIONAMENTO POR PARAFUSO: HIDRÁULICO

Key data: 600 t

Comprimento máximo da ferramenta: 3000mm Largura máxima da ferramenta: 2000mm Altura mínima da ferramenta: 500mm Peso total da ferramenta: 20.000kg Velocidade máxima de fecho: 400 mm/s

Máquina PET Krauss Maffei com molde de acabamento de pescoço de leite 27.5G 48cav 450-4500 CS PET 450Ton ano 2010 Molde 27.5Gramas 38mm Acabamento do pescoço de leite (requer atenção) 48 cavidades Ciclo de 25seg Pode ser inspecionado

Manufacturer: KraussMaffei Model: KM 350-2700 C2 Year of Manufacture: 1998 Type of Machine : Injection Moulding Machine Machine Weight: 16,000 kg CE Certified: Yes Find more here - .ucymachines/ Contact us at - sales@ucymachines

Manufacturer: Krauss Maffei Model: 80-390-C2 Year of Manufacture: 2001 Type of Machine : Hydraulic Injection Molding Machine Tonnage (Clamping Force): 80 t Tie Bar Distance (H x V): 405 x 405 mm Platen Size: 610 x 610 mm Ejector Hole: Centre Knee Lever: No Minimum Mold Height: 250 mm Maximum Mold Height: Not applicable Opening Stroke: 750 mm Screw Diameter: 35 mm Shot Weight: 140 g Core Functions: 2 Handling System: No Electrical Data Operating Voltage: 400 V, 3-phase Frequency: 50 Hz Total Current (Iges): not specified Motor Current (In Motor): 97 A Heating Current (In Heating): 117 A Single Motor Current: 37 A Fuse Protection: - Motor: 100 A - Heating: 125 A Find more here - .ucymachines/ Contact us at - sales@ucymachines

2008 KRAUSS MAFFEI 175-520-390 CZ Injection moldin machine Machine was functional before conservation, for reuse is neccesary aditional checks and possible repair activities Find more here - .ucymachines/ Contact us at - sales@ucymachines

Fita de armazenamento especialmente para automação (por exemplo, "ghost shift", prancheta, buffer) Compostas por duas fitas numa correia, as caixas vazias são e na segunda fita estão as caixas preenchidas. As duas correias transportadoras estão equipadas com a EUROMAP67. Isto permite que as correias sejam ligadas à máquina e ao robô de remoção programado. Fabricante: KRAUSS MAFFEI Ano de Fabricação: 2010 Comprimento das correias transportadoras: 6,00 m cada Largura das correias transportadoras: 1,75 m no total

Podemos oferecer extrusor Krauss maffei, moder ZE90A, fabricado em 2013, potência principal de 884kw, grande potência, instalado E equipamentos auxiliares usados disponíveis, comprador sério, contacte-nos.

Podemos oferecer extrusor Krauss maffei, moder ZE90A, fabricado em 2013, potência principal de 884kw, grande potência, instalado E equipamentos auxiliares usados disponíveis, comprador sério, contacte-nos.

Podemos oferecer uma máquina de moldagem de injeção Krauss Maffei, fabricada em 2017, pouco tempo a trabalhar, como a nova, um comprador sério cintact nos cintact.

Fabricante: Krauss Maffei Modelo n.º: PrecisionMolding 160-750 Ano: 2022 Condição: Usada Número de stock: 9405 Força de fixação: 160 t Diâmetro do parafuso: 50 mm Capacidade de injeção: 393 cm³ Distância entre os montantes (horizontal): 570 mm Distância entre postes verticais: 520 mm

The injection momlding machine corresponds to the hydromechanical two-platen series, clamping force: 550t, operating hours: approx. 80h, with Handling Krauss Maffei KM 250/ LRX-S 250. An on-site inspection is possible, the machine is located in Mexico.

A fully hydraulic large-format two-platen injection molding machine from Krauss Maffei with an LRX350 linear robot is available. Clamping force: 6500kN, injection unit: SP3000, screw diameter: 70mm, L/D ratio: 22.9, max. injection pressure: 2389bar, shot volume: 1232cm³, shot weight: 1121g, injection rate: 462cm³/s, screw speed: 285rpm, plasticizing rate: 108.6g/s, nozzle contact force: 129kN, mold opening force: 345kN, mold opening stroke: 1150mm, min. mold height: 600mm, max. daylight opening: 1750mm, ejector stroke: 250mm, ejector force: 95kN, max. mold weight: 11400kg, clear distance: 1200mm/1120mm, platen dimensions X/Y: 1510mm/1370mm. Robot payload: 35kg, travel X/Y/Z: 1200mm/2000mm/4000mm, conveyor dimensions X/Y: 2500mm/800mm, discharge height: 1000mm, max. conveyor belt temperature: 70°C. Machine dimensions X/Y/Z: approx. 8000mm/3000mm/2700mm, weight: approx. 31t, operating h ...

Hydraulic injection moulding machine manufactured in 1999. This Krauss Maffei KM800-5700 MC features a clamping force of 8000 kN and an injection unit size of 5700. It has a maximum mould height of 1,100 mm and an opening stroke of 1,400 mm. If you are looking to get high-quality moulding capabilities, consider the Krauss Maffei KM800-5700 MC machine we have for sale. Contact us for further details.

Key data: 4200 kN, 527 g/PS, 70 mm

1.0 St. Gebr. Máquina de Moldagem por Injeção com Robô Fabricante: KRAUSS MAFFEI Tipo: KM420-1900C2 Ano de fabricação: 2006 Força de fixação: 420 toneladas Espaçamento das longarinas 800 x 800 mm Parafusos DN: 70 mm Deslocamento máximo: 1.047 cm³ Peso da peça moldada: 853 g/hp Controlo: MC5 Equipamento: Comboio de núcleo de 2 PCS Robô SEPRO, tipo: SR4030 S3 VISUAL Controlo de canal de zona quente a 12 vias Unidade de controlo de temperatura de interface

Hydraulic injection moulding machine manufactured in 2002. This Krauss Maffei 4000-24500 MC features a clamping force of 40,000 kN and an injection volume of 10,735 cm³. The machine is equipped with a screw diameter of 135 mm and a maximum opening width of 4,200 mm. If you are looking to get high-quality injection moulding capabilities, consider the Krauss Maffei 4000-24500 MC machine we have for sale. Contact us for further details.

Clamping force: 3000kN, stroke volume: 1047cm³, shot weight: 953g, injection pressure: 1778bar, screw diameter: 70mm, tie-bar spacing: 630mm, opening stroke: 1150mm, ejector stroke: 200mm, installation height: 330mm, platen width: 1050mm, platen height: 995mm. Machine dimensions X/Y/Z: approx. 6250mm/2050mm/2400mm, weight: approx. 12500kg. Documentation available. An on-site inspection is possible.

A large-format injection molding machine Krauss Maffei is available. Clamping force: 6500kN, tie bar spacing X/Y: 1000mm/930mm, platen dimensions X/Y: 1530mm/1450mm, max. opening stroke: 900mm, mold height range: 350mm-650mm, max. platen spacing: 1550mm, ejector stroke: 250mm, ejector force: 110kN. Machine dimensions X/Y/Z: approx. 10000mm/2800mm/2450mm, weight: approx. 46000kg. Including a Wittmann handling unit. Documentation available. An on-site inspection is possible.

Key data: 3500 kN, 519 g/PS, 55 mm

1,0 pcs. Máquina de moldagem por injeção Fabricante: KRAUSS MAFFEI Tipo: KM350-2000CX Ano de Fabricação: 2008 Força de fixação: 300 toneladas Espaçamento das longarinas 710 x 7100 mm Parafusos DN: 55 mm Deslocamento máximo: 570 cm³ Peso da peça moldada: 519 g/hp Controlo: MC5 Equipamento: Comboio de núcleo de 2 PCS Fabricante do Robô: SEPRO Controlo de canal de zona ativa de 45 vezes Unidade de controlo de temperatura de interface Aproximadamente 67.530 horas de funcionamento

This 3-axis Krauss Maffei 1600-17200MC hydraulic injection moulding machine was manufactured in 2001. It features a clamping force of 16,000 kN and a screw diameter of 125 mm. The machine has a maximum shot weight of 7450 g and a platen size of 2600 x 2110 mm. If you are looking to get high-quality injection moulding capabilities, consider the Krauss Maffei 1600-17200MC machine we have for sale. Contact us for further details.

This Krauss Maffei 1000-8000 M hydraulic injection moulding machine was manufactured in 1997. The system offers an optional REMAK RE-CNC 6-axis robot with a maximum X-axis travel of 1000 mm, Y-axis travel of 1400 mm, and Z-axis travel of 3500 mm. The machine includes an injection pressure limit of 185 bar and a metering stroke of approximately 465 mm. If you are looking to get high-quality injection moulding capabilities, consider the Krauss Maffei 1000-8000 M machine we have for sale. Contact us for further details.

This Krauss Maffei KM 350-3000 was manufactured in 2003. It features a clamping force of 3500 kN and a maximum opening stroke of 920 mm. The machine is capable of processing various materials including PA, PP, PE, and ABS. If you are looking to get high-quality injection moulding capabilities, consider the Krauss Maffei KM 350-3000 hydraulic injection moulding machine we have for sale. Contact us for further details.

This Krauss Maffei KM 800-6100MX was manufactured in 2007. It features a clamping force of 8000 kN and an injection volume of 2695 cm³, making it suitable for various materials such as PA, PP, PE, and ABS. The machine is equipped with a Wittmann Robot System for enhanced handling capabilities. If you are looking to get high-quality injection moulding capabilities, consider the Krauss Maffei KM 800-6100MX hydraulic injection moulding machine we have for sale. Contact us for further details.

Parafuso ø 75-36D; aprox. 600 kg/h Motor A.C. 182,0 kW

Extrusor principal: KME 1-90-36R, acionamento principal 255 kW Camada Interior do Coextrusor: KME 45-30 Camada Exterior do Coextrusor: KME 45-36BR, Novo Parafuso Estado: bom, diretamente da produção. Design compacto, 1 gabinete de controlo comum Nota: Cabeça de tubo de 3 camadas disponível até 315 mm
