6 OKOMA máquina utilizada para venda

Tenoning spindle: 1 0 Number of milling agregates: 2 St. Spindle diameter: 40,50 mm Item 1: Okoma UF1 S Angle Combination Unit and Item 2: UF2 EG Rebating Machine, incl. Item 3: Tooling Set for IV78 Timber Windows, IV78 Timber Entrance Doors, and IV78 Timber-Aluminum Windows (Gutmann system) with straight and angled sash profiles For sale on behalf of a customer ------------------------------------------------------- Manufacturers Technical Description: Item 1: Okoma UF 1 S Tenoning and Profiling Machine / Rebating Machine --------------------------------- Compact, heavy-duty automatic window machine featuring a cast-iron construction, consisting of: Top-mounted cross-cut saw with 12-position turret stop system, Positive-guided saw guard for accident prevention Tenoning spindle: 40 mm diameter x 252 mm length, 2-step stroke mechanism for 3 tool positions (stroke height: 83 mm), Motor: 7. ...

Manufacturer: Okoma, Type: SF 6 SA, Year: 1985, Work piece width min-max mm: 40-300, Min.-max. workpiece length in mm: 30-3000, Min.-max. workpiece height in mm: 10-100, Trimming saw: yes, Diameter of saw: 380, Saw kW: ca.2,5, rotations controlled: 4500, Working hight mm: 150, Working range Z-axis mm: 600, Length lifting spindle mm: 650, Diameter of the spindle mm: ca.50, Travels of spindle: 5, rotations controlled: 4500, Working length max mm: 3000, Work piece hight max mm: 100, Main engine kW: 7,5, Clamping system: pneumatisch, Year :1985

Manufacturer: Okoma, Type: SF3 SFA , Year: 1983, Control: elektronisch, Controlled lenght stopper: no, 4-fach Konterholz: 2-fach, Studioeinrichtung Winkel: yes, Nutspindel: yes, Diameter of the spindle mm: 40, Length of tenoning spindle mm: 250, Tool travel range tenoning spindle: 2, Moulding spindles: 1, 1 length of profile spindle in mm: ca.200, Spindle for fittings groove mm: yes, Diameter of the spindle mm: 40, Constant stroke mm: 68, Main engine kW: ca 7,5, Outer profiling package: yes, Horizontal spindle clocked: yes, Work piece re-charging: no, Year :1983

Máquina de rebating automática / máquina de corte transversal automática 2 eixos

Number of spindles: 3 St. Number of tools: 2/3 St. Spindle diameter: 40/50 mm 1 OKOMA folding machine model UF 2 EG ------------------------------------- 1. Energy data: - Operating voltage: 3 phases, 380 V, 50 Hz. - Compressed air: Air requirement: 13 NL/min. Operating pressure: 8 bar up. Air: according to Pneurop 6611 2. Profile spindle 1: - Spindle arrangement: right - Power 11 kW - Speed 7000 rpm - Direction of rotation: synchronous and counter rotation - Spindle diameter 40 mm - Usable length 252 mm - Tool diameter max. 230 mm - U-movement of the profile spindle - Positioning vertically Drive: pneumatic cylinder 120 mm cycle for 2 tool positions Position sensor: limit switch - Positioning horizontally Drive: Pneumatic cylinder forward-back Position sensor: limit switch - Automatic immersion: immersion speed can be regulated for tear-free Fold over - Pro ...

Cortador de tenon Okoma PN 2 Marca: Okoma Tipo: PN2 Ano construção: N.º M: Dados da máquina: serra: 3.0 KW, 2.800 rpm, ferramenta: ø400 mm, 140 mm altura de corte - altura de corte da cabeça da torre Fuso da ranhura 7,5 kW - 2.800 rpm, ferramenta: ø400 mm, 4.000 rpm, comprimento da torneira: 170 mm comprimento de fixação do eixo: 160 mm Mesa: Elétrica, com grampos pneumáticos Altura de Tish: Curso 80 mm Stop: Stop também pode ser usado como miter stop Dimensões: aprox. 2,2 m x 1,6 m, 1,7 m de altura, mais mesa de tenão: 0,5 0,8 m Peso: 600 KG
