TRANER407C - CGAN 200 Chiller Can be used outside or inside.
For more than 1 machine depending of the power.
Recently used outside for a 10 colors Schiavi Patriot Press.
Eurovent Performances :
-Net Cooling Capacity (kW): 50.7
-Total Power inp ...
máquina usada
Can be used outside or inside.;
For more than 1 machine depending of the power.;
Recently used outside for a 10 colors Schiavi Patriot Press.;
;
Eurovent Performances :;
-Net Cooling Capacity (kW): 50.7;
-Total Power input in cooling (kW) : 19.1;
-Water pressure drop (kPa) : 29;
;
Units Amps : ;
Nominal (A) : 47;
Start-up Amps (A) : 148 ;
Short circuit unit capacity (kA) : 10 ;
Max supply cable size (mm2) : 16;
Min supply cable size (mm2) : 10;
;
Compressor :;
Number : 2 ;
Type : Scroll;
Model : (10T+10T) ;
Rated Amps (A) : 19+19 ;
Locked rotor Amps (A) : 120 ;
Motor RPM (rpm) : 2900 ;
Power factor : 0.84 ;
Sump Heater (W) : 100;
;
Evaporator :;
Number : 1;
Type : Brazed plate;
Water volume (total) (L) : 5.3 ;
Antifreeze Heater (W) : 115 ;
Unit Water Connections : Male ISO R7;
Water Connections Diameter : 2â€;
Coil :;
Type : Slit Fin;
Length (mm) : 2489 ;
Height (mm) : 1422 ;
Face Area (m2) : 3.54 ;
Rows : 2 ;
Fins per foot (fpf) : 204;
;
Fan :;
Type : Propeller;
Number : 2 ;
Diameter (mm) : 710 ;
Drive type : Direct drive;
Air flow (m3h) : 20200 ;
Number of motors : 2 ;
Motor HP (kW) : 0.6 ;
Rated Amps (A) : 1.5;
Motor RPM (rpm) : 700;
;
Dimensions :;
Height (mm) : 1897;
Length (mm) : 2800;
Width (mm) : 1100;
Operating Weight (kg) : 748;
Shipping Weight (kg) : 743;
;
System Data :;
Number of refrigerant circuits : 1 ;
Capacity steps : 2 ;
Minimum capacity (%) : 50
POSIMATACCESS N15 BOTTLE UNSCRAMBLER Bulk Bottle unscrambler POSIMAT N15 ACCESS
Brand: POSIMAT
Model: N15
SERIES: ACCESS
Stainless steel
Current format: 200ml ( We adapt the format depending on the client s needs)
Capable of speeds up to 200 bpm dep ...
Bulk Bottle unscrambler POSIMAT N15 ACCESS;
Brand: POSIMAT;
Model: N15;
SERIES: ACCESS;
Stainless steel;
Current format: 200ml ( We adapt the format depending on the client s needs);
;
Capable of speeds up to 200 bpm depending on application. ;
It has 4 inches dia container accumulation disc, with (14) horizontal polyethylene quick change container pockets and (14) vertical SS 24 inches L ;
Quick change container funnels;
12inches L x 3 1inches W ;
Left - right ;
Vacuum assist product discharge conveyer, e-stop, digital read out for bottle count, production rates, and speeds per minute.;
;
Quick format changeover:;
The N unscramblers in the Access Series have simple and quick format changeovers just by unplugging the existing set of choiceing pieces and funnels when done working with a certain bottle format, and plugging in the new set required for the new bottles to be positioned.;
This operation is done in just a few minutes without tools or adjustments.
ROBOZEOne D Printers OVERVIEW:
Brand: Roboze
Model: One
Application type: 3D Printing
Machine type: 3D Printer
Availability: Immediately
Construction year: 2017
Location: Portugal
Origin country: Italy
GENERAL DATA:
Measurements ...
