equipamentos periféricos (por exemplo, aquecimento, refrigeração, secagem) usadas para venda (248)

60 x 300 cm sem suporte

Key data: 95 , 9

Temperaturas de ferramentas usadas, TT-156E, TT-157E, TT-162E. Estão molhados, 95°C, 9-12 kW.

pronto para trabalhar 9 pcs. disponível

correia transportadora horizontal com hidromotor

Screw conveyor to collect from mixer and convey to big bag filling station, 1,5 kw motor, mounted on 2 fixed+2 pivoting wheels, adjustable discharging height 260-280 mm from ground, loading height 700 mm from ground, Used machine, reconditioned, installed power - used power in work: about 60-65% : 1,5 kw

Big Bag, 1-place holding structure, complete with supporting hooks, Constructed in solid, painted carbon steel, single place, Machine reconditioned

VIBRATING SCREEN 2 OUTLETS, Support structure made of painted carbon steel, Screen dimensions 1500x500 mm, n.2 material discharge outlets, upper screening frame 8 mm., closed at the start for 200 mm, with flow deflector flaps, AISI 304 stainless steel mesh, Drive system comprising 0.75 kW, 1 HP B3 P4 400 V 50 Hz electric motor,, eccentric drive unit., Fixed side and top safety guards,, Electrical system with start/stop switch and emergency stop button., Safety side protection carters, Instructions manual, CE, electrical drawings., If you need anything different please give us the following details., HEIGHT - LENGTH - SCREEN HOLES - NUMBER OF SCREENS - CAPACITY in kg/h, Standard classifying surface is 1500×500 mm. (x 1.000 mm H) which covers most extruders up to 1300 kg./h, but you can have longer surfaces when a cooling action is needed, particularly for PVC, or for higher capacity extr ...

SINGLE SCREW WASHING TANK, dimensions about 800 x 2.500 mm, simple washing/rinsing system for plastics, including:, hopper and screw conveyor to fill the buffer silo, buffer silo for regrinds, screw conveyor to the tank, n.1 horizontal screw with dipping paddles to sink the material with 1 gearmotor, extraction screw to centrifuge, DRYING CENTRIFUGE, 1300 mm long,, 22 kw drive, blower and pipes, installed power - used power in work: about 60-65% : 28, availability: immediate, options available: reconditioning , capacity: 300 kg/h depending on material and contamination

BINOVA WATER RING PELLETIZER, constructed in AISI 304 stainless steel, for HDPE LDPE LLDPE PC PP PS ABS, horizontal type, throughput rate 800-1200 kg/h depending on scraps and feeding rate, Users manuals, drawings, CE., Constructed in 2003, Offered checked and reconditioned, See how we recondition [HERE](.germanplast.eu/pages/what-we-do), availability: 5 weeks time, capacity: 1.500 kg/h, conditions: reconditioned

inner diam. 350 mm.

MOBERT Roller Bag maker 110 6M, for OT bags-in-a-roll with paper band, working on 2 or 3 lanes with gummed paper sleeves., Bag sizes:, Hight range 250-1500, Width 2 lanes from 150 to 460, Width 3 lanes from 150 to 300, Length 2 lane range 150 - 425, Length 3 lane range 150 - 280, Maximum speed 250 rpm, Main unwinder material width 620 - 1650 mm., Outer reel diameter 900 mm., Inner reel diameter 76 mm., Machine dimensions 11.000 x 3.650 x 2.400 mm., 380 V - 50 Hz, Constructed in 1998, excellent conditions, availability: immediate, working width: 1.100 mm., conditions: excellent, running, type: bags-in-a-roll

VERTICAL MIXER 16.000 lt., Total height approx 6.450 mm, Loading from top with cyclone and dust sleeves collector, Max diam.2.380 mm., Constructed in painted electro-welded carbon steel., Inner auger diam.350 mm., Sampling hopper with safety grid and shutter, mm.600×500, Pulley and belt transmission, protected by carters, Inspection doors with safety limits, Cleaning hinged door with on bottom of cone for complete discharging,, with safety opening, Side discharging pipe to big bag with valve, paddle type max level indicator, automatic greasing kit, 11 kw electric motor, Complete with control panel., Electric voltage: 400 V, 50 Hz, auxiliaries a.c. 24 V, CE compliance and instruction manual, installed power - used power in work: about 60-65% : 11

UNDERWATER PELLETIZER, suitable for a variety of materials, among which PE PP PS ABS TPE, etc., up to 2.500 kg/h, Total installed power 67,14 kW, The supply includes:, Connection from your screen changer to the diverter valve, made of C45 steel heated by mica electric haters., Diverter valve heated with electric heaters This allows the flow of product to be diverted to the drain to bring the extruder up to speed, it consists of a C45 steel body with a specially perforated plate that diverts the flow to the outlet or die. This plate slides via a position-controlled hydraulic cylinder, operated by a hydraulic power unit complete with high-pressure hoses. Pressure and product temperature control probes are also included., Cutting unit consisting of: electrically heated die adapter/diverter valve; AISI304 granulation chamber; die with hard metal inserts, heated by electrical heaters; auger h ...

BAG FILLING STATION WITH LIFTING AUGER, single or double bag filling station for 1000 kg. (apprx) big bags, all made in sturdy carbon steel structure

HERBOLD PU500 PULVERIZER, used for PVC, PE, PP, Output: 500-600 kg/h depending on materials, Constructed in th 90s but refurbished in 2010, Granulator with 55 kW drive, Siemens control, Blower, Grinding discs: Old and new ones, Electrical connections overhauled in 2010, Bearing housing in need of repair (possible supply of the machine reconditioned), installed power - used power in work: about 60-65% : 55 KW, capacity: 500-600 kg/h, type: PU500

ZERMA PM 500 PVC PULVERIZER, average throughput rate 500 kg/h, Disc diameter: 500 mm, 24 kW drive, Total installed power: 79 kW (200 A), including metal detector, Vibrating screen, 2-place big bag filling station, Loading screw and cyclon, Centralized dust extraction system Donaldson TDS8 year 2018, N.2 new spare discs, Complete valve and piping system, Test possible, installed power - used power in work: about 60-65% : 79 kw, conditions: testable

AUTOMATIC SCREENCHANGER, number of screens: 2, total filter area: 1.342 cm2 cleaned by 6 scrapers, for the separation of soft contaminants such as paper, wood, aluminium, copper, foreign polymers, etc. from contaminated plastic melt., For rigid and soft PP max 30 MFI gr/10, 1.400 kg/h max moisture 3%, screening at 250 my., Scraper disc and scraper ensure remarkable efficiency thanks to their innovative geometry and the directly connected discharge channels. Contaminants are lifted from the screen immediately and forwarded to the coaxial discharge screw. The contaminants are removed under control and with a minimum of melt via this optimised discharge system., The scraper and discharge screw speeds are controlled fully automatically., - fast removal of contaminants through self-cleaning filter system with rotating scraper for screen cleaning, - high separation capacity and lowest melt los ...

UNDERWATER PELLETIZER, for rigid and soft PP max MFI : 30 (and more), electrical heater max 14,6 kW, n.2 thermo regulating zones, A pressure transducer and a melt temperature transducer are mounted on the purge valve. The purge valve is controlled by a hydraulic cylinder connected to a hydraulic power unit with a 2.2 kW motor., Steel die with brazed tungsten carbide plates. A conveyor cone for the molten polymer is installed inside., stainless steel granulation chamber, Impeller shaft with 11 kW 2-pole drive motor (3000 rpm nominal, 4000 rpm max) controlled by an inverter with rpm variation and speed readout on the panel. The shaft output side has special seals and a labyrinth and safety water drainage to protect the motor bearings. The impeller motor is integral with a slide sliding on rolling guides, operated, via a recirculating ball screw, by a manual handwheel equipped with a positi ...

BUFFER SILO 15.000 lt. (or 8.000 - 12.000 - or bespoke), barrel Ø 2,2 mt. - height 3.0 mt., overall height 5,23 mt, made in electro-welded carbon steel sheet, sturdy supporting structure, internal rotor with spiral and agitator arms, inspection hatch on barrel wirh safety devices, bonfiglioli gearbox, power 3 kw electric motor, transmission with elastic coupling, finish painted externally with rustproofing and enamel, CE compliance + instruction manual, installed power - used power in work: about 60-65% : 3

VOBAU PROFILE DOWNSTREAM EQUIPMENT, Max Profile Section 250 x 100 mm,, Maximal Traction Force 20 kN, Maximal Speed 8.5 m/min, CALIBRATOR - 4000, Fixing Surface Calibration Tools 4.000 x 400 mm, 3 Vacuum Pumps 5 kW Each, Adjustments :, Longitudinal Lenght , Vertical Motorized,, Lateral Manual ., HAUL OFF - 175, Oscillating Pneumatic Top , Manual Down,, Carterpillers Adjustment, Carterpiller Length 175 x 2300 mm, 2 Gears Motors 2.2 kW , Each, Inverter Control , Maximal speed 8.5 m/min, SAW - 450, Ascending Saw , Suction Shaves, Translation Trolley Cut - 600 mm, Disc Ø 450 mm, Motor 2.5 kW, Tilting Table ., availability: immediate

Bausano Modular Compact Line , All 7m Lenght + Tilting, Maximal Profile Section 180 x 100 mm,, Maximal Traction Force 10 kN, Maximal Speed 15 m/min, Specifications: Calibrator type BP/2P/ML, Lenght Calibrator Holder 2500 mm, Longitudinal Adjustement 600 mm ( Gear Motor- Traverse Motor 0.37 kW ), Transversal Adjustment 40 mm, Vertical Adjustment 880 / 1130 mm, Cooling Water 12 Connections, Vacuums Pumps 2 x 4 kW, Vacuum 16 Connections, Haul-off unit type TNP 15 -150 MB, Tracks Lenght x Wide 1500 x 150 mm, Track Max Opening 95 mm ( 2 Pneumatic Cylinders ), Max Speed : 25 m/min, Max Take Off 23 kN, 2 Direct Gear box Motor to everyone carterpillar , 2 x 1.1 kW, Saw type TAV 90, Max Vertical Adjustment 95 mm, Max Cutting Lenght 300 mm, Motor 1.5 kW, Shaves Suction Motor 1.1 kW

CALIBRATING TABLE BATTENFELD K 160 V2, 2 Speck v-pumps 4 kw / 2 sections, 16 x vacuum-connections, 12 x water-connections, Blower for drying, HAUL OFF BATTENFELD P 100 SV, 2-belt haul-off (type caterpillar), Contact 1.200 x 160 mm, Speed approx. 0,5 – 15 m/min., Motor-power approx. 4 kw, Pulling-power approx. -6.000 N maxi., SAW BATTENFELD SPR 32 P, Profile-saw upstroking, Blade Ø 300 mm, Chip/dust-suction, control panles,, Electric manuals available

BECCARIA USED VERTICAL MIXER, mod.TS 8000, Nominal capacity 8.000 lt., complete with horizontal feeding screw and hopper, control panel, good overall conditions, availability: immediate, capacity: 8 m3, conditions: good

CACCIA HOT & COLD TURBOMIXER, Type CP1000, Hot mixer capacity 1.000 lt, 203 kw a.c.drive, + 1 CACCIA AG 3000, cooling unit, capacity 3.000 lt., installed power - used power in work: about 60-65% : 203 kw, availability: 3 weeks, capacity: 1000 hoìt -3000 cold, conditions: reconditioned, type: for PVC

BD PLAST NON-STOP SCREENCHANGER, Machine reconditioned Screen Ø 300 mm, suitable for 160 - 180 mm extruders, Heating capacity approx. 25 kW N. 4 heating areas Hydraulic pack., Machine offered reconditioned, complete with Users manual, CE compliance, el.drawings, installed power - used power in work: about 60-65% : 25

FIMIC RAS+REF 400 FULLY AUTOMATIC SCREENCHANGER, screening area 1.206cm², for PP / LDPE / LLDPE / HDPE / PS / EPS / ABS / PVB, possible setting as : continuous scraping OR scraping on an Amp.threshold OR backflush, it was mounted on extruder producing 800 kg/h with 100-150 my screening, Always used as RAS (REF equipment brand new), 30 kw drive, totally checked in 2024 by constructor, Immediately available, remote connection (Industry 4.0) with pressure control system from pulpit, 4-5 spare laser filters available, multipolar plug connectors, We can supply spare screens for this machine., Laser screen from 80 to 300 µ - Mesh from 180 to 50, Punched screen from 400 to 2.000 µ - Mesh from 40 to 10, ---------------------------------------------------------------------- -----------------, SEE ALSO OUR[OTHER FIMIC SCREENCHANGER](.germanplast/listings?q=GEMA100), installed power - used powe ...

WHEELED SCREW CONVEYOR to charge TANKER TRUCKS, for plastic granules, capacity ca.60 m3/h, Constructed in carbon steel with antirust painting, Outer Ø 300 mm, Bearing casing with dust seals, loading hopper 1.000 x 1.000 mm., 7,5 kw gearmotor, wheeled supporting structure, Total screw length 7,0 mt., Discharging height 4,5 mt., flexible pipe with capacity sensor on discharge, complete with control panel, CE compliance, Users manual, Electrical drawings., ALSO AVAILABLE IN STAINLESS STEEL VERSION, See other similar items with different features [GE751](.germanplast/listings/7506589-wheeled-tanker-loading-screw-con veyor-basic)[-GE753](.germanplast/listings/7553224-wheeled-tanker-load er-adj-height-with-automatic-retractable-sleeve)[-GE750](.germanplast/ listings/6874982-tanker-loading-system-60-m3-h-automatic-retractable-s leeve), installed power - used power in work: about 60-65% : 7,5, ...

WHEELED TANKER TRUCKS LOADING SYSTEM, for plastic granules, Loading speed 60 m3/h, Made in sturdy painted carbon steel structure, including two big bag supporting structures, n.2 frames to fix the bags on the structure by lifting the pre-hooked frames, The height of the structures can be adjusted to suit the size of the big bags, and two side ladders provide easy access to the top of the structure., The two bags rest on safety supports to prevent hands from being crushed when the bottom is opened., Sturdy hooks hold the big bag straps in place., 1.000 x1000 mm. hopper to collect the material from the big bags., A flap door at the bottom, with a safety micro, facilitates maintenance and cleaning operations., the 7,5 kw driven screw will lift material from the hopper, Discharge height 4,5 m.from floor, Screw length 8.300 mm, The screw can be lowered for storage, The bearings are dust-tight ...

WHEELED SCREW CONVEYOR to charge TANKER TRUCKS, capacity ca.60 m3//h, Constructed in carbon steel with antirust painting, Outer Ø 300 mm, Bearing casing with dust seals, loading hopper 1.000 x 1.000 mm., 7,5 kw gearmotor, wheeled supporting structure, adjustable height by manual hydraulic pump, Total screw length 7,0 mt., Discharging height 4,5 mt., flexible discharging pipe with Capacity sensor, complete with control panel, CE compliance, Users manual, Electrical drawings., ALSO AVAILABLE IN STAINLESS STEEL VERSION, See also other versions with different features [GE752-](.germanplast/listings/7553190-wheeled-tanker-loader-7-mt-long -4-5-mt-discharging-point-or-bespoke)[GE753](.germanplast/listings/755 3224-wheeled-tanker-loader-adj-height-with-automatic-retractable-sleev e)-[GE750](.germanplast/listings/6874982-tanker-loading-system-60-m3-h -automatic-retractable-sleeve), capacity: 60 ...

AMUTEC TCR S 1200, reel-to-reel pre-cut bags, Construction year 2003,, totally revisioned in 2024 by Constructors technicians, very well maintained
