outras máquinas para trabalhar o metal usadas para venda (11,484)

Existing documents - Wiring diagram - Servo (adjustable drive) - Control - Lift table

approx. 500 x 400 mm

Hand bending machine >br>height 100mm>br>weight 60 Kg>br>Dimensions 0.8 x 0.6 x 0.3 m

Electrode furnace:Capacity 5 KgInner dimension (LxWxD) 100 x 75 x 450 mmPower 0.4 kwConnection voltage 220 - 240 VSetting device 30 - 180 degreesWeight 10 kgDimensions L x W x H 570 x 200 x 150 mm Condition: never used / new (5)

Roller block- torch tripod- number of rotations infinitely variable- foot switch- operating instructions in EnglishLoad capacity 1000 kgWorkpiece diameter 20 - 800 mmDrum diameter 200 x 50 mmFeed rate 50 - 2000 mm/minWeight 65 kgTotal power requirement 0.6 kWSpace requirement approx. 0.8 x 0.6 x 0.6 m Condition: never used / new (5)

Notching machine>br>- Foot switch>br>- Emergency stop>br>sheet thickness 6 mm>br>pressure 18 t>br>Knife length 220 mm>br>angle adjustable from - to 90 degrees>br>table surface 1100 x 950 mm>br>bending length 835 mm>br>Machine weight approx. 1.1 t>br>Dimensions L x W x H 1.2 x 0.8 x 1.4 m

Measuring table approx. 1000x1000 mm, with panel, PC, monitor, keyboard

10 pcs Quick Clamping Bolts for 28mm SystemPlate Thicknesses 25mmNumber 10 Hole Diameter 28 mmWeight 10 kgDimensions L x W x H, 0.3 x 0.3 x 0.2 m Condition: never used / new (5)

This frame press is CE certified according to the latest guidelines>br>- with manual hydraulics>br>- to move cylinders sideways>br>- 2 pcs. press block 200x250x40mm / 200x70x40mm, max. 30t>br> with M16 threaded holes and some M16 threaded bolts>br>- 8 pcs. press bolts, 10 - 30mm,, with quick-change adapter, max. 20t>br>- 2 press pads>br>pressure 10 t>br>stroke 180 mm>br>Clear width between uprights 335 x 115 mm>br>installation height max. 340 mm>br>cylinder diameter 56 mm>br>Piston diameter 40 mm>br>Machine weight approx. 0.05 t>br>Space requirement approx. 0.75 x 0.53 x 1.6 m

Features• Self-aligning for several diameters• Infinitely adjustable speed of the drive unit• Polyurethane coating of the rollers• Optimal load distribution (4 rollers/unit), particularly gentle on workpieces with low wall thickness and sensitive surface• High stability due to solid construction of the machine• CE certificate• Very good price-performance ratio• Remote control on the cable• Documentation in EnglishLoad capacity 5 tWorkpiece diameter 300 - 2500 mmDrum diameter 250 x 100 mmFeed rate 100 - 1000 mm/minTotal power requirement 0.75 kWWeight 0.6 tDimensions L x W x H 1.5 x 1.0 x 0.6 m Condition: never used / new (5)

Tool System / Tool Magazine Tool stations 80 pieces Magazine Type: Chain Coolant pressure 50 bar4 additional working pallets 400mmx 500mm

Without clamping devices and supports, only the press Technical data Manufacturer: REIS GmbH & Co. Maschinenfabrik Type: EC 8-20D Year of Make: 1994 Machine Type: Hydraulic trimming press Press force: 200 kN Retraction force: 35 kN Max. stroke: 500 mm Installation height: 800 mm Speeds: Fast forward: 620 mm/s Pressing cycle: 90 mm/s Return: 540 mm/s Hydraulic pressure: max. 175 bar Fuel tank capacity: 355 l Pneumatics: min. 6 bar, connection R1/2" Motor power: 7.5 kW Connected load: 8 kVA Control voltage: 24 V Clamping surface: Table: 800 x 600 mm Plunger: 800 x 500 mm Dimensions (L x W x H): 1895 x 1400 x 3150 mm Weight: approx. 5000 kg Configuration Vertical construction Suitable for die casting deburring processes Documentation available Used machine

SMC GMPM32-TF25Z Compact Cylinder , 2B1 8DE , G WV , Max 1.0 MPa

equipped with 4 castors

Siegmund Set 2, 57 pieces, 28mm system, consisting of:18x quick-release bolts with twist lock short, without O-rings 6x universal stop 150 L - Nitrided 6x universal stop 225 L - Nitrided 4x stop and clamping angle 175 L - Nitrided 2x stop and clamping angle 300 G left - Nitrided 2x stop and clamping angle 500 G left - Nitrided 4x prism Ø60-135° burnished - with collar complete with shovel collar and countersunk head 6x Professional Screw Clamp - Nitrided 4x Professional Screw Clamp 45°/90° - Nitrided 4x Magnetic Bolt Aluminium 1x Accessory Set (283999) consisting of: Eccentric, Allen Wrench, Brush, Whetstone, Probe CleanBasic, Probe Non-Stick and Torch Holder. Condition: never used / new (5)

Technical data Note: There was no original machine documentation. To the best of our knowledge, all the following technical data were partially read from the nameplate and taken from publicly accessible online sources. Manufacturer: CHIRON Type: FZ 08 B/W Year of Make: 2000 Machine Type: CNC Vertical Machining Center Control: Siemens Sinumerik Operating voltage: 3/N/PE 400 V Frequency: 50/60 Hz Control voltage: 230/24 V Connected load: approx. 21 kVA Rated current: approx. 35 A Configuration Double clamping system / pendulum operation 2 clamping stations NC sub-unit Peiseler AWUP 100 Automatic tool changer Cooling lubricant system Extraction system Full fairing Compact design for series production

A lattice box as a loading aid

Machine number: 0152Operating voltage: 400 VConnection: 3.8 kWControl: HEIDENHAINFeed force Y-axis: 6600 NFeed force X- and Z-axis: 9500 NRapid traverse speed: 30 m/minProgrammable feed: 30000 mm/minTool holder: SK 40Spindle diameter: 70 mmincl. 24-fold tool changer, max. tool diameter: 70 mmMax. tool length: 300 mmTravel X-axis: 2000 mmTravel Y-axis: 420 mmTravel Z-axis: 400 mmdistance from spindle nose to table: 200 - 600 mmMachine table width: 500 mmMachine table length: 2500 mm, incl. the tool holders located on the tool changer

Mobile force former>br>- max pressure 500 bar>br>- hosepack 3.5m>br>- motor 3.2KW>br>see pictures

Sheet metal bending machine with:>br>– Electrically adjustable rear roller>br>– Digital display for the movement of the rear roller>br>– Hardened rollers>br>– Conical rolling>br>– Swivelling upper roller>br>– Brake motor>br>– Emergency stop>br>– Documentation>br>– Connection voltage 400V>br>Sheet width 1070 mm>br>Sheet thickness 4 mm>br>Stand width 1100 mm>br>Top roll diameter 110 mm>br>Total power requirement 5,0 KW>br>machine weight approx. 1.2 t>br>space requirement approx. 2.0 x 0.9 x 1.1 mm

including 1 x PBS fluid reservoir.

Set 4: 110-piece, 28mm system, consisting of:Clamps: 14 x 280610.NClamps: 10 x 280630.NPrism: 6 x 280648.1.NBolts: 30 x 160511Magnetic bolts 8 x 280740Stroke: 10 x 280410.NStroke: 10 x 280420.NStroke: 4 x 280430.NAngle: 8 x 160110.NAngle: 2 x 280152.NAngle: 2 x 280162.NAngle: 1 x 280164.NAngle: 1 x 280165.NAngle: 1 x 280166.NAngle: 1 x 280167.NTrolley: 1 x 280910Accessory set. 1 x 283999Number 106 PositionsWeight 283 kgCondition newHole diameter 28 mm

10 pcs quick-clamping bolts for 28mm systemClamping range from 5 to 50mmNumber 10 pcs. Clamping range 15 - 50 mmHole diameter 28 mmWeight 10 kgDimensions L x W x H 0.3 x 0.3 x 0.2 m Condition: never used / new (5)

This sandblasting cab includes as standard:Front loader with two gas struts.Blasting gun4-piece nozzle setset gloveslightingkit protective filmsfoot pedal.Pressure regulatorsuction with microfilterOriginal packagingInternal dimensions 1170 x 580 x 580 mmOperating pressure 2.2 - 5.5 barDimensions L x W x H 1.22 x 0.93 x 1.7 mMachine weight approx. 0.15 tSystem is supplied in the color black Condition: never used / new (5)

Segment bending machine>br>segment widths: >br>25, 30, 35, 40, 45, 50, 75, 100, 150, 250 and 275mm.>br>>br>Sheet width 1020 mm>br>Sheet thickness 2.5 mm>br>Column width 1050 mm>br>Opening width mm>br>Bending angle max. 135 °>br>Machine weight approx. 0.32 t>br>Dimensions approx. 1.4 x 0.6 x 1.3 m>br>

Welding table on lift table: Hole diameter: 28mmThe table is made of 15mm thick steel S355The surface is stained and oiled.Tolerance: +/- 1 mm at the top and +/- 1 degree at the sides. Sidewalls 150 x 10mmRibbed underside for reinforcement.Table length 1300 mmTable width 800 mmLoad capacity 1000 kgLifting height 510 - 1550 mmTotal connected load 1.5 kWConnected voltage 230 VMachine weight approx. 0.55 tCondition: never used / new (5)

Roller block withload capacity 1000 kgWorkpiece diameter 20 - 800 mmDrum diameter 200 x 50 mmFeed rate 80 - 1600 mm/minTotal power requirement 0.23 kWDimensions 600x500x500mm Condition: never used / new (5)

EBU 80 – Single-column eccentric press – Year of construction 1971 • Manufacturer: EBU Pressen • Machine type: Single-column eccentric press • Type: EBU 80 • Year of construction: 1971 • Machine number: 293 • Press force: 80 t (at 30° before subtitles) • Adjustable stroke: 12–60 mm • Plunger adjustment: 80 mm • Plunger stroke rate: 37–147 strokes/min • Weight: approx. 5,200 kg Dimensions (approx.) • Height: 2,500 mm • Width: 1,500 mm • Depth: 1,800 mm Equipment & Design • Mechanical eccentric press in heavy casting design • Large work table with T-slots • Adjustable stroke • Pneumatic unit with pressure regulator and pressure gauge • Side-mounted control cabinet with controls • Flywheel with protective cover • Tool holder on the ram Condition • Used machine • Signs of wear and tear due to age and use • Paint chipping and dirt  ...
