SODICKA500 EDM wire machine EDM SODICK A500
Max size of workpiece (W x D x H) 700 x 500 x 260 mm
Max weight of workpiece 700 kg
Table stroke (X x Y x Z) 500 x 350 x 270 mm
Auxiliary table travel (U x V)70 x 70 mm
Taper Angle 15 deg
Wire elect ...
used machine
EDM SODICK A500;
Max size of workpiece (W x D x H) 700 x 500 x 260 mm;
Max weight of workpiece 700 kg;
Table stroke (X x Y x Z) 500 x 350 x 270 mm;
Auxiliary table travel (U x V)70 x 70 mm;
Taper Angle 15 deg;
Wire electrode diameter dia. 0.1 � 0.3 mm;
Target Accuracy 2 to 5 microns;
CNC TYPE ;
Weight (approx) 3500 Kg;
Dimension (LxWxH): 2.3x2x2.1 m;
Waterjet type ;
Auto wire threading;
GLEASON17 M Bevel Gear Lapping Machines Max. distance between axis 305 mm.
Min. distance between axis 152 mm.
Max. diameter of the gear rim 457 mm.
Machine weight 2.565 Kg.
Max. distance between axis 305 mm.;
Min. distance between axis 152 mm.;
Max. diameter of the gear rim 457 mm.;
Machine weight 2.565 Kg.
KARL-KLINKRSI 25/D 1600 Broaching Machines INTERNAL VERTICAL BROACHING MACHINE
Max. stroke 1600 mm.
Min. stroke 630 mm.
Pulling force 25 Tn.
Distance between columns 635 mm.
Machine weight 11.500 Kg.
INTERNAL VERTICAL BROACHING MACHINE;
Max. stroke 1600 mm. ;
Min. stroke 630 mm. ;
Pulling force 25 Tn. ;
Distance between columns 635 mm. ;
Machine weight 11.500 Kg.
FORSTRISZ 10x1250x400 Broaching Machines INTERNAL VERTICAL BROACHING MACGINE
Pulling force 10 tons
Max. stroke 1250 mm.
Distance between tools 400 mm.
Max. length of the tool 400 mm.
Net weight, approx. 3600 kg.
INTERNAL VERTICAL BROACHING MACGINE;
Pulling force 10 tons ;
Max. stroke 1250 mm. ;
Distance between tools 400 mm. ;
Max. length of the tool 400 mm. ;
Net weight, approx. 3600 kg.
FORSTRISZ 6,3x1000x320 Broaching Machines INTERNAL VERTICAL BROACHING MACHINE
Traction movement 6,3 Tn.
Max. travel 1000 mm.
Working table width 355 mm.
Max. piece diameter with one brush 355 mm.
Max. piece diameter with two brushes 125 mm.
Max. piece ...
INTERNAL VERTICAL BROACHING MACHINE;
Traction movement 6,3 Tn. ;
Max. travel 1000 mm. ;
Working table width 355 mm. ;
Max. piece diameter with one brush 355 mm. ;
Max. piece diameter with two brushes 125 mm. ;
Max. piece diameter with three brushes 113 mm. ;
Return speed 24 mmin. Working speed 7,5 mmin. ;
Power 12 Kw. ;
machine weight 2350 Kg.
FORSTRISZ 6,3x1000x320 Broaching Machines Traction movement 6.3 Tn.
Max. travel 1000 mm.
Working table width 355 mm.
Max. piece diameter with one brush 355 mm.
Max. piece diameter with two brushes 125 mm.
Max. piece diameter with three brushes 113 mm.
Retu ...
Traction movement 6.3 Tn.;
Max. travel 1000 mm.;
Working table width 355 mm.;
Max. piece diameter with one brush 355 mm.;
Max. piece diameter with two brushes 125 mm.;
Max. piece diameter with three brushes 113 mm.;
Return speed 24 mmin.;
Working speed 7,524 mmin.;
Power 12 Kw.;
machine weight 2350 Kg.
