4 results
item-No.: 158705606
ES
Working dimensions Panel size:
X: min. 200mm / max. 3.200mm
Y: min 70mm / max 920mm
Z: min. 8mm / max. 70mm
Max. machining in X-direction without reclamping:
Milling / formatting minus cutter radius 1450 mm
for complete machining (milling, drilling, grooving) 1300 mm
max. machining in Y direction 920 mm
Connected load: 14 kW
operating pressure: 6,0bar
Printing requirement: ca.300 NL / min.
suction capacity:
milling unit: approx.1.40 ...
item-No.: 158549403
The "4-side gluing unit" is designed in such a way that it enables
cost-effective, precise edge processing of moulded parts on all sides.
The unit is engaged and mounted in the interface of the work spindle
via a pick-up system. If required, the aggregate can be quickly
removed from the pick-up station for easy maintenance and cleaning.
Rotation speed 12-18000 rpm.
Gluing unit 360°.
Gluing speed 5-20 m/min.
Edge height 16-45 mm. Options to 65 or 90 mm.
Edge thickness: veneer 0,4-2mm, melamine 0,4...mm, PVC/ABS ...
item-No.: 158518422
Workpiece thickness: min 12 mm max. 60 mm
With power control PC85 Hardware:
- PLC control with international standard IEC 61131
- Operating system Windows XP(US) embedded
- Intel Core 2 Duo processor
- TFT flat screen 17 inch
- 1 SATA hard drive at least 160GB
– Central USB port
- EtherNet connection 10/100 MBIT RJ45 (without switch)
- Wood WOP 5.0 with: -3D woodDesign;
WoodAssembler; -WoodWOP Mosaic
- WoodType CE SAFETY AND PROTECTION DEVICE DOKU – CONTROL AND
TEXTS:
GERMAN CONFIGURATION:
Processi ...
item-No.: 131839512
US
C.M.S. CNC Turret Head Machining Center
Model TRIAX R-65
Sn 285, 1986
IBH controller modus 1
(2) vacuum tables- each 48” deep x 60” long.
(1) five station lathe section. Max. part 6.5” x 45”
(2) vacuum pumps 5 hp. each.
Total of (30) routers.
(6) station turret with (5) routers per station.
Consisting of;
(2) stations of (5) routers each - 2 ½ hp. each.
(4) stations of (5) routers each – 8 hp. each.
Digitizing table for flat work or carving.
Lathe s ...
