28 results
Número do item: 131839512
US
C.M.S. CNC Turret Head Machining Center
Model TRIAX R-65
Sn 285, 1986
IBH controller modus 1
(2) vacuum tables- each 48” deep x 60” long.
(1) five station lathe section. Max. part 6.5” x 45”
(2) vacuum pumps 5 hp. each.
Total of (30) routers.
(6) station turret with (5) routers per station.
Consisting of;
(2) stations of (5) routers each - 2 ½ hp. each.
(4) stations of (5) routers each – 8 hp. each.
Digitizing table for flat work or carving.
Lathe s ...
Número do item: 132517898
5.200 €
ES
Weight approx.: 3600 kgDimensions (l x w x h) approx.: 5000 x 2250 x
2250 mmDescription: ? CNC machining center ? Serial number AL2967 ?
Total installed power 18 kw ? Working area approx. 2600 x 900 mm ?
Panel passage height 80 mm ? Travelling way X-axis: 3010 mm,
travelling way Y-axis: 1200 mm, travelling way Z-axis: 115 mm ?
Maximum travel speed in the axes direction x-y: 75-75 m/min ? Maximum
programmable speed in axes direction x-y-z: 50-50-22 m/min ? Tool
changer with 10 positions ? Main milling spindle with c ...
Número do item: 132412675
Weight approx.: 110 kgDimensions (l x w x h) approx.: 800 x 900 x 1700
mmDescription: Serial number 3256, To drilling and inserting hinges,
Motor 0.75 kw-2800 rpm, Head with 3 spindles, 2 Pneumatic clamps,
Actuating by button, Table size 800 x 500 mm, It is included the table
where it is mounted
Número do item: 132412684
Weight approx.: 2500 kgDimensions (l x w x h) approx.: 4900 x 2600 x
2450 mmDescription: Serial number AL1/003221, Total installed power
approx. 16 kw, Working area 2250 x 900 mm, Panel passage height 180
mm, Travelling way X-axis: 2535 mm, Travelling way Y-axis: 1080 mm,
Travelling way Z-axis: 200 mm, Maximum travel speed in the axes
direction x-y: 67-67 m/min, Maximum programmable speed in axes
direction x-y-z: 50-45-22.50 m/min, Main spindle 4.40 kw-max. 18000
rpm, Saw unit, Drilling head vertical X-axis: 6, Dri ...
Número do item: 132412695
Weight approx.: 420 kgDimensions (l x w x h) approx.: 1850 x 1180 x
1330 mmDescription: Multi drilling machine, dowel drilling machine
Serial number 891412 Workpiece thickness from 10 mm up to 80 mm
Maximum drilling depth approx. 80 mm Maximum lengthwise distance
between vertical heads approx.850 mm Maximum transverse distance
between first and last spindle 640 mm 1 x horizontal drilling head
with 21 spindles, pitch 32 mm, motor 001 kw 2 x swiveling vertical
drilling heads with 21 spindles each, pitch 32 mm, motor ...
Número do item: 132412696
Weight approx.: 5300 kgDimensions (l x w x h) approx.: 7000 x 3100 x
2650 mmDescription: ? CNC machining center ? Serial number 2930880772L
? Working table dimensions approx. 4000 x 1200 mm ? Travelling way
X-axis: 4420 mm, travelling way Y-axis: 1720 mm, travelling way
Z-axis: 330 mm ? Maximum travel speed in the axes direction x-y-z:
100-55-25 m/min ? Tool changer with 12 positions ? Main spindle with
connection HSK F63 ? Drilling head vertical X-axis: 5 ? Drilling head
horizontal X-axis: 1 + 1 ? Drilling head ho ...
Número do item: 132412699
Weight approx.: 2000 kgDimensions (l x w x h) approx.: 6250 x 2860 x
1650 mmDescription: ? CNC automatic drilling machine, CNC boring
machine ? Serial number 076412 ? Total installed power approx. 8.62 kw
? Maximum workpiece size approx. 4000 x 800 x 50 mm ? Minimum
workpiece size approx. 300 x 100 x 10 mm ? Drilling head vertical: 22
? Drilling head horizontal X-axis: 2 + 2 ? Drilling head horizontal
Y-axis: 1 + 1 ? Controlled by PC ? Input roller conveyor 2250 mm long
? Output roller conveyor 2200 mm long with li ...
Número do item: 132412736
Weight approx.: 2600 kgDimensions (l x w x h) approx.: 7400 x 2750 x
2480 mmDescription: ? CNC machining center ? Serial number 8144302 ?
Working area approx. 4400 x 1200 mm ? Panel passage height 65 mm ?
Maximum travel speed in the axes direction x-y-z: 75-45-15 m/min ?
Tool changer with 6 positions ? Main milling spindle HSD ES919 with
connection ISO 30 ? Saw unit motor 1.80 kw ? Vertical drilling
spindles in X-axis direction: 14 ? Vertical drilling spindles in
Y-axis direction: 5 ? Horizontal drilling spindles i ...
Número do item: 132412743
Weight approx.: 3100 kgDimensions (l x w x h) approx.: 4600 x 2700 x
2430 mmDescription: ? CNC machining center ? Serial number
0-250-05-2821 ? Working area approx. 2800 x 800 mm ? 2 x vertical
milling spindle with motor 5 kw-max. 18000 rpm ? Groove saw in X-axis
direction ? Vertical drilling spindles in X-axis direction: 7 ?
Vertical drilling spindles in Y-axis direction: 5 ? Horizontal
drilling spindles in X-axis direction: 2 + 2 ? Horizontal drilling
spindles in Y-axis direction: 1 + 1 ? Numerical control HOMATI ...
Número do item: 132412761
Weight approx.: 6000 kgDimensions (l x w x h) approx.: 6950 x 3140 x
2390 mmDescription: ? CNC Throughfeed drilling machine, CNC
throughfeed driller ? Serial number AL4237 ? Max. workpiece width
approx. 3100 mm ? Maximum workpiece thickness 60 mm ? Feeding by belts
of approximate length 1800 mm ? 2 loading arms with advance by belts
approx. 800 mm and 320 mm long ? Distance between drills 32 mm ? 1 x
Horizontal drilling group working from the right side with 19 drills ?
1 x horizontal drilling group working from th ...
Número do item: 132412769
Weight approx.: 120 kgDimensions (l x w x h) approx.: 1500 x 720 x
1480 mmDescription: ? Hinge drilling machine ? Serial number 58 ?
Motor 1.10 kw-2820 rpm ? Head with 3 spindles ? Actuating by foot
switch ? Table size 1500 x 430 mm ? It is included the table where it
is mounted
Número do item: 132412297
Weight approx.: 5000 kgDimensions (l x w x h) approx.: 11000 x 2400 x
2200 mmDescription: ? CNC machining center ? Serial number 69949 ?
Total installed power approx. 32.40 kw ? Working area approx. 3685 x
1600 mm ? Panel passage height 150 mm ? Maximum speed in the axes
direction x-y-z: 80-80-30 m/min ? C-Axis ? Tool changer with 10
positions ? Main spindle power 9 kw with connection ISO 30 and air
cooled ? Saw unit motor to groove in axis X direction, saw blade
diameter 120 mm ? Drilling head vertical X-axis: 6 ...
Número do item: 132412298
Weight approx.: 3100 kgDimensions (l x w x h) approx.: 5900 x 2600 x
2070 mmDescription: ? CNC machining center ? Serial number AL1/003093
? Working area approx. 3000 x 920 mm ? Panel passage height 180 mm ?
Travelling way X-axis: 3290 mm, travelling way Y-axis: 1180 mm,
travelling way Z-axis: 200 mm ? Maximum travel speed in the axes
direction x-y: 67-67 m/min ? Maximum programmable speed in axes
direction x-y-z: 50-45-22.5 m/min ? Main spindle with connection ISO
30 ? Drilling head vertical X-axis: 6 ? Drilling h ...
Número do item: 132412299
Weight approx.: 6200 kgDimensions (l x w x h) approx.: 8000 x 2400 x
2300 mmDescription: ? CNC machining center ? Serial number 69571 ?
Total installed power approx. 21.10 kw ? Working area approx. 6450 x
1342 mm ? Panel passage height 180 mm ? Maximum speed in axes
direction x-y-z: 80-80-30 m/min ? C-Axis, with air blower, floating
probe for operator head ? Tool changer with 12 positions ? Main
spindle power 12 kw with connection ISO 30 ? Saw unit to groove in
X-axis direction, maximum blade saw diameter 120 mm ? ...
Número do item: 132412872
Weight approx.: 250 kgDimensions (l x w x h) approx.: 700 x 850 x 1850
mmDescription: ? Bench drill, column drilling machine ? Serial number
1058/884 ? Chuck capacity 30 mm ? Motor 1.20 kw ? 10 speeds from 245
rpm up to 4000 rpm ? Table dimensions 460 x 550 mm ? Drilling depth
approx. 120 mm ? Column diameter 100 mm ? Mounted on metal table
Número do item: 132412899
Weight approx.: 15 kgDimensions (l x w x h) approx.: 400 x 300 x 250
mmDescription: ? Milling tools and drill bits for CNC ? Consisting in
approximately: ? 25 milling tools for CNC ? Approx. 68 drill bits for
CNC, approx. 20 of them are of new condition ? Indexable inserts ? For
more details see the photos
Número do item: 132412901
Weight approx.: 12 kgDimensions (l x w x h) approx.: 400 x 250 x 200
mmDescription: ? Milling tools and drill bits for CNC ? Consisting in
approximately: ? 20 milling tools for CNC ? 10 drill bits for CNC ?
For more details see the photos
Número do item: 132412905
Weight approx.: 12 kgDimensions (l x w x h) approx.: 600 x 550 x 500
mmDescription: ? Diamond core bits ? 3 x units with diameter 112 mm
and length 450 mm ? 1 x unit with diameter 82 mm and length 450 mm ?
For more details see the photos
Número do item: 132412656
Weight approx.: 3000 kgDimensions (l x w x h) approx.: 5300 x 2800 x
2250 mmDescription: Serial number 8145003, Working area approx. 4400 x
950 mm, Panel passage height 135 mm, Travelling way X-axis: 5281 mm,
Travelling way Y-axis: 1663 mm, Travelling way Z-axis: 200 mm,
Path-feed rate max. X-axis: 75 m/min, Path-feed rate max. Y-axis: 60
m/min, Path-feed rate Z-axis: 20 m/min, Main spindle HSD ES919 with
7.50 kw and connection ISO 30, Saw unit motor, Drilling head vertical
X-axis: 6, Drilling head vertical Y-axis: ...
Número do item: 132412660
Weight approx.: 9000 kgDimensions (l x w x h) approx.: 10200 x 4700 x
3000 mmDescription: Serial number 1BR7 / 98, Total installed power 30
kw, Maximum workpiece length approx. 1500 mm, Maximum workpiece
thickness approx. 50 mm, 2 rotation revolver units with 8 positions
each for drilling heads, 2 horizontal drilling heads with 5 drills
each in Z-direction, 2 horizontal drilling heads with approx. 12
drills each in X-direction, 3 fittings insertion groups with vibratory
feeding units GASCO, Panels loading magazine ...
Número do item: 131834214
Weight approx.: 670 kgDimensions (l x w x h) approx.: 4000 x 1500 x
1200 mmDescription: Multiple drill with 23 drill bits.
Número do item: 131834228
Weight approx.: 50 kgDimensions (l x w x h) approx.: 1600 x 500 x 1200
mmDescription: Single-phase 12 change-speed gears 1.5kW Tilting table
Número do item: 131834230
Weight approx.: 50 kgDimensions (l x w x h) approx.: 1600 x 500 x 1200
mmDescription: Single-phase 12 change-speed gears 750w Tilting table
Número do item: 131834232
Weight approx.: 50 kgDimensions (l x w x h) approx.: 1500 x 500 x 1500
mmDescription: Single-phase 5 change-speed gears 750w Tilting table
Telescopic
Número do item: 131762458
Weight approx.: 300 kgDimensions (l x w x h) approx.: 1600 x 1500 x
1400 mmDescription: ? Multi drilling machine ? Serial number 110702 ?
Drilling head with 21 spindles ? Distance between spindles 32 mm ?
Total distance between first and last spindle 640 mm ? Working table
dimensions 864 x 500 mm ? Max. Workpiece dimensions approx. 800 x 3000
mm ? Max. drilling depth 70 mm ? Tilting head 0°- 90° ? Motor 2.50
kw-2800 rpm ? 2 pneumatic clamps ? Actuating by pedal ? Turret VITAP
with 6 different preselected position ...
Número do item: 131763279
Weight approx.: 900 kgDimensions (l x w x h) approx.: 2900 x 2800 x
1600 mmDescription: ? CNC automatic drilling machine, CNC boring
machine ? Serial number 610257Z ? Maximum workpiece size approx. 3000
x 920 x 50 mm ? Minimum workpiece size approx. 270 x 150 x 12 mm ?
Maximum drilling depth in the axes direction x-y-z: 30-30-45 mm ?
Maximum travel speed in the axes direction x-y-z: 30-30-15 m/min ?
Router unit ? Saw unit to groove in X-axis direction, saw blade
diameter 100 mm ? Drilling head vertical X-axis: 5 ? ...
Número do item: 131300377
Weight approx.: 1700 kgDimensions (l x w x h) approx.: 3750 x 2900 x
1450 mmDescription: Feeding by belts of approximate length 1300 mm, 2
loading arms with advance by belts with length approx. 1400 mm, Max.
workpiece width approx. 1800 mm, Maximum depth of drilling 80 mm, 1 x
horizontal drilling head working from the right side with 21 drills, 1
x horizontal drilling head working from the left side with 21 drills,
10 x vertical drilling heads working from below, 5 x beam of 11 drills
each to place in the 10 possib ...
Número do item: 129980438
Weight approx.: 7000 kgDimensions (l x w x h) approx.: 3500 x 1300 x
3000 mmDescription: Serial Nº 391185019. Maximum machining diameter
180 mm. Maximum machining length 100 mm. No. of tools 12. Maximum main
spindle speed 7000 rpm. Stroke X-880 mm. Stroke Z-280 mm. Power 30 kW.
CNC MAZATROL 640C TN.
Você não encontrar a sua máquina queria?
enviar inquérito procurado
a todos os revendedores (registo não é necessário)
