sheet metal working used for sale (3,311)

Standard configurationMachine⦁ C frame⦁ Press beam⦁ Spherical bearing of the press beam with press beam tilting⦁ On-Demand Servo Drive with 4-cylinder technology⦁ Distance measurement system (Y axis) with dynamic deflection compensation⦁ Hydraulic oil filling (life-long filling)⦁ Extension of the open height/strokeBackgauge⦁ Gauge fingers (2 pieces)Tool clamp⦁ TRUMPF hydraulic lower tool clampControl⦁ Touchpoint TruBend machine control⦁ Integrated TRUMPF technology data⦁ 21.5 touchscreen⦁ User management systemData transmission⦁ USB interface⦁ RJ45 network interface⦁ Network capability⦁ Central Link⦁ Remote support interfaceOperation⦁ Operating unit with foot switches ⦁ Communications rail⦁ MobileControlSafety⦁ CE marking⦁ Standard safety device⦁ Lateral sliding doors⦁ Rear roller gateAdvanced standard configuration⦁ Electrical cabinet  ...

Standard configurationMachine⦁ C frame⦁ Highly dynamic electromechanical direct drive⦁ Electrical cabinet air conditioning up to an ambient temperature of 40 °CBackgauge system⦁ 6-axis backgauge (X1, X2, R1, R2, Z1, and Z2 axes) with backgauge sensor systemTool clamping system⦁ Segmented Wila tool clamps without Tool Identification System (TIS)Control system ⦁ Machine control with touch operation⦁ Mobile operator terminalOperation⦁ Lighting integrated in safety fencingData transmission⦁ USB interface⦁ RJ45 network interface⦁ Network capability⦁ Remote support interfaceBend Master (15) ⦁ Stable base body and manipulator⦁ Floor track⦁ Electric drives⦁ Gripper coupling on the BendMaster⦁ Pivoting-jaw gripper with jawsLoadMaster Bend ⦁ Handling system⦁ Multi-suction device with bellows suction cups⦁ Double sheet detection and separation⦁ Transfer sy ...

Standard configurationMachine⦁ Box frame⦁ Hybrid axis system⦁ Linear magazine with 20 stations for clamps and tools⦁ Hydraulic clamps (2 pcs.)⦁ Drives with maintenance-free three-phase motors⦁ Repositioning device with programmable presser foot⦁ 1st index pin (right inner)⦁ Foot switch for closing clamps⦁ Part chute, right including good parts container⦁ Part flap, left with sensor⦁ Stripper monitoring⦁ Brush tables with loading and unloading aidSafety⦁ CE marking according to the Machinery Directive⦁ Three-beam safety light barrierPunching head⦁ Delta Drive⦁ Rotary single station tool adapter⦁ Programmable presser foot position⦁ Tool length compensation⦁ Punch spray lubrication⦁ Punching slug vacuum⦁ Forming function⦁ Punch stroke counterControl⦁ TRUMPF control based on Rexroth IndraMotion MTX⦁ Touchpoint panel with TFT 19 color touchscree ...

Standard configurationMachine ⦁ Stable machine frame as all-steel construction⦁ Ram, stress relief annealed: Highly resistant to torsional forces, of ample size⦁ Spherical ram suspension, with ram tilt⦁ Electro-hydraulic downstroking drive with 4-cylinder technology⦁ Modern block hydraulics with control valves mounted on the cylinder⦁ Electronic pressure balance⦁ Measuring system⦁ Control panel with LCD panel, footswitch für Emergency up, down and E-STOP⦁ Oil cooler⦁ Switch cabinet cooling (air-air heat exchanger)⦁ Modern machine designBackgauge system ⦁ Backgauge system 2-axes⦁ 2 pieces back gauge fingersTool holder ⦁ Manual upper tool clamping⦁ Hydraulic lower tool clampingCrowning ⦁ Manual crowningLower tool shifting ⦁ Lower Tool AdjustmentSafety ⦁ Standard Safety equipment: Emergency Stop button, manual roller shutter rear, protective panels, CE c ...

Standard configurationMachine ⦁ Stable machine frame as all-steel construction⦁ Ram, stress relief annealed⦁ Spherical ram suspension, with ram tilt⦁ Electro-hydraulic downstroking drive with 4-cylinder technology⦁ Modern block hydraulics with control valves mounted on the cylinder⦁ Electronic pressure balance ⦁ Measuring system⦁ Hydraulic oil filled in the machine (lifetime lubrication)⦁ Oil cooler⦁ Switch cabinet cooling (air-air heat exchanger)⦁ Modern machine designBackgauge system ⦁ Backgauge system 2-axesTool holder ⦁ Manual upper tool clamping ⦁ Shifting: programmableCrowning ⦁ Manual crowning: Integrated in the table, manual adjustable crowning via wedgesLower Tool Adjustement ⦁ Lower tool adjustment CNC, programmableSafety ⦁ Standard Safety equipmentControl ⦁ TRUMPF TASC 6000Operation ⦁ Communication Track⦁ Control panel: With LCD panel, f ...

Standard configurationMachine ⦁ Stable C-frame for easy access⦁ Ball-fitted tables⦁ Coordinate guide for high-precision machining⦁ Linear magazine for tool stations and clamps⦁ 21 tool stations, 4 clamps⦁ Part chute for small parts 80 x 50 mm⦁ Parts flap 500 x 500 mm⦁ Good parts container⦁ Ability to retrofit ToolMaster Linear⦁ 1st index pin position inner side (right or left)Punching station ⦁ Electro-hydraulic punching head⦁ Rotatable single station tool adapter⦁ Manually adjustable presser foot force⦁ Programmable pressure foot (active /passive / repositioning)⦁ Tool length compensation⦁ Spray lubrication for punches⦁ Vacuum slug removal with condition monitoring⦁ Stroke rate punch⦁ Monitoring of fill level of tapping and tool lubrication⦁ On-Demand-Drive⦁ Stripper position measurement system with function sheet thickness detectionControl � ...

Standard configurationMachine ⦁ Box frame⦁ Press beam⦁ Spherical bearing of the press beam with press beam tilting⦁ Electro-hydraulic upper drive⦁ Block hydraulics⦁ Distance measurement system (Y axis) with dynamic deflection compensation⦁ Hydraulic oil filling (life-long filling)⦁ Oil coolerCrowning ⦁ Self-regulating, combined crowningBackgauge ⦁ Gauge fingers (2 pieces)Tool clamping ⦁ Manual upper and lower tool clampControl ⦁ T3500T Multi-Touch machine control⦁ Integrated TRUMPF technology dataData transmission ⦁ USB interface⦁ RJ45 network interfaceOperation ⦁ Operating unit with foot switchesSafety ⦁ CE marking⦁ Standard safety deviceAdditional equipmentCrowning⦁ CNC crowningBackgauge system⦁ 5-axis backgauge system : R1, Z1, Z2, X1, X2 (Delta X)Tool clamping⦁ Hydraulic upper tool clampingControl⦁ Teleservice per internetOperation ergonomi ...

Standard configurationMachine⦁ Closed machine frame⦁ Hybrid axis system⦁ Linear magazine with 20 spots for clamps and tools⦁ Hydraulic clamps (3 pieces)⦁ Drives with maintenance-free 3-phase servo motors⦁ Repositioning unit with programmable stripper⦁ Foot switch for closing clamps⦁ Beam guard⦁ Part chute right side⦁ Part removal flap left side⦁ Sensor for part removal flap⦁ Work area illumination⦁ FocusLine⦁ SortMaster Compact retrofit capabilityTRUMPF Laser⦁ Solid state laser TruDisk 3001 with 1 laser output⦁ Fiber optic cable according standard layout (10m)⦁ Laser power control⦁ Logbook function laser⦁ Closed beam guidance via laser light cable (LLK)⦁ Separate energy supply of TruDiskCompact cutting unit⦁ Solid-state compact cutting unit⦁ Protective glas⦁ Collision protection⦁ ControlLinePunching head⦁ Delta Drive⦁ Rotatable single t ...

Standard configurationMachine⦁ Stable machine frame as all-steel construction⦁ Ram, stress relief annealed⦁ Spherical ram suspension, with ram tilt⦁ Electro-hydraulic upper drive with 4-cylinder technology⦁ Optical set-up and positioning assistant⦁ Generous edge clearance⦁ Flat front covers⦁ Block hydraulics⦁ Electronic pressure balance ⦁ Measuring system with centered glass scales and deflection compensation⦁ Hydraulic oil filled in the machine (lifetime lubrication)⦁ Oil cooler⦁ Switch cabinet cooling (air-air heat exchanger)⦁ Modern machine design ⦁ TCB - Thickness Controlled BendingBackgauge system ⦁ Backgauge system 2-axes⦁ 2 pieces back gauge fingersTool holder ⦁ Hydraulic upper tool clamping⦁ Hydraulic lower tool clamping, hardened⦁ Lower tool shifting 2 positions, pneumaticCrowning ⦁ CNC crowningControl ⦁ TRUMPF TASC 6000⦁ Windows XPe ...

Standard configurationMachine⦁ C frame⦁ Press beam⦁ Highly dynamic electromechanical direct drive ⦁ Distance measurement system (Y-axis) with dynamic deflection compensation⦁ Electrical cabinet air conditioning up to an ambient temperature of 40 °CBackgauge system⦁ 3-axis backgauge with carbon fiber gauge finger (X, R and Z axis)Clamping system⦁ Manual TRUMPF upper tool clamp⦁ Manual TRUMPF lower tool clampControl⦁ TASC6000 machine controller⦁ Integrated TRUMPF technology data⦁ Data transfer⦁ Network capability⦁ USB interfaceOperation⦁ Foot switchSafety⦁ CE marking⦁ Standard safety deviceAdditional equipmentBackgauge system⦁ 6-axis backgauge systemErgonomic package⦁ Comfort support table (front)⦁ Comfort foot rest⦁ Front work area illumination (LED)⦁ Swiveling control panel⦁ Sitting and standing aid⦁ 2 pieces Support console + 2 pieces Docum ...

plate width: 370 mmplate thickness: 3 mmno. of straightening rolls: 12 roll diameter: 62 mmRoller diameter 60 mmWorkable strip thickness from 0.6 to 3.00 mmRoller configuration: 2+9+2 tempered and groundDouble input and output drive rollers pressed by 2+2 pneumatic cylindersInfeed and outfeed belt guide with 4 self-centering rollersHydraulic opening of the head for pilot release.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

tube: 6000 mmtube diameter: 42 x 3,0 mmwall strength: 3,0 mmbending radius min.: 150 mmtotal power requirement: 5,5 kWweight of the machine ca.: 1,2 tdimensions of the machine ca.: 7500 x 1.400 x 1.300 mRound steel tube: up to Ø 42 × 3.0 mmRound stainless steel tube: up to Ø 42 × 2.0 mmSquare tube: 25 × 2.5 mmMax. section modulus: 4.1 cm³Bending angle: up to 180° + 10° overbendingBending time at 90°: 2.7 sec. (forward stroke)Longitudinal feed speed: 450 mm / 1.5 sec.Rotary positioning speed at 90°: 1.0 sec.Repeatability of bending axis: ± 0.2°Controlled length tolerance: ± 0.3 mmControlled rotation tolerance: ± 0.2°Tube loading length / usable length for mandrel bending: 4,100 mmMax. radius range: 150 mmBending height: 850 mmFree-standing bending head: 850 mm longBending axis drive: electro-hydraulicRotation and length positioning: automatic via geared motorsBending direct ...

Key data: 3040 mm

FASTI 213/30/6 Folding machine – 3040 mm / 6 mm Motorized swivel bending machine for sheet metal processing with a maximum sheet width of 3,040 mm and a sheet thickness capacity of 6 mm with a material strength of 40 kp/mm². Manufacturer: FASTI-WERK Carl Aug. Fastenrath Model No.: 213/30/6 Machine type: Folding machine Maximum sheet width: 3,040 mm Maximum sheet thickness: 6 mm at 40 kp/mm² tensile strength Drive: Motorized Operation: Control panel with switches and display Bending Side: Continuous Upper beam: With continuous clamping strip Location: Siegen, Germany

AMADA HD 1703 L NT CNC die bending press – 170 t – 8 axes Hydraulic CNC die bending press with increased stroke, 8 controlled axes and fully automatic angle measuring system. Manufacturer: AMADA Model: HD 1703 L NT Machine Type: CNC Press Brake/Press Brake Year of Make: 2014 Press force: 1,700 kN (170 t) Table length: 3,110 mm Maximum bending length: 3,110 mm Distance between uprights: 2,700 mm Projection: 435 mm Maximum stroke: 350 mm Installation height without tools: 620 mm Control: AMADA AMNC PC Controlled axes: 8 Angle measuring system: Fully automatic Back gauge: CNC controlled Motor supply according to nameplate: 200 V Connected load: 16 kVA Hydraulic oil tank: 120 l Machine length: 4,750 mm Machine width: 2,750 mm Machine height: 3,170 mm Overall height: 3,190 mm Machine weight: 11,000 kg Serial Number: G100112 Date of manufacture: 10/2014 Acce ...

Key data: 31 t

Used CNC turret punching machine AMADA EMZ 3610 NT with AC servo direct drive, automatic tool change and automatic repositioning device. Manufacturer: AMADA Model: EMZ 3610 NT Machine Type: CNC Turret Punching Machine Year of Make: 2006 Punching force: 300 kN (30 t) Working area: 1,500 x 2,500 mm (according to available information) Tool stations: 45 Drive: AC servo direct drive Control: GE Fanuc Series 180i-PB Tool Change: Automatic Turret Tool Change Reset: Automatic Tool turret: With AMADA tool holders Material support: brush table Connected load: 27 kVA Noise level: 91 dB(A) Trail: 360 mm Machine weight: 24,500 kg Condition: Used

Max. cutting capacity: 3100mm cutting length with a max. sheet thickness of 6mm and a tensile strength of up to 450N/mm². Stroke rate: 10-45strokes/min. Ram stroke max.: 210mm. Working pressure max.: 18MPa. Blade clearance: 0.05-0.60mm. Cutting angle: 0.5-3°. Backgauge range: 10-750mm. Equipped with a backgauge and front sheet supports with rollers. Overall dimensions X/Y/Z: approx. 4045mm/3770mm/1750mm. Inspection possible by prior arrangement.

- Removes burrs after laser cutting, plasma cutting or punching.- Rounds sharp edges for safer handling.- Prepares metal components for painting or powder coating.- Reduces manual grinding and finishing costs.- Processes both sides in one pass on suitable models.- working width 1500 mm- Minimum thickness 0,5 mm- Maximum thickness 50 mm- Feed rate 0,3 - 5 M/Min- Minimum product size 380 x 50 mmThe ARKU EdgeRacer is an industrial deburring and edge-rounding machine, mainly designed for companies processing sheet metal.Its main advantage is that it can process both sides of metal parts simultaneously, reducing manual grinding and handling.

ARKU EdgeRacer ER 1500 D – Double-Sided Deburring and Edge Rounding MachineThe ARKU EdgeRacer ER 1500 D is a high-performance industrial machine designed for automatic deburring and edge rounding of sheet metal components.- Working width 1300 mm- Thickness minimum 0,8 mm- Thickness maximum 100 mmThe machine processes both the upper and lower sides of metal parts simultaneously in a single pass, significantly reducing production time and manual finishing work.What is this machine used for?- Removing sharp edges and burrs from laser-cut, plasma-cut and punched metal parts.- Rounding internal and external edges for improved safety and surface quality.- Preparing sheet metal components for painting, powder coating and further processing.- Improving edge quality for welding and assembly.- Processing steel, stainless steel and aluminium components.- Finishing complex sheet metal parts with h ...

material width:300 mmcoil weight:0,5 tcoil internal diameter:420 - 520 mmcoil external diameter:1400 mmweight:0,6 tdimensions (WxDxH):0,8 x 1,2 x 1,7 mexpansion:pneumatic

material width:250 mmmaterial thickness:0,25 - 3,0 mmno. of straightening rolls:11 straightening roll diameter:30 mmspeed:6 - 60 m/minpower requirement:15,0 kWweight:1,1 tdimensions (WxDxH):1,1 x 1,7 x 1,5 mstriaghtening pressure automatic:hydraulic coil loof control:ultrasonic

material width coil line:600 mmcoil weight:2 x 3,5 tcoil internal diameter:460 - 530 mmcoil external diameter:1500 mmmaterial thickness coil line:0,5 - 3,0 mmno. of straightening rolls:7 no. of rolls at in- and outlet:4 roll diameter:80 mmfeed length:0 - 500 mmpower requirement:10,0 kWweight:10,0 tdimensions of the coil line:8,8 x 4,0 x 2,55 mstraightening machine:Dimeco, 1676 EV double decoiler:2382 FFPS lag brake:pneumatic electronic roll feed:Microfeed

material width:800 mmcoil weight:12,0 tcoil internal diameter:470 - 520 mmcoil external diameter:1500 mmmaterial thickness:0,4 - 2,5 mmno. of straightening rolls:8 straightening roll diameter:53 mmnumber of draw-in rolls:2 inlet roll diameter:160 mmspeed:35 m/minmaterial thickness at 150 mm material width:2,5 mmmaterial thickness at 650 mm material width:1,5 mmmaterial thickness at 800 mm material width:1,0 mmstraightening machine:RM 8-53/160-800 decoiler:HE 200-1000

material width:250 mmcoil weight:2,5 tcoil internal diameter:430 - 520 mmcoil external diameter:1650 mmmaterial thickness:0,5-6 mmno. of straightening rolls:7 straightening roll diameter:60 mmnumber of draw-in rolls:2 weight straightener:1,2 tweight decoiler:1,4 tdimensions straightener (WxDxH):1,2 x 1,2 x 2,0 mdimensions decoiler (WxDxH):1,8 x 1,8 x 2,3 mexpansion:hydraulic

table-size: mmvertical movement: mm

material width:203 mmmaterial thickness:0,1 - 1,9 mmfeed length:101 mmweight:0,1 tdimensions (WxDxH):0,5 x 0,8 x 0,5 m

material width:450 mmmaterial thickness:1,0 - 14,0 mmcoil weight:10,0 tcoil internal diameter:470 - 520 mmcoil external diameter:1100 - 2000 mmno. of straightening rolls:12 straightening roll diameter:2x70 / 2x96 / 8x127 mmnumber of draw-in rolls:2 inlet roll diameter:160 mmmin. material width:100 mmspeed:15 m/minpower requirement:75,0 kWweight of decoiler:6,4 tweight of straightening machine:12,8 tdimensions decoiler (WxDxH):3,1 x 1,4 x 3,7 mmdimensions straightener (WxDxH):2,5 x 3,4 x 2,7 mmstraightening machine:RMS-Vario-12-70/96/127-0450 infinitely variable drive:insert drive upper straightening part:hydraulic liftable loop bridge:hydraulic driven threading wedge:hydraulic decoiler:HES 12-650 infinitely variable drive:insert drive lag brake:pneumatic snubber roll:hydraulic; motoric driven expansion:hydraulic coil lifting device:hydraulic cropping shears:HS-150-0450

material width coil line:600 mmcoil weight in kg:2 x 3000 kgcoil internal diameter:460 - 630 mmcoil external diameter:1500 mmmaterial thickness coil line:0,5 - 3,0 mmNumber of Straightening rolls:9 roll diameter:30 mmmaterial cross-cut:1200 mm²weight:9,5 tDimensions (WxDxH):4,3 x 2,6 x 2,6 mstraightening machine:30.600/9 double decoiler:Kohler, 3000.2 ausiliary drive:hydraulic lag brake:pneumatic expansion:hydraulic snubber roll:hydraulic; motoric driven

material width:250 mmmaterial thickness:0,5 - 4,0 mmno. of straightening rolls:9 straightening roll diameter:60 mmnumber of draw-in rolls:2 power requirement:3,8 kWWeight:0,8 tDimensions (WxDxH):1,6 x 0,8 x 1,5 m

sheet width:400 mmplate length:500 mmplate thickness:4 mmtotal power requirement:0,5 kWPunching and Nibling machine with 6 x 3 mm nibling and 4 mm for cuting
