11 DIMECO used machine for sale

For sale is a high-performance DIMECO LINAPUNCH MC-F CNC coil punching line for automated processing of strip material directly from the coil. The system is particularly suitable for the cost-effective production of perforated sheets, mounting plates, mounting rails, ventilation components and customer-specific stamped parts in medium and large quantities. Direct processing from the coil significantly reduces material consumption, set-up times and unit costs. LINAPUNCH technology combines the flexibility of a CNC punching machine with the productivity of a continuous coil line. The system works with standardized thick-turret tools and enables highly productive production processes. Technical data Manufacturer: DIMECO Type: LINAPUNCH MC-F Machine Type: CNC Coil Punching Machine/Punching Line Control: CNC, Siemens Simostar 370 Coil Processing Coil inner Ø: 508/610 mm Coil out ...

material width:500 mm material thickness:0,6 - 1,6 mm no. of straightening rolls:7 straightening roll diameter:60 mm number of draw-in rolls:2 + 2 inlet roll diameter:60 mm max. material thickness:2,0 mm material thickness at 150 mm material width:2,0 mm material thickness at 500 mm material width:1,6 mm weight:0,5 t dimensions (WxDxH):0,8 x 1,0 x 1,2 m

material width:300 mm material thickness:0,6 - 2,5 mm no. of straightening rolls:7 straightening roll diameter:60 mm number of draw-in rolls:2 + 2 diameter of draw-in rolls:60 mm max. material thickness:3,5 mm material thickness at 30 mm material width:3,0 mm material thickness with 300 mm material width:2,5 mm weight:0,3 t Dimensions (WxDxH):0,9 x 1,0 x 1,1 m

material width:550 mm material thickness:0,4 - 1,6 mm no. of straightening rolls:11 straightening roll diameter:60 mm number of draw-in rolls:4 diameter of draw-in rolls:60 mm band speed:4 - 50 m/min power capacity:3,0 kW weight:1,7 t Dimensions (WxDxH):2,5 x 2,0 x 1,7 m

material width:400 mm material thickness:0,6 - 2,8 mm no. of straightening rolls:5 straightening roll diameter:40 mm no. of pulling rolls:2 + 2 material thickness at 400 mm material width:1,8 mm material thickness at 65 mm material width:2,8 mm power capacity:3,0 kW weight:0,45 t Dimensions (WxDxH):0,8 x 1,8 x 1,35 m

material width coil line:600 mm coil weight:2 x 3,5 t coil internal diameter:460 - 530 mm coil external diameter:1500 mm material thickness coil line:0,5 - 3,0 mm no. of straightening rolls:7 no. of rolls at in- and outlet:4 roll diameter:80 mm feed length:0 - 500 mm power requirement:10,0 kW weight:10,0 t dimensions of the coil line:8,8 x 4,0 x 2,55 m straightening machine:Dimeco, 1676 EV double decoiler:2382 FFPS lag brake:pneumatic electronic roll feed:Microfeed

Dimeco 1675/Dnbsp;straightener with CNC feed system (cybelec) - width: 500 mm - max thickness: 1,6 mm

Dimeco 1675/Dnbsp;straightener with CNC feed system (cybelec) - width: 500 mm - max thickness: 1,6 mm

Dimeco 1675/D richtmachine met CNC-aanvoersysteem (cybelec) - breedte: 500 mm - maximale dikte: 1,6 mm

Dimeco afwikkel-/terugwikkelapparaat Dimeco microvoeder - maximale breedte: 815 mm - maximale dikte: 3,5 mm

A Dimeco Alipress coil-to-sheet line with decoiler, straightener, and shear is available. Sheet width range: 200mm-1300mm, sheet thickness range: 1mm-7mm, cross-section range: 1400mm²-3250mm², max. feed speed: 30m/min, max. stroke rate: 150/min, max. material feed: 1000mm/stroke, straightener: Schechtl MSB100. Documentation available. An on-site inspection is possible.
