window production machines used for sale (159)

Auction-ID: A3-46147-2501

System: 68, 78, 80, 92 IVAnzahl der Werkzeugsätze: 4 St.Bohrung: 50 mmGebrauchte Fensterwerkzeuge Leitz, Zuani IV 68,78,80,92------------------------------------------Fensterschnitte als PDF Anhang!------------------------------------------(technische Angaben laut Hersteller - ohne Gewähr!)Alle angegebenen Preise netto. zzgl. gesetzl. Mwst.Die Daten fü, dieses Inserat wurden erstellt mit ModulMWS - die Maschinenverwaltung von LogoTech oHG.

Window machining centerDimensions of workpieces:Workpiece length: 270 x 3000 mmWorkpiece thickness: 30 - 85 mmWorkpiece width: 180 mmEquipment:Electric length stop Crosscut saw, diameter 400 mm, motor 3 kW Tenoning spindle, diameter 50 mm, useful shaft length 600 mm, motor 7.5 kW3 x profile shaft, diameter 50 mm, length 600 mm, motor 7.5 kWGlazing bead saw, diameter 200 mm, effective shaft length 20 mm, motor 2.2 kWFeed device 1.5 kW, roller diameter 120 mmOertli tools included profile 68, 78, 82

Window suspension conveyor Tiger Surface area on the ceiling approx. 8.50 m x 3.20 m 20 hooks with 2 points already dismantled and ready for loading Shipping Dimensions 1 pallet 2800 mm x 800 mm x H 500 mm Weight 119 kg 1 pallet 1200 mm x 800 mm x H 600 mm Weight 120.5 kg

Working width: 4000 mmWorking height: 2550 mmNumber of cylinders: 6 St.Dimensions (L/W/H): 5.000 x 1.200 x 2.900 mmloading dimensions L x W x H: 5.000 x 1.200 x 2.900 mmS+S Bavaria 2000 L window frame and sash pressThe press was partially reconditioned at our warehouse, immediately available!Technical specifications:- Working dimensions: 4000 mm x 2550 mm (length x height)- Abutment and pressure plate depth: 100 mm- Automatic press cycle for mortise and tenon corner joints- hand control for manual pressing mode- 1 central pressure beam (accommodates heights up to 2550 mm)- 1 transverse pressure unit- 1 shut-off valve for the 3rd vertical cylinder- 1 shut-off valve for the upper horizontal cylinder- 3 controls for angled window processing (vertical cylinders)- 3 attachable pivoting pressure plates for pressing angles up to 60 degrees- 2 extensions for pivoting pressure plates (for triangu ...

Tenoning spindle: 1 St.Number of milling agregates: 4 St.Spindle diameter: 50 mmControl: Weinig PC-Nexus Weinig Unicontrol 6 with NC spindles-----------------------------------------Machine available for inspection while still in operation until September 2026Summary of technical data(please inquire about any additional accessories included)Item 1: Cross-cut saw----------------------------> Electronic cross-cut saw, horizontally continuously adjustable> Number of tools: 1 unit> Spindle speed: 2,800 rpm> Spindle diameter: 40 mm> Max. tool diameter: 400 mm> Motor power: 3.0 kW> Laser alignment light for identifying the cut position> NC length stop mounted on the slotting table included,positioning of the cross-cut saw integrated into the control system. > Length 3500 mmItem 2: Tenoning and slotting spindle----------------------------> Number of tools: variable, infinitely adjustable via NC ...

Tenoning spindle: 2 St.Number of milling agregates: 4 St.Spindle diameter: 50 mmweight: 5500 kgloading dimensions L x W x H: 7500 x 2500 x 2400 mm# 7020 Gubisch CW 3/8 with tooling-------------------------------------Sold on behalf of the customer from the customers location. Machine can be viewed in operationSummary of technical data(please inquire about any additional accessories included)-------------------------------------Cross-cut saw-------------------------------------Electronically controlled cross-cut sawNumber of tools: 1 pc.Spindle speed: 3000 rpmSpindle diameter: 30 mmMax. tool diameter: 350 mmMotor power: 3 kWLength stop-------------------------------------Electronic length stop2 Tenoning and slotting spindles:-------------------------------------Number of tools per spindle: 4/5 pcs.Spindle stroke: electronicSpindle speed: 3800 rpmSpindle diameter: 50 mmSpindle length: 320  ...

Tenoning spindle: 2 St.Number of milling agregates: 7 St.Spindle diameter: 50 mmcontrol: Weinig, PC-Nexus Weinig Unicontrol 12with radial and axial CNC spindles as well as VARIO table and milling carriage Machine dismantled professionally and in our warehouse in 73447 Oberkochen.Video and pictures were taken before dismantling.Technical data summary(please inquire about any additional accessories included) crosscut saw > Electronic crosscut saw, horizontally infinitely adjustable> Number of tools: 1 piece.> Spindle speed: 2,800 rpm> Spindle diameter: 40 mm> Tool diameter max.: 400 mm> Motor power: 3.7 kW> Laser directional light to detect the saw section> Axial adjustment path 150 mm NC axis, electronically infinitely variable> Radial pneumatic adjustment path 8 positions for e.g. edge rounding from aboveRounding aggregate > Position: horizontally below> Motor power: 1.5 kW> Spindle diam ...

Number of motors: 2 Stück0: 3000 mmControl: ja/CNC loading dimensions L x W x H: 4000 x 1500 x 1500 mmWeight: 800 kgHECHT Double Miter Saw Exenso DS350E - 3000 mm--------------------------------------For wooden glazing beads, mullions, profile strips, aluminum strips, etc.Item 1.1 Article number 942.51031 pc. HECHT Exenso DS350E- Working length 3000 mm- Swivel range 22.5° (inside) to 135° (outside)- Right head movable- Saw blade holder Ø 350 mm- Includes 1 pc. center support.- Pneumatic clamping of the components.- Exenso DS3 positioning control with 15 touch panel display in adustproof monitor housing.- 3-axis control, 1 longitudinal axis and 2 swivel axes.- Manual input of cutting data- Processing of data from a cutting list (data set according to specifications)- Processing of measuring rod data (GMF wireless caliper)- Ethernet connection 10/100 (TCP/IP)- USB interface- Includes c ...

Consisting of: belt conveyor in-feed system, 6-level double sided storage, central switch cabinet with Omron touchscreen controller and safety fence. Used floor space approximately 6000x7500mm Auction-ID: A1-48377-20

Consisting of: automatic feed through clamp, infeed roller conveyor and lifting table, 1x Dynma rotating belt conveyor size approximately 2500x700mm, 5x Dynma belt conveyor size approximately 5000x1000mm, 3x cross feed belt conveyor, 1x 2-lane belt conveyor size approximately 3000x1100mm, 1x Dynma roller tilting station, 1x Schmalz vacuum lifting device model Jumbo ergo with column and vacuum pump, central switch cabinet , control panel, safety fence and stair Auction-ID: A1-48377-21

Dimensions (L,W): 1400 x 1750 mmWeight: , kgtiltable yes/no: ja RUCHSER assembly tilting table RU-MKS 1,4---------------------------------------Universally applicable work table e.g. for frame assembly, roller shutter box assembly, bars, sash fittings, glazingEquipment of machine, alternative / optional equipment on request!Pos. 1.0: Article no .: 8820000RU-MKS-1,4 assembly tilting tableBasic dimensions 1400 x 1750 mm, extended 3400 x 2500 mmSupport surface with 3 support bars, 2 of which are adjustable,one permanently mounted on the upper extension,covered with felt. Support surface with width andHeight / depth pull-out. Pneumatic tilting device,Payload 130 kg. Actuation via foot valve.Roller conveyor can be folded down manually and pulled out to the sidefrom 1400-2500 mm, roll length 140 mmclosed. Roller conveyor height in verticalTable position adjustable from 300-380 mm,Horizontal wo ...

Dimensions (L,W): 2000 x 1200 mmWeight: 100 kgtiltable yes/no: nein Bauerle work table------------------------Length 2000mmWidth 1200mmHeight approx. 900 mm (height adjustable)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Number of milling spindles: 2 St.fence: ja ja /neinworkpiece: ja STEGHERR Cross-bar Milling Machine, Type KSF-mini--------------------------------------------------Specialized milling machine for the efficient production of intersecting muntin bar joints.The KSF-mini muntin bar milling machine embodies STEGHERRs extensive experiencein manufacturing specialized milling equipment for intersecting muntin joints.The KSF-mini enables the rapid and precise production of allstandard intersecting muntin joints encountered in practice.Muntin bars that have already been profiled can also be processed on the KSF-mini.Precise milling is achieved because the workpiece is machined on three sidesin a single clamping operation.The tools are driven by two three-phase motors, workpiececlamping is pneumatic.The profile cutter is designed to match the web width. The saw bladesthat perform the lap-joint cut  ...

Number of spindles: 4 St.Number of tools: 11 St.Spindle diameter: 50 mmSpindle length: 285,125 mmlength: 4000 mmwidth: 2000 mmheight: 2200 mmWeinig Univar 10/3 folding machine---------------------------------For milling around windows, doors and the like with unevencircumferential profiles. Machine suitable for wood thickness 68 to 92 mmTime required per frame milling, medium size 1.20 x 1.20 m - approx. 2 minutes.The available tool positions are selected using a selector switch on the control panelretrieved.Machine with 3 hydraulically controlled right precisionLifting spindles for holding 3 tool sets, 2 x 95 mm spindle stroke per spindleThe spindle stroke takes place in a U-movement, so that the opening is possible for short partsThe milling stop remains as small as possible. Spindle stroke horizontally fineAdjustable for both tool positions from the operator side.Central lubrication f ...

Tenoning spindle: 2 St.Number of milling agregates: 7 St.Spindle diameter: 50 mmcontrol: Weinig PC-Nexus Weinig Uncontrol 12with radial and axial CNC spindles and VARIO table.. The machine has already been professionally dismantled and stored in 73447 OberkochenSpecifications summary(please inquire about any additional accessories included).. crosscut saw.. > Crosscut saw electronically, horizontally infinitely adjustable> Number of tools: 1 pc.> Spindle speed: 3000-6000 rpm> Spindle diameter: 40 mm> Tool diameter max.: 400 mm> Motor power: 3.7 kW> Laser guide light for detecting the sawing section> Axial adjustment path 150 mm NC axis, electronically stepless> Adjustment path, radial, pneumatic, 8 positions, e.g. for edge rounding from aboverounding aggregate.. > Position: horizontally below> Axial adjustment path together with the crosscut saw.electronic length stop.. > Length 4500mm1. ...

Working width: 4500 mmWorking height: 3000 mmNumber of cylinders: 6 St.Dimensions (L/W/H): 5500x1400x3550 mmWeight: 3000 kgS&S frame press Bavaria 2000 L, built 2026---------------------------------SHORT TIMED availabe exw warehouse Engelfried, 73447 OberkochenNEW for the Holz-Handwerk 2026 trade fair in Nuremberg:Now also with semi-automatic positioning of the verticalpress cylinders 1, 2, and 3 via enabling switch,including ON/OFF selector switch for beam 2With automatic pressing cycle + manual controlfor corner connections tenon+slots and dowel connection/mortised tenon,can be switched using a selector switch on the control cabinet.With basic equipment for optional use of counter profiles if the sash is rebated on the loose part.CE versionBasic machine in the strongest frame welded construction,with thick-walled special hollow profiles.Guideways of the pressure beams for the press cor ...

Motor output: , kWautomatic: , Table dimensions: , mm! Please notice the VIDEO of this unit ! For window producers we recommend a spinde with 40 mm diameter and 160 mm usable length, Tools should have inside diameter of 110 to 120 mm Attached the description with options as pdf-file. Price list on request! For window production the manufacturer recommends following options of price list: Art.-Nr.bo1000 base unit Art.-Nr.bo1050 protection Art.-Nr.bk0180 arc marker Art.-Nr.gt0250 glazing bead construction 1 lengthenning : bo1720 ot bo2510. (technical details according to manufacturer - without guarantee!)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Clamp length: - mmClamp width: - mm0: - NmRuchser Glass bead nailer 2 P Jumbo automatic E.C. - new -Your advantages:- The corner connections are closed- No open glazing bead joints- There are no color differences when painting- The glazing bead frames are easy to assignClamp corner joining machine 2PJumbo Automatic E.C. for clamping glazing bead frames.Choice between automatic and manual operation,With angle system, clamping device from above and frontPressure can be regulated separately.Inserting parallel and superimposed onesClamps possible via electronic programming control.Stapler can be mounted on a suitable work table,Operation via foot valve.--------------------------------------Price in this version on request!Plus packaging/shipping--------------------------------------Pictures show Clamp corner joining machine 2P inlcuding the option of movable work table (please find details a ...

Tenoning spindle: 1 St.Number of milling agregates: 4 St.Spindle diameter: 40/50 mmWeinig Unicontrol 6--------------------------------------------Machine will be checked in our factory before delivery!Technical Data Summary(Please inquire about any additional accessories included)Item 1: Cut-off saw--------------------------------------------> Number of tools: 1 pc.> Spindle speed: 2,800 rpm> Spindle diameter: 40 mm> Maximum tool diameter: 400 mm> Motor power: 3.0 kW> Laser guide light for identifying the saw cutCNC-controlled length stop-------------------------------------------> Length: 3,600 mm> Electronic length stop including positioned cut-off sawItem 2: Tenoning spindle--------------------------------------------> Number of tools: 3 (stroke 2 x 100 mm) or 4 (Stroke 3 x 80 mm)> Tool clamping length: 320 mm> Pneumatic vertical spindle stroke: 240 mm for wood thicknesses 68 - 92 mm> ...

Working width: 230 mmWorking height: 15-120 mmNumber of spindles: 2 St.Weinig Hydro Planer Type Uniplan 23-------------------------------------------------------------------- Machine was factory overhauled by Weinig in 2024.Description:For two-sided horizontal woodworking with two working spindles.Spindle arrangement: horizontal, bottom and top.The two horizontal spindles are equipped with hydraulically tensioned counterbearingswithout axial adjustment. Built-in straight jointers on both spindleswith automatic stone feed, remotely controlled with the hood closed.Machine with continuous, chainless feed, equipped with rubber rollers.Electric up/down adjustment of the spindles according to a mechanical digital display(SIKO).On/off switch for limiting the up/down adjustment. Feed roller pressurepneumatic. Stops and table tops are not adjustable. Machine withsteel table tops.Machine with full ...

Tenoning spindle: 1 StNumber of milling agregates: 4 St.Spindle diameter: 50 mmControl: Weinig, PC-Nexus Weinig Unicontrol 10 CNC - Spindles radially and axially CNC-controlled-------------------------------------------------------- ------The machine was factory overhauled by Weinig in 2024.The control panel was also upgraded to a Siemens S 7 677 C,with a new membrane panel Touch.With the following machining units:Crosscut saw--------------------------------------------------------------with laser alignment light, motor power 3 kW, spindle diameter 40 mm,spindle speed 3,000Axially adjustable via NC axisRadial pneumatic adjustment to 8 positions for edge rounding from aboveUnit from below for edge rounding-------------------------------------------------------------A xially adjustable with crosscut sawTenon and slotting spindle-------------------------------------------------------------- ...

Working width: 3600 mmWorking height: 2600 mmNumber of cylinders: 5 St.loading dimensions L x W x H: 4400 x 1150 x 2970 mmweight: 3000 kgSchafberger + Sproedhuber Bavaria Frame Press---------------------------------Machine will be partially reconditonned by us before delivery.With automatic pressing cycle + manual controlfor tenon + slot corner joints.CE-certified versionBasic machine in the strongest welded frame construction,with thick-walled special hollow profiles.Guideways for the pressure beams for the press cornersin a low-wear machined design.Fast, smooth, manual width adjustmentvia ball-bearing carriages, fixed in ahole pattern.Height adjustment and pressing via long-stroke cylindersin a single work cycle. Right-side press corners withintegrated horizontal cylinders, therefore novertical positioning of the horizontal pressure cylindersnecessary, thus avoiding cylinder collisions ...

Tenoning spindle: 1 St.Number of milling agregates: 1 St.Spindle diameter: 40 mmSmall-scale window manufacturing consisting of:--------------------------------------------------1) Haberkorn FZS1 slotting machine. Price: €12,5002) Okoma SF3F table milling machine with glazing bead saw. Price: €4,0003) Oertli tooling for the Haberkorn and Okoma machines. Price: €7,5001 set of wooden windows IV 68/78/88 and 1 set of wood-aluminum windows IV 68/78, manufactured in 20114) Götzinger OBM Plus corner hinge and olive drilling machine, Maco MultiMatic hardware.Price: €7,000(Hardware can be converted for an additional charge upon request!)--------------------------------------------------Technical Manufacturers Description:- Haberkorn FZS1 slotting machine with automatic feed,- Stepless height adjustment D 40 mmCrosscut saw:- Spindle arrangement: top- Three-phase motor: 3 kW- Spindle diame ...

Working width: 3450 mmWorking height: 2000 mmNumber of cylinders: 5 St.loading dimensions L x W x H: 3600 x 1200 x 2720 mmHess Multipress Perforated Plate PressFor all sloped, segmental, and round-arch windows and doors.Also for interior work or frame construction.For gluing staircase block joints and much more.Largest working area approx. 3450 x 2000 mmExternal dimensions approx. 3600 x 1200 x 2720 mmThe vertical perforated plate press is constructed of heavy-duty, torsion-free steel.Thanks to its simple, robust, and economical design,it has a long service life.The perforated plate is made of 10 mm sheet steel with a 50 mm hole pattern. The pressure cylinders and abutments are self-locking.5 plug-in hand hydraulic cylinderson a perforated plate with a built-in pump, 2000 kp pressure relief valve, 140 mm pressure plate width, 80 mm pressure plate depth, 60 mm cylinder stroke4 fixed indiv ...

cut-off saw: 3 KWSpindle diameter: 50 mmSpindle length: 300 mmNumber of tools: variabel St.Control: CNC Dimensions (L/W/H): 2500x1700x2100 mmweight: 1700 kgHABERKORN - FZS-2 Electronic Slotting Machine with Stepless Slotting Spindlesand Automatic Roller Table----------------------------------------------Crosscut Saw---------Spindle Positioned at the TopThree-Phase Motor 3 KWSpindle Diameter 30 mmSpeed 2800 rpmSaw Blade Diameter 400 mm Automatic Brake with Speed Monitoring Stepless Saw Positioning with Siko Display Guard and Extractor Hood with 100 mm Diameter Extractor Nozzle2 Slotting Spindles 50 mm Diameter-----------------------------------Power 2 x 7.5 KWSpeed 4200 rpmSpindle Diameter 50 mmMax. Tool Diameter Approx. 360 mmUsable Length 300 mm Both slotting spindles can be positioned via ball screw Freely programmable 19 programs, display with function keys Protective and extraction h ...

Tenoning spindle: 1 St.Number of milling agregates: 5 St.Spindle diameter: 50 mmControl: Weinig, PC-Nexus Weinig Unicontrol 6 with NC spindlesMachine will be cleaned and completely checked before delivery--------------------------------------------Technical data summary(please enquire about any additional accessories included)Item 1: Cross-cut saw-------------------------------------------> Number of tools: 1 pc.> Spindle speed: 2,800 rpm> Spindle diameter: 40 mm> Max. tool diameter: 400 mm> Motor power: 3 kW> Radial adjustment path pneumatically controlled to 8 positions,e.g. for edge rounding from above> Laser aiming light for detecting the saw sectionItem 2: Rounding unit horizontal below-------------------------------------------> Position: horizontal below> Motor power: 1.5 kW> Spindle diameter: 20 mm> Clamping length 25 mm> Spindle speed: 9,000 rpm> Max. tool flight circle: 130 mm> ...

Tenoning spindle: 1 St.Number of milling agregates: 4 St.Spindle diameter: 50 mmcontrol: Weinig, PC-Nexus Weinig Unicontrol 6 with NC spindles-----------------------------------------Machine will be cleaned and completely checked before deliveryTechnical data summary(please enquire about any additional accessories included)Item 1: Cross-cut saw---------------------------> Electronic cross-cut saw, infinitely adjustable horizontally> Number of tools: 1 piece> Spindle speed: 2,800 rpm> Spindle diameter: 40 mm> Max. tool diameter: 400 mm> Motor power: 3.0 kW> Laser aiming light for detecting the saw section> NC length stop, mounted on slot table includedPositioning of the cross-cut saw integrated in the control system. > Length 3500 mmItem 2: tenoning spindle----------------------------> Number of tools: variable, infinitely variable adjustment NC axis> Tool clamping length: 320 mm> Vertica ...

Number of motors: 1 Stück0: 2500 mmControl: nein Hecht ES 350 single-sided glazing bead saw--------------------------------------Pneumatic pivoting against fixed stops.45º/ 90º/ 135ºwith pneumatic sawblade feedpneumatic tilting via manual tilt stopwith machine base, pneumatic clampingHM sawblade 350 x 3.0/2.2/30 Z 100Saw stand dimensions: length 700 mm, depth 1,600 mm, height 1,500 mm1.5 m touch stop1.5 m support with support3 m touch stopSupport extension from 1.5 m to 3 m with supportTable inserts grooved for rebated glazing beadsHECHT ASB manual length stop with digital display, 2,500 mmWith dust extraction unit(Technical specifications according to the manufacturer - no guarantee!)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Working width: 3500 mmWorking height: 2550 mmNumber of cylinders: 6 St.loading dimensions L x W x H: 4500x950x2900 mmHess Speedy frame press--------------------------------------will be checkedInsertion dimension / pressing length max. 3,500 mmInsertion dimension / pressing height max. 2,550 mmSliding carriage for width adjustment locking in 50 mmDouble hole grid systemElectric height adjustment of the long-stroke cylinders (hydraulic)Insertion height of the abutment plates can be preselected in 4 positions3 vertical printing cylinders stroke 1000 mmPressure force per cylinder 2000 kN / 20000 N3 horizontal printing cylinders stroke 80 mmPressure force per cylinder 1250 kN / 12500 NPrinting plate depth 100 mm width 140 mmGrid for cylinder fixation/rear bearing 50 mmMedium pressure beam with shut-off valveFinal pressure switch-off and pressure controlControl and pressing process in touch b ...
