Sheet Metal Bending Machines used for sale (18)

Profile cassettes and cutting dies for a roll forming line used in the production of trapezoidal sheet profiles. Two different profiles can be produced: H = 158 mm × W = 750 mm H = 153 mm × W = 840 mm Please refer to the photos for further details. Material Capacity Aluminum and steel Material thickness: 0.75 - 1.5 mm Scope of Supply Cassette 1 for Profile 153 and 158 Cassette 2 for Profile 153 and 158 Cassette 3 for Profile 153 and 158 Cassette 4 for Profile 153 Cassette 4 for Profile 158 Cassette 5 for Profile 153 Cassette 5 for Profile 158 Cassette 6 for Profile 153 Cassette 6 for Profile 158 Cutting die for Profile 153 Cutting die for Profile 158 All tooling comes from ongoing production and is being offered for sale due to a product change within the manufacturing operation. Please note: The offer includes the profile cassettes and cutting dies onl ...

: 1550 mm: 2,0 mm: 1,5 mmroll diameter: oben 90 mm: 560 kg: 2580 x 700 x 1250 mm mm- 2 central rollers driven by an electric motor- Swing-out upper beam- Conical bending device- separate control panel- self-braking main motor- CE mark/Declaration of ConformitySpecial equipment included in the price:- hardened rollers- Motorized rear roller adjustmentThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Cassettes + knives for roll forming line for the production of trapezoidal sheets. Two different profiles can be produced. H = 158 mm x W = 750 mm H = 153 mm x W = 840 mm See photos for details. Workable sheet metal : Alu + steel in 0.75 - 1.5 mm Composed of a total : - Cassette 1 for Profile 153 and 158 - Cassette 2 for Profile 153 and 158 - Cassette 3 for Profile 153 and 158 - Cassette 4 for Profile 153 - Cassette 4 for Profile 158 - Cassette 5 for Profile 153 - Cassette 5 for Profile 158 - Cassette 6 for Profile 153 - Cassette 6 for Profile 158 - Knife for profile 153 - Knife for Profile 158 Everything comes from ongoing production, the sale is due to a product change. It is only the cassettes + blades, without drives, reel, scissors, etc. Total weight : approx. 86,000 kg

sheet width: 1050 mmplate thickness: 1,8 mmpre-bending: 1,5 upper roll diameter: 70 mmmin. dia.: 105 mmtotal power requirement: 1,1 kWweight of the machine ca.: 320 kgdimensions of the machine ca.: 1700x700x1100 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

For sale is a new ROUNDO PASS 205 4-roll sheet metal bending machine from the Swedish manufacturer ROUNDO AB. The machine was delivered in 2011 and has a working size of 3000 × 4 mm. Machine data: Manufacturer: ROUNDO AB, Hässleholm, Sweden Model: PASS 205 wCNC² Machine Type: 4 Roll Sheet Metal Bending Machine Machine No.: 06764 Year of delivery: 2011 Operating hours: 216 h Capacity: 3000 × 4 mm Control: CNC - Hydraulic roller adjustment - Top roll diameter: Ø 205 mm - Pinch roll diameter: Ø 205 mm - Side roll diameter: Ø 160 mm - Motor power: 5.5 KW Minimum bending diameter: approx. 225 to 290 mm (strongly dependent on sheet thickness and material properties; usually 1.1 to 1.4 times the upper roll diameter) Weight: approx. 5,500 kg Features & Features: -Modern CNC control for precise and reproducible bending processes -Programmable bending programs  ...

sheet width: 2100 mmplate thickness: 40 mmpre-bending: 30 mmupper roll diameter: 390 mmlower roll diameter: 360 mmside roll diameter: 300 mmtotal power requirement: 22 kWmachine weight ab.: 17200 kgOverall size: 5060 x 2200 x 2180 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 6000 mm, 6 mm

Zschokke HAP 063a - 4/6 - Hydraulic press brake - Year of construction 1967 Technical data - Max. bending force: 630 t - Max. oil pressure: 400 atü - Column passage: 4100 mm - Max. bending length: 6000 mm - Projection: 375 mm - Stroke (adjustable): 0 - 500 mm - Distance of the tool holding surface: 300 - 800 mm Hydraulic pumps: - Main pumps: 2x 22 kW - Idle flow rate: 2x 153 l/min - Full load flow rate: 2x 33 l/min - Control pump: 0.75 kW Installation: - Footprint WxD: 6960 x 3250 mm - Height above ground: 4100 mm - Underfloor front: 2200 mm - Underfloor rear: 600 mm - Operating voltage: 3x 400 V / 50 Hz - Machine weight: 51000 kg

sheet width: 2100 mmplate thickness: 6 mmpre-bending: 4 mmupper roll diameter: 160 mmlower roll diameter: 140 mmside roll diameter: 120 mmtotal power requirement: 2,2 kWOverall size: 4140x1040x1140 mmweight of the machine ca.: 2.350 kgAccessories / equipment:- Conical bending device- induction hardened rolls- digital display for side rollers- Machine made of steel construction- Separate control panel- two speeds- all rollers on ball bearings- Folding and support bearing from the top roller is actuated from the control panel.When the folding bearing is opened, the roller moves automatically upwards.- Conical adjustment of the rollers via control panel- Central rollers are via hydraulic motor and rotary reduction geardriven. (Top and bottom rollers)- CalibrationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 4100 mmplate thickness: 35 mmpre-bending: 28 mmupper roll diameter: 540 mmlower roll diameter: 541 mmside roll diameter: 440 mmtotal power requirement: 37 kWweight of the machine ca.: 48.100 kgMachine dimensions approx.: 7670x3000x2930 mmAccessories / equipment:- Conical bending device- induction hardened rolls- digital display for side rollers- Machine made of steel construction- Separate control panel- two speeds- all rollers on ball bearings- Folding and support bearing from the top roller is actuated from the control panel.When the folding bearing is opened, the roller moves automatically upwards.- Conical adjustment of the rollers via control panel- Central rollers are via hydraulic motor and rotary reduction geardriven. (Top and bottom rollers)- CalibrationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3100 mmplate thickness: 10 mmpre-bending: 8 mmupper roll diameter: 270 mmlower roll diameter: 250 mmside roll diameter: 210 mmtotal power requirement: 11 kWweight of the machine ca.: 7750 kgOverall size: 5600x1450x1600 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3100 mmplate thickness: 16 mmpre-bending: 13 mmupper roll diameter: 330 mmlower roll diameter: 300 mmside roll diameter: 240 mmControl: total power requirement: 11 kWOverall size: 5600x1650x1900 mmweight of the machine ca.: 10.600 kgAccessories / equipment:- Conical bending device- induction hardened rolls- digital display for side rollers- Machine made of steel construction- Separate control panel- two speeds- all rollers on ball bearings- Folding and support bearing from the top roller is actuated from the control panel.When the folding bearing is opened, the roller moves automatically upwards.- Conical adjustment of the rollers via control panel- Central rollers are via hydraulic motor and rotary reduction geardriven. (Top and bottom rollers)- CalibrationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3100 mmplate thickness: 6 mmpre-bending: 4 mmupper roll diameter: 210 mmlower roll diameter: 190 mmside roll diameter: 170 mmtotal power requirement: 7,5 kWOverall size: 5200x1400x1300 mmmachine weight ab.: 5.400 kgAccessories / equipment:- Conical bending device- induction hardened rolls- digital display for side rollers- Machine made of steel construction- Separate control panel- two speeds- all rollers on ball bearings- Folding and support bearing from the top roller is actuated from the control panel.When the folding bearing is opened, the roller moves automatically upwards.- Conical adjustment of the rollers via control panel- Central rollers are via hydraulic motor and rotary reduction geardriven. (Top and bottom rollers)- CalibrationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 2100 mmplate thickness: 8 mmpre-bending: 6 mmupper roll diameter: 190 mmlower roll diameter: 170 mmside roll diameter: 150 mmtotal power requirement: 3 kWweight of the machine ca.: 3.450 kgMachine dimensions approx.: 4040x1380x1255 mmAccessories / equipment:- Conical bending device- induction hardened rolls- digital display for side rollers- Machine made of steel construction- Separate control panel- two speeds- all rollers on ball bearings- Folding and support bearing from the top roller is actuated from the control panel.When the folding bearing is opened, the roller moves automatically upwards.- Conical adjustment of the rollers via control panel- Central rollers are via hydraulic motor and rotary reduction geardriven. (Top and bottom rollers)- CalibrationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3100 mmplate thickness: 25 mmpre-bending: 20 mmupper roll diameter: 390 mmlower roll diameter: 360 mmside roll diameter: 300 mmtotal power requirement: 18,5 kWweight of the machine ca.: 17.100 kgMachine dimensions approx.: 5800x2100x2000 mmAccessories / equipment:- Conical bending device- induction hardened rolls- digital display for side rollers- Machine made of steel construction- Separate control panel- two speeds- all rollers on ball bearings- Folding and support bearing from the top roller is actuated from the control panel.When the folding bearing is opened, the roller moves automatically upwards.- Conical adjustment of the rollers via control panel- Central rollers are via hydraulic motor and rotary reduction geardriven. (Top and bottom rollers)- CalibrationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: - tstroke: - mmtable-size: - mmtotal power requirement: - kWweight of the machine ca.: 1,5 tdimensions of the machine ca.: - m: ja The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3100 mmplate thickness: 40 mmpre-bending: 32 diameter of upper rolls: 460 mmdiameter of lower rolls: 420 mmside roll diameter: 360 mmpower capacity: 30 kWmin. bending diameter: 1380 mmweight of the machine ca.: 30,1 tdimensions of the machine ca.: 6,3 x 2,3 x 2,6 m4 Rolls Hydraulic Bending MachineStandard Features:- hardened and polished rolls- complete body made of ST-52 steel- hydraulically opened/closed drop end controlled from control panel - digital readout for side rolls- top and bottom rolls are driven by hydraulic and gearbox. Bottom rolls vertical movements are hydraulic powered- separate control panel- oil cooler - conic bending- in accordance to CE-norm- Warranty 12 monthsOptional Accessories:- variable speed of rotation (5.858,00 Euro)- material feeding table (5.100,00 Euro)- center support (18.750,00 Euro)- 2 x side supports (15.000,00 Euro)The data for this ad  ...

sheet width: 2070 mmplate thickness: 10 mmpre-bending: 8 mmtotal power requirement: 7 kWweight of the machine ca.: 5 tdimensions of the machine ca.: 4050 x 1470 x 1550 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 1570 mmplate thickness: 10 mmpre-bending: 8 total power requirement: 7 kWweight of the machine ca.: 4,5 tdimensions of the machine ca.: 3,5 x 1,5 x 1,55 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
