Manufacturer:
(Category: 709)
used
This APV Gaulin MS 18-6TPS homogeniser is a 3-cylinder machine which is designed for ± 3.500 liter per hour with a maximum pressure of 380 bar (5.500 PSIG). The homogensier is equipped with 1-stages with puppet valve cylinder, hydraulic controlled. Manometers. Motor: 45 kW - 460 V - 69,5 Amp - 60 Hz - 1.780 rpm. Oil pumping system inside the machine. Stainless steel cladded. Instruction manual available., Type of Machine: Homogeniser, Capacity: ± 3.500 liter per hour, Stages: 1 Stage, Max. Pressure: 380 bar (5.500 PSIG), Valve cylinder: Puppet valves, Product: Milk, Piston diameter: 1.3/4, Motor: 45 kW - 460 V - 69,5 Amp - 60 Hz - 1.780 rpm, Weight: 2.100 kg
used
Cream separator (Skimmer). Self cleaning. Machine comes with the bowl, motor (37 kW), motor cover, base plate with feet, water valves (original Westfalia), main panel and control panel with GEA Operator Panel, all inlet/outlet pipes with pumps, manual counter pressure valve, manometer and service tools for maintenance including pressing tool., Additional Features:, Machine has several repairwork to be arranged by the new owner:, - Small corrosion on the bowl bottom part., - Upper bowl part has small dents., - Weldings inside the hood., - Topdisc has welded cracks., Type of Machine: Cream Separator / Skimmer, Capacity: 30.000 liter per hour, Bowl speed: 4.850 rpm, Motor: 37 kW - 400 V - 50 Hz - 1.470 rpm - 57 A , Production hours: 40.164 hours, Weight: 2.150 kg, Dimensions: 205 x 111 x 180 cm
used
The GEA Nu-Con CV 375 C is a Convey Through Sanitary Rotary Valve (Airlock) for use in gravity or pneumatic conveying systems, handling food, dairy, pharmaceutical, nutritional products and other dry ingredients. Quick disassembly without tools allows for rotor removal and access to all product contact areas for inspection and cleaning. The rotary valve has 8 bladed cylindrical rotors and accurately gauged clearances are maintained between the rotor tips and ends within the valve bore. Blow through (CV) with product entering at the top and discharging horizontally at 90 ° to inlet via a pneumatic conveying line, either vacuum or pressure. Previously used for transporting of Casein in a dairy factory. Material: SS SS AR. Drawing No. A3-33456-01. Motor: 0,25 kW - 220-240 / 380-415 V @ 50 Hz or 240-266 / 415-460 V @ 60 Hz - 1.300/27 rpm or 1600/34 rpm - 1,27/0,73 Amp or 1,15/0,66 Amp - 3 P ...
used
Milk pasteurisation line of 25.000 ltr/h with cream separator / skimmer. Temperature cylce: ± 3/4° (in) - regeneration - ± 55 °C (separator) - ± 72/75 °C (pasteurisation) - holding - regeneration - ± 3/4 °C (out). Line existing out of open level tank (2x lid, spraybowl), product pump (APV W 50/50), digital flow transmitter (Yokogawa FLXA402), Transmitter (Rosemount 8712) plate heat exchanger (APV N35 RKS, year: 2004, serial nr 1286, drawing no: NZ032, 4 sections, working pressure 6 bar), cream separator / skimmer (Westfalia MSA200-01-076, year 1980, serial nr 1669 642, self cleaning, bowl, motor (37 kW), motor cover, base plate with feet, water valves (original Westfalia), control panel including original GEA operation panel, all inlet / outlet pipes with pumps, flow indicator and only a few service tools for maintenance, holding tube with slope, booster pump (APV Puma 2-2 1/2) s ...
used
Gouda Euroblock Cheese Production Line for Sale due to the installation of a larger cheese production line within the existing cheese factory. The plant was designed for a milk intake capacity of approximately 100.000 litres per day, producing around 10.000 kg of Gouda cheese per day. The line manufactures Gouda cheese in Euroblock format, with dimensions of 500 x 300 x approximately 100 mm and an average weight of 15 kg per block. This corresponds to a daily production of approximately 650 Gouda cheese blocks., The production line consists of the following main components:, - 2 x Closed Cheese Vats with Whey Extraction Sieve., Manufacturer: Tetra Pak Tebel, Type: OST IV, Year: 1991, Capacity: 8,000 litres each, Cheese Vat 1:, Stocknumber: #1005, .hamburg-machinery/listings/4811812-used-cheesevat-tebel-tetra-pak-ost -iv, Cheese Vat 2:, Stocknumber: #1006, .hamburg-machinery/listings/4811 ...
used
The Mapro Positive Displacement Blower consist basically of a pair of Tri-lobe rotors, mounted on parallel shafts, rotating in opposite directions inside a properly shaped casing closed at the ends by side plates. The two Tri-lobe rotors are synchronized by a pair of timing gears. As the rotors rotate, air is drawn into the inlet side of the casing, is moved from the inlet to the outlet side by the free volumes, between rotors and stator and finally is forced out of the outlet side against the connected system pressure. The blower does not develop pressure within the casing but the discharge pressure depends only upon the connected system resistance. Motor: 22 kW - 400 V - 50 Hz - 2.950 rpm - 38,8 A. P(inlet): 1.013 hPa. P(outlet): 800 hPa. PS: 820 hPa. T amb: 20/40 °C. Blower speed: 2.500 rpm. Q: 372 cfm. Sound level: 89 dB(A)., Type of Machine: Positive displacement blower, Stock Numb ...
used
Lumacon automatic crate filling line, Automatically feeding of 4 crates/ boxes per cycle., When the weight has been reached the conveyor belts will remove the filled crates and prepare 4 empty crates for filling., - Complete with inclined conveyor belts, - Buffer belts, - Weighing belts, - Multiple lines available from stock (Emmeloord)
