Manufacturer:
(Category: 206)
CNC – controlled frame gluing press for automatic gluing of all frame constructions with dowel connection – tine connection – 45° miter connection, automatic centering of the press plates and the upper press beam. The frame presses are available in the following sizes – pressing area 3,000 x 1,700 mm – 3,000 x 2,000 mm and 3,500 x 2,500 mm. Two vertical press cylinders – pressing force per cylinder 7 tons (optional four vertical press cylinders). Two horizontal press cylinders, stroke range 150 mm - pressing force per cylinder 3 tons. Maximum tread depth 130 mm (larger tread depths on request). CNC control from SIEMENS® with touch screen for calling up three automatic pressing cycles, 99 compression programs can be stored per pressing cycle. Among other things, the following parameters can be programmed: frame size, frame profile structure, pressing time, pr ...
SPECIFICATIONS: Cold press Working table mm: 2500 x 1300 No. 4 pistons Vertical stroke: 450 mm
SPECIFICATIONS: Hydraulic hot press Dimensions of the work table mm: 3,000 x 1,300 Mounted serpentine table Maximum temperature: 120°. Number of pistons: 6 diameter Ø 65 mm Installed capacity KW: 30,5 Complete with intermediate plate Diathermal oil operation Complete with electric oil boiler
Press line SPECIFICATIONS: Automatic / manual operation Dimensions of the work table mm: 3,000 x 1,300 Number of pistons: 8, diameter Ø 70 mm Wood boiler Complete with loading and unloading system
SECOND-HAND HYDRAULIC BENDING PRESS MM. 2400X1300 - Platens mm. 2400X1300 - Opening mm. 1200 - N. 2 cylinders - Top bottom movement
Frame Press Hess Hydraulic Frame Press Type ECONOMIC Built in 1986 Electro-hydraulic Workspace Width 3050 mm x Height 2050 mm With hydraulic pump 0.75 kW 3 beams with pressure cylinders from above Fence side left 1 movable pressure bar from the right with 2 pressure cylinders Cylinder stroke approx. 150 mm Compressive force per cylinder 2100 kp (1kp = 1kg) Pressure plate depth 100 mm External Dimensions Space Requirements 3950 mm x 900 mm x H 2550 mm Loading dimensions approx. 3950 mm x 800 mm x H 2250 mm +Pallet with press bar (3 pieces) 2500 mm x 800 mm x H 1000 mm
Briquette press with extraction system Make Mütek Type MPP60 Year of construction 2011 Briquette mould cylindrical Diameter 50 mm Depending on the material, capacity up to 60 kg/h Drive motor 5.5 kW Volume of chip hopper approx. 0.7 m³ Weight of the press 680 kg Dimensions briquette press 1680 mm x 1100 mm x 1500 mm Height with container 2050 mm Including extraction system 33 filters, filter length 1300 mm, diameter 200 mm Extraction system filter area 27 m² Capacity 2,970 m³/h Fan motor power 5.5 kW Intake diameter 300 mm Overall dimensions with extraction system and fan 4300 mm x 1150 mm x height 3700 mm Almost all shredded materials can be briquetted with a residual moisture content between 6% and 18% without binder. e.g.: wood shavings, milling and sawdust, dust, paper, cotton flaky, coconut, wheat straw, hemp, hay, flax, plant stems, ma ...
Veneer press Ott Type: JU 65 Pressing surface 2250 x 1200 mm 2 electrically heated plates Total pressing pressure 65 tons Spec. Pressing pressure at full occupancy 2.4 kg/cm² Spec. Pressing pressure at 2 m² occupancy 3.25 kg/cm² Printing cylinder 4 x diameter 80 mm Rack and pinion guide Maximum opening between plates 300 mm Connection per heating plate approx. 6.0 kW Hydraulic pump approx. 1.1 kW Total connected load 12 kW Heating time approx. 20 min. Dimensions 2600 mm x 1330 mm x H 1760 mm Weight approx. 2800 kg
Frame press pneumatic Pressing dimension L 3550 mm x H 1850 mm 3 pneumatic punches from the top 1 sliding press bar from the right with 2 pneumat. Cylinders Bearing surface on the press cylinder 100 x 80 mm Dimensions: Length 4500 mm Width 600 mm Height 2500 mm Weight approx. 500 kg
Continuous press Wemhöner Year of construction: 1978 Upper piston press – lower press table is always standing at a constant height Pressing area approx. 4300 mm x 1350 mm 8 pressing cylinders from above was used as a cold press Water pipes available for connection to hot water still electrically connected, in operational condition with 1 roll replacement continuous film 1400 mm wide
Code: 0252 Brand: COLOMBO Model: 13/8 Presses (No. 2) suitable to bend different types of materials such as solid wooden strips and veneer - es: curved plywood, shells for chairs, seats, sofas, etc. - Equipped with with high-frequency generator The presses can work with mould and counter-mould or with steel-belt 1° Press Platen dimensions mm 1300 x 800 Opening mm 700 Thrust Piston diameter mm 150 Overall dimensions mm 2100 x 1000 x 2500 h 2° Press Platen dimensions mm 1300 x 800 Opening mm 700 Thrust Piston diameter mm 150 Overall dimensions mm 2100 x 1000 x 2500 h High frequency generator GIORDANO COLOMBO Overall dimensions mm 1100 x 1100 x 1900 h
Code: 0249 Brand: KOLMAG Model: PGP 120 Hydraulic hot press for veneer, furniture, custom-made furniture, doors, wooden panels, coated panels, chipboard, composite materials, Mdf, solid wood, cork, plastic laminates, technological materials, aluminium, etc. Technical data: Platen dimensions mm 3500 x 1300 N°6 pistons Total pressure ton 120 Platen heating by water boiler Opening between platens mm 400 Hydraulic unit Perimeter emergency cable Overall dimensions mm 4200 x 1600 x 2300 h Weight kg 4000
Briquetting press MATEC F-Cube 20 new Dimension press LxWxH: 130x74x112 cm weight 233 kg Briquette square 30x30 mm Capacity approx. 10-25 kg briquettes / hour Size feed funnel approx. 0.33 m3 Motor hydraulic pump 2.2 kW, 3x 400 V, 50 Hz Electricity consumption approx. 1.1 kWh How we work Continuous operation Year of construction 2021 Additional options: - Extension line for briquettes with stand -Auto. Start-stop system for operation with level monitoring - Sensors for level monitoring - Hydraulic oil 30 liters - 3 m cable with Euro plug 16 A - Flange adjustment filter-hopper press The spec. Density of briquettes is about 900 kg / m3. The maximum wood moisture content is 15%. The measured noise level is 62 dB. New machine, ready for operation. Subject to change, error, prior sale ! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden ...
HYDRAULIC PRESS with hot platens model MANNI PMC 90/36 second hand machine for wood, veneer, composite materials, furniture, panels etc platen useful size mm.3000 x 1300 n.06 cylinders diam.mm.70 max. thrust Ton.90 opening mm.430 hydraulic pump motor power Hp 2 hot water plates heating via wood boiler weight kgs. 3800 volt. 380/50
HOT PRESS model SIMI 4LP second hand machine plates useful size mm. 2500 x 1300 n.04 pistons diam.mm. 80 max. thrust Ton. 60 specific pressure max. kg.2 / cm2 opening mm. 320 hot water plates heating via wood boiler (optional) weight kgs. 3000
STEGHERR 2, 5 m Edge press 2, 5 m length on one side from the bottom with edge - preheating rail Driving device Space requirement approx. L = 2900 B = 600 H = 900mm G &-2789
MOULDING & FORMING PRESS - VILMAR PS 900 machine not according to CE standards Table size 900x500 mm Opening 310 mm Total thrust pressure 200 tons (55 kg/cm3 on 80% of the floor) n. 3 thrust cylinders diameter 160 mm each Hydraulic pump motor power 4 kW (5.5 hp) Power of electric heaters 11 kW (15 hp) Overall dimensions for transport 1500x900x2250h mm Weight approx. 3000 kg
Briquetting machine make Por series A 6 Complete with 36 sleeve filter, aspirator and connection ring to the machine Engine power HP 10 (kW 7.5) Briquette diameter 60 mm Maximum briquette length 50 mm with flat punch Number 14 cycles per minute Production 0.819 m3/h (+/- 10%) with maximum humidity 17% (purely indicative data which may vary based on the physical structure of the material) Dimensions: Height 1430 mm / Front 1660 mm / Depth 1100 mm / Weight 760 kg Inspection door with viewer Automatic start/stop level sensor Electromechanical panel
Complete pellet line for biomass or animal feed. CPM 3020-4 with 132 kW motor Including CPM Conditioner, CPM press and Geeelen cooler with fan and cyclone. Positive direct gear drive 132 kW, provides a 98% energy transfer Rounded cast gear case with internal ribbing for quieter operation Segmented die clamps for quicker die changes Metal-to-metal seals between components Modular gearbox design for production flexibility Replaceable quill flange Stainless steel pellet chamber Single motor 132 kW for greater efficiency Very good condition.
Embossing press - embossing machine Hydraulic Pressing surface, 600 x 2700mm Heated pressing surface
