peripheral equipment (e.g. heating, conveying, drying) used for sale (620)

Length 6.04 m.Roll width 40 cmRoller diameter 75 mmBelt driveCenter distance of the rollers approx. 50 cmWorking height adjustable 85 - 95 cmElectrical cabinet not included

Roller diameter: 90 mmRoller center distance: 155 mmRoller length: 1050 mmChain motor: 0.75 kWHeight: 290 mmRoller conveyor length: 1300 mm

Roller diameter: 90 mmRoller center distance: 155 mmRoller length: 1050 mmChain motor: 0.75 kWHeight: 290 mmRoller conveyor length: 5400 mm

Roller diameter: 90 mmRoller center distance: 155 mmRoller length: 1050 mmChain motor: 0.75 kWHeight: 290 mmRoller conveyor length: 3400 mm

Nominal lifting capacity: 5000kgCenter of gravity distance: 600mmTotal lifting height: 3.3mEngine: FORDTransmission: Grazziano

Motor: 5.5 kWSpeed: 2980 rpmInput diameter: 25 cmOutput dimensions: 30 x 20 cmWith mounting bracketWith control box

RobotMaximum reach: 3195mmRated payload: 180kgMaximum payload: 230kgMaximum supplementary load, rotating column / link arm / arm: 300kg / 130kg / 150kgPose repeatability (ISO 9283): +-0,07mmNumber of axes: 5Mounting position: FloorFootprint: 754mm x 754mmWeight: 1017kgProtection rating (IEC 60529): IP65 Running hours: 1053hVacuumsystemDimensions: 1700mm x 900mm 350mmConstruction of 56 SCHMALZ cups dia 50 and 70mm with pushrod for loosen plateFESTO components for compressed air/vacuumEach cup separately controlled by FESTO controllerCommunication via Profibus

curved conveyor beltbend 90?width carpet 500 mmtotal width 700 mmmin/max height 890/990 mmlength inner size 2800 mmengine 0.55 kW

Panel return system for single-sided edging machine in left-hand version with a length of approx. 12m50Panel length 240 to 2700 mmPanel width 60 to 1000 mmPanel thickness 8 to 80 mmMin/max panel dimensions with 4-sided machining: 240 x 80 mm, 2500 x 1000 mmWorking height 950 mmAt the machine outlet is a tilting air table that returns the workpieces on a conveyor belt to the machine operatorTilting air table with dimensions 2500 x 1400 mmAir table at the front of the machine inlet with dimensions 720 x 580 mmBrush cleaning of the return beltair table at the end of the return conveyor with dimensions 2500 x 1250 mm

Heating volume: 1,500 m?Air displacement: 6,300 m?/h2 hot air pipes, diameter 250 mmFlue diameter: 180 mmFan power: 1.5 kW

Workpiece dimensions up to approx. 5 m. length, 250 mm widthSliding blocks for possible loading with singulatorTransverse transport with 5 parallel driven belts, approx. 1.5 m in length, motor 0.37 kW Intermediate distance x 1m25 x 0m80 x 0m80 x 1m00 x4 perpendicular stop rollers4 non-driven feed rollers1 Interroll driven feed roller, built-in motor 0.37 kW, speed 0.20 m/sWorking height 70 cmElectrical cabinet not included

In line 90? panel turning device (or transport crosswise without turning)Panels entering lengthwise, turning them to crosswiseFence side at the leftPanel sizes:-Width from 220 mm to 1000 mm-Length from 320 mm to 3200 mmThe panels are transported on a roller conveyor, they are taken by 2 clamping discs iin order to turn them freely without friction and are placed back on a roller conveyor bringing them to the next machineConsisting of: -First roller conveyor with inclined driven rollers, length 3000 mm and width 1500 mm, rollers are soft pvc covered, centers 150 mm, feedspeed adjustable from 20 to 80 m/min, power installed 1,1 kW, additional roller coveyor aside in case of transport without turning-Adjustable fence-Clamping and turning device-Second roller conveyor with inclined driven rollers, length 1500 mm and width 3000 mm, rollers are soft pvc covered, centers 150 mm, feedspeed adjus ...

In line 90? panel turning devicePanels entering crosswise, turning them to lengthwiseFence side at the leftPanel sizes:-Width from 220 mm to 1000 mm-Length from 320 mm to 3200 mmThe panels are transported on a roller conveyor, they are taken by 2 clamping discs iin order to turn them freely without friction and are placed back on a roller conveyor bringing them to the next machineConsisting of: -First roller conveyor with inclined driven rollers, length 1500 mm and width 3000 mm, rollers are soft pvc covered, centers 150 mm, feedspeed adjustable from 20 to 80 m/min, power installed 1,1 kW-Clamping and turning device-Fixed fence-Second roller conveyor with inclined driven rollers, length 3000 mm and width 1500 mm, rollers are soft pvc covered, centers 150 mm, feedspeed adjustable from 20 to 80 m/min, power installed 1,1 kW

Volume: 2000lGas: airMax pressure: 10.7 barMax temp: -15/55?C

Conveyor for wet pieces in laquer lineLength: 3 m.Width: 1,3 m.Cleaning brush at the bottomMotorised feedworks

gebr. Three-shaft shredder (slow-rotating) Ackermann Type: JUNIOR Year: 1987 Power: 15 kW Rated Current: 31A Perforated sieve: 40 mm Hopper Dimensions: 70x46 cm (top) 35x46 cm (bottom) Hopper filling height: approx. 175 cm Dimensions (approx. dimensions): W: 125 cm T: 74 cm H: 196 cm Reading hours: 3,078 h

Used Höcker Dreisack 180 Socks with Feet Without blower

Used hot air generator with oil burner Ready for operation at the site

TECHNICAL DATA: 03 Reels Installed power: 0.6 kW

gebr. Clean air extraction SCHUKO VACOMAT 200 Dust Extractor YOC 1996 Motor power: 3.7 kW (400V) Rated current: 7.5 A Suction nozzle: 200 mm Nominal volume flow: 2,950 m³/h Min. volume flow: 2,251 m³/h pneumatic filter cleaning 3 mobile chip containers Chassis (suction wheeled) incl. various extraction pipes (see pictures) A total of 4 machines were connected to the extraction system. External dimensions (approx. information): 235 x 80 x 216 cm (L x W x H) Weight: 350 kg Good condition! The machine from a 1-man workshop.

Suction diameter: 300 mm; Discharge diameter: 300 mm; Volume flow: 5400 m³/h; Motor power: 2.5 kW; Weight: 100 kg; Very stable blower with steel impeller.

Suction diameter: 160 mm; Blow-out diameter: 160 mm; Volume flow: 2500 m³/h; Motor power: 2.2 kW; Weight: 50 kg; Very stable blower with steel impeller.

Suction nozzle diameter: 1 x 200, 3 x 100mm; Nominal volume flow: 1760 m³/h; Residual dust content: 0.1 mg/m³; Chip collection volume: 240l; Filter cleaning: motorized; Motor power: 3 kW; Noise level: 78dB(A); Machine length: 1340 mm; Machine width: 900 mm; Machine height: 2170 mm; Weight: 178 kg; Clean exhaust air by separating dust in the cyclone separator and cartridge filter Effective cartridge filter with a large filter area, easy to remove for cleaning or changing Automatic filter cleaning for consistently high extraction performance Included

intake connection: 200mm; Maximum volume flow: 3200 m³/h; nominal volume flow: 2862 m³/h; volume flow: Differential pressure indicator; Vacuum: 2336 pa; filter area: 16,8 m²; Residual dust content: smaller 0,2 mg/m³; SPL: db; chip bag volume: l; filter regeneration: pneumatic; motor power: 4 kW; machine length: 2300 mm; machine width: 900 mm; machine height: 2200 mm; weight: 350 kg;

Suction nozzle diameter: 300mm; maximum volume flow: 6000 m³/h; Nominal volume flow: 5089 m³/h; Volume flow monitoring: pressure differential indicator; Filter area: 31.8 m²; Residual dust content: less than 0.1 mg/m³; Sound pressure level: 70 db; Scout bag volume: 480 l; Filter cleaning: mororic; Motor power: 7.5 kW; Extinguishing device: yes; Machine length: 3245 mm ; Machine width: 1030 mm; Machine height: 2595 mm; Weight: 780 kg; The Riedex vacuum dust collectors have been developed for the extraction of wood chips, wood dust and related substances, but also

Suction nozzle diameter: 200mm; maximum volume flow: 3200 m³/h; Nominal volume flow: 2262 m³/h; Volume flow monitoring: pressure differential indicator; Negative pressure: 2250 pa; Filter area: 16 m²; Residual dust content: less than 0.1 mg/m³; Sound pressure level: 65 db; Späh bag volume: 320 l; Filter cleaning: mororic; Motor power: 4 kW; Machine length: 2340 mm; Machine width: 880 mm; Machine height: 2190 mm; Weight: 385 kg; The Riedex vacuum dust collectors have been developed for the extraction of wood chips, wood dust and related substances, but also for

Suction nozzle diameter: 160mm; maximum volume flow: 2000 m³/h; Nominal volume flow: 1448 m³/h; Volume flow monitoring: pressure differential indicator; Negative pressure: 3000 pa; Filter area: 10.5 m²; Residual dust content: less than 0.1 mg/m³; Sound pressure level: 64 db; Scout bag volume: 160 l; Filter cleaning: mororic; Motor power: 3 kW; Machine length: 1800 mm; Machine width: 820 mm; Machine height: 2220 mm; Weight: 320 kg; The Riedex vacuum dust collectors have been developed for the extraction of wood chips, wood dust and related substances, but also for

Suction nozzle diameter: 300mm; Nominal volume flow: 5087 m³/h; Volume flow monitoring: pressure differential indicator; Filter area: 32 m²; Residual dust content: less than 0.1 mg/m³; Spähne bag volume: 4 x 131.5l; Filter cleaning: pneumatic; Motor power: 7.5 kW; Extinguishing device: yes; Machine length: 3689 mm ; Machine width: 1590 mm; Machine height: 2555 mm; Weight: 967 kg;
