used
Vertongen Tenoning Machine P04 year 1979 S/N 5811 in great condition from a vocational school in Finland Included with tools Automatically adjustable tenoning machine Saw unit, max cutting height 130mm, spindle 30 mm /3000rpm, 400mm diameter saw blade 2 horizontal cutter blocks diam 160mm, spindle diameter 40 mm /4500rpm 2 vertical spindles 40 mm working height 160mm, 4000rpm ( Top + bottom ) 1 vertical spindle 40mm, working height 160mm / 4000rpm all spindles are adjustable in the horizontal and vertical direction Tenoning carrige 1000x280mm Sliding guide 2400mm with manual pressure and fence Power 380V 3-phase 50Hz Extraction needs (dust collector) 2400 m3/h Weight approx.1100 kg technical information under subject for corrections
used
KRÜSI chalet building machine / log house production line type CM 40 Manufacturer Krüsi Maschinenbau AG CH-9105 Schönengrund AR Year of manufacture 1996 CE- marked Condition: good, technically checked and cleaned / ready for operation Functional principle Machining of timber for chalet construction / log house production The beams can be processed in one pass - cutting to length - horizontal- and vertical milling of the necks / grooves in one clamping - drilling - milling the face grooves workpiece: - Cutting height max. 200mm - Cutting width max. 250mm Robust construction in welded design. Machine (horizontal and vertical milling unit) with 4 special milling motors, with hardened and ground guides for highest machining accuracy. Carriage guided by dust-protected and preloaded ball-bearing rollers. Working range up to 200 x 250 mm. Completely r ...
used
Wooden entrance length: min. 130 mm Max. 1000mm Ø370mm Wood cross-section: Min. 20x40mm Max. 80x180mm Wooden output length: Min.3700mm Max.7400mm Tine version vertical/horizontal 10/11 3.8mm pitch PVAC White Glue, 2-sided glue application Connected load 65 kW
used
Wooden entrance length: min. 130 mm Max. 1000mm Ø370mm Wood cross-section: Min. 20x40mm Max. 80x180mm Wooden output length: Min.3700mm Max.7400mm Tine version vertical/horizontal 10/11 3.8mm pitch PVAC White Glue, 2-sided glue application Connected load 65 kW
used
CNC unit for boring, routing and sawing Brand: Atemag Type: Ultra Line Duo With two tool interfaces, angle 90° Max. drive speed 10,000 R.P.M. Max. tool spindle speed 15,000 R.P.M. Gear ratio i = 1:1,5 Turning direction left/right Torque max. 22 Nm Tool interfaces: ER 25, ER 32, saw blade flange 30 mm, dia. max. 300 mm We recommend with saw blade or for heavy duty rough milling a gear reduction: Type DUO, version R Max. drive speed 12,000 R.P.M. Max. tool spindle speed 8,000 R.P.M. Gear Ratio i = 1:0,676 Torque max. 22 Nm
used
CNC unit for boring, routing and sawing Brand: Atemag Type: Ultra Line Vario Viso Angle adjustment 2 x 0 - 100° on two sides adjustable Max. drive speed 13.760 R.P.M. Max. tool spindle speed 15,000 R.P.M. Gear ratio i = 1:1,09 Turning direction left/right Torque max. 22 Nm Tool interfaces: combination ER 25 and saw, saw blade flange 30 mm, Pitch circle 45mm and 52mm
used
CNC unit for moulding or saw blade package Brand: Atemag Type: Ultra Line Mega Cutter Position of tool spindle 90° Max. drive speed 12,000 R.P.M. Max. tool spindle speed 7.690 R.P.M. Gear ratio i = 1:0,641 Turning direction left/right Torque max. 22 Nm Tool interfaces: arbour with 30mm diameter, 120 clamping length, max. tool diameter 160mm - without tools -
used
CNC Drawer fronts processing machine Brand: Comec Type: FRONTAL CN 1500 2S New machine for point to point drilling and milling, with automatic loader and pieces return to the operator Structure Frame of electro-welded steel sheet of heavy-duty construction Loading system 1 fix left shoulder and 1 mobile right shoulder on which are fixed the loader, magazine and locking system. Manual adjustment of the mobile shoulder on ball bearings slides with measure indication by digital display. Automatic loader with vertical adjustable magazine. Pieces advancement system step by step with 2 working stations, complete with locking cylinders on each station. Pieces return system Pieces return system composed with: 1 transversal motorized belt kW 0.37. 2 ejector cylinders. 1 longitudinal, lateral motorized belt kW 0.37. 1st Working station: vertical-horizontal Point to Poi ...
used
CNC unit for routing and boring Brand: Atemag Type: Function Line Soft Touch One With surface copying function with fix spindle ER25 and fix bell Max. drive speed 18,000 R.P.M. Max. tool spindle speed 18,000 R.P.M. Gear ratio i = 1:1 Turning direction left/right Torque max. 10Nm Tool interface: fix ER25 Adjustment distance: 70mm
used
CNC unit for boring and routing Brand: Atemag Type: Function Line Quattro With four tool interfaces 2x boring / 2x routing Max. drive speed 10,000 R.P.M. Max. tool spindle speed 15,000 R.P.M Gear ratio i = 1:1,5 Turning direction left/right Torque max. 20 Nm Tool interfaces: ER 25, ER 32
used
CNC unit for boring, routing and sawing Brand: Atemag Type: Function Line Vario Viso With adjustable angle 0 - 100° Max. drive speed 15,000 R.P.M. Max. tool spindle speed 15,000 R.P.M. Gear ratio i = 1:1 Turning direction left/right Torque max. 15 Nm Tool interfaces: combination ER 25 and saw, saw blade flange 30 mm Version with one single clamping screw, locking with the lever
used
CNC unit for routing and boring Brand: Atemag Type: Function Line Soft Touch Pro With surface copying function with floating bell GX1 or GX2 or GX4 Max. drive speed 18,000 R.P.M Max. tool spindle speed 18,000 R.P.M. Gear ratio i = 1:1 Turning direction left/right Torque max. 20 Nm Tool interface: modular for ER 25, ER 32, saw flange, shrink- fit chuck
used
CNC unit with oscillating cutter head Brand: Atemag Type: Function Line Soft Cutter Pro Max. drive speed 6.000 R.P.M Max. tool spindle speed 9.000 R.P.M. (Frequency 150Hz) Gear ratio i = 1:1,48 Torque max. 8Nm Amplitude: 4mm
used
CNC unit for boring, routing and sawing Brand: Atemag Type: Ultra Line Mono With one tool interface, angle 90° Max. drive speed 10,000 R.P.M. Max. tool spindle speed 15,000 R.P.M. Gear ratio i = 1:1,5 Turning direction left/right Torque max. 22 Nm Tool interfaces: ER 25, ER 32, saw blade flange 30 mm, dia. max. 300 mm We recommend with saw blade or for heavy duty rough milling a gear reduction: Type MONO, version R Max. drive speed 12,000 R.P.M. Max. tool spindle speed 8,000 R.P.M. Gear Ratio i = 1:0,676 Torque max. 22 Nm
used
CNC - Bearbeitungszentrum Fabrikat: COMEC Typ: MD TOP XL Die ideale Lösung für CNC - Bearbeitungen an schmalen, komplizierten Werkstücken COMEC macht´s Ihnen einfach Kopfkonfigurationen individuell konfigurierbar für: - Sägen mit 360 Grad - Achse - Fräsaggregate für horizontale und vertikale Bearbeitungen - Bohrköpfe mit einzeln abrufbaren Spindeln vertikal und horizontal - Mehrspindelreihenbohrköpfe einzeln abrufbar auch horizontal - Horizontalfräsaggregat mit 360 Grad C - Achse Speziell entwickelter Spanntisch, verfährt in X - Richtung automatisch programmgesteuert Individuelle Ausstattung möglich, zum Beispiel: Grundrahmen Schwerer Grundmaschinenständer, Elektroverschweißt. Maximale Werkstückgrößen: X-Achse 3350 mm (oder 1500 + 1500 mm in zwei Arbeitsfeldern) Y-Achse 200 mm Z-Achse 180 mm Verfahrbarer Aggregateträger 3 ...
used
CNC unit for boring and routing Brand: Atemag Type: Function Line Extra with two tool interfaces angle 90° Max. drive speed 10,000 R.P.M. Max. tool spindle speed 15,000 R.P.M. Gear ratio i = 1:1,5 Turning direction left/right Torque max. 20 Nm Tool interfaces: ER 32 / ER 16 Spindle for omega router/ ER 16
used
CNC unit for corner notching in off-set design Brand: Atemag Type: Function Line Extra 2 Max drive speed 8,000 R.P.M. Max. tool spindle speed 12,000 R.P.M. Gear ratio i = 1:1,48 Turning direction left/right Torque max. 20 Nm Tool interface: Special Attention: price is just valid for standard version
used
CNC Machining Center Brand: Weeke Type: Optimat BHC 550 Technical Specifications: Axes: 4 (X/Y/Z - C) Operating Hours: approx. 29,307 hours Number of Parts: approx. 300,411 pieces Vacuum Pump: 2 Siemens ELMO-L Program: WoodWop 4.5 Operating System: Windows XP External Dimensions Including Barriers: L/W/H - 6650/4500/2370mm Support Table: L/W - 3250/1300mm (for all-around machining) Workpiece Thickness: 100mm Spindle Mount: HSK - F63 Front Tool Changer: 8 Positions Rear Tool Changer: 18 Positions Veneer Stop: Rear Swivel Stops Front and Side Rotation Stops Accessories: 6 Clamps 2-circle workpiece H = max. 82 mm 10 x 2-circle suction cups 130 x 35 mm 8 x 2-circle suction cups 125 x 75 mm 11 x 2-circle suction cups 110 x 135 mm 1 x single-slot lock case unit Rotatable on C-axis 1 x MEC saw/milling/double-slot unit Rotatable on C-axis 1 x double-slot lock case ...
used
CNC unit for boring, routing and sawing Brand: Atemag Type: Vario Classic With one tool interface, angle 90° Max. drive speed 10,000 R.P.M. Max. tool spindle speed 15,000 R.P.M Gear ratio i = 1:1,5 Turning direction left/right Torque max. 20 Nm Tool interfaces: ER25, ER 32, saw blade flange 30 mm, sawblade dia. max. 180 mm or modular
used
New CNC Maschine Brand: Comec type: MD JAMB CNC machining center for complete machining of a wide range of door frames. 3 machining supports for cutting to length on miters, milling for corner connectors and door lock panels. A complete door frame element with decorative cladding and rebate cladding is machined in one set-up. A complete frame can thus be machined in approx. 2.5 - 3 min. Machining equipment can be individually adapted to the customers requirements.
used
Troughfeed boring machine Make: VITAP Type: ACOUSTIC For creation of acoustic panels for noise reduction Boring machine with through feed panel, boring from the bottom and automatic panel return to the operator. Three controlled axes: - X Axis - Panel movement by means of a strong pneumatic clamp - Y Axis - Boring head movement - Z Axis - Panel boring - Newly patented, high rigidity boring head movement on Y and Z axis. - Constant Side pusher: Side pusher with constant preload for perfect positioning of the panel on the machine zero point. - New frontal and more user friendly tool change system No limit in panel length High productivity and flexibility - The drilling head processes several holes at the same time - Different grids are possible also drilling grids with shift - Different drilling heads are optional available Easy TPA programming - Control: F ...
used
Multispindle drilling head unit for cnc working centres Make: ATEMAG Multispindle drilling head for economical drilling of numerous holes or complex hole patterns in just one machining stroke. Max. drive speed: 10.000 Rpm Max. tool spindle speed: 10.000 Rpm Gear ratio i= 1:1 Torque: max 1-5 Nm Number of tool output: on request
used
Trimming machine Make: VITAP Type: RC 92 New machine Technical data: - 2 high frequency motors HP.0,75 (Kw 0.55) each. 12000 RPM, in vertical opposite position with inverter; - 2 cutter heads with cutters one knife straight 15° the other radius 3mm; - CE standards Options (for a surcharge): - Couple of cutters (without knives) ? 274,00 - Set 8 knives 15 degrees angle and radius 2 mms. ? 122,00 - Set 8 knives 15 degrees angle and radius 3 mms. ? 122,00 - Pneumatic lifting of the upper motor ? 474,00 - Optional for panels max. high 120 mms ? 227,00
used
Corner rounding machine Make: VITAP Type: ROUNDER New machine Technical datas: - For corner rounder and straight corners - Standard cutters 15° R2 mm or R3 mm; - Foot pedal to start the cycle; - Movable reference with mechanical digital readout; - Complete protection with safety microswitch; - CE standards Options: CUTTER R1 MM CUTTER R2 MM CUTTER R3 MM
used
CNC boring- routering machine Brand: Vitap Type: K3 New machine Throughfeed process from the bottom and automatic panel return to the operator. Develop a new individual class: - With this machine you can do grooves and drill processings as well as different milling works, from simple edge milling to the milling of forms and letters. - There are no limits for your creativity Easy beginn with CNC programming: - TPA makes it easy: drillings, grooves, linear millings, form millings or the millings of letters - The CAD Software shows the processings on a virtual workpiece - Good overview about all processings on the single sides of the workpieces - Mirror function for parallel processings on other positions - Choose reference points via entering the exact position or just via click on the virtual workpiece Vitap Bar Nesting - efficient and time saving - This patent ...
used
Drilling- cutting machine Brand: Comec Type: Frontal 2 CN New machine Drawer parts machining in compact design Fast set-up for the smallest possible batch sizes thanks to CNC technology - Perfect machining The FRONTAL CN is ideally equipped for the machining of drawer parts and can be optionally equipped with drilling units from above, but also laterally, e.g. for drawer side parts. The drilling units at the top are suspended at the front of the upper beam so that a grooving saw unit can be mounted at the rear, for example, for drawing in top grooves. The machines can be equipped either with manual feeding or with automatic feeding magazine, so that the machines can work in continuous operation. For larger batch sizes, the FRONTAL is also available as a BASIC machine with conventional control.
used
CNC - processing center Brand: COMEC Type: MD TOP The ideal CNC solution to process narrow and complicated work pieces EASY with COMEC processing length up to 2.000 mm Head configuration individually customizable for: - saw with 360° - axis - milling unit for horizontal and vertical processing - drilling head with separate jumping spindles vertical and horizontal - multiple spindle drilling heads separate jumping even horizontal - horizontal milling unit with 360° C - axis Special developed clamping table, moves automatically program controlled in X direction Furthermore, optionally available: - Automatic raw work piece feed with finished work piece return to the operator TPA control unit: CNC control with graphical user interface Parametric software with 3D modeling Necessary processing macros customized to you pre-installed
used
Swivel spindle milling machine Brand: Panhans type: 245/200 New machine Solid 880 kg machine with smart control system - Infinitely variable speed regulation 1500 - 10,000 rpm, - 7.5 kW motor with 11 kW frequency converter - Pushbutton with electronic soft start 7 touch control, optional use, top and bottom - Cutter zero point selectable in program, 3 reference points - Simple operating menu through innovative touch control (max. 2 levels) - Operating hours counter - Warning messages in case of operating errors - Remote maintenance via Internet (VPN tunnel) - USB interface for data backup and import of tools, programs and users - Tool database for 5 tools (20 programs are possible per tool) - 2-axis positioning control for height and swivel adjustment - Electronic position and speed displays Double-sided swiveling, fixed milling spindle for the swiveling range ...
used
CNC punching machine Brand: Vitap Type: MICRA New machine High-Performance CNC machine for the production of acoustic panels with Micro-Perforation - Every 4 seconds the punching of 1.000 up to 2.331 holes are possible (depending on the workpiece) 3 controlled axes: - X-axis: drive via 2 motors and planetary reduction gear, guidance via pinion and rack - Y-axis: drive via 1 motor and planetary reduction gear, guidance via pinion and rack - Z-axis: drive via central hydraulical unit Easy handling with TPA control - Virtual display of programmed punching holes in the CAD environment - Optimization software for the working process - LCD TFT Monitor 20 - USB port - Basic Version CAD TPA - Macro programming Processing head - 5mm grid in X- and Y-direction - Punch depth: 3mm - Changable punching tools The processing head can optionally be customized ...
used
CNC boring machine Brand: VITAP Type: POINT 2 New machine Vitaps smart solution for throughfeed drilling and grooving with autom. panel return to operator 3 controlled axis - Axe X Uninterrupted movement of the panel due to a ?New patented belt transport system?. - Axe Y Movement of the drilling head - Axe Z latest generation motor and ball screw. - No limit in panel length Perfect for batch 1: - Setup time = 0 - High productivity and flexibility Easy TPA programming - Monitor LCD TFT 19 5/4 Usb port for loading programs run on a station in each office - Cutting optimization Software - Graphics programming CAD TPA, base version - Saving all files with all data - Macro Programming - Import DXF files - Control: Full Parametric - Office programming software TPA Technical data: - 9 vertical independent spindles - 2+2 horizontal spindles on X ax ...
