post press: gatherers used for sale

Size: 350 x 500 mmEquipments:This StitchLiner 5500 includes the following components2x VAC-100a and VAC-100m Collating TowersST-40 StackerACF-30 Accumulator and FolderSPF-30 Saddle StitcherHTS-30 Three-Knife TrimmerTB-30 Transport BeltKey Features:- 20 stations- U-shaped layout: Efficient space utilization and easy monitoring- Inline production from collating to finished product- Variable data processing: Handles personalized pprinting- Fully automatic format adjustment for quick job changes- Touchscreen for user-friendly operation, even for less experienced operatorsSpecifications:- Sheet sizes: Max. 500 x 350 mm, Min. 148 x 120 mm- Paper weight: 40-350 gsm- Processing thickness: 8-200 pages (max. 5 mm spine thickness)- Production speed: Up to 5,500 booklets/Technical Details:- Trimming (untrimmed): Max. 350 x 250 mm, Min. 140 x 103 mm- Trimming (trimmed): Max. 312 x 230 mm, Min. 120 x  ...

Reference Num.: 4198Brand: HorizonType: Horizon Collator MC-80a + MC-80m + Stitcher & Folder SPF-11 + FC-11Available: directlyStatus: Not in productionLocation: Deutschland

Size: 500 x 350 mmEquipments:Horizon Stacker Receiving Tray with Right-Side Delivery, ST-20Rair suction collator VAC-100aTechnology: touch & workmodel: air-suction collatorbins: 10 each collatorerror avoidance: misfeed-,doublefeed- and jamming controlsaveable jobs: 9 memories for repeat ordersextensibility: up to 6 collators (60 bins)stack opportunities: flat or laterally shift

Size: 318 x 470 mmEquipments:6 pockets, suction feedCriss-Cross Stacker and Max size: 318x470mm min. size: 148x210Max speed: 2400 hDimensions: 1650x650x1650

Reference Num.: 4199Brand: HorizonType: Collator AC-1200Available: directlyStatus: Not in productionLocation: Deutschland

• Model: TB Sprint 315 VP • Year of construction: 2005 • Machine type: Gathering machine (suction/blow principle) • Machine type: Processing machine / brochure production • Stations: 15 automatic stations + 1 manual docking station • Paper sizes: min. 65 × 100 mm, max. 350 × 500 mm • Output: up to approx. 3,300 cycles/hour • Alignment: Scale band with clock-by-bar alignment at head and side stop • Offset stacking possible (criss-cross stacking) • Vacuum and blow suction towers: can be switched off individually per station • Integrated transfer unit (jogger bridge) for further processing, e.g. with stapling/folding/cutting modules • Connected load: approx. 8.9 kW / 380 V / 50 Hz • Machine weight: approx. 2,650 kg • Space requirement (incl. joggers): approx. 7.35 m × 1.40 m • Condition: Used, functional tested

Format: min. 10 x 14 cm , max. 35 x 50 cm

2019 Duplo 600i Digital Booklet System Perfect condition – only 1 million total counter Available immediately Year of manufacture: 2019 Configuration includes: - 2 × Duplo DSC-10/60 Suction Collators 10 bins each Suction-fed for smooth and reliable handling of both digital and offset stocks - 1 × Duplo DBM-600 Bookletmaker Fully automatic stitch and fold unit Fast changeovers with automated format adjustments Ideal for short-run and high-volume digital production - 1 × Duplo DBM-600T trimmer Fore-edge trimming unit for clean booklet finishing Integrated and synchronized with bookletmaker - 1 × Duplo DBM-LS1 Long Stacker Delivery Long delivery system for continuous operation Perfect for high output jobs - 1 × Duplo DC-12JR Jogger Paper jogger for proper sheet alignment before collation Helps ensure smooth feeding and reduc ...

CP Bourg BMC Booklet Production System Year of Make: 2017 Condition: Very good – ready for immediate use We are pleased to offer you this complete CP Bourg booklet production system, which is ideal for high-volume production environments. The machine is fully functional, has been regularly serviced and used in a professional printing environment. It offers reliable performance and high-quality results. System configuration (per unit): BSTe 10-Station Suction Air Gathering Machine BSTe 10-Station Slave Gathering Machine BMC Booklet Manufacturing Unit Bourg front edge cutters – for clean and professional finishing Squarefold unit – for a square spine with a book look Key features: High-speed gathering with suction air system Fully automated booklet production with minimal operator effort Compatible with a wide range of paper sizes and weights  ...

max. format 35 x 50 cm Year of construction 1998 15 stations gathering machine Stack Feeder Vibrating delivery Transfer to the stitching machine Stitching - Folding Cutting Unit 303 Shed display Marking device Price on request. We supply and install worldwide.

Laconda Gathering Machine Spare Parts, Double Sheet Control Sensor, Suction Cleaner, in Good Condition, Immediately Available Robr Sb Njwivfbowkou If you are interested, we will also be happy to inform you about other machines in our company. You are welcome to visit the machine in our house by prior appointment

Polar RA4 Jogging Table – Year 2000 – Excellent condition Professional Polar RA4 jogging table, manufactured in 2000 and owned by the first user. This machine has been regularly serviced by the official dealer and was recently fully inspected and certified. It is in good working order and ready for immediate use. Specifications: • Brand/model: Polar RA4 • Year: 2000 • Condition: Technically 100%, fully operational • Maintenance: Always dealer-serviced • Inspection: Certified and approved • Surface: Stainless steel vibrating table • Application: Perfect for easy and precise alignment of paper stacks for cutting processes This jogging table significantly improves workflow efficiency around your cutting system and is a valuable addition to any print shop or bindery. Viewing by appointment is possible.

Size: A3Equipments:Good condition without any damage10 stations

Unbeatable flexibility for high mail volumes: The AS-ORBIT BASE addressing system can be installed in no time at all without much IT effort and fits seamlessly into your existing mail processing processes. Complete system consisting of feeder, tabber, printer with software and delivery belt. The AS-Orbit Base printing system is specially designed for demanding applications with a high production volume and is characterized above all by its high processing speed. The CSV-810 conveyor belt transports print material at a transport speed of up to 2.0 m/s. An integrated suction system enables controlled transport of light and bulky materials. Incl. dryer, computer and Flexmail control software. In addition, a delivery belt from Schneider with which the products are gently transported into the shed delivery after printing and dry during this time. Feeder FF-309 Robust feeder for transp ...

Gathering machine Horizon VAС-100 С Art.Nr. L858

Jogger Make Polar Model R-2 Year 1999 Max size 72 x 87 cm Details automatic jogger regulated vibration regulated jogging angle stainless steel Airbed Requirers compressed air for the side tables to open/close Available Direct

stations: 16 max. speed sets: 3500 /hmax. paper size: 32 x 47 cmstiching folding unit: SPF-10 Trimmer: FC 20 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Theisen & Bonitz TB Flex B314HP Year 2000 Maximum size 350 x 500 mm Stations 14 automatic stations Pile height 65 cm Finisher TB Flex 303 QSM stitch+fold+trim with 2 Hohner stitching heads Jogger yes, zig-zag jogger Speed up to 3.300 cycles per hour in 1:1 modus and 4.200 in 1:2 modus Details with double sheet control and miss feed control, 1 hand feeding position, can work in modus 1:1 & 1:2 (so either 1x14st or 2x7st)

21 gathering stations S9260 stacker

Bourg booklet maker 2x BST 10- suction feeding towers, with stitching and trimming unit(finishing), Hohner universal stitching heads, under power in printshop. Can ship worldwide. AGR-T folding section PA-T sewing section TR-T front cut-off Rutler format (350 x 520 mm) paper weight: from 70g to 350g

Collating Machine TMF N14 1990 14 Stations Collating Machine Size A3 7 Stations Collating Machine Size A2 Panel Operation and Controls double-sheet and no-sheet control Pre-set counter - Full receiving Tray + Böwe Stitcher-Folder-Trimmer combination + Transport Channel K5 + Stitcher H5 + Folder F5 + Front Edge Trimmer S5 + Delivery Module A5 available: immediately in production location: Germany

Foil wrapping line for mailings with - shrink tunnel Make Dekapacker Model SPK 4-35 Year 1999 basic description this line exists of 4 feeders, a bundle packer with side seal, a shrink tunnel, a U-turn belt and a delivery belt Dekapacker feeders Station 1 non/stop push feeder for i.a. books or other rigid materials Station 2+3+4 non stop rotary vacuum feeders for booklets, signatures, sheets, labels Dekapacker wrapper Model SPK 4-35 Width 90 - 350 mm Height up 120 mm Speed up to 40 cycles per minutes Sealing on 2 or 4 sides Dekapacker shrinking tunnel Width 500 mm Heigth 300 mm Belts Belt 1 U-turn belt Belt 2 Straight belt General information Foil details For PE and shrink foils, 20-60 micron. up to 600 mm Details waste material is winded up Video Click here Available direct

- collator tower contruction - paper thickness: 20 - 250 g/qm - Size min. 105 x 148 mm max 350 x 500 (in 10 Stationen) or 500 x 700 mm in 5 Stationen - jogger - compressor

Reference Num.: 4152Brand: LacondaType: 620Construction year: 1988Available: directlyStatus: Not in productionLocation: Deutschland

2 x VAC-1000 collators – 20 stations (2 x 10) 1 x ST 40 stacker 1 SPF-30S stitching and folding unit 1 HTS-30S three-knife trimmer TB-30 conveyor

Bielomatik-P268 - Zusammentragmaschine/ Collator for web offset - YOC 1967 - Format: 24"-25" - with sheeter P271/34 - built in 1971 - retrofitted - with folding - with 5 satations - with cold gluing - with filing stations - with Nuemmereiwerk - with counter - with many accessories - Location of the machine: Germany - Machine in production - Sale of the machine ex site

Duplo System - 5000 Brochures Manufacturing – Gathering Machine - Year of construction: 2006 - Counter: approx. 7.8 million fold - stapling - 2 x DC-10/60 Gathering Towers from System 5000 - Collator Number of stations: per tower 10 Suction and blowing air collection tower - Duplo – DBM - 500 – Stitching and folding unit with Höhner stapling heads - Duplo – DBM - 500T - Front Trimmer - Duplo – DBM – 500 P – Press System - Duplo – Lifting Unit – Unit LUL – HM – Lift-Lift Unit - Duplo – Belt delivery - With touch control - Format: min.120mm X 148 mm / max. 350mm X 500 mm - Location of the machine: Germany Machine is technically and visually in good condition

Continous Form Collator Micro Pack S 50Serial-No. 92-164 / 1992/51/ mpkc 6 Stationen / Stations Format / Size max. 330 x 12 Zoll umstellbar bis auf 7 Zoll / convertible until 7 inch Standard 240 x 12 Zoll / inch Einlauf breite bis / Infeed width until 55 cm Crimpung alle 2 Zoll mit Ersatzmesser / Crimp every 2 inches with spare blade Online-Video-Inspection by Skype-VideoWe would be very pleased with your visit - more machines on StockAvailable Immediately - Can be inspectOn Stock Emskirchen / Nürnberg - Can be test

3 x gathering towers duplo 10/60i, a ́10 feeder PC Control D - Port Converter (Verb. DKT 200 to DBM-S) Vibrating offset delivery right Ultra Sonic Double Sheet Control LUL- HM handover with manual attachment – station DBMS - F2 (Collective Creasing and Flight Seam Module) 6 Page Envelope - Furnishing DBM-S Stapling Station with DBMi (4 Stitching Heads 2 Hohner Standard, 2 Hohner Ring Eye Stitching Heads DBMS-T Trimmer + DKT 200 Foot, Head Trimming Cut-out device for 6 mm DBMS-LW belt delivery long Requirements separation (kicker)

Reference Num.: 3344Brand: LacondaType: 620Available: directlyStatus: In productionLocation: DeutschlandEquipment:- 7 Stationen- Heft-, Falz-, Schneideaggregat Theisen Bonitz
