33 results

item-No.: 160759374
HERMLE 5 AXIS WITH TNC-530 Control. Year: 2018. 7200 hours on it. Certification Verifications By EMT Hartland Manufacturer: Hermle C600U Build in Gosheim / Germany. Geometrie - Test and Ball Bar Test, Heidenhain – TNC530 CNC Control Machine Travels X 23.622? Y 17.717? Z  17.717? Rapid Traverse X/Y/Z 1,377 IPM 5-Axis Table Style Trunnion Style Table Table Size 11.024? (280mm) Diameter Work Table (Optional you can put Larger table top on the machine) 5th Axis Swivel Range +/- 110.1 Degrees Spind ...
item-No.: 160713715
Tos WHQ 13 CNC Table Type Boring Mill (2012) Specifications Spindle Diameter: 5.1" Main Spindle HP: 55/60 HP Main Spindle RPM: 3000 RPM Spindle Taper: CAT 50 Number of Tool Stations 40 ATC X Axis Travel 78.74" Y Axis Travel 78.74" Z Axis Travel 62.99" W Axis Travel 31.5" Max Table Load Capacity 26,455 lb Equipped With: Heidenhain iTNC 530 CHOV 13-20 Thru Spindle coolant Auxiliary Spindle air  ...
item-No.: 160713714
Tos WHQ 13 CNC Table Type Boring Mill (2012) Specifications Spindle Diameter: 5.1" Main Spindle HP: 55/60 HP Main Spindle RPM: 3000 RPM Spindle Taper: CAT 50 Number of Tool Stations 40 ATC X Axis Travel 78.74" Y Axis Travel 78.74" Z Axis Travel 62.99" W Axis Travel 31.5" Max Table Load Capacity 26,455 lb Equipped With: Heidenhain iTNC 530 CHOV 13-20 Thru Spindle coolant Auxiliary Spindle air  ...
item-No.: 160681698
CNC FANUC 31i-B5 New in 2017 Table size 850×410 mm. Max weight allowed of table 300 kg Rotary table Nikken 5AX-DD200BF2 X/Y/Z travels 700x400x330 mm. Max tool weight 3 kg Max tool length 200 mm Tip distance from the head to the table 250-580 mm Spindle speed 24.000 rpm Rapid feed all axis 54 m/min Taper BT-30 Compressed air consumption 150 L/min, 0.35-0.55 Mpa ATC INCLUDED Positions in ATC 21 Double contact system INCLUDED Internal Coolant 25 Bar INCLUDED Deposit Capacity 250 l INCLUDED Deublin ...
item-No.: 160681697
Manufacturer LAGUN Model GNC 5M Year 2003 CNC HEIDENHAIN TNC-426 Digital Table Table Surface 1.525 x 325 mm T Slots 3x16x80 mm Table weight allowed on table 400 kg. Travels and feeds Longitudinal Traverse X Axis 1.000 mm. Cross Traverse Y Axis 450 mm Vertical Traverse Z Axis 540 mm. Quill Traverse W Axis 150 mm. Controlled axis 4 Rapid Traverse X, Y, Z Axis 5.000 mm/min Max. Working Feed 4.000 mm/min Spindle Taper ISO-40 Turning Speeds 60 – 4.000 rpm Main Motor Power 5.5 / 7,5 kW Head range ...
item-No.: 160465329
GF Mikron 500U VMC, 2020- 5-Axis, HSK, Low Hours, Excellent Condition,Probe Year: 2020 X-axis- 19.68 in (500 mm) Y-axis – 17.71 in (450 mm) Z-axis – 15.74 in (400 mm) B-axis – 65°/+120° C-Axis- 360° endless Spindle drive type- Cartridge Spindle max.- 20,000 RPM Spindle Power at S1-30.8 HP (23kW) Spindle Power at S6-48.2 HP (36 kW) Spindle Torque at S6-88.5 ft. lbs. (120 Nm) Spindle tool interface- HSK-A63 Distance from table top to spindle 5.90 – 21.65 in (150 – 550 mm) Rapid traverse X,Y ...
item-No.: 160455701
DMG DMU-200P 5-Axis CNC Machining Center Year of build 2001. Cat 50 Spindle. 10,000 RPM. High pressure thru tool coolant (40 and 80 bar). High Capacity coolant system. Wash down pistol. Blum laser tool setter. Renishaw part probe. High Capacity 180 pocket tool magazine. Chip Conveyor. Recent new spindle. A nice, clean, well maintained full 5 axis mill with low hours. Under power and ready for inspection.
item-No.: 160416953
Mitsubishi MAF 240/180B CNC Floor Type HBM, New 1980 (Recontrolled in 1999) Condition: Very Good Type of CNC Control: Gidding & Lewis 8000B CNC Control - Recontrolled 1999 Spindle Diameter: 7.08"(180mm) Milling spindle diameter: 9.44"(240mm) Vertical Head Travel, Y-Axis: 169"(4300mm) Horizontal Column Travel, X-Axis: 1200" (30500mm) Headstock Travel, Z-1 Axis: 47.24"(1200mm) Spindle Travel, Z-2 Axis: 47.24" Total Axial Travel: 94.49"(2400mm) Rapid Traverse, X&Y Axes: 315 IPM Rapid traverse, Z, W and U  ...
item-No.: 160213494
Nakamura Tome WT-300 Multi Axis CNC Turning & Milling Center Age : 2007 FEATURES: FANUC 18I-TB CNC CONTROL TWIN 24-STATION TURRETS WITH MILLING TWIN OPPOSED SPINDLES C-AXIS BOTH SPINDLES Y-AXIS UPPER TURRET LNS QL SERVO S3 MAGAZINE BAR FEED CHIP BLASTER HIGH PRESSURE COOLANT SPECIFICATION: MAXIMUM SWING 9.84" MAXIMUM TURNING DIAMETER 10.62" MAXIMUM TURNING LENGTH 30.71" DISTANCE BETWEEN SPINDLES 43.3" BAR CAPACITY 2.5" MAIN SPINDLE: MAIN SPINDLE SPEEDS 45-4500RPM C-AXIS ROTATION 0.001 DEGREE MAI ...
item-No.: 160198002
-
43.500 USD
country-us US
Kasuga Quantum Q-1500V CNC Vertical Machining Center Age : 2000 FEATURES: FANUC 18IM CNC CONTROL 40-STATION AUTOMATIC TOOL CHANGER 16" 4TH-AXIS ROTARY TABLE SPECIFICATIONS: X-AXIS TRAVEL 62" (1575mm) Y-AXIS TRAVEL 34" (864mm) Z-AXIS TRAVEL 32" (813mm) TABLE SIZE 94" x 36" (2388x915mm) TABLE LOADING CAPACITY 5500 lbs.(2500kg) FLOOR TO TABLE 36.4" (925m) TABLE TOP TO SPINDLE END 7.8"-40" SPINDLE SPEEDS 50-6000RPM SPINDLE TAPER CAT 50 SPINDLE MOTOR (2-SPEED) 30 HP RAPIDS(X,Y) 787.4 IPM RAPID Z-AXIS  ...
item-No.: 160095944
Technical Features of this 5 Axis Machining Centers Table Table surface 340 x 300 mm Max weight allowed on table 250 kg T slots 12H8 x 4 Travels Longitudinal Travel X Axis 450 mm. Cross Travel Y Axis 620 mm Vertical Travel Z Axis 500 mm. Range of table A Axis 150º ( +30º-120º) Turning table C Axis 360º continuo Feeds Max. Working Feed (X/Y/Z) 60.000 mm/min Rapid feed (X/Y/Z) 60.000 mm/min Main spindle Taper HSK-A63 Spindle speed range 50 -20000 rpm Main spindle power 22/11 kW Torque 95/28  ...
item-No.: 160095943
Manufacturer IBARMIA Model ZVH55 L3000 Year 2004 CNC HEIDENHAIN TNC-530 Table Surface 3.600 x 850 mm Carrying Load Table 2.000 kg. T slots 7 T slot size 1×18(H8)- 6X18(H12) Distance between T slots 125 mm. Integrated Rotary Table INCLUDED Rotary Table Diameter 800 mm. Maximum Swing Diameter 1.400 mm. Travels (X/Y/Z) 3.000/800/800 mm Titling head range (B Axis) ± 105º Rapid Feed Axis (X, Y, Z) 30 m/min Rapid Feed for B axis 170 rpm Turning Speeds 9.000 mm/min Taper BT-50 Main Motor Power 25 kW  ...
item-No.: 159963717
Gantry type CNC Vertical Machining Center Maker : Dorries Scharmann New : 1993 /2009 CNC retrofitted Model : 100FZG 600/700 CNC Control : Siemens 840D Table size : 6000 x 21000 mm Workpiece length : 22000 mm width : 7000 mm Height : 6000 mm Milling ram stroke : 2000 mm Milling spindle motor : 140 kw Rotating speed : 20 ~2000 rpm Milling ram section : 550 x 460 mm With ATC, 8 AAC as 3 Angle attach, Universal attach, 3 special attach.
item-No.: 159600839
Takang TKV-860-HT CNC Twin Spindle Vertical Turning Center Year 2015 . GENERAL SPECIFICATIONS Max. Cutting Diameter: 800 to 1000mm Max. Swing Diameter: 1000mm Max. Cutting Length: 860mm Spindle Motor (FANUC aP40): (2) 50 HP Alpha P40 2-Speed Gearbox Motors Spindle Speed Range: 10-1500 RPM Spindle Nose: A2-11 Spindle: Spindle Motor (FANUC aP40): (2) 50hp Alpha P40 2-Speed Gearbox Motors Spindle Speed Range: 10 - 1,500rpm Max Chuck Diameter: Installed 31.5" 3- Jaw Hydraulic Chucks Spindle Nose: A2-11  ...
item-No.: 159573478
DMG MORI Model DMC 1035 V ECOLINE VMC, New 2013 Description: Beautiful condition, under power and available for inspection. X- 40.7" Y- 19.9" Z- 20.1" Power - 13 HP RPM - 12,000 RPM ATC - 20 Position Taper - CAT-40 Table-W- 22" Table-L - 47.2" CNC Control - (Mori DMG.) Equipped with: - 12,000 RPM Spindle - High Pressure Coolant - Chip conveyor
item-No.: 159530803
MIGHTY VIPER Model VTL 600LT CNC Vertical Turning Center New: 2016 (Low Hours) Specifications Control: Fanuc 0iTD Table Diameter: 12" (Will accept a larger chuck on if needed) Max. Turning Diameter: 23.6" Max. Turning Height: 15.7" Max. Mass of Workpiece: 1650 Lbs X-Axis Stroke: -1.2" +14.4" Z-Axis Stroke: 16" Number of tool station: 12 Rapid Feedrate (X axis): 945 ipm Rapid Feedrate (Z axis): 197 ipm Table Motor (30 min/Continuous: 40/50 HP Machine Dimensions: 13`8" x 5`3" x 9`10" Equ ...
item-No.: 159428854
DIXI CNC Horizontal MC Year: 2008 Model: DHP50-4X Pallet: Pallet Size (2 Pallets): 19.69" x 19.69" Pallet Indexing: Full 4th Axis Maximum Load On Pallet: 1102 Lbs Travels: X-Axis Travel: 700mm Y-Axis Travel: 700mm Z-Axis Travel: 700mm Spindle: Spindle Speeds (RPM): 12,000 RPM Spindle Taper: HSK A 63 Main Motor (HP): 25 kW Tool Changer: Tool Changer Positions: 220 ATC Machine: Power: 1880 kVA Voltage: 460 / 3 Ph Equipped With: Fanuc 16iMB Control Comes with a lot of new spare pa ...
item-No.: 159412431
CNC controller: SIEMENS 840D Axes X-axis travel mm: 4.000 Y-axis travel mm: 1.500 Z-axis travel mm: 3.500 Worktable Number of pallets: 2 Table dimensions mm: ø1.500 Spindle (Automatic 1ºx1º) Spindle speed rpm: 5.000 Spindle drive power kW: 37 Cooling High-pressure bar: 60 Tool system Tool holder: ISO-50 Tool magazine slots: 2x 40 Equipment Electronic Handwheel Chip conveyor Infrared probe Signal lamp High pressure pump Workarea light Basic machine dimensions / weight Length mm: 9.365 Wi ...
item-No.: 159335224
SNK CMV-100/5 5-Axis CNC Horizontal Machining Center New 2016 - Installed 2017 CNC Control: yes CNC Control: Fanuc 31i-B5 Main Specifications - See Below: See Below Table Size:: 1000mm x 1000mm (39.3 x 39.3 in) Distance from Pallet surface to spindle center: 0-1,300mm (0 -51.1 in) Distance from pallet surface to spindle end (when spindle is in vertical position): 0-1,000 mm (0-39.3 in) Max Table Load: 1,500 kg / table (3,300 lbs.) Spindle:: See Below Spindle Speed: 40 to 8,000 RPM Spindle Nos ...
item-No.: 159294320
BRAND: SACEM YEAR: 1995 MODEL: Racem-603 PRODUCTION HOURS: APPLICATION TYPE: BORING LOCATION: SPAIN MACHINE TYPE: BORING MACHINE AVAILABILITY: IMMEDIATELY Technical Information CONTROL UNIT BRAND: NUMMODEL: 1060 MAIN DRIVE SPINDLE SPEED RANGE: 4-2500 1/MINNUMBER OF AXIS: 4 MOVEMENT X-AXIS MOVEMENT: 5000 MMY-AXIS MOVEMENT: 2500 MMZ-AXIS MOVEMENT: 2000 MM WORKPIECE WORKPIECE WEIGHT: 35000 KG MEDIA MAIN ELECTRONIC CONNECTION: 220-380V/ 50 HZ ADDITIONAL EQUIPMENT -  ...
item-No.: 159269068
SNK BP 130 3.5 CNC HORIZONTAL BORING MILL Age: 2012 FEATURES: FANUC 31I-B5 5-AXIS CNC CONTROL 60 POSITION AUTOMATIC TOOL CHANGER THREAD CUTTING RIGID TAPPING HELICAL INTERPOLATION BUILT-IN "B" AXIS ROTARY TABLE 90 DEGREE POSITIVE SHOT PIN AIR BLOW DEVICE COOLANT THRU SPINDLE (2) ITS CH FACING HEADS (4) ITS CONTROLLED BORING BARS CAPACITY: SPINDLE DIAMETER 5.12 " (130mm) SPINDLE TAPER CAT-50 VERTICAL HEAD TRAVEL, Y-AXIS 98.42 " (2500mm) TABLE TRAVEL, X-AXIS 137.80 " (3500mm) COLUMN INFE ...
item-No.: 159185593
UNION FLOOR TYPE HORIZONTAL BORING MILL BFP 130/6 Search Note: In 1989 Upgraded Ball screws & Fanuc Servo Drive to the Head Vertical Travel & the Column Transverse Travel. Currently we believe there are 2 Fanuc control cards that are NOT functional and thus the machine control does not boot up and that makes the machine not operational. When the machine did work it worked fine. This is NOT a cnc machine. It still uses the manual pendant for operational control. Column Longitudinal Travel: 18' 3"(5500mm), Rack & ...
item-No.: 159079912
Hermle C650 5-Axis VMC Control:Heidenhein TNC 640i Condition: Excellent Under Power: Yes Specifications: X-Axis: 1050 mm Y-Axis: 900 mm Z-Axis: 600 mm Rapid Linear Traverse Rate (X / Y / Z): 35 / 35 / 35 m/min Max. Workpiece Diameter: 900 mm Max. Workpiece Height: 600 mm Spindle Speed: 18,000 RPM Spindle Motor: 42 kW Spindle Taper: HSK-63 Tool Magazine: 42 ATC Equipped With: Heidenhain TNC 640 Control Dynamc Efficiency (ACC, AFC, Trochoidal Milling) Dynamic Precision (CTC, AVD, LAC) Dimensions  ...
item-No.: 159007332
MAKINO VIP+D500 Control: FANUC Professional 5 Ejes X mm: 550 Y mm: 1000 Z mm: 500 Grado de recorrido del eje A: 150 (+30 - 120º) Grado de recorrido del eje C: 360 (rotación continua) Avance rápida m / min: X: 48 Avance rápido m / min: Y, Z: 50 Avance rápido m / min: A, C: 48 Avance mm / min: X: 1 - 32.000 Avance mm / min: Y, Z: 1 - 40.000 Avance mm / min: A, C: 1 - 18.000 Mesa de trabajo Diámetro de la mesa giratoria mm: 500 Tamaño máximo de la pieza de trabajo (D x H) mm: 650 x 500 (con res ...
item-No.: 158965837
Control: FANUC Professional 5 Ejes X mm: 550 Y mm: 1000 Z mm: 500 Grado de recorrido del eje A: 150 (+30 - 120º) Grado de recorrido del eje C: 360 (rotación continua) Avance rápida m / min: X: 48 Avance rápido m / min: Y, Z: 50 Avance rápido m / min: A, C: 48 Avance mm / min: X: 1 - 32.000 Avance mm / min: Y, Z: 1 - 40.000 Avance mm / min: A, C: 1 - 18.000 Mesa de trabajo Diámetro de la mesa giratoria mm: 500 Tamaño máximo de la pieza de trabajo (D x H) mm: 650 x 500 (con restricciones)  ...
item-No.: 158637385
Kramatorsk Model KJ1910 serial number 1913 Swing Over Bed: 1600mm Maximum Workpiece Length: 6300mm Maximum Drilling Diameter: 991mm Spindle power: 125.00kW Spindle Speed: 1 - 320 RPM Infinitely Variable power Existing Additional Chuck workholding range: 200 - 1250mm diameter, workpiece weight capacity using two open roll supports: 60,000kg, size range in closed backrest: 200 - 800mm, size range in open backrest: 630 - 1380mm, pressure head speed range: .125 - 500 infinitely variable, pressure head spindl ...
item-No.: 158482504
ravel of X 1150 mm, Y 710 mm, Z 710 mm, spindle speed from 20 up to 12000 rpm, tool holder SK 40 (DIN 69871), with C- and D-axis, clamping surface 795 x 1500 mm, diameter 800 mm, 11 T-slots, feed rate of X Y Z from 0 up to 30000 mm/min, rapid traverse of X Y Z 30000 mm/min, set-up operation of X Y Z from 0 up to 2000 m (or mm)/min, with HEIDENHAIN ITNC 530 CNC control system, with chip conveyor, coolant unit, internal coolant supply, stand platform, incl. tool holders which are mounted at tool turret as well as too ...
item-No.: 158438139
-
8.000 €
country-es ES
max. torque 800 Nm, speed range 10 to 6300 rpm, tool holder SK 40 (DIN 69871), feed force 12000 N, ejection force 3000 N, travel X-axis 600 mm, travel Y-axis 600 mm, travel Z-axis 450 mm, feed speed (X and Y) 2 to 10000 mm/min, feed speed (Z-axis) 2 to 8000 mm/min., rapid traverse (X and Y-axis) 10 m/min, rapid traverse (Z axis) 8 m/min., clamping surface 530 x 900 mm, number of T-slots 8, T-slot width 14 H7, T-slot distance 63 mm, max. workpiece weight 400 kg, with 22-fold drum magazine, max. tool diameter with fu ...
item-No.: 157604228
Technical Features of this 5 Axis Machining Centers Manufacturer QUASER Model MV204IIU / 10 Year 12/2002 CNC HEIDENHAIN ITNC530 3 Working Tables / Pallets Table 1 Size Ø280 mm. Table 2 Size Ø 500 mm. Table 3 Size 600×400 mm. Max weight allowed on table 265 kg Min-max distance over table 150-760 mm. Axis Longitudinal Traverse (X Axis) 700 mm Cross Traverse (Y Axis 590 mm Vertical Traverse (Z Axis) 480 mm Titling spindle head range (A Axis) ±110º A Axis positioning 0.001º Table turning (C Axi ...
item-No.: 157216863
Technical Features of this Second Hand VMC Manufacturer: MAZAK Model: VTC 200B Year 1.999 CNC MAZATROL FUSIÓN 640 M Table Surface 1.460 X 460 mm Max Weight Allowed on Table 800 Kg. Longitudinal Travel (X- Axis) 1.120 mm. Transversal Travel (Y-Axis) 510 mm Vertical Travel (Z- Axis) 510 mm. Min-Max. Distance Table to Nose Head 180 – 690 mm. Rapid Traverse (X,Y,Z Axis) 36.000 mm/min Max. Working Feed 20.000 mm/min Taper CAT-40 Spindle Speeds 10.000 rpm. Engine Power 15 Kw. Automatic Tool Charger I ...
