retificadoras usadas para venda (2,211)

Moedor cilíndrico (ROLL) CNC Minakuchi NWT-300, fuso I.D., Fanuc O-GC, 30HP, Novo 1990 Capacidade total da máquina: 32inch x 120inch Balanço: 32inch Distância entre centros: 120inch Balanço máximo sobre a mesa: 32inch Diâmetro máximo de moagem: 30inch Peso máximo da peça de trabalho: 20000 LBS. Estimativa em 32inch x 120inch Rebolo: 24inch x 1.968inch x 10inch Largura máxima da roda de moagem: 1.968inch Velocidade do eixo: 1410/1530 RPM Motor da roda do eixo: 30 HP Peso da máquina: 30000 Lbs. Aproximadamente Equipado com: Controle: Fanuc Series O-GC (os parâmetros precisam ser recarregados) Roda de mão remota Fanuc Funções de controle da máquina: Interruptores On/Off de refrigerante, MODO: Off/Auto/Jog/Handle/Zero, Over Ride: 0-150%, Botões: PRC, HIX, Spindle Inching, OTR on/off Switch, Cycle Start, Spindle Off, RT, Return, Feed Hold, Grind Off, ZRN ...

Moedor cilíndrico de naxos CNC Ano: 1987/2013 Max. Balanço: 630mm Max. Cabeça de trabalho à distância face ao tailstock face: 4850mm Máx. viagem para eixo Z: 5000mm Máx. Distância de moagem para a roda principal: 4520mm X eixo infeed viajar para ambos os headstocks: 720mm Aproximadamente, peso entre centros: 4000kg Requisitos de energia: 460/3/60 Esta máquina foi completamente refabricada às novas especificações em 2013 e instalada em 2014. Foi despojado até à fundição nua, cabeças de mesa/base/roda/cabeça de trabalho e cauda e os segundos eixos z foram ajustados e rescrapados. Foram adicionados novos armários elétricos com novas cablagens à máquina e novos componentes, linhas hidráulicas, linhas de ar e novos porta-cabos. Novos motores Marathon 60HP para ambas as cabeças de roda moedora. (As unidades no armário estão definidas para 40 Cv) Os eixos  ...

WALDRICH SEIGEN WST IV H80 X 12000 MOEDORA DE ROLOS ANO: 1981 / INSTALADO 1982 DIÂMETRO MÁXIMO DE MOAGEM: 78" (1981,2 mm) COM RODA DE 32" (812,8 mm) DE DIÂMETRO DISTÂNCIA ENTRE CENTROS: 472,40" (12000mm) PESO MÁXIMO DA PEÇA DE TRABALHO: 176000 lbs. (80t) RODA OD MÁXIMO: 32,00" LARGURA DA RODA MÁXIMA: 4.00" ID DA RODA: 12.00" POTÊNCIA DO EIXO DA RODA: 27 - 59/59 CV ARMÁRIO DE RODAS: ROLO MONTADO NA CAMA VIAGEM DE CABEÇA DE RODA: 25.60" VIAGEM À MESA: (VIAGEM DE CABEÇA DE RODA) 488,40"( 12405 mm) VELOCIDADE DA MESA: (VELOCIDADE DA CABEÇA DE RODA) 157,5 in/min (4000 mm/min) VELOCIDADE DO FUSO DA RODA: 450 - 1800 RPM Variável Infinita POTÊNCIA DE CABEÇA DE TRABALHO: 1.9 - 59/59 CV VELOCIDADE DA CABEÇA DE TRABALHO: .5 - 300 RPM CAMINHOS: FERRO FUNDIDO HIDROSTÁTICO COMPLETO TRANSPORTADOR DE LAMAS: NENHUM COOLANT: SIM SISTEMA DE FILTRAção: COMBINA ...

grinding length:1250 mmgrinding width:400 mmworkpiece height:550 mmworkpiece weight:750 kgtable-size:1720 x 400 mmmagnetic clamping plate:1250 x 400 mmdist. center of grinding spindle - table:750 mmturning speed range - grinding wheel:3000 U/minLength movement of the table:1300 mmgrinding wheel size:Ø 400 x 50 x 127 mmswitchgear cabinet:inkl. hydraulic power unit:inkl. coolant:inkl. voltage:380 Vtable load:max. 1100 total power requirement:13,8 kWweight of the machine ca.:6000 kgdimensions of the machine ca.:5000 x 3400 x 2400 mmDocuments:inkl.

internal diameter:315 mmgrinding depth:315 mmswing diameter:420 mmnumber of spindle speeds:32 - 360 U-minwheel box:-drehzahl 100 - 8000 U/minface diameter:500 mmtotal power requirement:12 kWweight of the machine ca.:5900 kgdimensions of the machine ca.:3400 x 1750 x 2000 mm

total power requirement:10,5 kWweight of the machine ca.:4800 kgdimensions of the machine ca.:3000 x 2100 x 2000 mmcentre distance:1200 mmHeight of centres:200 mmgrinding-table stroke max.:X -Achse 1000 mmtable-size:2060 x350 mmz-axis:Querhub 250 mmFeed speed:0,005 - 5 m/min.grinding head - swivable:360 °taper ISO:50 control:Sinumerik System 8 Documents:vorhanden

grinding length:1000 mmgrinding width:250 mmworkpiece height:400 mmtotal power requirement:12 kWweight of the machine ca.:3,8 tdimensions of the machine ca.:3.300 x 1.800 x 2.300 mmhydraulic power unit:400 x1000 x 1500 mmcontrol cabinet:2 Stück, 1000 x 1400 x 1500 mm

grinding length:150 mmtotal power requirement:3 x 380 /220 Vweight of the machine ca.:2100 kgdimensions of the machine ca.:1200 x 1700 x 2000 mmgrinding wheel diameter:280 - 350 mmgrinding wheel width max.:20 mmworkpiece diameter:65 - 120 mmworkpiece turning speeds:1,5 -20 U/minDocuments:vorhanden

working width:880 mmworkpiece height:1- 70 mmwork height max.:1000 mmFeed speed:4- 8 m/min.voltage:50 Hz, 400 Vweight of the machine ca.:2.800 kgdimensions of the machine ca.:2500 x 1715 x1675 mmwidth:min. 350 mmSanding cylinder diameter:420 mmelectr. connected load:20 KWRequired air-pressure:1 x R3/ 8 " pressure:5 bartank:des Bandfilter ca.200 lautomatic magnetic filter unit:vorhanden grinding tools:1540 x 900 mmaccessories::9 Bänder Documents:vorhanden

grinding length:1370 mmgrinding width:560 mmworkpiece height:800 mmtotal power requirement:50 kWdimensions of the machine ca.:9 mABA Z&B 2000, profile grinding machine with swivel dresser Mounting fixtures: magnet, dividing head E-axis dresser B-axis dividing head

total power requirement:12 kWweight of the machine ca.:4,6 t

total power requirement:16,5 kWweight of the machine ca.:3,8 t

total power requirement:380V, 50Hz, 7,9A kWweight of the machine ca.:1 tdimensions of the machine ca.:4 x 3 m

grinding length:600 mmgrinding width:200 mmtotal power requirement:5 kWweight of the machine ca.:1,4 tdimensions of the machine ca.:3 x 3 m

grinding diameter:4000 mmcentre height:310 mmweight of the machine ca.:17 tdimensions of the machine ca.:10.5 x 3.6 x 1,9 m

grinding wheel diameter:300 mmvoltage:380 Vtotal power requirement:1,5 kWweight of the machine ca.:310 kgdimensions of the machine ca.:1100x900x1250 mm

grinding length:1500 mmweight of the machine ca.:12 tKarstens EMAG H310 Universal Grinding MachineYear of manufacture: 2004Center distance: 1500 mmCenter height: 325 mmReinforced workpiece spindle, load capacity up to 250 kgDriven C-axis for polygon, thread, and eccentric grinding.3 individually mounted grinding spindles.Siemens 840D control system

weight of the machine ca.:6,5 t3 identical machines available from OEM productionThe Junker Jucam 1S 51 is designed for grinding bearings and camshaft bushings (exhaust and intake).Parts are automatically fed and removed via an external loading cell.

grinding diameter max.:400 mmmax. width of grinding wheel:180 mmgrinding range:2-100 mmtotal power requirement:24 kWweight of the machine ca.:3,2 tOut of valve production

grinding length:1500 mmgrinding width:700 mmworkpiece height:580 mmtable load capacity:2380 kptable speed -stepless-:5 - 35 m/mingrinding wheel dia. x width:500 x 100 x 203 mmgrinding wheel motor:18 kWspeeds::stufenlos elektronisch total power requirement:35 kWweight of the machine ca.:12 tdimensions of the machine ca.:5,3 x 2,9 x 3,8 (3,18) msurface grinding machine,paper-filter,DRO 3 axis,automatic infeed,el.handwheel,full cabin

grinding diameter:250 mmgrinding length:2710 mmmax. module: min. module: total power requirement:45 kWweight of the machine ca.:15 tspace required L x W X H:7,1 x 4,7 x2,7 mmax. wheel dia.:450 mmSpindle drives Arena SiemensFor Worm grinding we have not module, but pitch. Pitch is freely programmable from 0.001 to big value i.e. 500mm

grinding height:-- mmgrinding width:220 mmgrinding wheel diameter:762 mmtotal power requirement:90 kWweight of the machine ca.:13 tgrinding spindle 1 drive::37 kWgrinding spindle 2 drive::37 kWGrinding machine for pre-grinding the connecting rodWith 2 replacement spindle motors

x-travel:400 mmy-travel:250 mmworkpiece height:500 mmgrinding diameter:220 mmtable surface area:600 x 320 mmthroat:310 mmrange of angles:12 °grinding wheel stroke - vertical:110 mmstroke speeds:0 - 6 m/mingrinding spindle speed:bis 50000 U/minperipheral speed:max. 35 m/seccapacity:ca. 7 kVApower capacity:6 kWweight of the machine ca.:2 tdimensions of the machine ca.:3 x 3 x 3 mrotary table d = 300 mmfrequency changerTexte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht.Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt.Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt.Copyright © 2005-2024, Josef Weber. All rights reserved.

grinding diameter:600 mmgrinding length:3000 mmcentre height:300 mmweight of the machine ca.:11,8 tdimensions of the machine ca.:7100x2300 mmspindle turning speed range:14 - 220 U/mingrinding wheel diameter:650 mmgrinding wheel flange for width 25-40 mm:3 Stk.open tailstocks:3 Stk.chuck:Ø310 mmfixed steady:320 mmDistance between center: 3000 mm.Height of centres: 300 mm.Spindle speed: (n°12) 14 - 220 RpmMax grinding diameter: 600 mm.Stroke the wheelhead:(rapid) 50 mm.Stroke the wheelhead:(rapid+ micrometrical): 1 5 500 m mmm. .Max grinding wheel diameter: 650 mm.Max tilt table: 3° 30'Total absorbed power: 27,7 HpDimension: 7100x2300 mm.Weight approx: 11800 Kg.

grinding diameter:600 mmgrinding length:3000 mmcentre height:315 mmworkpiece weight max.:3000 kgwork piece spindle speed:8 - 120 U/mingrinding wheel motor:25 kWgrinding wheel speed:45 m/secgrinding wheel width x diameter:750 x 80 mmtable speeds:30 - 4500 mm/minfeeds of grinding head:0 - 5 mm/mintable swivelabel +/-:7,5 °total power requirement:55 kVAweight of the machine ca.:18 tdimensions of the machine ca.:11,5 x 4 x 2,2 m- Internal grinding device- taper grinding up to 10,1° based on diameter- automatic grinding cycle- grinding wheels and flanges- dressing device- coolant attachment- dust exhauster, various steady rests

workpiece diameter:5-125 mmgrinding depth:50-1000 mmclamping length:1000 mmtotal power requirement:1.9 KVAweight of the machine ca.:630 kgmax. workpiece weight:100 kgCenter Hole Grinding Machine.Workpiece must be rotated by machine during grinding

grinding length:600 mmgrinding width:300 mmworkpiece height:450 mmtotal power requirement:8 kWweight of the machine ca.:2,2 tdimensions of the machine ca.:2,8 x 3,0 x 2,0 mgrinding spindle speed:1440 / 2905 U/minwith magnetic plate 600 x 200 mmautom. vertical feed coolant attachmentTexte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht.Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt.Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt.Copyright © 2005-2024, Josef Weber. All rights reserved.

grinding length:450 mmgrinding width:250 mmworkpiece height:280 mmTable area:760 x 250 mmgrinding spindle drive:2,5 kWgrinding wheel dia. x width:250x 25 mmgrinding spindle speed:1430/2900 U/minway of grinding spindle saddle, vertical:400 mmtotal power requirement:4,5 kWweight of the machine ca.:1,8 tdimensions of the machine ca.:1,8 x 1,4 x 2,0 mMachine equiped with magnetic plate- dresser
