Categoria 207: espalhadores de cola

BLACK BROTHERS 56 working capacity top/bott

Black Brothers top and bottom glue spreader- 56" working capacity- Top section: rubber coated application roll(composite grooving) and chrome doctor roll Bottom section: rubber coated application roll(composite grooving) and chrome doctor roll Complete with; push button magnetic starter and safety guards 220 Voltage

BRANDT OPTIMAT KTD 72

Edgebander for Shaped Pieces

Weight approx.: 300 kgDimensions (l x w x h) approx.: 2100 x 1200 x 1100 mmDescription: ? Edgebander for shaped pieces, contour edgebander ? Serial number 0-260-05-1197 ? Total installed power 3 kw ? Useful table dimensions 1180 x 300 mm ? Edge thickness: min. 0.5 mm - max. 3 mm ? Worpiece thickness: min 10 mm - max. 55 mm ? Internal minimum edging radius 25 mm ? With power feeder ? Feed speeds: 4 m/min and 9 m/min ? With shear

BLACK BROTHERS top and bottom glue spreader

Glue application equipment

Black Brothers top and bottom glue spreader- 50"working capacity- Top section: rubber coated application roll(composite grooving) chrome doctor roll Bottom section: rubber coated application roll(composite grooving) chrome doctor roll Complete with; push button magnetic starter and safety guards 220 Voltage

EGURKO ORTZA PDA 48 1

Double End Tenoner

Weight approx.: 5000 kgDimensions (l x w x h) approx.: 6700 x 2400 x 2100 mmDescription: ? Double end tenoner ? Serial number 83724.00 ? Total installed power approx. 40 kw ? Max. working width approx. 3500 mm ? Max. workpiece thickness approx. 160 mm ? Chain length approx. 2400 mm ? Machine equipped identically on both sides with 3 aggregates on each side: ? 1 - Scoring unit: depth, height and angle adjustable, motor 1.10 kw-3000/6000 rpm ? 2 - Hogging unit: depth, height and angle adjustable, motor 5.50 kw-3000/6 ...

STEFANI SOLUTION

Edgebander

Weight approx.: 3200 kgDimensions (l x w x h) approx.: 5800 x 1500 x 2000 mmDescription: ? Edgebander, edge banding machine ? Serial number AH/004688 ? Edge thickness in strips from 0.3 up to 22 mm ? Edge thickness in roll from 0.3 up to 3 mm ? Worpiece thickness from 10 mm up to 60 mm ? Minimum workpiece lenght 135 mm ? Minimum workpiece width 90 mm ? Extendable support extension from 0 to 1000 mm ? Adjustable feed speed from 10 m/min up to 25 m/min ? Control PC Office ? Edge magazine for 1 edge roller ? Gluing un ...

SCM CONTURA

Edgebander for Shaped Pieces

Weight approx.: 250 kgDimensions (l x w x h) approx.: 1760 x 1000 x 1400 mmDescription: ? Edgebander for shaped pieces, contour edgebander ? Serial number AH/101148 ? Total installed power 6.30 kw ? Useful table dimensions 900 x 380 mm ? Edge thickness: min. 0.5 mm - max. 3 mm ? Worpiece thickness: min 12 mm - max. 60 mm ? Minimum internal edging radius 30 mm ? With power feeder ? Variable feed speeds from 2 m/min up to 10 m/min ? With shear ? Heater for PVC edges

VIRUTEX EB 35

Edgebander for Preglued Edges

Weight approx.: 140 kgDimensions (l x w x h) approx.: 1800 x 1070 x 1350 mmDescription: ? Edgebander for preglued edges ? Serial number 1126 ? 220 V, total power 4 kw ? Edge thickness from 1 mm up to 3 mm ? Worpiece thickness: min 13 mm - max. 50 mm ? Workpiece lenght min 110 mm ? Workpiece width min. 102 mm ? Adjustable temperature from 0° C up to 500° C ? Automatic feed of the edge ? Feed speed approx. 4 m/min ? Snipping unit ? Top and bottom trimming unit

HOMAG OPTIMAT KL 74 A 3 S 2

Edgebander

Weight approx.: 3500 kgDimensions (l x w x h) approx.: 6200 x 1500 x 2000 mmDescription: ? Edgebander, edge banding machine ? Serial number 0-200-13-7690 ? Edge thickness in roll from 0.3 up to 3 mm ? Worpiece thickness from 12 mm up to 60 mm ? Minimum workpiece lenght 150 mm ? Minimum workpiece width 55 mm ? Adjustable feed speed from 18 m/min up to 24 m/min ? Feed motor 1.50 Kw-1395 rpm ? Control HOMATIC NC21 ? Joint trimming unit, 2 x motors ? Edge magazine for 2 edge rollers ? Gluing unit HOMAG A3 ? Pressure gr ...

COMEVA PICCOLINA 110

Edgebander for Shaped Pieces

Weight approx.: 320 kgDimensions (l x w x h) approx.: 1220 x 1380 x 1780 mmDescription: ? Edgebander for shaped pieces, contour edgebander ? Serial number M09-007 ? Total installed power 2.40 kw ? Useful table dimensions 1200 x 250 mm ? Tilting table ? Edge thickness: min. 0.4 mm - max. 3 mm ? Worpiece thickness: min 10 mm - max. 110 mm ? With power feeder ? Variable feed speeds from 1 m/min up to 18 m/min ? With shear ? Feeder STEFF 2034 with 3 rollers

HOMAG OPTIMAT KAR 310/10/A20/S2

Edgebander

serial number: 0-200-13-0434 Weight approx.: 10000 kgcontrol: Power Control PC22 Dimensions (l x w x h) approx.: 16300 x 5500 x 3600 mmfeed: 18 m/minedge thickness: 0,3 - 20 mmworkpiece thickness: 12 - 60 mmjoint trimming unit: 52 BASIC (2 x 3 kw) gluing unit: A20 snipping unit: HL81 (2 x 0,22 kw) rough trimming unit: 2 x 1,50 kw fine trimming unit: MF21 (2 x 0,55 kw) profile trimming unit: FF12 (4 x 0,40 kw) universal trimming unit: UF11 edge sanding unit: 6 units total power approx: 42 KWedge magazine with: 1 -fo ...

HOMAG OPTIMAT KAL 210/5/A3/S2

Edgebander

Weight approx.: 3500 kgDimensions (l x w x h) approx.: 6200 x 2100 x 1800 mmDescription: Single Side Edge bander. CNC HOMAG PC22. Input adjustable Pre-milling Unit (vertical joint Trimmers): 2kW. Glue Pur unit. Corner Rounding unit (Contour Trimming) 4 motors. Profile edge scraping unit. Cleaning group with fluids. Movil touchscreen. Edge (tape) thickness in rolls min/max: 0,3-3 m. Edges thickness in stips/lipping min/max 0,4 -20 mm. Panels Thickness min/max 8-60 mm. Feeding speed m/min 18-25

BIESSE ROXYL 5.5

Edgebander with Return System

Weight approx.: 4500 kgDimensions (l x w x h) approx.: 9000 x 2400 x 2200 mmDescription: ? Edgebander with return system, edge banding machine with return system ? Serial number 30157 ? Edge thickness in strips from 0.4 up to 22 mm ? Edge thickness in roll from 0.4 up to 3 mm ? Worpiece thickness from 10 mm up to 65 mm ? Minimum workpiece lenght 140 mm ? Minimum workpiece width 50 mm ? Feed speed 25 m/min ? Numeric control with 10 touch screen ? Spraying unit ADZ-700 ? Joint trimming unit FI-502, 2 x motor 3.50 Kw  ...

EGURKO CU 3

Edgebander

Weight approx.: 3000 kgDimensions (l x w x h) approx.: 6200 x 1300 x 1450 mmDescription: Serial number 638023 Maximum worpiece thickness approx. 70 mm Minimum workpiece width 110 mm Adjustable feed speed from 10 m/min up to 40 m/min Edge magazine for 1 edge roller Gluing unit Pressure group with (1+3) rollers Snipping unit Rough trimming unit Fine trimming unit Milling unit Sander unit with width belt 120 mm

OLIMPIC NOVA

Edgebander

Weight approx.: 3500 kgDimensions (l x w x h) approx.: 5450 x 1000 x 1500 mmDescription: Edgebander, edge banding machine Edge thickness from 0.4 up to 30 mm Worpiece thickness from 10 mm up to 60 mm Feed motor 1.50 Kw Edge magazine for 1 edge roller Gluing unit Pressure group with (1+3) rollers Snipping unit, 2 motors Fine trimming unit, 2 x motor 2.20 kw-12000 rpm Profile scraper unit

HOLZ-HER 1356

Edgebander

Weight approx.: 700 kgDimensions (l x w x h) approx.: 2980 x 970 x 1380 mmDescription: Serial number 1795 Total power approx. 10 kW Edge thickness from 0.4 up to 25 mm Maximum worpiece thickness 60 mm 3 feed speeds: 10 - 13 - 16 m/min Feed motor 0.75 kW Gluing unit Pressure group with (1+4) rollers Rough trimming unit

SCM K 203E

Edgebander

Weight approx.: 830 kgDimensions (l x w x h) approx.: 3200 x 1300 x 1800 mmDescription: Gluing unit, automatic loading for strips and coiled edges, cutter for coiled edges: max thickness 3x45 mm, 3 edge pressure rollers: the first roller is powered, frictioned and teflon-coated. End cutting unit with two independent motors sliding on prismatic guides can be tited from 0-15 degrees. Trimming unit tiltable between 0-10 degrees including vertical disc copiers and horizintal pad copiers, available with 2-positions pneu ...
