mandriladoras e centros de usinagem usadas para venda (3,234)

x-travel: 730 mmy-travel: 730 mmz-travel: 850 mmcontrol: MSX 701 IV MAPPS 4Main spindle:: max. spindle speed: 14.000 min/-1power capacity - milling spindle: 22 / 18,5 kWtool taper: HSK A-63 distance ground floor - table top edge: 1.200 mmdistance Spindlenose and center of table: 100 - 950 mmpallet changer:: numbers of pallets: 2 size of pallet: 500 x 500 mmmax. workpiece weight: 500 kgmax. workpiecediameter: 800 mmmax. workpiece height: 1.000 mmchange time of pallets: 7 secIndexing-time: 1,57 secB-axis (table): 0,001 °Tool-Presetter:: number of toolpositions: 120 pos.tool taper: HSK A-63 max. tool diameter: 70 mmmax. tool-dia with free toolbox: 140 mmmax. tool length: 500 mmmax. tool weight: 12 kgfeeds:: rapid traverse: 50 m/minfeed speeds: max. 50.000 mm/minTipp feed: 0 - 1.260 mm/mintotal power requirement: 51 kVAweight of the machine ca.: 12 tdimensions of the machine ca.: 5,5 x ...

x-travel: 762 mmy-travel: 460 mmz-travel: 460 mmtable surface area: 1.000 x 460 mmcontrol: Okuma OSP 20 M rapid traverse: 40/40/32 m/mintable load: 0,7 tturning speed range: 12000 U/minpower capacity - milling spindle: 22/18,5 kWmax. torque on the spindle: 198 Nmno. of tools in the magazine: 32 Stückinternal coolant system feed: 20/43 bartool taper: BT 40 weight of the machine ca.: 6,8 tdimensions: 2.22 x 2,9 x 2,75 mCNC- vertical machining centre with internal coolantFirst installation 2014- coolant through the spindel 15 bar, 20 ltr/min- air throug the spindle- chip conveyor- signal lamp- Dual tool change arm- external electric hand weel- tool lenght measuring and toolbreak detection- filter system- X- axis in gantry style- spindle oil cooler- thermal compensation spindel and bed- USB and Ethernet port- Hi-Cut Pro high speed control- 100 Zero offsets- thread millingThe data for this a ...

• CNC machining centre • Serial number 0-250-06-1632 • Total installed power approx, 18 KW • Useful working area approx, 2750 x 1000 mm • Travelling way X-axis: 3455 mm, Y-axis: 1480 mm, Z-axis: 260 mm • Maximum travel speed in the axes direction x-y-z: 80-60-20 m/min • Tool magazine with 8 positions •  Electrospindle: power 7,50 KW-max, 24000 rpm, automatic tool change, for HSK F63 tool holder, liquid cooled • Milling / saw group with 1,50 KW motor • Saw unit to groove • Vertical drilling spindles in X-axis direction: 11 • Vertical drilling spindles in Y-axis direction: 8 • Horizontal drilling spindles in X-axis direction: 3 + 3 • NUM 1040 numerical control • Software Windows 95 / HOMAG WOODWOP • 6 consoles with 2 vacuum suction cups each • 6 lifting modules for heavy workpieces • BECKER KVT 3,100 vacuum pump with capacity 100 m³/h • Operatin ...

• Serial number AA1/013786 • Working table dimensions 3050 x 1200 mm • Panel passage height 280 mm • Travelling way X-axis: 4420 mm, Y-axis: 1720 mm, Z-axis: 400 mm • Maximum travel speed in the axes direction x-y-z: 105-80-25 m/min • Tool magazine with 12 positions •  Electrospindle: power 11 kW, max, 18000 rpm, automatic tool change, for HSK F63 tool holder, liquid cooled • Saw unit with 2,20 kW motor • Vertical drilling spindles in X-axis direction: 5 • 2 heads for horizontal drills • NUM POWER 1040 numerical control • Software Windows / Xilog Plus • RIETSCHLE VTB 250 vacuum pump with capacity 250 m³/h • Operating conditions of this machine: unchecked. • This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A7-50834-34

CNC control: Heidenhain TNC 530Machine 5 simultaneous axesStrokes: X = 730 mm, Y = 560 mm, Z = 560 mmSpindle speed: up to 12,000 rpmCone: SK40Feeds: 20 – 20,000 mm/minFast feeds: 30 m/minTable: 1000 x 600 mmMax load table: 800 kgTool changer: 24 / 30 positionsMachine hours≈ 31,481 hSpindle hours≈ 25,087 h Lots sold as is, unchecked, without tools or tool holders. Auction-ID: A1-50714-4011

Year: 1995Serial No.: 488-11Type / Function: 4-axis vertical CNC machining centerConfiguration: 2 pallets, 2 × 4th axis Peiseler RT 160Numerical control: SIEMENSSpindle: New spindle replaced in 2021Included equipment: KNOLL filter unit, chip conveyorWeight: 4000 kg Auction-ID: A1-50714-4044

Table size: 500x500 The machines are generally offered without documentation. If documents are available, they are attached to the respective machine. Auction-ID: A7-50868-10

ul>CNC control: Heidenhain TNC 530 5-axis(B-axis head ±90°, C-axis table 360°)Strokes: X = 1060 mm, Y = 710 mm, Z = 710 mmSpindle speed: 20 – 12,000 rpmSpindle power: 15 kWCone: ISO40Fast feeds: 30 m/minTable: 1500 x 795 mmMax table load: 900 kgTool magazine: 32 positionsSpindle centre coolant + refrigeration unit + mist suction Lots sold as is, unchecked, without tools or tool holders. Auction-ID: A1-50714-4006

CNC Control: SIEMENS 810 DX/Y/Z axis strokes: 1020 × 510 × 510 mmTable dimensions: 1200 × 500 mmPermissible load on table: 800 kgMax. spindle speed: 10,000 rpmSpindle power: 10 kWSpindle taper: ISO 40Tool changer: 20 positionsWeight (kg): 5800Year & Manufacturer: 2000 – HURON Auction-ID: A1-50714-4024

CNC Control: Siemens 828D ShopMillCourses X/Y/Z: 1220 / 600 / 610 mmTotal power: 10 / 14 kWSpindle speed: 8,000 rpmSpindle taper: SK40Tool magazine: 20 positionsEquipment: Chip conveyor, coolant, technical documentationPower supply: 400 V – 50 HzManufacturer: HuronYear: 2012Serial No.: M02741Estimated dimensions (mm): 3500 x 2800 x 3200Weight (kg): 10000 Auction-ID: A1-50714-4005

CNC Control: FANUC series O-MAxis strokes: X 600 mm / Y 420 mm / Z 450 mmTable: 750 × 400 mmSpindle speed: 6000 rpmSpindle power: 13 kWSpindle taper: ISO 40Tool changer: 30 positionsIncluded equipment: NIKKEN 4th axis divider Ø 250 mmYear: 1989Manufacturer: SIGMALots sold as is, unchecked, without tools or tool holders. Auction-ID: A1-50714-4066

Numerical Control: HAAS X/Y/Z Axis Travels: 750 × 410 × 500 mmMax. Spindle Speed: 10,000 rpm4th Axis: HAAS-compatible (presence shown)Spindle Hours: Approx. 19,678 h (meter reading)User documentation: presentWeight (kg): Approx. 5600Year & Manufacturer: 2000 – HAAS Auction-ID: A1-50714-4050

Manufacturer: DMG (Deckel Maho Gildemeister)Year: 2006Type: CNC Vertical Machining CenterNumerical Control: Heidenhain TNC 530Strokes: X 635 mm / Y 510 mm / Z 460 mmSpindle: 12,000 rpmTool magazine: 32 positionsSpindle center coolant: 20 barFiltration: Cartridge filtrationTooling: No tooling supplied with the machineWeight (kg): approx. 6000Notes: Multi-purpose CNC vertical machining center. Serial number included in the description. Auction-ID: A1-50714-4016

Manufacturer: MORI SEIKIYear: 1994Type: CNC Vertical Machining CenterNumerical Control: FANUC 16M / Mori MSG 6Strokes: X 800 mm / Y 460 mm / Z 510 mmTable: 1000 × 460 mmSpindle: ISO 40 – 8,000 rpmTool magazine: 30 positionsWeight (kg): approx. 6000Notes: Robust Japanese-made CNC vertical machining center. Lots sold as is, unchecked, without tools or tool holders. Auction-ID: A1-50714-4009

CNC vertical machining center for machining metal parts. Numerical control: Siemens 810DStrokes: X 630 mm / Y 500 mm / Z 500 mmTable: 800 × 500 mmMax. table load: 500 kgSpindle cone: ISO 40Spindle speed: 10,000 rpm Auction-ID: A1-50714-4012

equipped with automatic cooling system; unused; in suitcase; 5637 Auction-ID: A1-50865-309

50/60Hz; core drill dia 35mm; twist drill dia 13mm; stroke 210mm; cable length 2.5M; 7750 Auction-ID: A1-50865-305

Manufacturer: HARTFORDYear: 1999Type: CNC Vertical Machining CenterNumerical Control: FANUC O-MAxes: 3 Axes (X, Y, Z)Strokes: X 1000 mm / Y 500 mm / Z 550 mmSpindle: BT40 – 8000 rpmEquipment: Chip Conveyor, Full Documentation (Operator Manual, Electrical Diagrams, FANUC Documentation)Condition: Machine in working order, truck loaded (LOADED)Condition: Used Auction-ID: A1-50714-4054

X / Y / Z axis strokes: 1020 × 510 × 550 mmSpindle power: 11 kWMax. spindle speed: 6,000 rpmSpindle taper: BT 40Tool magazine: 22 positionsWeight (kg): approx. 6000Year & Manufacturer: 1993 – FONG LEE Lots sold as is, unchecked, without tools or tool holders. Auction-ID: A1-50714-4060

CNC vertical machining center for machining metal parts. CNC control: Heidenhain TNC 410Axes: 3 axesStrokes: X 1,020 mm / Y 610 mm / Z 560 mmTable: 1,400 ×,650 mmMaximum load table: 2,000 kgSpindle taper: BT 40Spindle speed: 10,000 rpmSpindle power: 15 kWTool changer: 40 positionsHigh-pressure coolant: 20 bar through spindleEquipment: Chip conveyor, 2 augers, spindle cooling, closed cab, machine lighting Auction-ID: A1-50714-4038

CNC Vertical Machining Center Order: Heidenhain TNC 426 Axes: 3 Table (mm): 1100 × 600 X/Y/Z strokes (mm): 1000 × 600 × 800 Spindle: ISO 40, max. 8,000 rpm Tool magazine: 40 positions Equipment: Chip conveyor Serial number: Remarks: Used machine, Auction-ID: A1-50714-4030

Numerical control: FANUC 0M (original manual)Number of axes: 3Axis strokes: X 1100 mm / Y 650 mm / Z 800 mmMaximum spindle speed: 8000 rpmCooling: with coolantSpindle taper: BT40Tool changer: automatic, 30 stationsYear: 1994Manufacturer: SUPERMAX Auction-ID: A1-50714-4040

Manufacturer: SIGMAYear: 2002Type: CNC Vertical Machining CenterNumerical Control: FANUC 18MAxes: 3-Axis (X, Y, Z)Strokes: X 750 mm / Y 400 mm / Z 450 mmTable: 900 x 400 mm – max. load 600 kgSpindle: SK40 (DIN 69871-A) – 6,000 rpm – 15 kW – max. torque 191 NmTool magazine: random carousel – 21 toolsGuides: linear guidesWeight: 6,000 kgRemarks: Italian-made CNC vertical machining center, functional machine. Auction-ID: A1-50714-4032

OKK VC-X350L 5-axis continuous vertical machining center with turning function (C-axis), Fanuc 31i-A5 control. Machine from 2011 in very good condition, very well equipped, in operation. Features Brand / Model: OKK VC-X350L Serial No.: 125 (Manufacture No. MAJ15026) Year of Manufacture: 2011 CNC Control: Fanuc Series 31i-Model A5 with Data Server 5-axis continuous with TCP function Spindle: 12,000 rpm, BT 40 taper Turning function (C-axis): 1,000 rpm Coolant center high pressure 40 bar Coolant refrigeration unit Renishaw OMP60 workpiece probe Renishaw TS27R probe Tool magazine: 60 positions Power supply: 380 V / 50 Hz / 3 phases – 54 kVA, current 82 A Equipment and accessories included Set of 60 tool holders of different types Chip conveyor Fanuc data sheet and original purchase invoice provided History and condition Spindle completely rebuilt by IBAG about 2,000 hours ago: bearin ...

Auction-ID: A1-50051-2

equipped with automatic cooling system; unused; in suitcase; 5637 Auction-ID: A1-50865-4085

CNC vertical machining center for machining metal parts. Axes: 3 axesStrokes: 610 x 410 x 450 mmNumerical control: Fanuc OTEquipment: Chip conveyorManufacturer: Yang Iron Works Co., Ltd.Country of Manufacture: TaiwanSerial No.: Z00321 Auction-ID: A1-50714-4056

CNC Vertical Machining CenterManufacturer: HEADModel: CUV-10Year: 2001Order: FANUC OMDStrokes: X 1,020 mm / Y 510 mm / Z 635 mmSpindle: up to 7,500 rpm2-speed transmissionConstruction: shrouded machine, integrated coolantCondition: Used machine Auction-ID: A1-50714-4048

Manufacturer: KAO FONG MACHINERY CO., LTD. (KAFO)Year: 1990Type: CNC Vertical Machining CenterNumerical Control: FANUC Series 15-MAxes: 3-axis (X, Y, Z)Strokes: X 1030 mm / Y 210 mm / Z 610 mmSpindle: BT40 – up to 6000 rpm – power approx. 11 kWTool magazine: 20 positions BT40Weight: approx. 6000 kgOrigin: TaiwanNotes: Robust CNC vertical boring milling machine for general machining. Auction-ID: A1-50714-4018
