TECHNICAL SPECIFICATIONS Manufacturer: GIPO Designation: 1-Deck Pre-Screen / Step Screen Type: VS 1330 Year of construction: 2012 Screen length: 3,000 mm Screen width: 1,300 mm SPECIFIC COMMENT - Without drive - Incl. springs

TECHNICAL SPECIFICATIONS Designation: Loading Belt / Conveyor Belt Version: stationary Wheelbase: approx. 54,000 mm Belt width: 1,000 mm Propulsion: Slip-on geared motor Drive power: 30 kW Hot-dip galvanized: yes Catwalk: single-sided Discharge height: 4,250 mm Coverage: no SPECIFIC COMMENT - Belt and idlers not available

The following items can be purchased in the package or subpackage: Pos. 01) -> 9 pieces of conveyor belt drums Surface: Blank Drum length: 950 mm Drum diameter: currently 224 mm or 240 mm with 8 mm rubber coating Shaft diameter: 70 mm Axle length: 1,250 mm Incl. 6 SKF pillow block bearings Pos. 02) -> 1 piece conveyor belt drums Surface: Rubberized Drum length: 950 mm Drum diameter: 260 mm including rubber coating Shaft diameter: 50 mm Axle length: 1,230 mm Pos. 03) -> 2 pieces of conveyor belt drums Surface: Blank Drum length: 950 mm Drum diameter: currently 456 mm or 480 mm with 12 mm rubber coating Shaft diameter: 60 mm Axle length: 1,250 mm Item 04) -> 7 pieces of conveyor belt drums Surface: Blank Drum length: 950 mm Drum diameter: currently 216 mm or 240 mm with 12 mm rubber coating Shaft diameter: 50 mm Axle length: 1,150 mm Pos. 05) -> 2 pieces ...

TECHNICAL SPECIFICATIONS Manufacturer: SMT STICHWEH Description: Drainage bucket wheel Design: Cup wheel in the middle Type: ES 40 BB Year of construction: 1983 Tub length: 3,375 mm + plus spout 490 mm Tub height: 1,150 mm Tub width: 4,080 mm Transmission: Stiebel Parallel shaft gearbox 5042 Dimensions screen mat: 700 x 740 x 8 mm Weight: approx. 5,500 kg SPECIFIC COMMENT - 1 discharge conveyor available (AA= 10 m /BB= 650 mm) - No cracks, no deformations

TECHNICAL SPECIFICATIONS Manufacturer: GIPO Designation: Feed chute / vibrating chute Type: FA 1235 Width: 1,200 mm Length: 3,500 mm Propulsion: Vibration motor Drive power: 2 x 5.6 kW SPECIFIC COMMENT - Incl. rubber buffer

TECHNICAL SPECIFICATIONS (impact crusher) Manafacture: SBM Designation: Impact crusher Version: Semi-mobile Type: RHS 12/12/4 Year of construction: 1998 Drive cable: 160 kW Drive type: V-belt Throughput: 130 t/h Inlet opening (width/depth): 1,264 / 1,047 mm Maximum feed size: 800 mm Number of blow bars: 4 pcs. Rotor diameter: 1,280 mm Rotor speed: 33.3 m/s Weight impact crusher: approx. 15,500 kg SPECIFIC COMMENT - Selective crushing of soft to medium-hard natural stone, reinforced concrete and rubble - Without grinding track - Can also be used as a secondary crusher OVERALL SYSTEM CONSISTING OF: - SBM impact crusher RHS 12/12/4 - Feed hopper with vibrating chute - Bar sieve for pre-screening - Outlet channel - Discharge conveyor - Overbelt magnet - Stockpile conveyor - SIMENS Simatic OP7 controller -Structural steelwork - Generator set - Optionally a ...

TECHNICAL SPECIFICATIONS Manufacturer: BINDER+CO Designation: BIVITEC expansion shaft screening machine Design: Dry screening Type: KRL 1600x6 Number of screen decks: 1 pc. Year of construction: 1995 Drive cable: 22 kW Feed capacity: 80 - 100 t/h Dimensions (length/width): 6,000 x 1,600 mm Screening area: 9.6 sqm Screen lining deck 1: Synthetic Strainer tank: available SPECIFIC COMMENT - Very good technical condition (optically only flash rust) - Incl. solid steel support on carriage - Incl. discharge conveyor - Incl. numerous spare parts/wear parts - Control attached directly to steel support

TECHNICAL SPECIFICATIONS Manufacturer: Förderanlagen-Maschinenbau Kanert Name: Conveyor belt Version: stationary Wheelbase: 20,000 mm Strap width: 650 mm Year of construction: 2015 Drive power: 11 kW Drive type: STIEBEL slip-on gearbox Support: free supporting structure Catwalk: single-sided Handover: baffle plate / synthetic Belt tension: Tension carriage Top chord cover: no Segment length: 1 x 2,000 mm / 1 x 8,000 mm / 1 x 13,000 mm SPECIFIC COMMENT - Very good technical condition

TECHNICAL SPECIFICATIONS Designation: Discharge belt Version: stationary Axle distance: 6,000 mm Belt width: 1,200 mm Year of construction: 2006 Drive power: 15 kW Drive type: Plug-on gear motor Support: free supporting structure Catwalk: not available Handover: Transfer hood Belt tension: Tensioning carriage Galvanized version: yes SPECIFIC COMMENT - Exhaust conveyor belt with close upper belt stations - No trough angle / straight load flow

TECHNICAL SPECIFICATIONS Manufacturer: FAM Designation: Walzenmühle Type: 1004 H Year of construction: 1996 Machine size: 1004 Roller diameter: 1,000 mm Roller width: 400 mm Roller speed: n = 122 1/min Roller circumferential speed: v = 6.4 m/s Machine V-belt pulley: ∅ 800 mm Transmission V-belt pulley: ∅ 400 mm Drive power: 2 x 22 kW, 233 1/min, 400/690V Drive type: SEW gear motor R 102 DV 180 L4 TF Total weight: 8.9 t Materials Roller jacket: G-X 110 MnCr 18.2 Wear plates: Hardox 400; 20 mm Material guidance: Hardox 400; 15 mm SPECIFIC COMMENT - Including hydraulic unit and control - Previous service life approx. 5 years

TECHNICAL SPECIFICATIONS Manufacturer: MOGENSEN Designation: Stangensizer / Stangenrost Type: DX3527 Year of construction: 1994 Version: Two-deck Clear length: 3,500 mm Clear width: 2,300 mm Total height: 2,750 mm Rod diameter above: 70 mm Rod diameter bottom: 40 mm Top gap distance: 216 mm Gap distance below: 330 mm SPECIFIC COMMENT - Reappraisal 2020, since then unused - Robust construction - Ideal for coarse separation

TECHNICAL SPECIFICATIONS Manufacturer: ROHR GmbH Designation: friction drum Type: Hurricane HS-5 Year of construction: 2000 Throughput: 50 - 100 t/h Drive power rotor outside: 55 kW Drive power rotor inside: 90 - 132 kW Drum diameter: 1,800 mm Drum length: 3,100 mm Weight: 20.410 kg SPECIFIC COMMENT - For polishing, grinding, cleaning and rounding aggregate

TECHNICAL SPECIFICATIONS Manufacturer: Weserhütte Description: Double Knee Lever Jaw Crusher Type: DBS1200x960 Year of construction: 1979 Version: Heavy version for hard rock Drive power: 110 kW Flywheel diameter: approx. 2,400 mm Inlet opening (width x height): 1,200 x 960 mm SPECIFIC COMMENT - Incl. pusher SW1250x4000 - Incl. stepped grate with pre-screening - Incl. control unit TECHNICAL SPECIFICATIONS Manufacturer: Weserhütte Description: Double toggle jaw crusher Type: DBS1200x960 Year of manufacture: 1979 Version: Heavy duty for hard rock Driving power: 110 kW Flywheel diameter: approx. 2,400 mm Inlet opening (width x height): 1,200 x 960 mm SPECIFIC COMMENT - Incl. step grate with pre-screening - Incl. control unit If you are interested please let us know, we appreciate to send you a detailed quotation. EuroConsult Dimitrios Piretzidis

TECHNICAL SPECIFICATIONS Designation: Conveyor belt Version: stationary Axle distance: 12,000 mm Belt width: 1,200 mm Drive power: 7 kW Drive type: Plug-on gear motor Support: free supporting structure Catwalk: not available Belt tension: Tensioning carriage Galvanized version: yes

TECHNICAL SPECIFICATIONS Designation: Conveyor belt Version: stationary Axle distance: 8,000 mm Belt width: 1,000 mm Year of construction: 2005 Drive power: 7 kW Drive type: Plug-on gear motor Support: free supporting structure Catwalk: not available Handover: Transfer hood Belt tension: Tensioning carriage Galvanized version: yes

COMPOSED OF: 1 x Rotor Remanufactured + balanced+ equipped 2 x Rotor (need to be refurbished) 1 x Clamping device for balancing 9 x Impact strips (Large) 6 x Impact bar (small) 2 x Enema cone 3 x tear-off edge various rotor protection plates CONSISTING OF: 1 x Rotor newly reconditioned + balanced+ fitted 2 x Rotor (must be reconditioned) 1 x Clamping device for balancing 9 x Blow bars (large) 6 x Blow bars (small) 2 x Inlet cone 3 x Tear-off edge Various rotor protection plates

TECHNICAL SPECIFICATIONS Manufacturer: BINDER+CO Designation: BIVITEC clamping shaft screen Type: LIV/ED 2600x8 Design: Dry sieving Number of screen decks: 1 Year of construction: 2005 Screen length: 8,000 mm Screen width: 2,600 mm Weight: approx. 16.5 t SPECIFIC COMMENT - Incl. drive - Incl. supports ------------------------------------------------- TECHNICAL SPECIFICATIONS Manufacturer: BINDER+CO Description: BIVITEC Flip Flow Screen Type: LIV/ED 2600x8 Version: Dry screening Number of screen decks: 1 Year of construction: 2005 Screen length: 8,000 mm Screen width: 2,600 mm Weight: approx. approx. 16.5 t SPECIFIC COMMENT - Incl. drive unit - Incl. supports

TECHNICAL SPECIFICATIONS Manufacturer: GHH Designation: Double toggle jaw crusher Design: Heavy duty version Type: 86 Year of construction: 1968 Throughput: 45 - 55 cbm/h at crushing gap 80 - 100 mm Inlet opening: 800 x 630 mm Maximum feed size: approx. 450 mm Drive power: 112 kW Weight: 27.000 kg SPECIFIC COMMENT Complete semi-mobile system consisting of: - GHH double toggle jaw crusher - Feed funnel - Plate tape 1,000 x 5,000 mm - Plaster tape (under the plate tape) 800 x 8,000 mm - Solid steel construction ---------------------------------------------------------- TECHNICAL SPECIFICATIONS Manufacturer: GHH Description: Double toggle jaw crusher Version: Heavy duty version Type: 86 Year of construction: 1968 Throughput capacity: 45 - 55 cbm/h with crushing gap 80 - 100 mm Feed opening: 800 x 630 mm Maximum feed size: approx. approx. 450 mm Drive power ...

TECHNICAL SPECIFICATIONS Manufacturer: BÖHRINGER (Germany) Name: Impact crusher Type: PB 1300 x 1200 Year of construction: 1978 Weight: approx. 26,000 kg Drive line: 200 kW Drive type: V-belt Throughput: 200 - 300 t/h Inlet opening (width / height): 1,330 mm / 1,500 mm Maximum task size: approx. 1,000 mm Number of impact strips: 3 pcs. Rotor diameter: 1,200 mm Rotor width: 1,300 mm TECHNICAL SPECIFICATION Manufacturer: BÖHRINGER (Germany) Description: Impact crusher Type: PB 1300 x 1200 Year of construction: 1978 Weight: approx. 26,000 kg Drive power: 200 kW Type of drive: V-Belt Throughput: 200 - 300 t/h Feeding opening (width / height): 1,330 mm / 1,500 mm Feeding size: approx. 1,000 mm Number of rotor ledges: 3 Pcs. Rotor diameter: 1,200 mm Rotor width: 1,300 mm

TECHNICAL INFORMATION Manufacturer: Främbs & Freudenberg Name: inclined circular swing sieve type "Roberg" Design: Wet screening Number of screen decks: 2 Drive power: 15 kW Feed power: 150 t/h Dimensions (length/width): 5,000 x 1,500 mm Screen area per deck: 7.5 sqm Screen inclination: 13° Screen covering first deck: Synthetic Screen covering second deck: Synthetic Siebwanne: available Water requirement Brewing: 200 cbm/h Schurrenwagen: available If there is any interest, we are happy to send you an offer with photos. EuroConsult Dimitrios Piretzidis
