Francis Shaw KO Intermix Year: Jan 1987 Approx. mixing capacity 1.8 litres Mawdsley DC motor, shunt wound, serial no. 180T827, 30kW, 460 volts, 74 amps, 1800rpm, continuous rating Apex Denison Hydraulic Pump Holroyd Gearbox Barco Rotary Joints Fortress Interlock system Water steam inlet Water steam drain Mixing Chamber Rotors Plunger Drop Door Grease points With Hopper Thorn EMI electronic star drive; 415 volts, 3 wire, 50 cycles, 54kva, November 1987 Operator Panel consisting of rotor speed, main motor current process timer, mix temperature Complete with control panel
GK90E Mixer Manufacturer : Harburg Freudenberger Maschinenbau Machine type : Internal mixer Model number : GK 90 E Year of construction : 1987 Chamber volume : 90L Standard rotor speed: 10-50 1/min. Rated motor power : 440KW. Main drive 1850 A Rotor geometry : PES-5 Machine parts : Baseplate Mixer Body Feeding hopper Pneumatics system Gearbox KWE Couplings ESCO Gear CST 220 Complete with motor Main drive Leroy Somer Hydraulic unit Gearbox Lubrication unit Dust seals Lubrication unit Grease pump PLC Advise 2.0 (control cabinet) without server
Betol PVC Extrusion Line Type BC50 0-100rpm 4x Eurotherm barrel controllers Start / Stop Stainless Steel Water trough Width 200mm x 36” Comes out hot and goes through tunnel which cools it down and turns it rigid and into a Haul Off
GK 260N Mixer Manuf.: Werner & Pfleiderer Rotor type ZZ2 Type N tangential Ram Pneumatic pressure 10 bar Camber volume 255 litres Useful volume 220 litres Grease lubrication Dust seal lubrication Stainless steel hopper replaced in August 2011 Pneumatic ram replaced in May 2022, New piston rods, sealings Gearbox Coupling shafts between the mixer and the gearbox Hydraulic central unit With Grease and Oil lubrication pumps The machine was used on natural rubber, NBR and EPDM
LBBC Steam Autoclave 800mm diam. x 1.2m long Quick Lock Door Hydraulic Test Pressure 180psi Safe Working pressure 120psi Welded construction
VF600 MK3 Shadow Graph Manufacturer: Starrett Horizontal Travel 8" (200mm) Vertical Travel 4" (100mm) Focus Travel 4" (100mm) Top Plate 16" x 9" (400 x 230mm) Glass Insert 9-1/4" x 5-1/2" (235 x 140mm) Image: erect and reversed With new screen, curtains & wiper brackets Fully operational / functioning optimally
Barwell Cryogenic Deflashing and Deburring Machine Freeze Trim Chamber Model BFT10
LBBC Autoclave Internal dims: 1.8m diam. x 2.6m long Steam heated Max. working pressure 60psi Quick Lock Door Welded Construction Pressure Certificate Year 1999 External dims: 2.4m high x 3.6m long x 2.6m wide
LWB Steinl Injection Moulding / Vulcanizing Presses Models available: VCEFE-B and VCEFE Clamping force 2500kN Injection volume 1000 cm3 Compressed air 6 bar 76 kW Hydraulic oil 46/40 cst Pattern size 760 x 630mm LWB Flex touch screen Qty 2 Tool Kemp model TT-188 Weight 13500 kgs
LWB Steinl Injection Machine Type VCE -T 500/160 T Clamp power 500 KN Injection volume 160 cm3 Year 2006 6 Bar 400 v 50 hz 26 KW
LWB Steinl Injection Machine Type VREFE 1600/1000/170 Heating platen size 500 X 510 X 63 mm Sliding platens Top and bottom ejectors Clamping force 1600kN Opening force clamp 100kN Clamping stroke 395mm Injection volume E 1000 ccm Max. Injection Pressure E 2200 bar Injection volume EF 170 ccm Max. Injection Pressure EF 1800 bar Hours: 700 since new Year 2009 Weight 6000kg
Strip cooling system system Cantilever, built in 2004, strip width 2-fold up to 120 mm, 1-fold up to 200 mm, thickness 6 to 12 mm, Throughput 500 to 800 kg/h
ROLL DIAMETER 550 mm POLL WORKING LENGTH 1530 mm MOTOR POWER 110 KW DIMENSIONS: 630022301830 (LĂ—WĂ—H) SPEED RATIO OF ROLLS 1:1.27 Structure description 1 Base frame is welded and annealed . 2 The motor is 3- phase asynchronous motor, protection levels :IP54. 3 The driving type :Single out- shaft or double out- shaft. The speed reducer is hard gear reducer,which has long service life and low noise. 4 The roller bearing is rolling bearing with Low noise, save power almost 20%. the roller bearing use grease lubricating. 5 The nip adjusting Motor type 6 This machine is equipped with two pieces of moving blade. 7 Safety device : Pull the safety rod to achieve emergency stop. It can be installed with kick stop device and emergency stop device for safety. 8 The electrical design theory conform to the TWO ROLL MILL specifications strictly . It is equipp ...
5501500 TWIN SCREW 1. 1 PC 5501500 OPEN MILL RUBBER MIXER 2. 1 PC 5501500 OPEN MILL RUBBER MIXER 3. ELECTRIC CONTROL CABINET WITH DRIVER 4. DIRECT CONNECTION (COUPLED) 5. BRONZE BEARINGS 6. AUTOMATIC LUBRICATION 7. 160 KW 990r/min
L/D=20.7 External dimensions 2700Ă—1000Ă—1400(LxWxH) Screw stiffness HRC65-68 Screw diameter 90mm Engine power 30KW/1470rpm SCREW LENGTH 1860 mm Heating section number/power 6kwĂ—2
ROLL DIAMETER 400mm POLL WORKING LENGTH 1000mm MOTOR POWER 45 KW DIMENSIONS: 447118501760 (LĂ—WĂ—H) SPEED RATIO OF ROLLS 1:1,27 Structure description 1 Base frame is welded and annealed . 2 The motor is 3- phase asynchronous motor, protection levels :IP54. 3 The driving type :Single out- shaft or double out- shaft. The speed reducer is hard gear reducer,which has long service life and low noise. 4 The roller bearing is rolling bearing with Low noise, save power almost 20%. the roller bearing use grease lubricating. 5 The nip adjusting Motor type 6 This machine is equipped with two pieces of moving blade. 7 Safety device : Pull the safety rod to achieve emergency stop. It can be installed with kick stop device and emergency stop device for safety. 8 The electrical design theory conform to the TWO ROLL MILL specifications strictly . It is equipped ...
Buzuluk 14231 CE conversion in 2010 Antifriction bearing Motor: 55 kW Motorized NIP adjustment Baseplate
Plates 510x400 mm Clamping force 150 t max. injected volume 750 cmÂł clear width 440 mm
