Zeiss CNC Coordinate Measuring Machine Prismo MP5 Year of manufacture: 8/1999 Last calibration 9/2023 Measuring range: X= 900 mm, Y= 1200 mm, Z= 700 mm Device features, equipment: Control C98 with control panel Sensors RDS with RST Pushbutton Changer Magazine 5-fold RST 5x probing system Dpp7Jl Pushbutton Accessories Measuring ball Calculator with monitor Software Calypso Basic 5.4 Loading system Other accessories Complete retrofit C99 and Calypso possible

Zeiss Prismo VAST Gold with rotary table Year of manufacture 1999 Retrofit Measuring range: X= 900 mm, Y= 1200 mm, Z= 700 mm Control C98 with control panel BP26_SE Roundtable VAST Gold probe Stylus Changing Magazine 13-Fold Stylus changer plate Pushbutton Accessories Calibration ball Technical documentation Other accessories Workstation with monitor Software Calypso Basic other options of your choice

Maximum turnerable diameter 1200 mm Maximum permissible diameter 1250 mm Spindle engine power (S1/S6) 55 / 66 Kw Spindle maximum laps 1200 rpm ASA 15" Spindle Attachment Fast speeds 12 m/min X-axis stroke 750 mm Z-axis stroke 750 mm Rated engine torque 20 (X)-20 (Z) Nm Peak engine torque 80(X)-80(Z) Nm Nominal thrust force 1200(X) -120 (Z) N Screw pitch 10 (X) -10 (Z) mm Tools 24 Crown HIRT tool attachment Maximum weight per cell 15 kg Tool change cycle time 10 seconds Maximum weight on tool change ~ 250 Average tool weight ~ 10 Maximum milling tool diameter 150 mm Maximum tool length 350 mm Siemens Sinumerik Control

Workpieces are fed in bulk, checked, bad parts are sorted out and good parts are placed in containers as bulk goods. Workpiece: Bolt, Ø 6 - 12 mm Workpiece length: 33 - 56 mm Cycle time: 1.8 s Camera inspection (dimensions and surface defects) - high-resolution matrix camera (21 Mp), dimensions - Line scan camera (4K), surface inspection Parts bunker SKAKO, 71 l volume HSMA07903 up to 125 kg in stock Original price: € 230.000,-

The machine is in good technical condition, testing is possible by prior arrangement.  ...

• more information

Ref. -No.: 10157 Manufacturer: CARL ZEISS Year of construction: 1997 Type of control: HP 9000 Serie 700 Control: Betriebsystem HP-UX.9.05 Storage location: Halberstadt Country of origin: Deutschland Turntable: 1000x2100 mm Machine weight: 4.800 kg Machine Height: 3050 mm Table height above the floor: 850 mm X-Axis: 850 mm Y-Axis: 1800 mm Z-Axis: 600 mm Further information: Three coordinate measuring machine Microcomputer control X-axis as a longitudinally movable portal Y-axis cross slide in the portal Z-axis as measuring head quill (vertical) Passage between the portal approx. 1,000 / 1080 mm Passage in height approx. 750 mm

Offered is a 3D coordinate measuring machine. Working area X/Y/Z: 850mm/1200mm/600mm, probe holder: Renishaw PH10M, table surface: granite plate, resolution: 0.1µm, air supply: 5bar, control: Zeiss CMM Controller. Equipped with control panel with joystick, SCR200 probe change magazine, calibration sphere, extensive probe accessories. Weight: approx. 2400kg, overall dimensions X/Y/Z: approx. 2100mm/1900mm/2350mm. Inspection possible by arrangement.

Stand unit with steel plate with C99 control Measuring ranges: x=5000 mm, y=2600 mm, z=2100 mm Measuring plate: 6000 mm x 3000 mm Rotary swivel head RDS for TP Control panel Dynalog Travelling control unit on the stand, opto-coupler, screen, keyboard, mouse Active vibration damping Without software and hardware. We reserve the right to make changes and errors in the technical data as well as to make the interim sale. Price plus transport and installation.

Carl Zeiss Axiovert 40C Inverted Light Microscope The Carl Zeiss Axiovert 40C is a routine inverted microscope specifically designed for the study of living cells and cell cultures in biology and medicine. Due to the inverted design, the objectives are located below the stage, which allows observation in larger culture vessels such as petri dishes or microtiter plates. Technical features Optics: Equipped with the ICS system (Infinity Color-corrected System) from ZEISS for high optical performance in all contrast processes. Lighting: Equipped as standard with a 12V 35W halogen lamp for transmitted light; optionally, an HBO 50 mercury vapor lamp can be used for fluorescence applicat ...

total power requirement:380V, 50Hz, 7,9A kW weight of the machine ca.:1 t dimensions of the machine ca.:4 x 3 m  ...
