used Surface planing machines for sale

SPECIFICATIONS: Max. width of the work table mm: 500 Total length of the 2 work tables mm: 2,550 Number of knives: 3 Installed power kW: 5.0

SURFACE PLANER CASADEI DS 510 second hand machine volt. 380/50 working width mm. 510 length of table mm. 2800 cutterblock 4 knives motor power Hp 5,5 net weight kgs. 750

Description: Bench width 410 mm bench length 2400 mm with 4-blade head.Approx. Onsite Dimension. (l x w x h): 0 x 0 x 0 mm, weight approx.: 0 x 0 x 0 kg

Description: Four-sided planer for processing classic parquet with chain drive It can process parquet from 200 to 600 mm and from 32 mm to 100 mm wide The capacity of the machine depends on the size of the parquet, up to approx. 150 to 300 m2 per shift Approx. Onsite Dimension. (l x w x h): 2,400 x 900 x 1,500 mm, weight approx.: 1,500 kg

Description: CASOLIN Planer with a chain for the drive and has the option of processing the upper, lower, right or only upper and lower elementsApprox. Onsite Dimension. (l x w x h): 2,900 x 900 x 1,900 mm, weight approx.: 3,000 kg

SECOND-HAND SURFACE PLANER EXCEL LUCK INDUSTRY MOD. MB50 - CE RULES - mm. 500 - sn 2108301 - year 2021

Working width: 510 mmLength of the planing table: 2.250 mmNumber of knives: 4 St.Motor output: 5,5 kWDimensions (L/W/H): 2.427 x 1.340 x 890 mm: Ja weight: 750 kgDust suction hood: 140 mm: Keilleistenmesser The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Code: N0617 Brand: FIMAL Model: PF 530 A - CE Standard SURFACE PLANER - CE STANDARD Shaft motor 7,5 Electromagnetic brake Auxiliary guide for narrow workpieces Shaft with tersa-type knives Pneumatic planer guide locks Automatic infeed table positioner "CE" EQUIPMENT Electrical system to standards Electromagnetic motor brake Suction hood Bridge planer protection MACHINE READY FOR DELIVERY

Working width: 530 mmLength of the planing table: 3.000 mmNumber of knives: 4-TERSA St.Motor output: 5,5 kWFIMAL surface planer type PF 530 N---------------------------------------NEW MACHINE Partnership EditionTechnical specifications:---------------------------------------Planing table dimensions: 3,000 x 530 mmFeed table length: 1,800 mmDressing fence dimensions: 1,500 x 175 mmSwivel range stop: 0 - 45 °4-knife cutterblock system TERSA d = 120mm: 5,000 rpmMax. Chip removal dressing according to CE: 8 mmMotor 380 volts / 50 Hz .: 5.5 kWSound level according to EN 27960: 82.9 - 88.9 dB (A)Basic equipment:Electrics according to CE standardsMagnetic brakeExtraction nozzle d = 150mmBridge protectioncontrol panel operated aboveOriginal AIGNER aluminum stop with integrated auxiliary stop---------------------------------------Special offer from stock: 8,990.00 euros-------------------------- ...

Specifications/Equipment: - Planing width 510 mm - Chip removal max. 8 mm - Table length 2250 mm (dual folding system with spring support) - Swivel dressing fence with parallelogram guide - Dressing protection "Comfort" - 4-knife system planer shaft, 510 mm - Speed 4,600 rpm - Suction nozzle Ø 140 mm - Connection: 400 V, 50 Hz, 3~, 5.5 kW - Weight approx. 700 kg

Description: Planing width 530 mm, table length 2300 mm, thicknessing table length 920 mm, planing shaft diameter 120 mm, knife 4, without documentation and CE certificateApprox. Onsite Dimension. (l x w x h): 2,400 x 1,400 x 1,200 mm, weight approx.: 1,100 kg

Description:  , serial number: 212serial number: 212, Approx. Onsite Dimension. (l x w x h): 2,550 x 1,350 x 1,000 mm, weight approx.: 800 kg

Used dressing Int. Kind. Ref. m3217 Manufacturer Hofmann Type unknown Planing width 510 mm 4-knife shaft Weight approx. 800 kg Item location: 58730 Fröndenberg/Ruhr The machine can be visited. We will be happy to send you further photos by e-mail. A forklift/crane for loading is available. Prior sale is reserved. It is possible to expertly examine the items for sale on site. Specific questions should be clarified in advance. The information, such as technical data.B, dimensions, year of construction, condition are non-binding and have been shown to the best of our knowledge and belief. Errors are therefore reserved. The warranty / guarantee is excluded. The goods are sold ex location / warehouse, with transfer of risk to the buyer, this also applies to a shipment on our part, which we have carried out on your behalf. This offer is only aimed at traders, deale ...

New, unused You can call or write to us. We can speak and write German and Russian. You can also send messages in English.

Straightening planer AF 3 E Product name: Planing machine Manufacturer: Julius Lindner & Co. Görlitz Type: AF 3 E Year of construction: 1966 Machine number: 3420 Condition: used, cleaned, completely refurbished and checked! Technical details: • Machine dimensions (L x W x H): 1,480 x 300 x 770 mm • Table size (L x W): 1,480 x 700 mm • Knife shaft speed: 5,400 rpm • Number of knives: 2 • Weight: 400 kg • Suction nozzle diameter: 120 mm Engine data: Voltage: 380 V Power: 1.5 kW Speed: 2,870 rpm The machine has been completely refurbished. The flat belt, the motor circuit breaker, the supply lines and the motor were renewed. Furthermore, a connection for an extraction system was retrofitted. Price: €1,250.00 (EUR) plus VAT ex Grunow (Brandenburg) (Subject to changes and errors regarding technical data and prices!)

Technical details: - Max. planing width: 500 mm - Maximum chip depth: 5 mm - Length of feed table: 1,300 mm - Length of the take-off table: 1,500 mm - Total length of the table: 2,800 mm - Table height: 800 mm - Max. workpiece length without support: approx. 1.5 m - Length of the joining fence (Aigner joining fence with integrated auxiliary fence): 1,300 mm - Height of the joining stop: 150 mm - Joining stop adjustable up to 45° and extendable over the entire width of the table - Diameter of the TERSA knife shaft: 125 mm - Nominal speed of the TERSA knife shaft: 5,000 rpm - Number of planer blades: 4 pieces - Minimum width of planer blades: 17 mm - Diameter of suction nozzle: 160 mm - Required air velocity: min. 20m/s - Required air volume: 1500 m³/h - Vacuum at 20m/s air velocity: 705 Pa - 6 x machine shoes with adjustment screws - incl. EMERGENCY STOP switch En ...

Technical data (subject to change) Working width approx. 500 mm Chip depth as well as hollow and pointed joint indication Speed approx. 5,000 rpm Swivelling dressing stop Brake via foot pedal Weight approx. 950 kg

Brand: Martin Type: T54 Year of construction: New Motor power: 5.5 kW Knife shaft speed: 5,000 tpm Knife shaft: Z-4 Tersa, ø125 mm Planer width: 5000 mm Spahn removal: max.8 mm Table length: 2.850 mm Task - Table length: 1.640 mm Removal - table length: 1.200 mm Table height: 855 mm Dressing stop: Aigner stop, 45°Movable with dunn material planing strip weight: 1.200 KG

SPECIFICATIONS: Max. machining width mm: 110 Table length mm: 2000 Number of knives: 3 Voltage: 380 volts

Planer Brand: Panhans Type: 335/20 New machine Technical data: - Planing width 510mm - Feed table length 1620mm - Delivery table length 1170mm - Total table length 2850mm - Blade shaft speed 5000 rpm. - Extraction nozzle Ø 160mm - Chip removal up to 8mm - Weight approx. 1,050 kg Motor power 5.5kW / 7.5PS Voltage 400V / 50 Hz Required space approx. 2900 x 1500mm Solid German mechanical engineering For dressing and joining, including hollow and pointed joint setting for planing widths up to 510 mm and max. Chip removal up to 8 mm Ergonomic working position directly on the blade shaft PANHANS solid steel blade shaft ø 125 mm with 4 pieces of Tersa reversible blade Finely planed machine tables, total table length 2850 mm Control panel above at eye level with digital display of chip removal, the current delivery table situation (neutral, hollow or pointed joint),  ...

Specifications/Equipment: Planing width 410 mm Chip removal max. 8 mm Table length 2,850 mm TERSA knife shaft with 4 blades Knife shaft speed 5000 rpm SUVAmatic planer shaft protection cover electr. Feed table height adjustment Dispensing table with hollow and pointed joint adjustment Stop can be tilted up to 45° Motor power 4 kW Suction nozzle Ø 160 mm Space requirement 2,850 x 1,950 x 1,027 mm Weight approx. 870 kg All information is subject to the actual equipment

We can offer you following machine (Subject to being unsold ) Terms of delivery/payment: payable before/ by order . All information and offers are subject to our general terms & conditions If there are further questions, don't hesitate to contact us. Planer Paolioni PF500 Year of construction 1996 Manufacturer: Paoloni Italy S/N 0006 Working width 500 mm Number of knives / (strip planer knife ): 4 Length of dressing table ( total ) 2500mm both adjustable tables Stop angle adjustable electric brake       Diameter of the extraction nozzle 150 mm Motor 4kW, 380 V, 50 Hz Dimensions length x width x height: 2500x920x1050mm Weight 680 kg CE marked Technical specifications are subject to change Surface planer Paolioni PF500 Year of construction 1996 Manufacturer Paoloni Italy S/N 0006 Working width 500 mm Number of knives / (strip planer knives):  ...

SPECIFICATIONS: Working dimensions mm: 3000 x 530 Speed 5000 rpm Number of knives: 04 Installed capacity: KW 5.5

CATALOG NUMBER 5843 TECHNICAL DATA - shaft width 510mm - 3-knife shaft - shaft cover - length of the tops 2530mm - cast iron tops - both adjustable tops - cast iron guide adjustable at an angle - 3kW engine - dimensions length / width / height 2530x900x1000mm - weight 897 kg ADVANTAGES - Italian production - used planer - intended for professional use Net price: PLN 11500 Net price: EUR 2738 depending on the price EUR 4.20 (Prices may change with higher fluctuations)

Gebr. Planer REX A510 YOC 1981 Motor power: 4 kW Planing width: 51 cm Table length: 245 cm 2-Knife Shaft Strip Plane Knife Working height: 100 mm Additional overarching fence (standard dressing fence) incl. 2 rollers Feeder Wood Type ETK 0.3 / 0.5 HP Aigner Relief Stop Weight: approx. 950 kg Sold in ACTUAL condition and unrefurbished from carpentry dissolution. Fixed price.

Working width: 530 mmLength of the planing table: 2.900 mmNumber of knives: 4 St.Motor output: 4 kWweight of the machine ca.: 850 kg: Tersa : Ja The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Good day! I would like to offer you the following machine: 1 used dresser SCM F 410 - 41 cm planing width - 2.60 m table length - 125 mm knife shaft with 4 knife Centrofix - 4 KW 380 volt motor -Main switch -Circuit breaker - Automatic engine brake - 8 mm chip removal - Joining stop can be swivelled up to 45° - Auxiliary stop - Low-noise design with serrated steel table lips - Suction nozzle 140 mm - Star triangle switch renewed (150,-- € + 19 % VAT) - 4 Leitz-Centrofix knives newly installed (80,-- € + 19 % VAT) - Weight: 750 KG - Price: €4,300,-- + 19% VAT The machine is technically checked, cleaned and adjusted. Cables and plugs available and ready to use. Very good condition. Bank transfer before shipment or cash payment on pick-up. Loading by forklift is not a problem. The machine is sold without an ...

Working width: 410 mmLength of the planing table: 2.600 mmNumber of knives: 4 St.Motor output: 4 kWDimensions (L/W/H): 2.600 x 1.400 x 1.200 mmweight of the machine ca.: 561 kg: Tersa : Ja The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Flush planer SCM model F410N : - 410x2610mm tops - shaft D.120mm with 4 knives - control panel on rear pine cone Machine according to CE standards.

SPECIFICATIONS: Work table size mm: 2600 x 400 Installed capacity: KW 5.0 Complete with hole punch, knives and regulator

SPECIFICATIONS: Width of work tables mm: 500 Length of work tables mm: 2,600 Number of blades: 4 Diameter mm 120 Installed capacity KW: 4,0

Working width: 410 mmLength of the planing table: 2.200 mmNumber of knives: 5 St.Motor output: 5 kWweight of the machine ca.: ca. 411 kg: Tersa : Ja Dust suction hood: 120 mmturning speeds: 5.000 U/minThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

SCM planing machine F410 Product name: Planing machine Type: F410 Manufacturer: SCM (Italy) Machine number: AB.43770 Year of manufacture: unknown Condition: used, revised and checked Technical details: -Total length of both tables: 2,600 mm - Length of feed table: 1,450 mm - Length of acceptance table: 1,150 mm - Planing width: 410 mm - Diameter knife shaft: 120 mm - Number of planing knives: 4 pieces Tersa knives - Blade shaft speed: 5,000 rpm - max. chip removal: 5 mm - 1 x suction nozzle, diameter 120 mm - 1x joining stop (length: 1,100 mm, height: 170 mm, tiltable 90° - 45°) - 1x folding stop Engine data: - Voltage: 380 V - Current: 6.5 A - Frequency: 50 Hz - Power: 5.5 kW - Speed: 2,800 rpm Machine dimensions (set-up dimensions) L x W x H: 2,600 x 1,200 x 1,050 mm Transport dimensions (L x W x H): 2,700 x 1,200 x 1,200 mm (on pallet) - Number o ...

SPECIFICATIONS: Width of slabs mm: 500 Length mm: 2620 Roller with 4 blades Voltage: 380 volts

SPECIFICATIONS: Max. working width mm: 500 Table length mm: 2600 Number of knives: 4 Installed capacity: KW 5.0

SPECIFICATIONS: Length of work table mm: 2700 Width of work table mm: 500

TRADE Plane Model CM500

Type MB504C Working width 400 mm Overall length 2500 mm Measurements of fence 880x110 mm Fence tilting 45° Number of knives 3 Speed of spindle Motor power 4 kW

Type MB505C Working width 500 mm Overall length 2500 mm Measurements of fence 880x110 mm Fence tilting 45° Number of knives 3 Speed of spindle Motor power 4 kW

Type MB506C Working width 600 mm Overall length 2500 mm Measurements of fence 880x110 mm Fence tilting 45° Number of knives 3 Speed of spindle Motor power 4 kW

Description: -Approx. Onsite Dimension. (l x w x h): 0 x 0 x 0 mm, weight approx.: 0 x 0 x 0 kg

SPECIFICATIONS: Table width mm: 260 Table length mm: 1,300 Number of knives: 3 Voltage: 380 volts

Weinig planing machine Product name: Planing machine Type: AF51 Manufacturer: Weinig Machine number: unknown Year of manufacture: unknown Condition: Used Technical details: - Total table length: 2,600 mm - Feed table: 1,380 mm - Removal table: 1,080 mm - Table height: 810 mm - Chip removal: 0 – max. 8.0 mm - Stop (L x H): 1,250 x 155 mm (obliquely adjustable up to 45° without scaling) - Planing width: 500 mm - 4-knife shaft with 4 strip planing knives - Suction nozzle: 160 mm - Power: approx. 3kW - Weight: approx. 750 kg - 4 knives installed with slight signs of wear - 1 piece Barkomat adjustment gauge - the engine and the knife shafts have been re-mounted - the table lips have been re-milled (approx. 8 mm slots) to reduce the noise level. minimize Machine dimensions/set-up dimensions (L x W x H): 2,600 x 1,350 x 810 mm Transport dimensions (L ...
