Screw Compressor BOGE SLF51/3

Lot 606: Boge Screw Compressor


Variable Frequency Rotary Screw Compressor
The 2019 Boge SLF51/3 is a high-efficiency, frequency-controlled screw compressor ensuring optimal and continuous industrial air supply with minimized energy consumption.



Technical Details
‍

1. Machine identification data

Name: Screw Compressor
Manufacturer: Boge
Model: SLF 51/3
Year of manufacture: 2019

2. Operational parameters

Effective free air delivery (Min - Max): 2.36 – 7.16 m³/min
Operating pressure: 8.00 bar
Main drive motor rated capacity: 37.0 kW
Fan motor rated capacity: 1.10 kW
Motor protection / Insulation class: IP 55 / F
Operating voltage: 400 V / 50 Hz
Control voltage: 230 V AC / 24 V DC
Ambient temperature range: +5°C to +40°C
Cooling air flow volume: 5,500 m³/min
Residual oil content: < 3 m³/min
Sound pressure level: 79 dB(A)
Operating hours: 18,650 h

3. Weights

Total machine weight: 1,250 kg

4. Dimensions

Overall dimensions (Width x Depth x Height): 2,040 x 1,090 x 1,450 mm
‍

Disclaimer: The technical specifications provided are for general reference only and have been sourced from publicly available information for the same or similar model.
