hermle boring mills and machining centers used for sale

Universal milling machine vertically / horizontally from a training workshop Manufacturer Hermle Type FW801 Tool holder SK40 automatic feed in three axes Digital display in three axes Machine technically in very good condition under electricity ready for demonstration Technical data: Travel: x=350mm y=150mm z=220mm Spindle speeds from 50 to 3,150 rpm can be infinitely variable Feed speed infinitely adjustable via rotary pot from 10 to 5,000 mm/min, aisle Special price Used milling machine Hermle FW 801

x-travel: 410 mm y-travel: 310 mm z-travel: 400 mm table-size: 700 x 280 mm control: Heidenhain TNC 145 tool adaptor: SK40 turning speed range: 40- 2.000 U/min rapid speed: 1,5 m/min feed speeds: 1500 mm/min power requirement: 2.2 kW quill stroke: 63 mm weight: 1,3 t total power requirement: 2,2 kW weight of the machine ca.: 1,5 t dimensions: 1,4 x 2,1 x 2,0 m Features: - New TFT screen - Coolant system - Hydraulic tool clamping - Milling head with spindle sleeve - Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Stock number: 3885 PROCESSING Manufacturer: HERMLE, Type: C800 V Machine NO.: 14187, Year of manufacture: 2000 Specifications: Table size 1000 x 560 mm Longitudinal movement (X) 800 mm Transverse movement (Y) 600 mm Vertical movement (Z) 500 mm Spindle cone SK 40 Infinitely variable spindle speeds 10,000 rpm Spindle motor 25/16.8 Kw Total power 43 KVA Tool changer 30 places Feed rate 1-2000/30000 mm/min Rapid traverse 35 m/min Control Heidenhain TNC 430 Fabr. Operating hours spindle 9318 hours Accessories: Chip conveying. Touch Probe Renishaw Cooling by spindle Spindle Cooling Miscellaneous accessories. Operating instructions Delivery time: August 2024 Length: 2700 mm, Height: 2930 mm, Width: 2210 mm, Weight: 7000 kg

Stock number: 3896 PROCESSING Manufacturer: HERMLE , Type: C800 V Machines NO.: 14337, Year of manufacture: 2001 Specifications: Table size 1000 x 560 mm Large table load 1500 kg Longitudinal movement (X) 800 mm Transverse movement (Y) 600 mm Vertical movement (Z) 500 mm Spindle cone SK 40 Stepless spindle speeds 0-16000 rpm Spindle motor 25/16.8 Kw Total power 31 KVA Control Heidenhain 430 - 3 Axis Fabr. Operating hours spindle 9666 hours Accessories: Tool holders 2 pcs Operating instructions Length: 2700 mm, Height: 2930 mm, Width: 2210 mm, Weight: 7000 kg

x-travel: 1000 mm y-travel: 1100 mm z-travel: 750 mm total power requirement: 71 kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

General Manufacturer: Hermle Type: C 40 U Year of Make: 2005 Control: Heidenhain TNC 430 Travels: X 850 mm, Y 700 mm, Z 500 mm B swivel axis Working spindle Speed: 28,000 rpm Tool/movement Tool changer: 38-speed Tool holder: HSK63A Dimensions and weight Weight: 10,500 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included Spindle coolers IKZ high-pressure system 80 bar Blum Laser Measurement Workpiece probes Electric Handwheel HR410 Chip conveyor Oil mist extraction

Control Heidenhain iTNC 520 Travel X/Y/Z: 1200 x 900 x 500 mm Spindle speed 16,000 min-1 Tool magazine for 30 Wkz. + additional magazine for 57 Wkz. HSK-A 63 IKZ 40 bar Chip conveyor Measuring Probe Heidenhain Blum Laser System

Key data: 800 mm, 600 mm, 500 mm

CNC Vertical - Machining Center HERMLE B 300 V With track control Heidenhain iTNC 530 Year of Make: 2014 Travel : X 800 Y 600 Z 500 Speed range : 20 – 18,000 rpm infinitely variable With the following accessories: Rigid angle table 1000 mm x 560 mm clamping surface Vertical tool changer with 30 magazine positions ( HSK 63 ) Blowing air through the centre of the spindle IKZ 40 bar Scraper belt conveyor Tool measurement in the work area ( BLUM Laser ) Coolant Setup Manual Cab Door , Manual Cab Roof Polycarbonate Safety Lenses Electronic Heat Compensation iTNC 530 Electr. Manual control module HR 410 3 D Probe Control cabinet cooling unit ( RITTAL) Spindle Oil Cooler Swarf Spray Gun 4 Pieces Height Adjustable Machine Shoes Operating Instructions

x-travel: 650 mm y-travel: 600 mm z-travel: 500 mm control: Sinumerik 840 D pl Siemens Main spindle:: turning speed range - main spindle: 20 - 28.000 min/-1 power capacity - main spindel: 23 / 18 kW max. Torque: 79 Nm tool taper: HSK-A63 NC-Tilting round table:: table surface area: Ø 630 mm Swivel range: A: +30° / -115 ° rotatable: C: 360 ° max. table load: 500 kg max. workpiece sizes: Ø 630 x 313 mm table speed: A:25 / C:65 min/-1 Tool-Presetter:: number of toolpositions: 117 pos. max. tool diameter: 90 (125) mm max. tool length: 300 mm feeds:: rapid traverse ( X / Y / Z ): 60 m/min Accelaration: 10 m/s² feed power: 8,5 kN total power requirement: 43 kVA weight of the machine ca.: 10,5 t dimensions of the machine ca.: 6,5 x 4,5 x 3,0 m Documents: high pressure coolant: Coolantsystem: through spindle coolant: 80 bar / 1.300l elektr. hand wheel: Automatic Tool Changer: 117 p ...

CNC Vertical - Machining Center HERMLE B 300 V With track control Heidenhain iTNC 530 Year of manufacture: 12/2010 Travel : X 800 Y 600 Z 500 Speed range : 20 – 15,000 rpm infinitely variable With the following accessories: Rigid angle table 1000 mm x 560 mm clamping surface Vertical tool changer with 30 magazine positions ( SK 40 ) IKZ 40 bar Scraper belt conveyor Coolant Setup Manual Cab Door , Manual Cab Roof Polycarbonate Safety Lenses Electronic Heat Compensation iTNC 530 Electr. Manual control module HR 410 3D Probe Renishaw Control cabinet cooling unit ( RITTAL) Spindle Oil Cooler 4 Pieces Height Adjustable Machine Shoes Operating Instructions

number of spindle speeds: 18.000 U/min NC rotary indexing table Ø: 630 mm control: HEIDENHAIN - iTNC 530 numbers of positions in the tool changer: 32 tool taper: SK 40 5-axis simultaneous machining center | HERMLE - C 30 U equipped with ITC (80 bar), NC swivel rotary table, tool changer & chip conveyor. The machine has only 13.924 H spindle hours. The machine is in a well-maintained condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: C30U | C-30U | C-30 U The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

number of spindle speeds: 10.000 U/min NC rotary indexing table Ø: 630 mm control: HEIDENHAIN - iTNC 530 numbers of positions in the tool changer: 32 tool taper: SK 40 5-axis simultaneous machining center | HERMLE - C 30 U equipped with ITC (80 bar), NC swivel rotary table, tool changer & chip conveyor. The Z-axis motor was replaced in 2025, and the spindle was already replaced in 2015 at 7,100 operating hours. The machine is in a well-maintained condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: C30U | C-30U | C-30 U The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 650 mm y-travel: 600 mm z-travel: 500 mm control: Sinumerik 840 D pl Siemens Main spindle:: turning speed range - main spindle: 20 - 28.000 min/-1 power capacity - main spindel: 23 / 18 kW max. Torque: 79 Nm tool taper: HSK-A63 NC-Tilting round table:: table surface area: Ø 630 mm Swivel range: A: +30° / -115 ° rotatable: C: 360 ° max. table load: 500 kg max. workpiece sizes: Ø 630 x 313 mm table speed: A:25 / C:65 min/-1 Tool-Presetter:: number of toolpositions: 117 pos. max. tool diameter: 90 (125) mm max. tool length: 300 mm feeds:: rapid traverse ( X / Y / Z ): 60 m/min Accelaration: 10 m/s² feed power: 8,5 kN total power requirement: 43 kVA weight of the machine ca.: 10,5 t dimensions of the machine ca.: 6,5 x 4,5 x 3,0 m Documents: high pressure coolant: Coolantsystem: through spindle coolant: 80 bar / 1.300l elektr. hand wheel: Automatic Tool Changer: 117 p ...

travel: 600 mm length: 450 mm width: 400 mm spindle turning speed range: 20 4500 U/min Control: Heidenhain TNC 425 weight: 3300 kg dimensions of the machine ca.: 4,0 x 3,8 x 2,1 m total power requirement: 15 kW tool taper: HSK A 63 table-size: 850 x 440 mm 3-axis machining centre X-axis travel: 600 mm Y-axis travel: 450 mm Z-axis travel: 400 mm Table size: 850 × 440 mm Tool holder: HSK-A63 Spindle speed: 20 – 4,500 rpm Control system: Heidenhain TNC 425 Total power requirement: 15 kW Machine weight: approx. 3,300 kg Space requirement (L × W × H): approx. 4.0 × 3.8 × 2.1 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 600 mm y-travel: 450 mm z-travel: 450 mm total power requirement: kW weight of the machine ca.: 6.5 t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

HERMLE U 740 ist ein Bearbeitungszenter hoher Präzision und Zuverlässigkeit. Kapazitäten: Tisch 900×500 mm, 8 T-Nuten (65 mm Teilung, 14 mm Breite), Zuladung 700 kg; Wege X915 Y500 Z500 mm; Werkstück max 900×500×500 mm. Technische Daten: Spindel SK40 20–12000 t/min, 32 kW; Eilgang X/Y 30 m/min Z 20 m/min; Netz 3×400 V 50 Hz; Druckluft 6 bar; Anschlussleistung 26 kVA; Gewicht ~7300 kg; Abm. 2760×2390×2370 mm; 78 dB(A). Ausstattung: Werkzeugwechsler 16 Plätze (Ø Werkzeug max 125 mm, 180 mm freie Plätze), Werkzeugl.300 mm, Gewicht max 6 kg; 3-Backenfutter Ø200 mm, Werkstücktaster HEIDENHAIN TS 640, Teilapparat 4. Achse HOFMANN RW/NC-160, RS232, Ethernet, Schaltschrank-Klimagerät, Spülpistole. Erreicht enge Toleranzen; typische Branchen: Automotive, Luftfahrt, Medizintechnik, Uhrmacherei, Maschinenbau. Technische Daten ohne Gewähr

HERMLE C 42 U ist ein 2 x 5-Achsen Zentrum mit Laderoboter, ausgelegt auf hohe Präzision und Zuverlässigkeit. Tisch 400×400 mm, 450 kg, Wege X800 Y800 Z550 mm, A ±130°. Spindel HSK-A63 0–18.000 rpm, 42 kW, 148 Nm; Eilgänge 45/45/40 m/min. Magazin 42+160, 54 Paletten, KUKA Roboter, IKZ 80 bar, Renishaw/BLUM. Einsatz: Automotive, Luftfahrt, Uhrmacherei, Medizintechnik Technische Daten ohne Gewähr

HERMLE C 600 V ist ein 3-Achsen Bearbeitungszenter, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Tisch 800×465 mm, Verfahrwege X 600 / Y 450 / Z 450 mm, Max. Werkstückgewicht 200 kg; Werkzeugwechsler 30 Plätze, Aufnahme HSK-A63. Spindel 20–16.000 min-¹, Leistung 15 / 10 kW; Vorschub 1–30.000 mm/min, Eilgang 35 m/min, Vorschubkraft 6000 N. Anschluss 3×400 V 50 Hz, Gesamtbedarf 35 kVA, Gewicht ~6800 kg, Abmessungen 2500×2020×2750 mm, 78 dB(A). IKZ 40 bar. Erreicht enge Toleranzen; Anwendungen: Automotive, Luftfahrt, Medizintechnik, Uhrenindustrie, Werkzeugbau. Technische Daten ohne Gewähr

HERMLE C 42 U ist ein 5-Achsen-Bearbeitungszentrum, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Kapazitäten: Tisch Ø440 mm, 5 T-Nuten 14H7, max. Werkstückgewicht 450 kg; Verfahrwege X800 × Y800 × Z550 mm, A ±130°, Tischdrehzahl 30 t/min; Hauptdaten: Spindel HSK-A63 0–18.000 rpm, Leistung 42 kW, Drehmoment 148 Nm, Eilgang 45/45/40 m/min, Netz 3x400 V 50 Hz, Druckluft 6 bar, Gesamtleistung 37 kVA, Gewicht ~13.500 kg, Abmessungen 5000×2450×3200 mm; Zubehör: Werkzeugwechsler 42 Plätze, Zusatzmagazin 160 Plätze, IKZ 80 bar, Schnittstellen RS232/Ethernet/USB, Schaltschrank-Klimagerät; geeignet für enge Toleranzen in Automotive, Luftfahrt, Medizintechnik, Uhrenbau, Werkzeugbau Technische Daten ohne Gewähr

CNC controller: HEIDENHAIN TNC 430 Axes X-axis travel mm: 600 Y-axis travel mm: 450 Z-axis travel mm: 500 Distance spindle nose - table surface mm: 573 Rapid traverse m/min: 10 Worktable Number of pallets: 1 Table dimensions mm: 800 x 465 Maximum workpiece size (D x H) mm: 900 x 528 Max. workpiece weight kg: 450 (500 in large workpieces) T-Slot version: 14 H7 Spindle Spindle speed rpm: 6.300 Spindle drive power kW: 8,6 Bearing Inner Diameter mm.: 70 Tool system Tool holder: SK 40 Tool magazine slots: 34 Max. Tool Diameter: 90 With free neighboring places mm: 125 Tool Magazine: UTC 34 Max. Tool Length mm: 250 Max tool weight kg: 8 Equipment Electronic Handwheel Rinsing gun Tool breakage probe Workarea light CE conformity Cooling Tank capacity: 170 L High-pressure bar: 40L / min Machine running times Rated power kVA: 16  ...

This 3-axis HERMLE C 1200 V vertical machining centre was manufactured in 2003. It features a robust clamping table measuring 1400 x 900 mm and a high-performance milling spindle with a maximum power of 10 kW, torque up to 87 Nm, and speeds up to 16,000 RPM. Ideal for complex machining tasks, the HERMLE C 1200 V machine we have for sale offers precision and durability. Contact us for more information.

This 3-axis Hermle C 800 V vertical machining center was manufactured in 1996. It offers robust construction and precision for complex machining tasks. If you are looking to get high-quality milling capabilities, consider the Hermle C 800 V machine we have for sale. Contact us for more information about this machine.

travel -x axis: - mm travel -y axis: - mm travel -z axis: - mm control: HEIDENHAIN - iTNC 530 number of spindle speeds: 18.000 U/min tool taper: HSK-A63 5-axis simultaneous machining center | HERMLE - C 20 U equipped with ITC & pallet changer. The machine is in a well-maintained condition, works in Switzerland. The machine and can be inspected at any time under power. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: C 22 | C22 | C-22 | C22U The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 3-axis HERMLE U 630 T was manufactured in 2001. It features an X-axis travel of 630 mm, Y-axis travel of 500 mm, and Z-axis travel of 500 mm. The machine includes a table size of 900 x 528 mm and a maximum table load of 400 kg. If you are looking to get high-quality machining capabilities, consider the HERMLE U 630 T vertical machining centre we have for sale. Contact us for further details.

This 3-axis HERMLE C600V was manufactured in 1999. It features a fully enclosed design with dual front sliding doors and an ergonomic tool changer system. The machine is equipped with a HEIDENHAIN control unit, ensuring precision and reliability. If you are looking to get high-quality machining capabilities, consider the HERMLE C600V vertical machining centre we have for sale. Contact us for further details.

This 3-axis Hermle C800V was manufactured in 1996. It features a SK40 spindle, capable of reaching up to 15,000 RPM, and includes tool length measuring. Ideal for precise vertical machining tasks. Contact us for more information about this machine.

This 3-axis HERMLE U 630 T was manufactured in 1999. It features a Heidenhain TNC 415 control system, ensuring precision and reliability in operation. The machine is in very good condition and fully operational. If you are looking to get high-quality milling capabilities, consider the HERMLE U 630 T universal milling machine we have for sale. Contact us for further details.

vertical machining center, year 2002, CNC TNC 430. Used machine in good condition. More info & price on IndustrialBuyer.

This 3-axis HERMLE UWF 1002 H was manufactured in 1995. It features an X-axis travel of 700 mm, Y-axis travel of 630 mm, and Z-axis travel of 500 mm. The machine has a table load capacity of 700 kg and a table surface area of 1000 x 490 mm. If you are looking to get high-quality machining capabilities, consider the HERMLE UWF 1002 H vertical machining centre we have for sale. Contact us for further details.

x-travel: 630 (875) mm y-travel: 500 mm z-travel: 500 mm Control: Heidenhain TNC 430 turning speeds: 20-7.000 U/min feed: 0-15.000 mm/min tool change unit: 16-fach rapid power traverse in X-and Z direction: 15 m/min tool taper: SK 40 table surface area: 900 x 528 mm max. table load: 400 kg spindle diameter in front bearing: 55 mm swivellable: 0-90 ° quill stroke: 75 mm spindle hours: 9.546 h total power requirement: 12/7,5 kW weight of the machine ca.: 4,8 t dimensions of the machine ca.: 4 x 3,6 x 2,2 m HERMLE U 630T 3-axis machining centre, built in 1999 The X-axis, with a stroke of 630 mm, can be extended to 875 mm by swivelling the tool changer out of the way. Accessories: Tool holders, see pictures The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

5-axis machining center, year 2004, CNC 840D. Used machine in good condition. More info & price on IndustrialBuyer.

A CNC universal tool milling and drilling machine Hermle is available. Travel X/Y/Z: 700mm/550mm/500mm, quill stroke: 95mm, spindle power: 12kW, spindle speed: 4200rpm, spindle swivel: +/-75°, tool holder: SK40, clamping force: 12kN, feed rate: 10m/min, rapid traverse: 10m/min. Machine dimensions X/Y/Z: approx. 4400mm/4250mm/2300mm, weight: approx. 4500kg, control: Heidenhain TNC 425. Documentation available. An on-site inspection is possible.

X-axis: 500mm, y-axis: 430mm, z-axis: 400mm, table dimensions: 510x450x410mm, max. table load: 250kg, angular clamping table: 800x390mm, feed rate x-/y-axis: 4-1600mm/min, z-axis: 4-1000mm/min, feed force: 5000N on all axes, rapid traverse x-/y-axis: 1.6m/min, z-axis: 1m/min, tool holder (DIN 2079): ISO 40, cutter drawbar thread: M16, hydromechanical tool clamping: 12,000Nm, quill stroke: 80mm, drive power: 3kW, 18-speed sliding-gear transmission: manually or automatically selectable, torque: 5Nm, spindle speed: 50-2500rpm, connected load: 6kW, control: Heidenhain TNC 114B (hand control type HS262), display resolution: 0.005mm, length: 1400mm, width: 1300mm, height: 1830mm, weight: 1.6t, space requirement: 2300x2300x2400mm, equipment: machine light, coolant tank: 18l, external coolant supply: 3bar, various tool holders, spindle tool. On-site inspection is possible.

Various sub-equipment from a training workshop, to hand over individually, e.g. lid sub-device with upper beam and counter holder, Universal part apparatus with initial division Walter UTA150E with counter holder and rotary chuck 3 partial discs with parts see above, Part apparatus Walter can be swivelled without initial division. Furthermore Luenetten standing and running, on request please Specify the tip height and distance mid prism to mid plan area. Rest according to photo. Other sub-equipment susengar, Direct division Indirect division, various large sum. Please ask Sub-discs for UTA 150 E 22 24 29 36 37 49 57 63 16 30 33 36 39 51 57 63 16 27 30 33 41 47 53 61 Special price

x/y/z = 500/360/400 mm, max. 4000 rpm, 4 clamping corner, 1 pushbutton, various shots, cabinet Lista

With CNC control, HEIDENHAIN, Type: TNC 155, measuring taster Separate control cabinet: 1260 x 500 x 1700 mm Travel distances 700 x 550 x 550mm Table area 1000 x 490 mm Accessories: Treatment / Cooling system / tool shots The machine stored since 2013. At the time of storage, the machine was fully functional.; ready for use

x-400,y-330,z-350,angle table 630x335,SK 40, 40-6,000 rpm,measuring probe

Table clamping area: 190 x 710 mm Table movement x: 390/360 mm Table movement y: 150 mm Table movement z: 280 mm Spindle holder: SK 40 Spindle speeds: 100 - 3100 rpm Feeds longitudinal 0 - 600 mm/min electr. Connection: 380 V, approx. 1.5 kW Space requirement: 1400 x 1200 x 1500 mm Weight: approx. 680 kg

x-travel: 600 mm y-travel: 400 mm z-travel: 420 mm Control: Heidenhain Tnc table-size: 900 x 460 mm turning speeds: 4000 U/min total power requirement: kW weight of the machine ca.: 2,9 t dimensions of the machine ca.: 3 x 2 x 2 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel:850 mm y-travel:630 mm z-travel:500 mm spindle taper ISO:40 milling head speed:25 - 4200 U/min table surface area:560 x 1200 mm total power requirement:15 kW weight of the machine ca.:4 t dimensions of the machine ca.:4,3 x 4,4 x 2,3 m with CNC HEIDENHAIN TNC 415

Control: iTNC 530 Max.travel range: X 850 mm Y 700 mm Z 500 mm A +/- 115? C nx 360? Spindle speed ? 18000 rpm Taper ? HSK 63 Tool changer ? 38+44 positon Coolant tank: 900l machine has spindle cooling, Erowa clamping system is available, measu

Stock number: 3886 PROCESSING Manufacturer: HERMLE, Type: C800 V Machine NO.: 15521, Year of manufacture: 2002 Specifications: Table size 1000 x 560 mm Large table load 1500 kg Longitudinal movement (X) 800 mm Transverse movement (Y) 600 mm Vertical movement (Z) 500 mm Spindle cone SK 40 Infinitely variable spindle speeds 10000 rpm Spindle motor 25/16.8 Kw Total power 43 KVA Tool changer 30 places Feed rate 1-2000/30,000 mm/min Rapid traverse 35 m/min Control Heidenhain TNC 530 Fabr. Operating hours spindle 10220 hours Accessories: Chip conveying. Cooling water system. Probe Renishaw OMP 60 Cooling by spindle Spindle Cooling Machines vice. Miscellaneous accessories. Operating instructions Delivery time: August 2024 Length: 2700 mm, Height: 2930 mm, Width: 2210 mm, Weig ...

Hermle B300 Universal Machining Centre (5-axis): Year of construction 2012 Heidenhain iTNC530 control with DXF import option Tool magazine with 30 places Tool holder HSK-A 63 spindle with 15,000 rpm IKZ with 40Bar Blowing air through spindle center Blum Laser Tool Measurement Heidenhain Probe TS440 Oil and Emulsion Separation Plant Rinsing gun Zero-point clamping system: Partool Powergrip 160 (4-fold) Weight: approx. 7.5t Machine times (as of 04/2024): Machine on: 20.272h Spindle on: 6.618h

Universal milling machine Hermle UWF 802M with Heidenhain TNC124 track control in super CONDITION Specifications: Year of construction approx. 1996 Rigid angle table Speed: 17 to 3550 rpm Infinitely variable feed in 3 axes from 0 to 1600 mm/min Drive Power .:6 KW Travel X/Y/Z: 500/430/400 mm Vertical Quill and Horizontal Quill - SK40 Hydraulic tightening system Weight approx. 2000 Kg Dimensions Length 1.8 m , Width 1.8 m , Height 1.9 m Accessories and equipment: >> Heidenhain TNC124 Track Control >> Hydraulic clamping vertically and horizontally >> Automatic central lubrication >> spindle brake >> operating instructions About the machine : A Hermle UWF 802M tool milling machine with Heidenhain TNC 124 route control is offered. This universal milling machine is in very good condition. A very easy-to-use route control. Lengths and radius corrections are possib ...

x-travel: 600 mm y-travel: 450 mm z-travel: 400 mm Control: Heidenhain 430 ITNC tool taper: SK 40 spindle turning speed - stepless: 13465 U/min voltage: 400 V control voltage: 24 V weight of the machine ca.: 6 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 600 mm, 450 mm, 400 mm

x-travel: 600 mm y-travel: 450 mm z-travel: 400 mm Table size: 850 x 440 mm Spindle holder: SK 40 Control: HEIDENHAIN TNC 355 Spindle speeds: 20 - 4000 rpm Spindle motor: 5.9 kW Quill stroke: 80 mm Feeds - longitudinal/transverse/vertical: 1 - 2000 mm/min Feed force x/y/z: 7200 N Rapid traverse longitudinal and transverse: 10 m/min Rapid traverse vertical: 10 m/min Total power requirement: 12 kW Machine weight approx.: 2.5 t Dimensions L x W x H: 2.7 x 2.5 x 2.0 m Handwheel, coolant device

x-travel: 390/410 mm y-travel: 290/310 mm z-travel: 380/400 mm total power requirement: 4 kW weight of the machine ca.: 1,25 t dimensions of the machine ca.: 2100x2100x1700 m technical data please see attachment! The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CNC Milling Machine Universal Manufacturer: HERMLE Type: UWF 902 S Year of Make: 1995 Hours: 65 071 Control: HEIDENHAIN TNC 426 Working area X/Y/Z: 600 x 450 x 500 mm Range: Spindle speeds infinitely variable within 3 switching stages: 20 to 6,300 rpm Tool holder: SK40 Tool Changer Tool holder, horizontal and vertical: ISO 40 DIN 2079 Tool clamping hydromechanical, clamping force (vertical): 10 000 N Tool clamping hydromechanical, clamping force (horizontal): 12 000 N Spindle diameter on front bearing, horizontal / vertical: 75 / 55 mm Quill Ø 100 mm extendable vertical: 75 mm M & H 3D Probe Individual feed motors for each axis – three-phase current (brushless) Feed range in X, Y, Z manual / program-controlled: 1 to 2000 / 10 000 mm/min. Feed force in all axes (at 80% DC): 6 000 N Rapid traverse in all axes: 10 m / min. Angle table: 900 x 458 mm Table wei ...

CNC Milling Machine Universal Manufacturer: HERMLE Type: UWF 902 H Year of Make: 1995 Hours: 46,680 Control: HEIDENHAIN TNC 426 Working area X/Y/Z: 600 x 450 x 500 mm Range: Spindle speeds infinitely variable within 3 switching stages: 20 to 6,300 rpm Tool holder: SK40 Tool Changer Tool holder, horizontal and vertical: ISO 40 DIN 2079 Tool clamping hydromechanical, clamping force (vertical): 10 000 N Tool clamping hydromechanical, clamping force (horizontal): 12 000 N Spindle diameter on front bearing, horizontal / vertical: 75 / 55 mm Quill stroke vertical: 75 mm Renishaw 3D Probe Individual feed motors for each axis – three-phase current (brushless) Feed range in X, Y, Z manually / programmatically: 1 to 2000 / 10 000 mm/min. Feed force in all axes (at 80% DC): 6 000 N Rapid traverse in all axes: 10 m / min. Angle table: 900 x 458 mm Universal clamping  ...

x-travel: 400 mm y-travel: 330 mm z-travel: 350 mm total power requirement: 6,3 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 736 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control: HEIDENHAIN TNC-430 x-travel: 800 mm y-travel: 600 mm z-travel: 500 mm B-axis (table): 280 mm table swivelabel +/-: 220 (+/-110) ° -C-axis table rotating: 360 ° tool magazin:: 30 spindle taper: HSK63 spindle turning speed - stepless: -15000 U/min rapid traverse feeds rotary table: 36 U/min rapid travel x/y/z: 36 m/min Overall size: 3800X3600X3000 mm weight of the machine ca.: 8.5 t Coolant through spindle: pressure: 40 Bar 3D measuring tracer: RENISHAW Chip conveyor: Coolant installation: SIEMENS 840D www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Travel: X= 600, Y= 400, Z= 420 mm Speed range: 20 – 4000 rpm Gear Stages: 3 Mount: SK 40 Quill stroke: 75 mm Spindle motor: 5.9 kW Feed range: 1 – 5000/6000 mm/min (man./program.) Rapid traverse x, y: 7 m/min Rapid traverse z: 6 m/min Clamping area: 900 x 458 mm Weight: approx. 2300 kg Various tools (without cabinet)

Key data: 600 mm, 400 mm, 420 mm

Hermle UWF 900 Universal CNC Milling Machine BAZ Year of Make: 1996 Machine number: 11410 Machine weight: 2,900 kg Availability: By arrangement. Machine is still energized and in perfect condition.

Machine data: Control Heidenhain TNC 355 Year of manufacture 1989 Travel: X 600 mm travel Y 450 mm travel Z 400 mm travel Spindle speed 20 – 4000 min-1 Angle table size 850 x 440 mm Swivel table 650 x 395 mm Electronic handwheel The machine is still energized and in good condition.

Hermle milling machine

Key data: 600 mm, 500 mm, 450 mm

Universal milling machine Hermle UWF 900 E Manufacturer: Hermle Model: UWF 900 E Year of Make: 1990 Factory No.: 1893 Specifications Travel: X-axis (longitudinal movement): 600 mm Y-axis (transverse movement): 500 mm Z-axis (vertical movement): 450 mm Quill: 100 mm, extendable Spindle head swivel range: ±90° Milling spindle front bearing: Ø 55 mm Tool holder: SK40 DIN 2080 or SK40 DIN 69871 or BT40 Table size (universal clamping table): 420 x 650 mm, expandable to 935 mm NC rotary table (4th axis): Ø 380 mm, swivelling ⚙️ Equipment / Accessories: Vertical milling head with quill and fine adjustment Universal face and angle milling head Heidenhain Control Particularly suitable for Individual and small series production Tool and mould making Precision and complex milling work Condition Well-maintained, fully funct ...

Travel X/Y/Z: 700mm/550mm/500mm, table dimensions X/Y: 1000mm/490mm, tool holder: SK40, speed: 3150rpm, quill stroke: 100mm. Machine dimensions X/Y/Z: approx. 3500mm/2500mm/2100mm, weight: approx. 3300kg, control: Heidenhain 415, operating hours: approx. 64000h. Including coolant pump and an enclosed length measuring system LS403C. Documentation available. An on-site inspection is possible.

A CNC universal tool milling machine Hermle is available. Travel X/Y/Z: 700mm/550mm/500mm, table dimensions X/Y: 1000mm/500mm, quill stroke: 100mm, tool holder: SK40, spindle speed: 3150rpm, feed rate: 2m/min, rapid traverse: 5m/min, max. workpiece weight: 400kg. Machine dimensions X/Y/Z: approx. 3900mm/3300mm/2100mm, weight: approx. 3300kg, control: Heidenhain TNC 150. An on-site inspection is possible.

x-travel: 800 mm y-travel: 600 mm z-travel: 500 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Travel X/Y/Z: 600mm/400mm/420mm, feed rate X/Y/Z: 6m/min, rapid traverse: 6m/min, spindle power: 8kW, speed: 4500rpm, quill stroke: 75mm, table dimensions X/Y: 900mm/450mm. Machine dimensions X/Y/Z: approx. 2800mm/2200mm/2100mm, weight: approx. 2800kg, control: Heidenhain 415B, hours: approx. 56193h. Includes cooling lubricant system and 3D measuring probe. The brake of the Z axis is to be replaced. Documentation available. An on-site inspection is possible.

Key data: 450 mm, 600 mm, 330 mm

Catalog No. : 8975 Type: C 22 U Producer: Hermle Made in: 2018 Characteristic: Control system: Heidenhain TNC 640 Total hours: 23,000 h Number of stack positions: 192 Number of axis: 5 pcs X-Axis travels: 450 mm Y-Axis travels: 600 mm Z-Axis travels: 330 mm Block speed: 18000 1/min Taper: HSK-A63 Internal cooling: 80 bar Rotary table Ø 320 mm A ±135° / C 360° Hermle IH30/60 handling system (active) BLUM tool measuring system (LC50) BLUM workpiece probe (TC52) Dynamic Precision

CNC vertical machining center Type: U 630 T Manufacturer: Hermle Year: 2001 Control: Heidenhain TNC 426 X: 630 mm Y: 500 mm Z: 500 mm Max spindle speed: 7000 rpm Spindle motor: 7,5 kW Spindle taper: ISO 40 Table: 900 x 528 mm Max table load: 400 kg Machine weight: 4800 kg Tool probe: Heidenhain TS 220 Documentation Machine in good condition, fully functional, under power. Find more here - .ucymachines/ Contact us at - sales@ucymachines

CNC machining centre HERMLE U 1000 T – universal milling machine For sale is a high-quality CNC universal machining center from the renowned manufacturer Hermle, model U 1000 T. The machine impresses with its stable design, high precision and versatile applications. Ideally suited for toolmaking, single part production and demanding milling work. General information: Machine Type: CNC Machining Center / Universal Milling Machine Manufacturer: Hermle Model: U 1000 T Year of Make: 1999 Control: Heidenhain TNC 426 Condition: Used, good general condition, functional Shipping time: Immediately available Technical data: Travel (X / Y / Z): approx. 1000 / 630 / 550 mm Table size: approx. 1200 × 630 mm Tool holder: SK 40 Spindle speed: up to approx. 7000 rpm Tool magazine: approx. 16 places Quill stroke: approx. 75 mm Milling head: swivel 0 – 90° (unive ...

Three old Hermle and Deckel milling machines are available. 1) Horizontal milling machine Hermle FW 801, tool holder: SK40, travel X/Y/Z: 430mm/150mm/420mm, speed: 2000rpm, machine dimensions X/Y/Z: approx. 2250mm/1700mm/1500mm, weight: approx. 1000kg. 2) Universal milling machine Hermle FW 710, tool holder: SK30, table dimensions X/Y: 710mm/190mm, travel X/Y/Z: 400mm/150mm/350mm, speed: 2240rpm, machine dimensions X/Y/Z: approx. 1500mm/1000mm/1800mm, weight: approx. 700kg. 3) Deckel FP 2, year of manufacture: 1987, tool holder: SK40, travel X/Y/Z: 300mm/2200mm/400mm, table dimensions X/Y: 620mm/390mm, max. table load: 250kg, speed: 3150rpm, feed: 3600mm/min, rapid traverse: 4000mm/min, machine dimensions X/Y/Z: approx. 2500mm/2100mm/1800mm, weight: approx. 1250kg, control: Heidenhain TNC 355. An on-site inspection is possible. Individual sale possible, however a package sale is preferre ...

x-travel: 600 mm y-travel: 450 mm z-travel: 400 mm table-size: 850 x 440 mm spindle taper: SK 40 control: HEIDENHAIN TNC 355 ATC: 32 Pos spindle turning speed range: 20 - 4000 U/min spindle drive: 5,9 kW quill stroke: 80 mm feeds longditudinal/cross/vertical: 1 - 2000 mm/min power feed x/y/z: 7200 N rapid traverse longitudinal and cross: 10 m/min rapid traverse vertical: 10 m/min total power requirement: 12 kW weight of the machine ca.: 3 t Acc.: NC-dividing unit (=4th axis) make WALTER with 3-jaw chuck 160 mmø, vertical head with hydr. tool clamping and quill retraction, solid table, various tool fixtures, electron. hand wheel, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

For sale is a very well-maintained and technically flawless Hermle U 630 T universal milling machine from German quality production. The machine is in exceptionally good condition and was mainly used for single part or small series production. Particularly noteworthy is the low use: only approx. 11,000 switch-on hours only approx. 3,100 spindle hours The milling head or spindle was professionally overhauled directly at Hermle. Invoices and evidence for this are available. The machine can of course be inspected and tested under power. Technical data Manufacturer: Maschinenfabrik Berthold Hermle AG Model: Hermle U 630 T Year of Make: 2001 Control: Heidenhain TNC 426 Travels: X: 630 mm Y: 500 mm Z: 500 mm Spindle holder: SK40 Swivelling milling head Tool changer: 16-speed Switch-on hours: approx. 11,000 h Spindle hours: approx. 3,100 h  ...

5-axis machining center Type: U 1130 Manufacturer: Hermle Year: 2005 Control: Heidenhain TNC 530 X: 1130 mm Y: 720 mm Z: 630 Spindle taper: HSK63 Tool magazine: 28 positions IKZ 40bar Laser tool breakage detection Machine weight: 8500 kg Chip conveyor Machine in good condition, fully functional, under power Find more here - .ucymachines/ Contact us at - sales@ucymachines

Key data: 800 mm, 600 mm, 500 mm

For sale is a high-quality CNC-controlled 5-axis vertical machining center Hermle B 300 U, built in 2008, with Heidenhain iTNC 530 control. The machine is equipped with NC swivel rotary table Ø 280 mm and is ideal for precise 5-axis machining, toolmaking, mold making, single part production and complex CNC milling work. Technical data: Manufacturer: Hermle Type: B 300 U Year of Make: 2008 Machine No.: 19599 Control: Heidenhain iTNC 530 Travel X/Y/Z: 800 / 600 / 500 mm Spindle speed: 15,000 rpm Tool holder: SK40 Tool changer: 30 places NC swivel rotary table: Ø 280 mm Machine weight: approx. 8,500 kg Connection: 400 V / 50 Hz Total power: 41 kVA Equipment: 5-axis version NC swivel rotary table Ø 280 mm Heidenhain Probes Electric hand control module Scraper belt conveyor Coolant Setup closed cabin Electrical heat compensation Swarf Spray Gun

CNC - Universal milling machine HERMLE UWF 902-S -Heidenhain 426 -Built in 1997 -Travel X/Y/Z 600-450-500mm -Speed range 20-6300 rpm -Tool holder SK40 -Vertical - Horizontal milling device -Drill quill -Coolant device -Angle table -Machine enclosure -Documentation Dimensions: LxWxH 3,9x2x2Meter / Weight 4000Kg Hobkn Au Sjv Iklus Tol

With CNC control, HEIDENHAIN, type: TNC 155, with touch probe Travel: x=700 y=550 z=550mm. Size table area 1000 x 490 mm Accessories: Chip conveyor / coolant system / tool holders SK3. Machine is presentably ready for operation under power. Milling machine with protective cabin. The milling machine can be operated at any time without protective cladding and is then "quite handy". Dimensions of milling machine: , width is 1.6m, depth is 2.3m, height is 2.15m and cabinet width is 1.5m

x-travel: 700 mm y-travel: 550 mm z-travel: 500 mm spindle taper ISO: 40 control: Heidenhain type: TNC 155 milling-head swivable +/-: boring spindle: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG ...

x-travel: 500 mm y-travel: 360 mm z-travel: 400 mm Control: Siemens 810 tool taper: SK 40 table surface area: 800x390 mm T-slot - width: 14H7 mm number of T-slots: 6 T-slot - distance: 63 mm turning speeds: 20-4000 U/min transmission ratio: 4 Feed: 1-2000 mm/min rapid traverse: 5 m/min total power requirement: 9 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 2,5x2,9x1,9 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appoint ...

x-travel: 530 mm y-travel: 430 mm z-travel: 400 mm spindle taper ISO: 40 milling-head swivable +/-: boring spindle: : 650x440 mm table - swivable: Grad turning speeds: 45-2000 U/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m HS 570 4953 Automatic clamping spindle mount The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data  ...

Ref.nr. 00937 Name of the tool milling machine Manufacturer: Hermle Model UWF 800 HS 57 Year of manufacture 1995 general overhauled (Investment of approx. 41,158 euros) Condition Functional Remark: Non-functional digital display of the setting values. The setting values can be read mechanically on the screw wheels. Accessory box: With clamping sets, shaft extensions, mounts, etc. The digital display for the setting parameters does not work. The machine can otherwise be used in full working order, the setting parameters can be read manually on the adjustment wheels. Extensive accessories including mounts, shaft extensions, etc. are attached according to photo. Customer writes: System is fully functional, except that the digital setting display no longer works. But all settings can be read analogously on the machine. Deadline CW 43/2026 [Oct. 19-23, 2 ...

X-axis travel: 700 mm, Y-axis travel: 550 mm, Z-axis travel: 500 mm, spindle speed: 25 to 4200 rpm, three speed ranges, feed rate: 1 to 5000 mm/min, rapid traverse in X, Y and Z: 10 m/min, vertical quill travel: 95 mm, clamping table dimensions: 1000 x 500 mm, spindle motor power: 12 kW, connected load: 18 kW, control system: Heidenhain TNC 355, length: 4260 mm, width: 4400 mm, height: 2300 mm, weight: 3.5 t, operating hours: 31,248 h. The machine is equipped with an SK40 tool spindle in accordance with DIN 2079, a swivelling spindle head, a spindle head that can be swung away for machining with the horizontal spindle, an outboard support for horizontal machining, direct measuring systems, a coolant system with a 100 litre reservoir, approximately 38 tool holders, most of which are fitted with tools, a table with tool holders, a workbench with cabinet, various hand tools, various clampin ...

x-travel: 630 mm y-travel: 500 mm z-travel: 500 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control Heidenhain TNC 426 electronical hand wheel manual swivel head quill coolant device measuring feeler Technische Daten: /technical details X Weg / x travel 630 mm Y Weg / y travel 500 mm Z Weg / z travel 500 mm Drehzahlbereich 2-stufig / spindle speed range (2-steps) 20 - 7000 UpM / rpm Eilgang / rapid feed 15 m/min. Spindelaufnahme / spindle taper SK 40 Gewicht der Maschine ca. / weight 4500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm total power requirement: 3 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 2 x 2 x 2 m No. 2392 Universal tool milling machine HERMLE UWF 801 Working area: 500 x 430 x 400 mm Drive: 3 kW Control: TNC 135 With manual control: Working area 520 x 450 x 410 mm, fixed table 800 x 400 mm Tool holder SK 40 18 spindle speeds from 40 - 2000 1/min Feed stepless x,y 4 - 1600 mm/min z 4 - 1000 mm/min Dimensions 2.3 x 2.3 x 1.7 m Weight 1350 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 510 mm y-travel: 450 mm z-travel: 410 mm taper in main spindle: MAS BT 45° (SK40) table surface area: 800 x 395 mm T-slots: 6 Stk. turning speeds: 50 - 2500 U/min feed stepless: 4-1600/4-1000 mm/min voltage: 400 V total power requirement: 5.0 kW weight of the machine ca.: 1400 kg range L-W-H: 2300 x 2300 x 1800 mm from a training workshop maintained condition () - in checked conditions - machinevideo - https://www.youtube.com/watch?v=iSTVEdv2fO8 Furnishing : - robust universal milling machine - swiveling control panel, right front - rotatable universal milling head (re/li = 90°) with hydraulic tool clamping - manual milling spindle feed, with locking - swiveling milling spindle protection - Stable T-slot clamping/angle table - Axis feeds with rapid traverse - Central lubrication unit - Control cabinet, installed on the left Digital display - without function The data fo ...

x-travel: 500 mm y-travel: 430 mm z-travel: 400 mm total power requirement: 4 kW weight of the machine ca.: 1,4 t dimensions of the machine ca.: 2 x 2 x 2 m No. 3999 Universal tool milling machine HERMLE UWF 801 Working area: 500 x 430 x 400 Drive: 3 Control: Heidenhain TNC 135 Fixed table 800 x 390 mm chip tray documentation Spindle SK 40 Speed range 50 - 2500 min-1 Space requirement approx. 3 x 3 x 2 m Weight approx. 1400 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm total power requirement: 4 kW weight of the machine ca.: 1,8 t dimensions of the machine ca.: 222 m 1 x UWF 700 Digi 3 x UWF 801 TNC 135 + 124 1 x UWF 802 M From stock liquidation, partly not functional / in need of repair Price VHS / against bid The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 410 mm y-travel: 310 mm z-travel: 400 mm total power requirement: 2,2 kW weight of the machine ca.: 1,2 t dimensions of the machine ca.: 222 m Universal tool milling machine HERMLE UWF 700 Spindle holder SK 40 Speed range 40-2000 min Space requirement approx. 2 x 2 x 2 m Weight approx. 1100 kg For further data see attached PDF Rigid table 700 x 285 Horizontal milling machine vertical - milling head enclosed - partially rep. conditioned Documentation Working area: approx. 410 x 310 x 400 Drive: 2,2 Heidenhain digital display The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
