mikromat grinding machines used for sale

Very good surface grinding machine Table surface / working area 200 x 600 mm

Please see the pictures for the data!

Workpiece diameter range: 2mm-320mm, max. grinding length: 500mm, center distance: 1000mm, max. workpiece weight: 150kg. On-site inspection is possible.

Offered is a high-precision worm and thread grinding machine MIKROMAT 20G, used as a test and trial machine, nearly all available options included, technically flawless condition. Capabilities: external thread grinding, internal thread grinding, whirling Whirling, grinding length max. 2000mm, workpiece diameter max. 320mm, distance between centers: 2250mm NC tailstock option: 2050mm, workpiece weight max. 200kg 350kg NC tailstock, pitch range: 0-400mm, 7-axis system, feed speed: up to 15000mm/min, setting angle: +/-40°, positioning accuracy: uncertainty 0.0024mm P, upgrade to 23.5kW continuous power/45kW maximum power, grinding wheel speed: up to 50m/s, special equipment internal grinding: internal thread diameter up to 100mm, length up to 50mm, coolant system: KNOLL compact unit vacuum rotary filter, 2500l tank volume and oil cooling, installation dimensions X/Y/Z: approx. 6500mm/4000m ...

CNC vertical jig boring machine WMW MIKROMAT Type BKoZ 900x1400/5NC Travel X 1120 mm Travel Y 710 mm Spindle travel Z 315 mm Travel W 630 mm Numerical Command CNC NUM 1060 Spindle Ø 125 mm Cone SA40 Rotation from 36 to 2240 RPM Table size 1400 x 900 mm Distance between colums 1080 mm Maxi distance spindle nose/table from 0 to 900 mm max Maxi eligible load on table 1000 kg max Separate electrical panel Machine renewed in 2000 with CN NUM1060 Voltage 380 V Dimensions (L x W x H) 4000 x 2460 x 3030 mm Weight approx. 9 T MACHINE IN OUR STOCK IN FRANCE.

MIKROMAT Model / type:BKoE 630x1000 Technical data: > Mikromat BKoE 630 x 1000 > table clamping surface 1000 x 630 mm > longitudinal travel of the table 710 mm > cross travel of the table 700 mm > travel of headstock 630 mm > spindle stroke 200 mm > distance between spindle nose and table 20-850 mm

BKOZ 900x1400 spindle taper MK IV sleeve stroke 250mm table size 900x1400mm longitudinal 1000mm cross 750mm vertical movement by the head of main spindle 600mm spindle speeds 28-1400 Upm spindle feeds 0,02-0,8mm/U scales wreaths for all directions of motion hydr. clamping system coolant system sep. control cabinet Motor: 230/380V 50HZ 8KW dimensions base: 3.300 x 2.400mm height: 2.500mm weight: 7.500 kg

Key data: 2700 mm, 2200 mm, 1050 mm

CNC travelling column machining centre from the manufacturer MIKROMAT Werkzeugmaschinen GmbH & Co. KG, Dresden, designed for the precise and heavy-duty machining of large-format workpieces. The machine is designed in a classic travelling column design and is particularly suitable for tool, mould and machine building with a new design. Distance spindle nose – table Vertical: approx. 300 – 1,350 mm with universal milling head (UFK): Vertical: approx. –290 to +760 mm Horizontal: approx. –55 to +995 mm in the table area: approx. 180 – 955 mm Spindle / Speeds Spindle without extension: 10 – 6,000 rpm Spindle with extension: 10 – 6,000 rpm Universal milling head (UFK): 10 – 4,000 rpm Universal milling head (UFK) Rotation around vertical axis: 360° (indexing 2.5°) Horizontal axis swivel: ±110° (indexing 2.5°) Electrical data (nameplate) Connected load:  ...

spindle diameter: 125 mm x-travel: 1120 mm y-travel: 710 mm z-travel: 315 mm w-axis: 630 mm size of pallet: 1400 x 900 mm table load: 2 t number of T-slots: 9 Stück distance between columns: 1080 mm distance between table/spindle: 900 mm tool taper: SK 45 feed speeds: 16 - 500 mm/min rapid traverse: 10 m/min spindle motor: 5,5 kW spindle turning speed range: 28 - 1400 U/min max. torque on the spindle: 250 Nm total power requirement: 7 kW weight of the machine ca.: 7,5 t space requirements approx. LxWxH: - m DOUBLE COLUMN JIG BORING MACHINE - Hydraulic Unit - Coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

workpiece diameter: 320 mm threading length: 570 mm thread pitch: 315 mm total power requirement: 17 kW weight of the machine ca.: 12 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning length: 600 mm turning diameter over bed: 360 mm turning diameter over slide rest: 190 mm bed width: 295 mm number of spindle speeds: 45 - 2240 U/min. spindle bore: 33,0 mm tailstock quill taper MT: MK 3 feed: Längs 0,02-0,8 mm/U feed: Quer 0,0125-0,5 mm/U total power requirement: 5,5 kW weight of the machine ca.: 1900 kg range L-W-H: 2050 x 950 x 1280 mm Refurbished and repainted in 2013 Costs around 16.000 euros Furnishing: - WNW NILES 3-jaw chuck Ø 200 mm - Multifix steel holder size B with inserts - revolving center points - chuck key - Movable tailstock - Operation manual The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 3-axis MIKROMAT 8V gantry milling machine was manufactured in 2000. It features an Andronic 2000 control system, automatic tool change with a 16-position ATC, and a high-speed spindle capable of up to 30,000 rpm in short bursts. Equipped with a BLUM laser system for precise tool monitoring and measurement, and a scraper belt conveyor by Knoll for efficient chip removal. Consider the opportunity to buy this MIKROMAT 8V gantry milling machine. Contact us for more information about this machine.

This 4-axis MIKROMAT 20V gantry milling machine was manufactured in 1998. Ideal for precision milling, it offers robust construction and reliable performance. Consider the opportunity to buy this MIKROMAT 20V gantry milling machine. Contact us for more information.

Code 0776 Description Surface grinding machine Make ELB Type SWBD 030 MCNC82 Machine No. 18.346.0383 Manufacturing date 1983 Control MCNC / 82-PC Tablesize 3520 x 600 mm Table grinding size L x B x H 3000 x 600 x 600 mm Magnetical plate size L x B 3000 x 400 mm Speed table movement 0,2 – 6 m/min. Max. distance table – centre grinding wheel 850 mm Speeds vertical 3 – 375 mm/min. Speeds cross 1,2 m/min. Speeds grindingwheel stepless 750 – 1400 omw/min Grindingstone: Ø 600 x Wide:100 x Bore: 200 mm Weight 18.000 kg Motor power 37 kW – 380 Volt Accessoiries Electro table 3000 x 400 mm Grinding unit with water cooling Filtering unit with paperfilter Profile grinding unit Condition Machine is in very good condition

GER RS-12/50 surface grinding machine. Grinding area: 1200x550mm. Distance table-centre of spindle: 625mm. Table speed: 2 to 25m/min. Maximum table travel: 1250mm. Maximum work weight: 1200Kgs. Maximum cross travel: 500mm. Grinding wheel size: 400x80x127mm. Manual diamond grinder. Vertical orientable headstock. Vertical automatic feed. Power of grinding spindle: 12,5cv. Weight: 4500Kgs.

220627 Code Description Universal Cylindrical Grinder Make Jones - Shipman Model 1310 ( 8" x 18" ) Serial No. Year ? Grinding length, max. 450 mm Grinding diameter, max. 203 mm Center height 103 mm Weight workpiece kg Table tilting angle - 15 ° till + 15° Diam. Grinding wheel 350 mm Width Grinding wheel, max. 40 mm Motor power grindingwheel 1.5 kW Speeds Grindingwheel 1750 / 2300 rpm Speeds workpieceholder ( 6x ) 30 – 415 rpm Total power 3.5 kVA 380 Volts Machine size L x W x H 1.7 x 1.2 x 1.75 meters Weight 1800 kg Accessories internal grinding ( 10500-16500-24500 rpm ) coolant some tooling Condition Machine is in good condition

Machine overhaul , Repairs , On-site maintenance at the user's site , Spare parts supply , We specialize in the overhaul and repair of Kellenberger and Strausak universal grinding machines. We have the production and license rights of the company Strausak for the Type 57 U / W the resulting Special machines 82 S , multi-spindle fine milling machines, as well as CNC machines built from type 57 U / W We manufacture special machines especially for the ceramics and carbide industry.

In 2001 we acquired the license and production rights of Strausak. These rights include the entire 57 U / W conventional series as well as the CNC machines of the type U / W CNC in the tool grinding range 3 G / 4 G / 5 G as well as in the universal cylindrical grinding area, the 2 axes / 3 axes and 4 axes CNC machine and special machines 81 CNC. We have an extensive stock of spare parts. Our specialization is the general overhaul of these machines, as well as the new production of the above-mentioned machine types and the production of special machines.

NC – controlled precision rotary table face grinding machine with vertical grinding spindle and cup grinding wheel - brand new Rotary table diameter 400 mm Largest grindable diameter 400 mm Rotary table speeds 0 to 50 rpm infinitely variable Maximum workpiece weight 75 kg Cup grinding wheel Ø 200 mm x H 80 mm Grinding wheel speed 280 to 2,800 rpm infinitely variable Maximum workpiece height 170 mm Smallest programmable infeed dimension of the grinding wheel 0.001 mm Grinding wheel drive power 3 kW Rotary table drive power 0.5 kW Weight approx. 650 kg

ELB Perfect BD 15 PLC surface grinding machine, grinding area 1500 x 550 mm, grinding wheel 400 x 100 mm, electric perm magnetic clamping plate 1500 x 550 mm, automatic dresser with compensation, paper belt filter, the machine is overhauled, grinding spindle rebeared, guideways are scraped, meets the tolerance of a new machine. We are happy to take over the installation / training on site, as well as the subsequent service

Magnetic table 455 x 170 mm Digital Water tank Pulling device Wet grinding device

Precision Surface and Profile Grinding Machine FS1570 SL Grinding area: 1500 x 700 x 650 mm Grinding spindle motor: 18 KW Table drive: hydraulic Transverse drive: electromechanical Paintwork: RAL 6011 – reseda green Equipment: •Central lubrication • Wet grinding device • Fine adjustment knob on the transverse path handwheel • Dressing Diamond • Electro magnetic clamping plate 1500 x 750 mm • Magnetic plate adhesive force control Accessories: • Vertical automatic type SL with "LCD" flat screen and membrane keypad • Electric Straight Dresser • Stepless change of speed • Universal paper filter machine • Machine light • Column elevation by 200 mm • Precision balancing scale • 2 new grinding wheels Machine has been overhauled in 08/2018 "Invoice is available" Here's what was done: •Timing belt •Storage • Ball screw •  ...

ELB Perfect BD 10 750 PLC, Year of construction 2008 Control Siemens STC Grinding area 1000 x 750 mm Grinding wheel 400 x 100 mm Grinding spindle 10 KW Electro Perm Magnetic Clamping Plate 1000 x 750 mm Automatic straight-dressing device with compensation Coolant system with paper belt filter Machine is immediately ready for use CE compliant Installation / on-site training included

Condition of the machine: The machine is currently in a used, unoverhauled condition. All machine wear parts are replaced, including the feed spindle in the X-axis, and all assemblies are restored to like-new condition. After the overhaul, the machine can be easily compared to a new machine. Geometry: The machine is completely dismantled except for the guides. Before the geometry of the individual tables and assemblies can be restored, the two guides of the Z and X axes are scraped by hand and restored to mint condition. After completion of the work, the machine receives a measurement report according to the original specifications of the manufacturer. Electronics: The electronics and the control cabinet housing will be completely replaced. All electrical parts are replaced, including the motors. Hydraulics: The entire lubrication system, including the lubrication un ...

Favretto 500, Rotary table surface grinding machine, horizontal spindle, dia 500mm, electric elettrico with DRO

Cylindrincal grinding machine, KNUTH RSM 750, interna/external, DRO, This machine can be inspected under power in our warehouse., Mimu Machine Tools, Gussago BS Italy

CNC cylindrical grinding machine, STUDER S31 CNC LeanPro, with Pictogramming, Distance between centers: 1000mm, Center heigh 175mm, Grinding Wheel head rotation (B) 360° (1°), 2 ext Grinding Wheels, 1 int Grinding Wheel, Ext Grinding wheel, 400 mm x 40 mm x 127 mm, overhauled spindle > see photos, Workhead, CM 4, 0-1000 RPM, CNC Fanuc, Programming: Pictogramming, Heidenhain linear encoders, This machine can be inspected under power in our warehouse in Gussago BS Italy

The machine underwent a general overhaul in 2015 The following tasks were performed as part of the overhaul: repair of the electrical cabinet and hydraulics, scraping of the bed and table, replacement of bearings in the headstock, new springs for the axial bearings, new table piston rod and sleeves, installation of sludge separators. Documentation for the machine is available. Year of manufacture: 1980.

GENERAL Project No.: 905789 Quantity: 1 pcs. Manufacturer: BUDERUS Type: BDG 220 Control: Siemens 840 D solutionline Year of Make: 2020 Condition: Used machine Spindle Approx (hrs): 3000 Shifts machine one approx. (hour): rarely used DESCRIPTION GRINDING Max. workpiece diameter 440 mm Max. workpiece height 150 mm Travel in X 170 mm Max. rapid traverse speed in X/Z 30 m/min Max. feed speed in X 0.01-15 mm/min Max. speed workpiece spindle 1000 1/min OTHER EQUIPMENT Workpiece probes for measuring thickness deviation Gate sensor Splash protection cladding with fully encapsulated working area Automatic work room door Lighting in the work area Mechanical oil/emulsion mist extraction system Coolant device with paper belt filter High pressure pump 25 bar Mobile control unit for set-up operation with electronic handwheel Machine condition light Au ...

Favretto MD 300 Universal Surface Grinding Machine CNC Manufacturer [manufacturer]: Favretto Type [ type]: MD 300 Control unit: DTG Plus / Siemens 840D Baujahr[construction year]: 10/2006 Table size: 3,220 mm Grinding travel length: 3,200 x 900 x 725 mm Magnetic table/plate size [magnetic table/plate size ]: 3,000 x 600 mm Longitudinal table speed: 1–40 m/min Cross table speed: 5 m/min Cross locking mechanism speed: 1–50 m/min Maximum load: 4,000 kg (without magnetic plate) Grinding wheel size: 508 x 203.2 x 100 mm Grinding wheel speed: 1,400 rpm Motor power of grinding mandrel: 22 kW Weight of the machine approx.: 17,500 kg Dimensions[machine size]: 9,400 x 3,550 x 3,000 mm Accessories: Magnetic tabletop [magnetic tabletop] coolant press with paper filter various grinding wheels [various grinding wheels] Documentation We will be happy to answer any furt ...

CNC cylindrical grinding machine, (carousel) for internal, external and surface grinding. A lot of accessories, such as grinding wheels of different types and sizes. Retrofitted 2007 . Magnetic clamping plate dia 1500mm, Circumferential diameter 1800mm, Largest grinding diameter 1600mm Maximum grinding height 880mm Max. workpiece weight 5to Swivel angle of the grinding spindle: 90° left, 60° right

Control Other Grinding length [mm] 600 Grinding width [mm] 400 Grinding spindle: Speed 1,400 rpm Power 3.7 kW Grinding wheel dimensions (max.) 300 x 50 x 76.2 mm Work table: Clamping surface magnetic clamping plate, 600 x 400 mm Table load (max.) 600 kg Hydraulic table drive Longitudinal table stroke 200 - 650 mm Rapid traverse 28 m/min Grinding area 600 x 400 x 375 mm Equipment/accessories: Measuring System Engine Measurement System in X/Y/Z Dressing system prism arm for einkorn diamond Cooling coolant system with paper belt filter, tank capacity 140 l Other equipment Partial space encapsulation, work area light

-High performance -Belt grinding device height-adjustable 0-90° -Maximum usable face grinding surface -Belt adjustment with fine adjustment -Combined belt grinding/grinding machine -Longitudinal stop for material guidance -Perfectly balanced and low vibration -Double-sided connection for dust extraction Ø 50 mm -Motor circuit breaker with undervoltage trigger -Fixed stop -1 sanding belt standard (brown), grain 80 -1 grinding wheel 250 x 40 x 51 mm, grain 80 -Spark protection -Connection cable with CEE plug -with machine stand, EMERGENCY STOP push button, brake and suction Delivery: in Germany free domicile incl. packaging

Pot discs - diameter:175 mm spindle extension:180 mm operating voltage:400 V Machine weight approx.:300 kg room requirements approx.:0.90 x 0.60 x 1.80 m

Working diameter: 40 - 250 mm Automatic work piece loading and removing for ball diameters: 40 - 105 mm Manual loading for diameters: 105 - 170 mm Direct ball attaching: 170 - 250 mm Rotation speed, stepless: 10 - 300 rpm Grinding spindle speed range: -160 - 3150 rpm -80 - 1580 rpm -38 - 775 rpm -20 - 385 rpm Weight: 6,5 tn Electrical connection: 17 kW Year of manufacturing: 1991

Grinding wheel flange for Kellenberger / Strausak u.-Miwatec grinding machines type 57 U / W in special design. Questions us please at we do extensive accessories for these machine types.

Grinding wheels recording for Kellenberger / Strausak u.-Miwatec grinders. Grinding wheel holder for 76 mm bore. More technical info. on request.

Grinding wheels recording for Kellenberger / Strausak u.-Miwatec grinders. Wheels shot 38 mm. For more details please call us. We carry special accessories in our program. We repair and repaired on the spot and make complete engine overhauls Special grinding machines

Reduction sleeves for work piece headstock recording MK 5 Reduction MK 5 / MK 1 MK 5 / MK 2 MK 5 / MK 3 MK 5 / MK 4 Reduction sleeves with forcing nut. Price indication per piece. We carry new & - used Center points in special dimensions.

We give our wheel bearing. Vitrified bonded grinding wheels for metal processing. From 100 mm to 600 mm in diameter. We carry also diamond and CBN wheels for tool grinding machines new and used. Strausak Fleximat 91 we have yet complete disc sets for all common diameters for the machining of solid carbide and HSS milling and drilling tools. Price and info. on request.

We give our wheel bearing. Ceramic grinding wheels of different binding and hardness. Dimensions von75 mm to 600 mm. The discs are new, unused, and undamaged. Retail possible, price on request.

We have a very wide range of accessories for Kellenberger - Santiago &-Miwatecmaschinen. Grinding wheel flanges new u. - used. Chuck flange recordings MK 5 SK 50 for magnetic Chuck, three & four-jaw Chuck. Running with Center points, and fixed. Three-jaw four-jaw &-special Chuck. Magnetic clamping plates, cross - ring - Sternpolteileung. Truing devices, RADIUS &-inclined dressing Lynetten 2 & 3 jaw

We offer a new Movomatic Tischlängspositionier Setup. The device is new, unused and undamaged. The device is longer years in our camp, we have never used this. It is also can be used with security at other cylindrical grinders manufacturers.

Work table: 750 x 290 mm, table height: 185 mm band length: 2600 mm strap width: 150 mm abrasive belt rear: 850 x 200 mm grinding unit swiveling: 90°-45° belt speed: 20 m / sec. Additional table: 330 x 330 mm oscillation stroke: 20 mm Oszilationsmotor: 0.25 (0.34 kW) suction connection Ø: 120 mm motor power output S1 100%: 3.0 kW (4,0 PS) motor power S6 40%: 4,5 kW (6.0 HP) voltage: 400 V machine dimensions (W x D x H): 1700 x 700 x 1080 mm weight approx.: 180 kg

Band dimensions: 150 x 2000 mm speed: 14.5 / 29 m / sec. Contact plate: 200 mm / 155 mm plan grinding table diameter: 460 x 150 mm Extractor connection: 100 mm in diameter engine power: 4 kW

Surface grinding machine. Magnetic chuck of 550x250mm. Table travel: 700mm. Grind surface area: 600x350mm. Max. height: 375mm. Cross travel: 300mm. Wheel: 350x127x50 / 300x127x100 Weight: 2900Kg.

Tip height: workpiece or grinding diameter 500 mm centre distance: approx. 2000 mm maximum workpiece weight: 1200 kg wheel dimensions: 600 Ø x 300 mm wheel speeds: 965 RPM elect. Supply: 380 V, approx. 15 kW space: 2300 x 9000 x 2000 mm weight: 13000 kg

Tip height: Grinding diameter 250 mm centre distance: loop length 575 mm grinding wheel dimensions: 500 x 60 x 127 mm Electr. Supply: 380 V, approx. 9 kVA kW space: 2650 x 2600 x 2240 mm weight: 3400 kg

Key data: 1000 , 600 , 400

Surface grinders - horizontal ELB perfect BD 10 PLC Second-hand machine overhauled 2014 Surface grinders - horizontal ELB-SCHLIFF perfect BD 10 PLC Second-hand machine Grinding length: 1000 mm Grinding width: 600 mm Workpiece height: 600 mm Table size: 1000 x 600 mm Grinding wheel dimensions: 400 x 100 mm Grinding spindle motor: 11 kW Table speed: 2-30 m / min Grinding wheel speed: 0-35 m / s U/min Total power consumption: 35kW Machine weight approx.: 6 t Space requirement approx.: 3.8 x 2.5 x 2.5 m Part of 2014 overhauled with 12 month warranty Paper machine Magnetic clamping plate 1000 x 600 Automatic dressing device with compensation 1 flange Items put up

Spindle speed min: 9,000 Umd.min Max: 15.000 Umd.min Tip height min: 230 mm Max: 510 mm Spindle stroke: 210 mm Horiz. Table large: 700 x 1000 mm Table stroke: 1,800 mm Equipped with: - feed table - feed Hor. Grinding movement - coolant equipment - protection doors table

specifications: - Load capacity positioning base approx. 750 kg - Flatplate diameter 500 mm - max. workpiece diameter 1600 mm - Height turntable with horizontal position approx. 750mm - Turntable with right,- + left run - Axis of rotation turntable endless 360 ° - Rotation time per revolution 12.5 sec. - Pan left + right - Swivel axis rotation angle 180 ° - Swivel time for 180° swivel angle 10 sec. - 2 x double foot button for turntable + swivel arm - hydr. Clamping bolt for clamping the workpiece in the middle of the turntable - Clamping stroke / clamping distance of the clamping bolt 32 mm - Clamping force pressing / pulling 80 / 48.9 kN - Clamping cylinder female thread M 27 x 40 - Positioning control SIEMENS - Operation manually or via control - Space required approx. W 1500 x D 2800 x H 1100 mm - Weight approx. 2500 kg - separa ...

Band dimensions: 75 x 2,000 mm speed: 14.5 / 29 m / sec. Contact plate ø x B: 200 / 80 mm plan grinding table: 460 x 75 mm suction connection Ø: 100 mm motor power output S1 100%: 2.4 / 3.0 kW absorbed motor power S6 40%: 3.0 / 4.0 of kW voltage: 400V dimensions (L x W x H): 1080 x 440 x 1000 mm weight about: 67 kg

Horizontal grinding optimum surface grinders ELB - 6375 ND - PLC Second-hand machine Surface grinders - horizontal ELB optimal 6375 ND - PLC Second-hand machine overhauled 2016 Surface grinders - horizontal ELB-SCHLIFF optimal 6375 ND - PLC Second-hand machine Grinding length: 600 mm Grinding width: 375 mm Workpiece height: 375 mm Table clamping surface: 600 x 350 mm Grinding wheel dimensions: 300 x 50 mm Grinding spindle motor: 4.7 kW Table speed: 2-30 m / min Grinding wheel speed: 1450 RPM Total power: 12kW Weight approximately: 3.5 t Space requirement approx.: 2.8 x 2.5 x 2.5 m Part overtaken 2016 + 12 months warranty, condition Control with touch screen new Paper machine Magnetic Chuck 600 x 350 Automatic table dressing with compensation 1 flange Items put up Installation / commissioning / transport

Gr. Swing diameter: 600 mm Top width: 2200 mm Gr. Grinding diameter on grinding wheel 800 mm Ø: 125 mm Wheels Ø use of put sticks: 20-125 mm Grinding wheel dimensions: 800 x 28-800 x 42 x 305 mm 2 wheel speeds 3 workpiece speed: 32, 55 and 96 RPM Table Shift manual coarse/fine: 10/2 mm Machine. Feed speed of the grinding wheel: 0,005 - 0,025 mm Table 6-speed: 120-1540 mm / min Grinding spindle stock drive: 8 kW Electr. Supply: 380/400 V, 10 kW Space requirements: 6100 x 2300 x 1600 mm Weight: 7T

Discus Werke DSH 600/1000 Side Surface Grinding Machine This type of machine is a machine with a motor-driven grinding spindle. The clamping and grinding of the workpieces is carried out with clamping devices tailored to the respective work. The devices are attached to the machine bed. The column saddle on which the motor spindle is mounted serves as a feed, dressing and pendulum slide. Manufacturer: Diskus Werke Model: DSH 600/1000 Serial number: 6299 Type: Side Surface Grinding Machine Cooling lubricant: Isocool 1020 BF Coolant volume: 400 liters Concentration: 2.5% (x factor 1.6 ≙ 4%) Year of construction: 1964 Condition: used The side surface grinding machine is located in Hildesheim and can be dismantled and picked up by the customer there. Dismantling and transport according to offer and agreement also possible by us. Complete plant closure,  ...

Special price for stock goods! Only while stocks last! Belt dimensions: 75 x 2000 mm Belt speed: 29 m/sec. Contact disc Ø x W: 200 / 80 mm Face grinding table: 460 x 75 mm Suction connection Ø: 100 mm Motor output power S1 100%: 3.0 kW Motor input power S6 40%: 4.0 kW Voltage: 400 V Length: 1080 mm Width: 440 mm Height: 1000 mm Weight approx.: 66 kg Characteristics: - Good grinding performance due to high belt speed - Quick adjustment for horizontal and inclined position - Continuous face grinding surface for optimal grinding of long workpieces - Constant belt tension due to spring-loaded clamping device - Universally applicable for grinding edges, surfaces and cylindrical grinding - Including quick clamping system for fast belt changes - Easy adjustment of the parallel belt run by means of adjustment screw - Graphite coating on the face grinding surface increa ...

1 Qty.1 Second-hand brush grinding machine Mfc.: Gurutzpe Type: Brushes cutting machine Built: 1975 Model: Max. Q800x2500 2 Qty. 1 Second-hand Rubber Grinding Machine Mfc.: Churchill Type: PCH 24" X 96" Built: 1957 Model: Max. Q600x2400

High-quality construction Drive roller is crowned (thus the sanding belt centered automatically centered on the role) and fully Vulcanized for longest life and best smoothness Tool-less and allow fast, easy change of the sanding belt Stepless height adjustment for optimal setup of the belt sander on the user Free adjustable metal fence to the optimal and safe guide workpieces during use of the large plan grinding area Speed design optimized for burning of the workpiece during the machining can be excluded as far as possible Models with fume control system equipped with robust and flexible suction hose Motor protection switch with CEE collar Steckvorrichtung incl. phase inverter 5 year warranty on the motor 1 year warranty on the belt sander Strap length: 2000 mm Band width 75 mm Plan grinding range 600 mm Speed 15/30 m/s RAL 9007 colour Motor three-phase 400 V 3.0/3,75 kW Suction capa ...

TACCHELLA ELEKTRA 1518 MPC CNC grinding machine was built in Italy in 1999. Characterised by high reliability and performance, the machine is used in the process of highly accurate grinding of the external rotating surfaces of workpieces with a maximum length of 1500 mm and a diameter of 350 mm. The TACCHELLA CNC shaft grinding machine has a large workspace with tailstock, grinding wheel spindle and workpiece spindle. After placing a shaft with a maximum weight of 50 kg in the spindle holder, the workpiece is ground at high speed by an incremental encoder driven grinding wheel with a maximum diameter of 450 mm. In order to simplify the machining process, the ELEKTRA 1518 MPC CNC grinding machine is equipped with state-of-the-art features, such as the HOFLER BALANCE SYSTEMS VM 24 operator panel and a functional and user-friendly FAGOR CNC controller, which allows full control of the m ...

HF FeinfräÃ? & - grinding spindle, manufacturer Fischer Schaffhausen. Designation; MFVS 830, Series number: EL-S-007 The spindle is undamaged, unused and in their original packaging. The spindle can be used with electrodes and-precision Strausak type. 82 CNC. or as RF - internal grinding spindle. Tech. Data.: 220 V 600 HZ 4-pin 2.5 KVA 1.4 KW / 600 HZ for further information: The grinding technology: Tool &-profile grinding coarser has in 2001 of the production & - Strausak license rights wage purchased. The rights include the complete series 57 U/W, 57 U CNC, 57 W CNC 3.-4.u-5-axis, and from this all developed machines.

Machine type: CNC centerless grinding machine Make/Model: MIKROSA KRONOS M SPECS CNC Fanuc 21iM grinding wheel max sizes: 250mm wide x 610mm diameter 2 controlled axis on grinding wheel dressing (interpolated) 1 axis on regulating wheel 1 axis on plunge axis (workpiece diameter) Throughfeed grinding: yes Plunge grinding: yes can be inspected under power in our warehouse in Gussago BS (Italy)

Surface grinders - horizontal ELB-SCHLIFF SWBE 10 PLC Second-hand machine Mint Control cabinet, motors, wiring, control new Hydraulic new, trim, loop length: 1000 mm Grinding width: 500 (600) mm Workpiece height: 600 mm Table size: 1000 x 550 mm Grinding wheel dimensions: 400 x 100 mm Grinding spindle motor: 11 kW Table speed: 2-30 m / min Grinding wheel speed: 5-35 m / sn Total power: 18 kW Machine weight approx.: 5,5 t Space requirement approx.: 3.5 x 2.5 x 2.5 m General outrun 2019 with 12 month warranty Paper machine Levelling feet Installation included Instruction includes

Gr. Grinding length: 620 mm gr. Grinding width: 250 mm table size: 200 x 620 mm grinding wheel dimensions: 200 x 220 x 51 mm Electr. Supply: 380 V, 1/1.8 kW space: 1650 x 1450 x 1800 mm weight: 1350 kg

Mikrofinishingmaschine, microfinishing machine, used gebrauchtTyp: MA 3/1000Hersteller: Thielenhaus machine factory WuppertalSteuerung: manually, konv. maximum part size / max. worksize: d = 155 mmMax. 310 part length / max work.length: mmGenauigkeit / precision: 0.001 mmLeistung / load: 12.4 kW, 380/400 ~ specification: stock finish. grinding wheels Floor finishing tools including Machine application: high-precision surface grinding of piston pin

Stock number 1105-02617 Machine type flat grinding machine Make Elf Type OPTIMALLY 4250 NC-K Built in 1993 Control type NC Storage warehouse Country of origin Germany Delivery time immediately Exhibition Hall, ver free freight basis Technical details Grinding length 450 mm Grinding width 250 mm Workpiece height 375 mm Table length 800 mm Table width 250 mm maximum work-piece weight 400 kg Autom. Cross feed adjustable 3-50 mm / stroke Vertical delivery, 1 Division 0.001 - 0.06 mm Grinding wheel diameter 300 mm Grinding wheel width 50 mm Grinding wheel diameter 36 mm Voltage 380 V Grinding spindle motor 3.7 / 4.7 kW Total power demand 9 kW Machine weight approx. 2.6 t Space requirement of approx. 2800 X 2500 2300 mm Additional information automatic delivery -Electro magnetic clamping plate with straight fine pole pitch, dimens ...

Precision flat grinding machine Manufacturer: COSMOS Model: Earth 1050 NC Built: New factory Grinding length: 1000 mm Grinding width: 500 mm Grinding height: 400 mm Electric magnetic release plate 1000 x 500 mm Single fitters at the table firmly assembled for straight judting with compensation Programble display 4.7 " Unseated grinding spindle drive Universal paper tape filter

Type SAXW 63/3000 Producer WMW Meuselwitz Year of manufacture 1979 Parameters 63mm, 3000mm Location Praha CZ Swing 750 mm Distance between centres 3000 mm Max. weight of workpiece 6000 kg Machine suitable for modernisation

Tip width/grinding length: 1000/1075 mm Gr. Grinding diameter: 250 mm Table swivel: +/- 8° Gr. Table longitudinal movement: 1210 mm Workpiece spindle stick swivel: 0 - 90° Spindle bore/cone: 38 mm/MK 5 Grinding spindle stick easily swivelling Hydr. Quick adjustment approx.: 50 mm Grinding wheel dimensions: 400 x 50 x 127 mm 2 grinding wheel speeds due to V-belt step disc Drive power: 3 kW Space requirement: 2900 x 2200 x 1750 mm Weight: approx. 3.5 t

Drill diameter: 2 - 13 mm Tip angle: 90° - 140° Speed: 4800 rpm Connection: 230 V Engine power: 0.18 kW Weight, approx.: 11 kg Dimensions, approx.: 320 x 180 x 190 cm Characteristics: - Ideal for grinding HSS/hard metal spiral drills - Safe operation due to forced grinding - Peak angle adjustable from 90° - 140° - Compact design, with collet storage in the machine and handle for quick storage - Including sharpening device to reduce feed force - Device for back grinding of the drill cuttings to reduce the friction between the drill and the workpiece - Rotor with precision ball bearings Delivery: - Grinding wheel CBN - 11 collet pliers ER 20, 3 - 13 mm - collet holder ER 20

Drill diameter: 13 - 32 mm Tip angle: 90° - 140° Speed: 4800 rpm Connection: 230 V Engine power: 0.25 kW Weight, approx.: 28 kg Dimensions, approx.: 490 x 250 x 260 mm Characteristics: - Ideal for grinding HSS/hard metal spiral drills - Safe operation due to forced grinding - Peak angle adjustable from 90° - 140° - Compact design, with collet storage in the machine and handle for quick storage - Including sharpening device to reduce feed force - Device for back grinding of the drill cuttings to reduce the friction between the drill and the workpiece - Rotor with precision ball bearings Delivery: - Grinding wheel CBN - 20 collet pliers ER 40, 13 - 32 mm - collet holder ER 40 Optional extension, at extra cost: - collet set 5pcs. 8.0 / 9.0 / 10.0 /11.0 /12.0 mm

Grinding length 500 mm Grinding width 250 mm Workpiece height 375 mm max. table load 350 kg Table longitudinal movement 525 mm Table feed 2-28 m/min Total power requirement 4.5 kW Machine weight approx.1900 kg Control NC Height: approx.2.60 m Width: approx. 2.10 m Depth: approx. 2.00 m Total weight with cooling lubricant container: approx. 2.3 t.

Figure shows precision flat grinding machine: FSM 2550 AH Table size: 300 x 600 mm Installation height: 500 mm Max table load: 300 kg Engine power: 4.6 kW Connection: 400 V Dimensions: 2300 x 1790 x 2200 mm Weight, approx.: 2000 kg Equipment and scope of delivery: - All castings, such as machine stand, table, etc. made of MEEHANITE® quality casting - Automatic cross and longitudinal feed - Permanent lubrication - Automatic cross-stroke device - Rear splash protection - Grinding wheel - Grinding wheel flange - Pulling device - Balancing mandrel - Balancing scales - Dressing diamond - Machine light - Nivilier elements - Operating tool - Operating instructions - CE Special equipment of our storage machine: - Electric magnetic clamping plate 300 x 600 mm (fine pole) - 2-axis digital display, accuracy 0.001 mm, X 450 / Y 500 mm - Automatic verti ...

Ger RHC1500 Universal Rectifier. Indoor head. Distance between points: 1500mm. Maximum part diameter: 355mm. Point height: 180mm. Tooth diameter: 400mm. Power: 7.5hp. Weight: 4500Kgs.

Machine Details Stock number 1105-04042 Machine Type: Surface Grinding Machine Make JACOBSEN Type 1432 Year of construction 1992 Condition Conventional control type Storage location HAGUENAU FRANCE Country of origin Delivery time at short notice - by arrangement. Freight base delivery from site. Price Technical details Grinding length 900 mm Grinding width 410 mm Travel - x 900 mm Travel - y 410 mm Travel - z 300 mm Machine weight approx. 2700 kg Information Distance table - spindle center: 135-575 mm Table speed X: 30-30000 mm/min. Table speed Y: 4-3750 mm/min. Table speed Z: 4-4000 mm/min. Max. grinding wheel dimension: 300x50x76.2 mm Drive power grinding spindle: 4.7 kW MAGNETIC PLATE BRAILLON 800 X 400 MM 5 GRINDING FLANGES

Machine Details Stock-No. 1105-04056 Type of machine Surface Grinding Machine - Horizontal Make CHEVALIER Type FSG- 818 AD Year of manufacture 1998 Type of control conventional Storage location HAGUENAU FRANCE Country of origin Taiwan Delivery time immediately Freight basis ex stock Price Technical details grinding length 450 mm grinding width 200 mm workpiece height 350 mm electro magnetic clamping plate 350 x 200 mm table speed -stepless- 5 - 25 m/min dimensions of grinding wheel 200 Ø x 19 x 32Ø mm total power requirement 1.7 kW weight of the machine approx. 3.6 t Additional information automatic vertical feed, dressing devise, electro magnet, coolant with paper filter, hydraulic separate

Machine details 1105-02942 Machine type Flat Grinding Machine - Horizontal Make Sit Type R4 CA Built 1981 Control type Conventional Location France Origin Germany Delivery Right away Freight base EX WORK Price On request Technical details Grinding length 450 mm Grinding width 180 mm Workpiece height 300 mm Total performance requirements 9 kW Information Grinding length max. 500 mm Table stroke maximum 600 mm Grinding width max. 180 mm Table size 600 x 300 mm Working height under grinding wheel 500 mm Grinding head Vertical path 300 mm Vertical delivery 0.001 - 0.06 mm/stroke Grinding slide adjustment across 200 mm Grinding wheel size 400 x 150 x 305 mm Grinding wheel speed stfl. 47 - 970 rpm Table load.600 kg Table lifting speed max. 30 m/min. Grinding spindle drive 12 kW Total drive approx. 20 kW - 380 V - 50 Hz Weight approx. 2,00 ...

Steel grinding machine Offer number: 20064 Make: REMA Type: DS 12 ST Machine Number: 108267 Built: 1988 Technical data: - Grinding wheel diameter approx. 125 mm - 2 disc speeds 1450 / 2200 rpm - Right, - Left-hand run - tilting fixed support table ATF 340 x 150 mm - Support table -5° to +15° tiltable - Lighting - Drive 400 V / 0.65 / 0.9 kW - Working height 1000 mm - Space requirement approx. W 850 x H 1150 x D 550 mm - Weight approx. 120 kg

Used 4 flanges fit on a JUNG, HF 50 (R or RD) Scope according to pictures ! ( 4 flanges , . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Offer via gebr. Suhner Shaft Grinding Machine Rotofera DKM 4 Flexible shaft machine shaft grinding machine grinding Rotofera The 7-speed transmission Speed range: 850, 1600, 2100, 3200, 5700, 8000 and 12000 min-1 (400 V, 50 Hz, 3 Ph, 1.0 kW) Mobile Continuous - Separation of motor and tool guaranteed fatigue-free working Applications - Grinding - Disconnect - Roughing - Milling - De-rusting - Polishing - Brushes For light work, especially stainless steel, boiler and steel construction, polishing workshops, apparatus construction, kitchenand hospital supplies, etc.

Circular saw sharpening machine Vollmer Cne
