15 ALTENDORF joiners circular saws used machines

Altendorf WA6 Format circular saw new Format sliding table: 2600mm Engine power: 400V 4 KW (5.5 hp) Saw blade: 315mm swivel: 90°-45° Pre-scoring unit: with engine 0.37 KW (0.5 HP) For wood, plastic and non-ferrous metal G&AL-WA6-2600 ASSEMBLED CHECKED AND MEASURED! SPECIAL PRICE Format sliding table:also in 1600mm SPECIAL PRICE Accessories: Saw blade pendulum protection (upper protection) for saw blade 350mm

Operating voltage: 400 volts, power: 4 kW, speed: maximum 6,000 rpm, saw blade diameter maximum: 400 mm, work table with 2 T-slots width: 2500 mm, adjustable with depth stop: 0 - 800 mm, with suction device Errors excepted!

SPECIFICATIONS: Sliding table saw with 45° swiveling saw blade Diameter saw blade mm: 400 Diameter of the scorer mm: 120 Length of carriage mm: 3800 cutting width mm: 1600 Motor power KW: 5,5 Motor with brake Complete with: - 01 pneumatic presser - Digital control panel - Duplex continuous inclined cutter 0°-90°

Sliding table saw Altendorf TRK 45 Year of construction: 1986 S/N 86-9-209 checked in our workshop for normal operating condition Carriage length: 1350 mm Height and swivel adjustment manually with handwheel Motor power: 5.5kW Cutting width: 1250 mm 4 speeds 3/4/5/6000 rpm, Blade diameter max mm: 450 ( without scoring machine ) with scoring Automatic engine brake Weight approx. 1100 kg Technical specification subject to change + 2 additional saw blades

Key data: 45 °, 2800 mm

Sliding Table Saw Main motor 5.5 KW Scoring saw

Sliding table saw Altendorf WA 80 Digital display angle and cutting height Motor power 5.5 kW Scoring 0.75 kW Carriage length 3200 mm Saw blade diameter max. 500 mm, can be lowered below table height Cutting height max. 125 mm, at 45° max. 87 mm Cutting width at the rip fence 1350 mm Height adjustment electromotive Swivel angle adjustment electromotive 0 – 45° Angle stop, cutting to length up to 3200 mm Table extension 840 mm Machine weight approx. 1100 kg Work table height 910 mm Top condition

Sliding table saw Altendorf WA 80 Digital display angle and cutting height Motor power 5.5 kW Scoring 0.75 kW Carriage length 3200 mm Saw blade diameter max. 500 mm, can be lowered below table height Cutting height max. 125 mm, at 45° max. 87 mm Cutting width at the rip fence 1350 mm Height adjustment electromotive Swivel angle adjustment electromotive 0 – 45° Angle stop, cutting to length up to 3200 mm Table extension 840 mm Machine weight approx. 1100 kg Work table height 910 mm Top condition

Length of the rolling table: ca. 2280 mm Saw blade diameter: ca. 400 mm weight: ca. 900 kg Parallel stop: Stop sliding table: 1550 mm with mitre rail incl. side stop extension to 1000 mm Star delta circuit has been renewed The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Length of the rolling table: ca. mm Saw blade diameter: ca. 400 mm weight: ca. 900 kg Parallel stop: Stop sliding table: 1460 mm with stop extension to 2840 mm Star delta circuit has been renewed The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 45 °, 2800 mm, 800 mm

Sliding Table Saw Table Saw Circular Saw Carpenter Saw Altendorf Type: F45 Year: 1978 Sliding table length: 280 cm Trimming width/ rip fence approx.: 80 cm Parallelogram Guard with Top Extraction Hood Boom table with cut-to-length stop Miter stop Motor power: 5.5 KW Condition see pictures, or follow the item description. Parts can also be picked up by yourself. All measurements are approximate. All information to the best of our knowledge but without warranty. Subject to prior sale. The items can be picked up by yourself or shipped at the expense of the buyer. the indicated shipping costs are an approximate price, depending on the distance and unloading option, they may vary. Please inquire. The item offered is offered with differential taxation. The sales price shown is the gross final amount. An invoice with VAT will not be issued.  ...

PART NUMBER 8006 SPECIFICATIONS - max diameter of the main disc with a scoring scoring rod 350mm - max diameter of the main blade without a scoring rod 450mm - cutting height with the blade in place: 350mm, 100mm - electric adjustment of the main disc up/down + angle - Electric angle display - electric adjustment of the undercut up/down, right/left - spindle diameter 30mm - Spindle locking - with a sliding trolley - cutting length on a trolley 3400mm - cutting width at the guide 1300mm - with sidecar - with an undercutter - max scoring diameter 120mm - spindle diameter 22mm - 0.75kW scoring motor - main motor 5.5kW - 4 types of rotational speed - electronic speed display - Diameter of the extraction port 120mm, 80mm - table top dimensions 1220x730mm - Table top dimensions with widening 1440mm - Table top dimensions with extension 2060mm - shield cover - dim ...

Sawblade tiltable: 0-46 ° Length of the rolling table: 3200 mm cutting width: 1000 mm Motor output: 5,5 kW Cutting height: 179 mm Cutting height at 45°: 123 mm Saw blade diameter: 500 mm Speed: 3/4/5000 U/min. weight of the machine ca.: 1300 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Altendorf TKR45 Manufacturer: Altendorf Type: TKR45 Mach. Nr: 89-1-221 Year: 1989 saw length: 1350mm Sidetable: JA Saw width: 850mm saw height: 155mm Saw diameter (max): ø450 Saw spindle: ø30 Saw blade tilting: 0-45° Motor: 5,5 kW Speed: 3000/4000/5000 omw/m Weight: 910KG

Altendorf F45 ELMO III Panel saw Manufacturer: Altendorf Type: F45 ELMO III Year: 1996 Mach.Nr.: 96-02-044 Technische gegevens: Control: LCD screen, eye level, swing away saw width, saw height, saw tilting, Sliding Table: 3200 mm (Double trolley on hard-chrome rail, smooth upper carriage lock) Cutting Width: 1300 mm Main saw: ø250 – 450 mm, 5.5 KW, 3.000-6.000 rpm NC-electromotive height and swivel adjustment 0-46 °: h Scoring saw: Non Sidetable: extendable 700 mm Length stopper: 0-3.500 mm, with fixed 90 ° position, 2 stoppers Condition: well-maintained machine, functional and technically checked. Avaialable: immediate

Year: 1965 M.-No.: 65-10-82

CIRCULAR SAW model ALTENDORF F45 with 2 axes by CNC second hand machine in excellent working condiiton CE mark . with Use and Maintenance Booklet and Declaration of Conformity 2 CNC controlled axes: 1st axis: blade lifting 2nd axis: blade inclination digital display inclination blade digital display blade height digital display rpm blade double front / rear ignition control electric movements of scoring unit , from the control panel technical data : anodized aluminum carriage mm. 3000 max.diam. blade ( with scoring blade ) mm.350 max.diam. blade ( without scoring blade ) mm. 450 blade rotation speed g/min.3000/4000/5000/6000 with scoring unit : Yes blade group inclinable at 45° cutting width on the parallel guide mm.1350 main saw blade . motor power 7.5 Hp scoring unit motor power Hp 1 machine equipment: aluminum telescopic rod n.01 DIGIT L digital disp ...

Panel saw Type: F45 ElmoDrive Manufacturer: Altendorf Year: 2022 Basic equipment: Sliding table 3400 mm CNC-controlled parallel fence, electromotor-adjustable 0–1300 mm Mitre fence extendable up to 3200 mm Main motor power 5.5 kW / speeds 3000/4000/5000 rpm Max. blade diameter: 500 mm Max. cutting length: 3300 mm ELMO DRIVE control system 12” touch display with keyboard Up to 9,999 programs Automatic dimension correction when cutting at angles Extended tool management (up to 100 stored tools) Functions: grooving, angle cutting, geometric shape calculations, calculator, USB interface, machine diagnostics Automatic calculations for angled and bevel cuts Simple, intuitive interface with quick access to functions Machine equipment: Increased main motor power to 5.5 kW CNC parallel fence – cutting width 1300 mm Extension of the sliding table to 3400 mm DIGIT L an ...

CIRCULAR SAW Mod ALTENDORF F45 second hand machine CE mark . with Use and Maintenance Booklet and Declaration of Conformity digital display inclination blade digital display blade height digital display rpm blade double front / rear ignition control Technical data : anodized aluminum carriage mm. 3000 max. blade mm.400 blade group inclinable at 45° saw blade self-braking power motor Hp 7.5 telescopic aluminum pole suspended "bridge" protection on the blade cutting width on the parallel rail mm.1300 n.02 additional aluminum frames fixed table dimensions mm.1200x750 blade rotation speed g / min.3000 / 4000/5000/6000 net weight kgs. 1000 Volt. 380/50

Underfloor circular saw, crosscut saw, pull saw, chop saw, sliding table saw, table saw, circular saw, panel saw -Manufacturer: Altendorf, sliding table saw type TKR 45 -Main motor: Bauknecht 5.5 kW with brake -Scorer motor: Emod 0.75 kW -Speed: 3000/4000/5000 rpm -Saw blade: Ø 300 mm / max. Ø 350 mm -Max. Cutting height: 90° 95 mm / 45° 70 mm -Miter cut: up to 45° -Cutting width: 2250 mm -Table length: 1400 mm -Dimension total 3480/1530/H1370mm -Weight: 1104 kg

Sawblade tiltable: 45 ° Length of the rolling table: 3000 mm cutting width: 1000 mm Motor output: 5,5 kW The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

* General * SKU050C482 * MakeMAVAG Altendorf * No.91.1923 * Year of construction1992 * Mounted on legs(Mounted on wheels) * Pressure * Working pressure6 Bar * Vacuum possiblecheck * Main Features * MaterialStainless steel * Volume100 Ltr. * Motor1.5 KW * Specified Features - Stirring vessel * Closed stirring vesselcheck * Capacity100 Ltr. * Vessel sizesø 600x400mm * Dished bottomcheck * Dished top sidecheck * Manholecheck * Top connections(6x) * Outletø 20mm * With propellor stirrer(bottom mounted, magnetic stirrer) * Motor1,5 kW 400 V 1450 rpm (Ex) * MaterialStainless steel 1.4435 (316L) * General * LocationBarneveld * With switchcheck * Floorspace1,0 x 0,9 m * Total height1,9 m * Weight250 kg * ATEX designedcheckFine chemicalsStarchOther chemicalRubberBiotechnologyAgrochemicalsSpicesPlastic & polymersCatalysts & fillersFeed additivesSolventsDetergent & surf.Other pharmaceuticsCosmeti ...

* General * SKU210P145 * MakeMavag AG Verfahrenstechnische Apparate und Anlagen (CH) * TypeR-2-18-400-40-500-316L * No.29.1000 * Year of construction2009 * Mounted on framecheck * Pressure * Working pressure6 Bar * Vacuum possiblecheck * Working pressure jacket6 Bar * Main Features * MaterialStainless steel * Surface2 m2 * Cake60 Ltr. * Specified Features - Horizontal plate filter * Plate filtercheck * Horizontalcheck * Filter surface2 m2 * Number of platens18 * Platen sizesdia.400mm * Between the plates40mm * Top connectionsdia.28mm * Solids outletdia.260mm * Liquid outletdia.28mm * Max. temperature-5 / +120 degr.C. * Motor3,0 KW, 230/400 Volt * Cake capacity60 Ltr * Centrifugal cake dischargecheck * MaterialStainless steel 1.4301 (304), Stainless steel 1.4404 (316L) * General * LocationBarneveld * Floorspace1,0x1,0 M * Total height2,7 M * CEcheckFine chemicalsOther chemicalBiotechnolog ...

* General * SKUR0856 * MakeMavag AG (CH) * LocationBarneveld * CEcheck * TypeHP840 * Pressure * Working pressure3.5 Bar * Vacuum possiblecheck * Working pressure jacket6 Bar * Vacuum possible jacketcheck * Main Features * MaterialStainless steel * Surface6 m2 * Specified Features - Horizontal plate filter * Plate filtercheck * Without platescheck * Top connectionsdia. 80mm (1x) dia. 50mm (2x) dia. 25mm (1x) * Solids outletdia. 50mm * Liquid outletdia. 50mm * With jacket(50 ltr) * Max. temperature-10/80 degr.C * With hydraulic drivecheck * Motorpneumatic driven * With pumpcheck * Capacity250 bar * MaterialStainless steel 1.4404 * With jacketcheck * General * No.24.1801 * Year of construction2005 * Mounted on legscheck * Floorspace2,1x1,3 M * Total height2,5 M * Weight1300 kg * Extra SpecificationsWITHOUT FILTER PLATESFine chemicalsOther chemicalBiotechnologyAgrochemicalsPlastic & polymers ...

* General * SKUR0856 * MakeMavag AG (CH) * LocationBarneveld * CEcheck * TypeHP840 * Pressure * Working pressure3.5 Bar * Vacuum possiblecheck * Working pressure jacket6 Bar * Vacuum possible jacketcheck * Main Features * MaterialStainless steel * Surface6 m2 * Specified Features - Horizontal plate filter * Plate filtercheck * Without platescheck * Top connectionsdia. 80mm (1x) dia. 50mm (2x) dia. 25mm (1x) * Solids outletdia. 50mm * Liquid outletdia. 50mm * With jacket(50 ltr) * Max. temperature-10/80 degr.C * With hydraulic drivecheck * Motorpneumatic driven * With pumpcheck * Capacity250 bar * MaterialStainless steel 1.4404 * With jacketcheck * General * No.24.1801 * Year of construction2005 * Mounted on legscheck * Floorspace2,1x1,3 M * Total height2,5 M * Weight1300 kg * Extra SpecificationsWITHOUT FILTER PLATESFine chemicalsOther chemicalBiotechnologyAgrochemicalsPlastic & polymers ...

* General * SKUR0856 * MakeMavag AG (CH) * LocationBarneveld * CEcheck * TypeHP840 * Pressure * Working pressure3.5 Bar * Vacuum possiblecheck * Working pressure jacket6 Bar * Vacuum possible jacketcheck * Main Features * MaterialStainless steel * Surface6 m2 * Specified Features - Horizontal plate filter * Plate filtercheck * Without platescheck * Top connectionsdia. 80mm (1x) dia. 50mm (2x) dia. 25mm (1x) * Solids outletdia. 50mm * Liquid outletdia. 50mm * With jacket(50 ltr) * Max. temperature-10/80 degr.C * With hydraulic drivecheck * Motorpneumatic driven * With pumpcheck * Capacity250 bar * MaterialStainless steel 1.4404 * With jacketcheck * General * No.24.1801 * Year of construction2005 * Mounted on legscheck * Floorspace2,1x1,3 M * Total height2,5 M * Weight1300 kg * Extra SpecificationsWITHOUT FILTER PLATESFine chemicalsOther chemicalBiotechnologyAgrochemicalsPlastic & polymers ...
