ALZMETALL alzstar used machines

Drilling capacity in St 60: 40 mm threading in St 60: M 24 mm threading in GG 20: M 30 bore stroke: 120 mm Short spindle: MK 3 throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514 x 360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle - machine table min./max.: 117 / 701 mm feed: 0,10 + 0,20 mm/U spindle turning speed range: 160 - 2250 UpM total power requirement: 1,45 / 1,9 kW height of the machine: 1840 mm weight of the machine ca.: 285 kg Standard equipment: - Mushroom pushbutton (latching) for EMERGENCY STOP - Reversing switch for right-left rotation - Motor protection switch - Speed adjustment stepless - Speed display digital - Feed overload protection - Protection IP 54 - Connector (fully assembled, cable length 2 m) - Spindle protection with electrical protection Pos. 25 Coolant device B, consisting of: separate container (33l), Pu ...

bore capacity in steel (diameter): 40 mm throat: 293 mm bore stroke: 120 mm spindle taper MT: 3 column diameter: 115 mm table surface area: 514 x 360 mm spindle turning speed - stepless: 160 - 2250 U/min total power requirement: 1,0/1,6 kW weight of the machine ca.: 0,285 t dimensions of the machine ca.: m Condition: new / unused: The machine can be viewed under current.: 37981 400 V, 50 Hz, colour: light grey RAL 7035 continuous speed control, digital speed indication, push button for emergency switch off, turning switch for clockwise/counterclockwise rotation, motor protection switch, IP 54, connecting plug, finish: structure varnish, new spindle bearing, new step pulleys, belts aso. operation manual, wiring diagram. Machine has been checked in our workshop, including electr. testing report. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Box column drill Alzstar 40S 16 A 380 V Speed 160 - 2250 rpm Length 1 m Width 0.80 m Height 1.80 m Weight 270 kg Work lamp Color: White

bore capacity in steel (diameter): 18.0 mm throat: 190 mm bore stroke: 80 mm morse taper: 2 Kurzspindel MK turning speeds: 225 - 4.300 U/min voltage: 400 / 50 Hz Volt table:: 300 x 240 mm column diameter: 65 mm engine output: 0.37 / 0.55 kW weight: 110 kg Furnishing: - Large spindle speed range - stepless speed adjustment - machined base plate - Electrically secured spindle protection - Main switch lockable with motor protection switch - Reversing switch for clockwise and counterclockwise rotation - Operating instructions in German The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel St 60: 30 mm bore capacity in cast iron GG 20: 30 mm Drilling capacity in St 60: 30 mm threading in St 60: M 16 threading in GG 20: M 20 Short spindle: MK 3 spindle stroke: 140 mm throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514 x 360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle-table min.: 132 / 724 mm feed: von Hand spindle turning speed - stepless: 225 - 4300 U/min total power requirement: 1,0/1,6 kW weight of the machine ca.: 260 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 30.0 mm throat: 293 mm bore stroke: 140 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 225 - 4300 U/min engine output: 1.0 / 1.6 kW column diameter: 115 mm distance spindle /table: 132 / 724 mm weight: 260 kg Machine height: 1790 mm Features: - Lockable main switch - Mushroom push button for EMERGENCY STOP - Reversing switch for clockwise and counterclockwise rotation - Motor with thermal protection contact - Stepless speed adjustment - Digital speed display - Protection class IP 54 - Motor insulation class “F” (155°) - Connection cable (without plug, cable length 2 m) - Spindle guard with electrical protection - DD textured paint finish in signal white RAL9003, PANTONE 7545c, black The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 23.0 mm throat: 250 mm bore stroke: 100 mm morse taper: 2 MK table:: 370 x 300 mm turning speeds: 225 - 4300 U/min column diameter: 90.0 mm distance spindle /table: 140 / 670 mm engine output: 0.6 / 0.95 kW weight: 175 kg Machine height: 1770 mm Furnishing : - Mushroom pushbutton (latching) for EMERGENCY STOP - Reversing switch for clockwise and counterclockwise rotation - Motor protection switch - Infinitely variable speed adjustment - Digital speed display - Protection class IP 54 - Connection plug (fully assembled, cable length 2m) - Spindle protection with electrical fuse - Painting: DD textured paint, light gray RAL 7035, anthracite RAL 7016 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40.0 mm throat: 293 mm bore stroke: 120 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 160 - 2250 U/min column diameter: 115 mm feed: 0.10 + 0.20 mm/U distance spindle /table: 117 / 701 mm total power requirement: 1.45 / 1.90 kW weight: 285 kg range L-W-H: 500 x 800 x 1840 mm Furnishing: - autom. Feed 0.10 + 0.20 mm / rev - stepless speed adjustment - Short spindle MK 3 - Mushroom pushbutton (latching) for EMERGENCY STOP - Reversing switch for clockwise and counterclockwise rotation - Digital speed display - Feed overload protection - Spindle protection with electrical fuse - 2 m cable with plug 16A - Operating instructions in German including special equipment: - Coolant device B pos. 25. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel St 60: 30 mm bore capacity in cast iron GG 20: 30 mm Drilling capacity in St 60: 30 mm threading in St 60: M 16 threading in GG 20: M 20 Short spindle: MK 3 spindle stroke: 140 mm throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514 x 360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle-table min.: 132 / 724 mm feed: von Hand spindle turning speed - stepless: 100 - 1.800 U/min total power requirement: 1,0/1,6 kW weight of the machine ca.: 260 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 18 mm : M 12 : M 14 : MK 2 : 225-4.300 U/min. spindle stroke: 80 mm throat: 190 mm column diameter: 65 mm : 300x240 mm : 2 x 12 x 80 mm : 75/357 mm : 300x240 mm : 2 x 12 x 80 mm : 437/437 mm feed: von Hand : Handkurbel total power requirement: 0,37/0,55 kW Machine height: 840 mm weight: 120 kg Standard equipment: - Main switch with motor protection switch lockable - Reversing switch for clockwise and anti-clockwise rotation - Speed adjustment stepless - Protection IP 54 - Mushroom pushbutton (latching) for EMERGENCY STOP - Spindle protection with electrical protection Option 12 - LED machine light, with radially adjustable light beam, power rating 230 V, protection class IP 65 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 40 mm threading in St 60: M24 threading in GG 20: M30 Short spindle: MK 3 Center of spindle to wall or column: 293 mm spindle turning speed - stepless: 160 - 2250 U/min Column diameter: 115 mm spindle stroke: 120 mm Machine table - usable table surface: 514 x 360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle-table min.: 117/701 mm feed: 0,10 + 0,20 mm/U Motor output: 1,45 / 1,9 kW height of the machine: ca. 1840 mm weight of the machine ca.: 285 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 30.0 mm throat: 293 mm bore stroke: 140 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 225 - 4300 U/min column diameter: 115 mm distance spindle /table: 132 / 724 mm engine output: 1.0 / 1.6 kW weight: 260 kg Machine height: 1790 mm ** NEW ALZMETALL MODEL RANGE ** 7 TFT - LCD display with touch function: * Spindle speed setpoint * Actual speed display * Integrated drilling depth display * with touch zero point transfer * Virtual drilling depth scale in the display * Machine status displays and warnings in the display * Service information * Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Infinitely variable speed setting by means of an adjusting lever - Spindle protection with electrical fuse - Three separate buttons for clockwise rotation - counterclockwise rotation - stop - Mushroom pushbutton (latching) for EMERG ...

bore capacity in steel (diameter): 40.0 mm throat: 293 mm bore stroke: 120 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 160 - 2250 U/min column diameter: 115 mm feed: 0.10 + 0.20 mm/U T-slots: 2 x 14 x 224 mm distance spindle /table: 117 / 701 mm engine output: 1.45 / 1.90 kW weight: 285 kg Machine height: 1840 mm ** NEW ALZMETALL MODEL RANGE ** 7 TFT - LCD display with touch function: * Spindle speed setpoint * Actual speed display * Integrated drilling depth display * with touch zero point transfer * Virtual drilling depth scale in the display * Machine status displays and warnings in the display * Service information * Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Infinitely variable speed setting by means of an adjusting lever - automatic spindle feed with feed overload protection - Spindle protection with electrical fuse - Three separate butt ...

bore capacity in steel (diameter): 40.0 mm throat: 293 mm bore stroke: 140 mm morse taper: 3 MK table:: 415 x 350 mm turning speeds: 160 - 2.250 U/min column diameter: 115 mm total power requirement: 1.45 / 1.90 kW weight: 285 kg range L-W-H: 500 x 800 x 1920 mm Features: - Heavy-duty column drill press - Continuously variable speed control (V-belt) - Pole-changing motor - Fixed drilling depth stop - Machine table with 2 T-slots * Height-adjustable via hand crank - Mushroom-head pushbutton (latching) for EMERGENCY STOP - Reversing switch for clockwise and counterclockwise rotation - User manual (PDF) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40.0 mm throat: 293 mm bore stroke: 140 mm morse taper: 3 MK table:: 415 x 350 mm turning speeds: 160 - 2.250 U/min column diameter: 115 mm total power requirement: 1.45 / 1.90 kW weight: 285 kg range L-W-H: 500 x 800 x 1920 mm Features: - Heavy-duty column drill press - Continuously variable speed control (V-belt) - Pole-changing motor - Fixed drilling depth stop - Machine table with 2 T-slots * Height-adjustable via hand crank - Mushroom-head pushbutton (latching) for EMERGENCY STOP - Reversing switch for clockwise and counterclockwise rotation - User manual (PDF) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Alzmetall AB4SJ Tool holder MK4 automatic feed with 3 feed speeds 2 shoot stages and infinitely variable speed control right left barrel, thread cutting device Cooling agent device in the foot Round table with holes without rev counter Machine hood modern made of plastic with cracks and loechers Speed: 80-710 rpm Table diameter: 450 mm Max distance from spindle to foot: 1200 mm Extension to center spindle: 170 mm Machine hoe approx. 200 cm Bt323s8 SPECIAL PRICE due to visually poor condition according to photos, technically usable condition, the drill is not locked at the shaft drill spindle tool holder in the rotational motion (see photos). If the drill is not firmly in the drill spindle, it rotates through. Special price

see side sheet below, with 2-spindle drill head Franz X. LINDNER SBS-2/2, spindle distance 300 mm, (translation 1:1)

with NC round table WALTER 1000 mm, see pictures

: 55 mm : M 30 : M 36 : MK 4 spindle turning speed - stepless: 70-1.200 U/min spindle stroke: 140 mm throat: 300 mm column diameter: 145 mm : 615x430 mm distance spindle /table: min./max. 150/735 mm : 2 x 14 x 224 mm feed: 0,1 + 0,3 mm/U Machine height: 1850 mm weight: 380 kg drive motor: 1,8/2,9 kW Standard equipment: - Lockable main switch with motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP - Infinitely variable speed adjustment - Digital speed display - Feed overload protection - Protection class IP 54 - Spindle protection with electrical fuse Item 20.1 Thread cutting device with foot switch, for thread cutting with Stop, max. 6 threads / min., (Thread cutting performance dependent on spindle speed) ************************************************** ***************************** !!! NEW FOR YOU AS A SERVICE !!! Machine leasing up to 60 months without down ...

Multi-stand drill Prior sale reserved - errors possible Internal Reference Number: D-1143-1

Column Drilling Machine ALZMETALL AB3 ESV Spindle: CM3 Rotation: 1 range 220 -800 RPM + 1 range 800-2900 RPM Table size: Length 615 mm x Width 470 mm Spindle travel: 160 mm Throat depth: 280 mm Speed adjustment by belt drive Rotative table at 360° Automatic Descent 3 speeds: 0,006 - 0,12 - 0,18 mm/min. Lubricant pump Voltage: 380 V Width: 800 mm Depth: 1300 mm Total height: 1900 mm Weight: approx 800 kg

offer 22326 Specifications: - Drilling capacity in steel ST 60 35 mm - Drilling capacity in steel ST 60 40 mm - Drilling spindle holder MK 4 - Drilling spindle stroke 170 mm - Projection 345 mm - Rotary table with 2 T-slots 550 mm - distance table – drilling spindle 650 mm - distance base plate – drilling spindle 1000 mm - Feed rates 0.09 - 0.16 - 0.28 mm/rev - AZ transmission continuously variable with manual transmission - Drilling spindle speeds infinitely adjustable 40 - 720 rpm -Right. - Left-hand rotation - Drive 400 V / 2.5 kW -Lighting - Coolant device - Space requirement approx. W 750 x H 1950 x D 1000 mm - Weight approx. 700 kg

Drilling capacity steel/GG: 18/23 mm Spindle mount: 2 MK Projection: 250 mm Table size: 250 x 370 mm Spindle speeds: 400 - 5000 rpm Drive motor: 0.48/0.6 kW Space requirements: 750 x 500 x 1670 mm Weight: 130 kg

- Drilling capacity in St 60, 30 mm - Short spindle MK 3 - Spindle stroke 120 mm - Projection 293 mm - Table support 420 x 300 mm, 2 T-slots - Machined base plate 320 x 329 mm, 2 T-slots - Distance base plate - drill chuck 1000 mm - Feed via turnstile - Weight 220 kg - Spindle speed 160 - 2250 rpm. - Operating voltage 380V-50Hz - Infinitely variable speed adjustment, by means of an adjustment lever - Engine speed in 2 stages, 700/1435 rpm - Tapping device with rotation direction change after reaching the end stops - Coolant device fully installed. - Coolant tank in machine base - Work light with LED - RÖHM drill chuck 1 - 16 mm - Precision machine vice new (test winner)

Specifications: - Drilling capacity in steel ST 60 40 mm - Drilling capacity in steel ST 60 50 mm - Drilling spindle holder MK 4 - Drilling spindle stroke 180 mm - Drilling spindle speeds infinitely adjustable with countershaft - Level 1: 60 - 210 rpm - Level 2 210 - 765 rpm - Projection 330 mm - 3 feeds 0.1 - 0.2 - 0.3 rpm - Table with 2 T-slots 720 x 360 mm - Table height-adjustable via rack with hand crank - Max. distance table – drilling spindle approx. 780 mm - Max. distance between machined base plate and drilling spindle approx. 1250 mm - Coolant device -Lighting - Drive 400 V / 4 kW - Space requirement approx. W 720 x H 2050 x D 1150 mm - Weight approx. 500 kg
