ARBURG 570 used machines

Three similar Arburg injection molding machines are available. 1) Arburg ALLROUNDER 570 A 2000-800, year of manufacture: 2010, clamping force: 2000kN, distance between tie bars: 570mm/570mm, pressure: 575bar, control system: Selogica direct 4.090, operating hours: 91917h, weight: approx. 9800kg. 2) Arburg ALLROUNDER 570 A 2000-800, year of manufacture: 2011, clamping force: 2000kN, distance between tie bars: 570mm/570mm, pressure: 575bar, control system: Selogica direct 4.090, operating hours: 82736h, weight: approx. 9800kg. 3) Arburg ALLROUNDER 570 A 2000-800, year of manufacture: 2011, clamping force: 2000kN, distance between tie bars: 570mm/570mm, pressure: 575bar, control system: Selogica direct 4.090, operating hours: 90722h, weight: approx. 9800kg. Documentation available. An on-site inspection is possible.

This Arburg 570 S 2200-800/290 was manufactured in 2020. It features a hydraulic drive system and the Selogica control system for precise operations. With a clamping force of 2,200 kN and a screw diameter of 40 mm, it is ideal for detailed injection moulding tasks. Consider the opportunity to buy this Arburg 570 S 2200-800/290 hydraulic injection moulding machine. Contact us for more information.

B&A REF: 8759 TON: 200 SHOT WEIGHT: 297 SCREW DIAMETER: 50MM STROKE VOLUME: 353CM3 INJECTION PRESSURE: 2050AR PLATEN SIZES: 795 X 795MM DBTB: 570 X 570MM MIN MOULD HEIGHT: 300MM MOULD OPENING STROKE: 650MM MAX DAYLIGHT: 950MM EJECTOR STROKE: 225MM CONTROLS: SELOGICA AIR VALVES: 1 MOTOR: 30 HEATING CAPACITY: 12KW SCREW DRIVE: ELECTRIC

Screw diameter; 55mm Injectable volume: 427 cm3 Injection pressure: 1720 bar Passage between columns: 570 x 570 mm Minimum mould thickness: 250 mm max: 750 mm Opening stroke: 600 mm Cores: 2 Robot interface: NO Options: Electrical dosing motor

Key data: 2000 , 678 , 60

Screw diameter; 60 mm Injectable volume / Shot volume: 678 cm3 Injection pressure: 2000 bar Column Passage /Bettween tie bar: 570 x 570 mm Mould tickness thickness: 250 mm max: 550 mm Opening stroke: 450 mm Core Pulling: 2 Robot interface: yes / Yes E67 Options: 12 Zones chauffe - 12 heating way

Injection moulding machine Arburg 570C 2000/150 60 2 K BJ 2007

Key data: 2000 kN

Arburg 570C 2000-350/150 / Production line with the Arburg Multilift side robot / 2K machine Year of Make: 2003 Injection unit: Screw diameter: 40 mm Injection weight: 153 g Spray pressure: 2120 bar Dosing volume: 182 ccm Clamping unit: Clamping force: 200 t Handlebar spacing: 570x570 mm Size of the clamping plates: 795x795 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA Additional equipment: Production line with the Arburg Multilift side robot 2K Machine Air Valve x 1 Hydraulic core pull x 5 Control with hot runners Reinforced Injection Units – Bimetal Proportional valves on sprinkler units - precise spraying The vertical injection unit - screw diameter: ⌀25 mm - 49 g/hp All offered machines are started by our service technicians before they are sold. It is possible to receive a video of the technical tests of the selected machine o ...

Key data: 2200 kN

Arburg 570S 2200-290/100/100 / Production line with the Wittmann W823 robot / Operating hours: 20,499 h in automatic mode Year of Make: 2016 Injection unit: Screw diameter: 35 mm Injection weight: 132 g Spray pressure: 2000 bar Dosing volume: 144 ccm Clamping unit: Clamping force: 220 t Handlebar spacing: 570x570 mm Size of the clamping plates: 795x795 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: 3-component injection moulding machine, high-speed Very good technical condition Operating hours: 20,499 h in automatic mode Euromap 67 Robot interface Air Valve x 6 Hydraulic, needle-core pull, controlled by a proportional valve x 4 Control with hot runners Hardened injection unit - Bimetal Proportional valve on the injection unit – precise injection Machine with two cylinders / battery with compressed ni ...

Key data: 2000 kN, 359 g/PS, 50 mm

Arburg 570A-2000-800/170 Two-component hybrid injection moulding machine with sorting flap (247) Category: Injection moulding machines Brand: Arburg Number: 247 Availability: in stock Year of production: 2009 Producer: Arburg Condition of Injection Molding Machine: Used Screw diameter [mm]: 50//35 Injection weight [g]: 359//105 Injection pressure [bar]: 2000//1470 Clamping force [kN]: 2000 Gap spacing [mm]: 570 x 570 Plate size [mm]: 795 x 795 Minimum mould height [mm]: 400 Control Type: Selogica Tongue: English, German Working time [h]: 84609 Weight [kg]: 10.950 Dimensions [mm]: 6000 x 2000 Feed hopper: NO Air Valve: 1x

Key data: 2000 kN, 434 g/PS, 55 mm

Arburg 570C-2000-800 Injection moulding machine with conveyor belt (259) Category: Injection moulding machines Brand: Arburg Number: 259 Availability: in stock Year of production: 2010 Producer: Arburg Condition of Injection Molding Machine: Used Screw diameter [mm]: 55 Injection weight [g]: 434 Injection pressure [bar]: 1650 Clamping force [kN]: 2000 Gap spacing [mm]: 570 x 570 Plate size [mm]: 795 x 795 Minimum mould height [mm]: 300 Control Type: Selogica Tongue: English, German Installed power [kW]: 44.4 Working time [h]: 58238 Weight [kg]: 7510 Dimensions [mm]: 6000 x 1900 Feed hopper: NO Core string: 2x Robot connection: 67 Euro Air Valve: 1x + 1x double coil

Key data: 2000 kN, 359 g/PS, 50 mm

Arburg 570A-2000-800 /170 Two-component hybrid injection moulding machine with sorting flap (243) Number: 243 Availability: in stock Year of production: 2010 Producer: Arburg Condition of Injection Molding Machine: Used Screw diameter [mm]: 50//35 Injection weight [g]: 359//105 Injection pressure [bar]: 2000//1470 Clamping force [kN]: 2000 Gap spacing [mm]: 570 x 570 Plate size [mm]: 795 x 795 Minimum mould height [mm]: 250-550 Control Type: Selogica Tongue: English, German Working time [h]: 79008 Weight [kg]: 10.950 Dimensions [mm]: 6000 x 2000 Feed hopper: NO Air Valve: x5 Core string: 1x

Various injection molding machines are available. 1) Arburg Allrounder 420 A 1000-400, clamping force: 100t, screw diameter: 30/35mm, year of manufacture: 2005. 2) Demag 1000-420-310 EL-Exis S, clamping force: 100t, screw diameter: 30mm, year of manufacture: 2003. 3) Demag 1000-420-200 EL-Exis S, clamping force: 100t, screw diameter: 25mm, year of manufacture: 2003. 4) Arburg 570 C 2000-150/60 2K, clamping force: 200t, screw diameter: 25/12+15mm, year of manufacture: 2007. 5) Arburg 420 C 1000-250, clamping force: 100t, screw diameter: 35mm, year of manufacture: 1996. 6) Arburg 420 C 1000-250, clamping force: 100t, screw diameter: 30/25mm, year of manufacture: 1995. 7) Arburg 420 C 1000-250, clamping force: 100t, screw diameter: 30mm, year of manufacture: 1994. 8) Netstal Synergy 600-110, clamping force: 60t, screw diameter: 25mm, year of manufacture: 2001. 9) Arburg 900T 800-150, clampi ...

- agregat card ARB 425 - analog output card ARB ARB 390 - output card ARB 409 - base board card SN. 193170 + SN 143537 ARB 729 + SN 173858 - panel card ARB 256, ARB 414 - control card ARB 692 - CPU card ARB 726, ARB 251 - diagnose card ARB 389 - disk controller card ARB 500 - input card ARB 254, ARB 705 - injection control card ARB 460, ARB 328, - elektronic card ARB 252, ARB 255, ARB 380 - inside press card ARB 259 - base board card ARB 372, ARB 523 - motor control card ARB 307, ARB 440 - 24V card ARB 381 - proporcional valve card 0 811 405 047, ARB 330 - memo card ARB 339, ARB 508, ARB 526 - heating control card ARB 365, ARB 404, ARB 530 ARB 640, ARB 730, yPIII - distributor card ARB 511, ARB 534, ARB 538, ARB 539 - video card ARB 258, ARB 535 - amplifier card, modul card - rectifier - transducer card ARB 302, ARB 399, ARB 733 - power supply Deutronic ED-60 -  ...

Complete screw and cylinder with filament and lockable nozzle. NEW!

Key data: 600 , 132 , 35

Manufacturer/Manufacturer: Arburg Type/Type: 370C 600-250 Bau-year year: 1999 Control/Controller: Selogica Clothing Power/Clamping Force: 600 kN Schliessart/Clamping Type: Hydraulisch/Hydraulic Holmabstand/Dist.Betw.Tiebars: 370 mm x 370 mm Plate Groesse/Platen Size: 570 mm x 570 mm WZ Einbauhoehe/Mould hight: min 250 mm Oeff-weg/opening stroke: 500 mm Plate distance max/Max. Open Daylight: 750 mm Snail/Screw size: 40 mm Lifting volume/shot volume: 188 cc/158 gram hp Spez. Spray./injection pressure: 1900 bar General General Motor/Motor Power: 11 kW Heating/heating power: 8.1 kW Dimensions: 4.3 m x 1.7 m x 1.8 m Weichtt/Weight: 3180 kg Screen text/Language: Deutsch/German Additional equipment/Additional equipment

Key data: 800 , 132 , 35

Manufacturer/Manufacturer: Arburg Typ/Type: 370C 800-250 Bau-year year: 2003 Control/Controller: Selogica Clothing kraft/Clamping Force: 800 kN Schliessart/Clamping Type: Hydraulisch/Hydraulic Holmabstand/Dist.Betw.Tiebars: 420 mm x 420 mm Plate Groesse/Platen Size: 570 mm x 570 mm WZ Einbauhoehe/Mould hight: min 250 mm Oeff-weg/opening stroke: 500 mm Plate distance max/Max. Open Daylight: 750 mm Snail/Screw size: 34 mm Lifting volume/shot volume: 144 cc/132 gram hp Spez. Spray./injection pressure: 1820 bar General General Motor/Motor Power: 15 kW Heating/heating power: 8.6 kW Dimensions: 4.2 m x 1.7 m x 1.8 m Weichtt/Weight: 3180 kg Screen text/Language: Deutsch/German Additional equipment/Additional equipment Euromap

Key data: 1300 , 194 , 45

Manufacturer/Manufacturer: Arburg Typ/Type: 420C 1300 kN-350 Bau-year year: 1999 Control/Controller: Selogica Closing Power/Clamping Force: 1300 kN Schliessart/Clamping Type: Hydraulisch/Hydraulic Holmabstand/Dist.Betw.Tiebars: 420 mm x 420 mm Plate Groesse/Platen Size: 605 mm x 605 mm WZ Einbauhoehe/Mould hight: min 250 mm Oeff-weg/opening stroke: 500 mm Plate distance max/Max. Open Daylight: 750 mm Snail/Screw size: 40 mm Lifting volume/shot volume: 182 cc/166 gram hp Spez. Spray./injection pressure: 1670 bar General General Motor/Motor Power: 22 kW Heating/heating power: 8 kW Dimensions: 4.3 m x 1.7 m x 1.8 m Weicht/Weight: 5100 kg Screen text/Language: Deutsch/German Additional equipment/Additional equipment Core Pulling: x1 Euromap Vario

horizontal conveyor belt with hydromotor

Arburg 470C-2000-675 (No. 40) without picker Built: 1998 TECHNICAL DATA Screw diameter [mm]: 60 Spray weight [g]: 427 Spray pressure [bar]: 1440 Closing force [kN]: 2000 Tie bar distance [mm]: 470x470 Clamping plate size [mm]: 715x715 Tool installation height min. [mm]: 250 Control Control: Selogica Monitor: Yes Control cabinet: Yes Language: Polish, German Other Power [kW]: 45.8 Engine hours [h]: 94737 Weight [kg]: 6630 GR - EUROMAP

Key data: 1000 , 194 , 45

Manufacturer: Arburg Type: 420 C 1000 - 350 Built: 1999 Control: Selogica Closing type: Hydraulic Closing force: 1000 kN Tie bar ratio: 420 mm x 420 mm Plate size: 570 mm x 570 mm Tool installation height: min 250 mm Opening distance: 500 mm Plate spacing max.: 750 mm Screw: 45 mm Lifting volume: 230 cc / 194 gram PS Spray pressure: 1670 bar General Engine: 22 kW Heating: 8.8 kW Dimensions: 4.3 m x 1.7 m x 1.8 m Weight: 3430 kg Screen text: German

Key data: 1300 , 166 , 40

Manufacturer: Arburg Type: 420C 1300 - 350 Built: 2000 Control: Selogica Closing type: Hydraulic Closing force: 1300 kN Tie bar ratio: 420 mm x 420 mm Plate size: 605 mm x 605 mm Tool installation height: min 250 mm Opening distance: 500 mm Plate spacing max.: 750 mm Screw: 40 mm Lifting volume: 182 cc / 166 gram PS Spray pressure: 2120 bar General Engine: 22 kW Heating: 8 kW Dimensions: 4.3 m x 1.7 m x 1.8 m Weight: 4080 kg Screen text: German Optional extras Robot interface Core pull x2

Arburg 420C-1000-60-150 ( 123) 2-component with robot and cage Year of production: 2004 TECHNICAL DATA Screw Dia [mm]: 18/30 Shot Weight [g]: 17/65 Injection Pressure [bar]: 2500/2210 Clamping Force [kN]: 1000 Tie Bar Distance [mm]: 420x420 Platen Size [mm]: 570x570 Mould Height min. [mm]: 250 CONTROL Type of Controls: Selogica Monitor: Yes Control Cabinet: Yes Language: German OTHER Power [kW]: 34,5 Workinghours [h]: 61792 Dimensions [m]: 4,6x1,8 Weight [kg]: 4000 CR - CORE PULL R - ROBOT ZP - AIR VALVE

Key data: 350 , 41 , 25

Manufacturer: Arburg Type: 221K 350 - 100 Year of construction: 09/2005 Control: Selogica Closing force: 350 kN Locking type: Knee lever Tie bar spacing: 221 mm Plate size: 324 mm x 250 mm Tool height: min 150 mm - 300 mm Opening distance: 200 mm Plate spacing max.: 350 mm - 500 mm Screw: 25 mm Stroke volume: 49 ccm / 41 gram PS Injection pressure: 2000 bar general Engine: 7.5 kW Heating: 4.6 kW Dimensions: 2.7 m x 1.4 m x 2.2 m Weight: 1200 kg Optional extras Core train x1 Hot channel integrated

Manufacturer: Arburg Type: 320 C 500 - 170 Year of construction: 11/2006 Control: Selogica Closing type: Hydraulic Closing force: 500 kN Tie bar spacing: 320 mm x 320 mm Plate size: 446 mm x 446 mm Tool height: min 200 mm Opening distance: 350 mm Plate spacing max.: 550 mm Screw: 35 mm Lifting volume: 115 ccm / 105 gram PS Injection pressure: 1470 bar general Engine: 11 kW Heating: 9.4 kW Dimensions: 3.4 m x 1.4 m x 1.9 m Weight: 2430 kg Screen text: German Additional equipment Core train x1
