6 BECHE used machine for sale

Key data: 2700 kg, 855 mm

Line Description ‍ ‍ The complete line consists of the following machines: ‍ Tilting Device, Stahlmann Step Conveyor, Stahlmann Cold Belt Conveyor Conductive Heating System, Schneider, KEA 303, 2002 Transfer Conveyor Short-Stroke Die Forging Hammer, Beche, KGH 4B, 1994 Discharge Conveyor with Blow-Off Control, Stahlmann, 2001 Gas furnace, Stahlmann Eccentric Press for Hot Trimming, Ruhrmann, EVR 125 H ‍ ‍ Technical Details ‍ (1994) Short-Stroke Die Forging Hammer BECHE KGH 4B ‍Machine identification data Name: Short-Stroke Die Forging Hammer Model: KGH 4.0B Machine number: 941 5435 Year of manufacture: 1994 ‍ Operational parameters Working capacity max. 40 kJ Max. impact frequency 98/min Max. usable impact rate 48/min Max. ram stroke 855 mm ‍ Weights Total machine weight approx. 58,000 kg Anvil bed 46,000 kg Drive head compl ...

Key data: 2700 kg, 790 mm

Semi-Automated Forging Hammer Line (2001) BECHE KG H 4B (40 KJ) Line Description ‍ ‍ The complete line consists of the following machines: Tilting device, Stahlmann Step conveyor, Stahlmann Cold conveyor belt Conductive heating unit with 3 modules, Schneider, KEA, 2002 Frako reactive power compensation unit; - Cooling system is required - Hot conveyor belt Impulse blower Short-stroke drop hammer (forging), Beche, KGH 4B, 2001 ‍ ‍ Technical Details ‍ (2001) Short-Stroke Die Forging Hammer BECHE KGH 4B ‍Machine identification data Name: Short-Stroke Die Forging Hammer Model: KGH 4B Machine number: 127050 Year of manufacture: 2001 ‍ Operational parameters Working capacity max. 40 kJ Max. impact frequency 98/min Max. usable impact rate 41/min Max. ram stroke 790 mm ‍ Weights Total machine weight approx. 58,000 kg Anvil bed 46,000 kg  ...

Key data: 3700 kg, 775 mm

Fully Automated Forging Hammer Line (2002) BECHE KG H 5B (55 KJ) Line Description ‍ The complete line consists of the following machines: ‍ Tilting Device, Stahlmann Step conveyor, Stahlmann Cold Belt Conveyor with Lifting Device Conductive Heating System, Stahlmann, E89, 2019 Heated Conveyor Belt Forging Robot, Lasco / Kuka, KR 60-3F, 2019 Central Control Cabinet Safety Fence with Safety Doors Short-Stroke Die Forging Hammer, Müller Weingarten (Beche), KG H 5B, 2002 Extraction robot, Kuka, KR 60-3F, 2019 Discharge station, Stahlmann ‍ Technical Details ‍ (2002) Short-Stroke Die Forging Hammer BECHE KGH 5B ‍Machine identification data Name: Short-Stroke Die Forging Hammer Model: KGH 5B Machine number: 127050 Year of manufacture: 2002 ‍ Operational parameters Working capacity max. 55 kJ Max. impact frequency 99/min Max. usable imp ...

Key data: 3700 kg, 775 mm

Fully Automated Forging Hammer Line (2004) BECHE KGH 5B (55 KJ) Line Description ‍ ‍ The complete line consists of the following machines: ‍ Tilting device, Stahlmann Conductive heating system, Stahlmann, D400G21/39000 XSH, 2004 Frako reactive power compensation Automation system, Lasco, 2009 2 Forging robots, Kuka, KR 30-3F Conveyor belt with lifting device Control cabinet with higher-level control system Short-stroke drop hammer, Beche, KG H 5.0B, 2004 Discharge robot for removal, Kuka, KR 30/2, with bucket, 1999 ‍ Technical Details (2004) Short-Stroke Die Forging Hammer BECHE KGH 5B ‍Machine identification data Name: Short-Stroke Die Forging Hammer Model: KGH 5.0B Machine number: 155002 Year of manufacture: 2004 ‍ Operational parameters Working capacity max. 55 kJ Max. impact frequency 99/min Max. usable impact rate 55/min Maximum ...

impact energy:207951 mkg ram hammer stroke:660 mm no. of strokes:100 /min impact energy:2040 kJ distance lower die block / ram gudeway:660 mm Throat:750 mm steel forging - rectangular up to:240 mm steel forging - diameter up to:270 mm power requirement:75,0 kW weight of hammer:16,5 t weight of anvil:15,5 t ram hammer weight:750 kg weight:32,0 t dimensions (WxDxH):3,2 x 1,45 x 3,45 m Mode of operation:pneumatisch

no. of strokes:150 /min impact energy:420 kJ distance lower die block / ram gudeway:435 mm Throat:425 mm steel forging - rectangular up to:110 mm steel forging - diameter up to:125 mm power requirement:22,0 kW weight of hammer:3,9 t weight of anvil:3,0 t ram hammer weight:200 kg weight:6,9 t dimensions (WxDxH):1,1 x 2,3 x 2,4 m
