132 DOOSAN used machine for sale

Inv. Num. : 7585 Type: DNM 400 Producer: DOOSAN Created: 2010 Parameters: Control system: Fanuc Switch-on hours: 3042 h Work table length: 920 mm Work table width: 435 mm X-axis travel: 762 mm Y-axis travel: 435 mm Travel Z-axis: 510 mm

Listing ID: 22693 Brand Engine: Doosan Model: L126 TIM Power: 400 PS (294 kW) RPM: 2100 General condition: Very low hours only test hours Features: Flywheel housing: SAE-1 Flywheel: 14 inch Starter: 1 x 24V Governor: Mechanical Exhaust system: Water cooled Turbo: Water cooled Cooling system: H-E cooled Weight: 1060 kg Dimensions (cm) 150x90x130

Inv. Num. : 5839 Type: PUMA TT 1800 SY Producer: DOOSAN Created: 2013 Parameters: Control system: FANUC 31i-B Duty cycle: 8981 h Maximum turning length: 600 mm Maximum turning diameter over bed: 300 mm Maximum turning diameter over support: 230 mm Number of spindles: 2 pieces Maximum main spindle power: 22 kW Spindle clearance: 76 mm Maximum spindle speed: 5000 1/min Maximum workpiece weight: 120 kg Max. rod diameter: 65 mm Axis X1/X2: 165/190 mm Axle Z1/Z2: 700/720 mm Axis Y: 100 mm B-axis: 770 mm C1/C2 axis: 360 Weight: 7800 kg Equipment: Bar feeder SS 2500 Conveyor Feeder/Dispenser

CNC lathe LYNX 2100 B Manufacturer: DOOSAN Year: 2017 Control Fanuc ... i Series Turning diameter ... 350mm Rotation length ... 330mm inclined bed Spindle bore ... 76mm Turret Machine weight... 2750kg Axis X ... 300mm Axis Z ... 360mm Feed diameter ... 210mm Spindle speed ... 1-4500/min. L x W x H ... 2350x1595x1693mm The machine is in good condition, possible to test under electricity.

Doosan DNM 750 II Machining center - vertical - new in 2016 - control system: FANUC

Doosan G15S-2 Forklift truck Serial: DG01041 Runs on LP GAS, up to 1500Kgs lift capacity, max lift height 4730mm, treble masts, tilt forwards and backwards, with sideshift, comes with fork extensions

DOOSAN PU126TI 395 HP - 2100 RPM / 0 HOURS AFTER OVERHAUL / NEW PISTON RINGS / CONNECTING RODS / BEARINGS

MAX DIAMETER OF ROTATION: 750 MM MAX DIAMETER SWITCHABLE: 680 MM SWITCHABLE LENGTH: 1195 MM CNC: FANUC 18i-TB MAIN SPINDLE: MAX SPEED. OF ROTATION: 2800 RPM DIN 55026 8 ' ' CHUCK NOSE BAR PASS: 95 MM MOTOR POWER: 30 KW SELF-CENTRING DIAMETER: 315 MM Tailstock: POSITIONING STROKE: 1310 MM RACEWAY: 150 MM TUBE DIAMETER: 115 MM TORRETA TOOLHOLDER: MOTOR POWER: 10-17.5 KW TOOL DIMENSIONS: 25X25 MM BARENI DIA DIMENSIONS: 32-40 MM

X-AXIS STROKE MM 2,400 Y-AXIS STROKE MM 960 AXLE STROKE Z MM 800 TABLE SIZE MM 2600X900 ATTACK: BT50 SPEED ROTATION REVOLUTIONS/MIN 12,000 TOOLS N ° 30 FANUC 31I MODEL A CONTROL YEAR: 2012

Classification L136TI Cylinder L6 Aspiration TI Displacement (Liter) 8.1 Bore x Stroke (mm) 111 x 139 kW(ps)/rpm Heavy Duty 169(230) @ 2200 Dimension (L×W×H) (mm) 1364 x 911 x 937 Dry Weight (kg) 773 Emissions Tier 2 Power Range (kW) 169 Speed Range (rpm) 2200 The value is based on Output (ISO 3046, 8528).

Specifications Classification L136 Cylinder L6 Aspiration NA Displacement (Liter) 8.1 Bore x Stroke (mm) 111 x 139 kW(ps)/rpm Heavy Duty 118(160) @ 2200 kW(ps)/rpm Medium Duty - kW(ps)/rpm Light Duty - Dimension (L×W×H) (mm) 1266 x 875 x 937 Dry Weight (kg) 743 Emissions Tier 1 Power Range (kW) 118 Speed Range (rpm) 2200 The value is based on Output (ISO 3046, 8528).

Model L126TI No. of Cyl. L6 Aspiration TI Displacement (Liter) 11.1 Bore x Stroke (mm) 123x155 Output (ISO 3046, 8528 kW(ps)/rpm) 265(360) / 2000 - Dimension (L×W×H) 1235x855x1073 Dry Weight (kg) 1,060 Emission TIER-2

New CoBot Brand: Doosan Robotics Type: H2017 The video shows a DOOSAN H2017 CoBot in cooperation with a CNC machining center VITAP K2 2.0 with automatic package. The Doosan Robotics H2017 Carries loads up to 20kg and works with a reach up to 1700mm. Including robot column, vacuum gripper, commissioning, pre-assembly, interface, training, safety technology and CE certification, the recommended retail price is approx. 65,000? net. The time required for teaching new parts is about one hour - always depending on the complexity of the work steps. The optimal area of application for this CoBot is recurring small batches and series that utilize the robot over several shifts. Have you become curious? Then please feel free to contact us about the topic!

Horizontal turning machine manufactured in 2018. This DOOSAN Lynx 2100A features a maximum turning diameter of 350 mm and a turning length of 330 mm. It is equipped with a spindle speed of 5,000 rpm and a chuck size of 8” (210 mm). If you are looking to get high-quality turning capabilities, consider the DOOSAN Lynx 2100A machine we have for sale. Contact us for further details regarding this machine.

Horizontal turning machine manufactured in 2021. This DOOSAN Lynx 2100A features a maximum turning diameter of 350 mm and a turning length of 330 mm. It is equipped with a spindle speed of 6,000 rpm and a chuck size of 6” (160 mm). If you are looking to get high-quality turning capabilities, consider the DOOSAN Lynx 2100A machine we have for sale. Contact us for further details.

This 6-axis DOOSAN M1013 collaborative robot was manufactured in 2021. It features a payload capacity of 10 kg and a reach of 1,300 mm, making it suitable for various applications. The machine includes a stable construction with an aluminum plate and a rotary table for enhanced functionality. If you are looking to get high-quality automation capabilities, consider the DOOSAN M1013 collaborative robot we have for sale. Contact us for further details.

This 4-axis DOOSAN Puma 2600YB II was manufactured in 2019. It features a maximum turning length of 725 mm and a swing over bed of 780 mm. The machine is equipped with a FANUC i Series controller and includes 12 turret stations for enhanced productivity. If you are looking to get high-quality turning capabilities, consider the DOOSAN Puma 2600YB II machine we have for sale. Contact us for further details.

CNC lathe Type: Lynx 220 Manufacturer: Doosan Year: 2012 Control: Fanuc i Series Spindle hours: 1743 Max. turning diameter: 320 mm X: 175 mm Z: 330 mm Spindle speed: 5000 rpm Turret: 12 positions Tailstock Chip conveyor Tool probe Part catcher Machine in good condition, fully functional, under power Find more here - / Contact us at -

This 4-axis DOOSAN ACE HC-500 was manufactured in 2005. It features an X-axis travel of 850 mm, Y-axis travel of 700 mm, and Z-axis travel of 750 mm. The machine includes a robust pallet size of 500 x 500 mm with a maximum pallet load of 500 kg. If you are looking to get high-quality machining capabilities, consider the DOOSAN ACE HC-500 horizontal machining centre we have for sale. Contact us for further details.

turning diameter: 760 mm turning length: 1540 mm control: Fanuc 31i-B dimensions of machine: 5500 x 2700 x 3110 mm chip conveyor: 6900 x 2400 mm total power requirement: 94,42 kW weight of the machine ca.: 15,5 t dimensions of the machine ca.: m Turning center with infinitely variable swiveling milling head and Y-axis, motorized lower turret and subspindle. Condition: Very well preserved, machine comes from a company liquidation. Time recording: Control unit on: 13127 hours Runtime: 3833 hours Processing time: 2835 hours The upper head is fed by a tool magazine and can turn or mill at various angles. Even highly complex components can be completely machined without further repositioning. Fanuc 31i-B CNC control Swing diameter over bed: 1000 mm Maximum turning diameter: 760 mm Maximum turning length: 1540 mm Maximum bar diameter (manual/continuous): 76/76 mm Y-axis travel: 230 mm (±115  ...

This 3-axis DOOSAN DNM 5700 was manufactured in 2017. It features an X-axis travel of 1050 mm, Y-axis travel of 570 mm, and Z-axis travel of 510 mm. The machine includes a table size of 1300 x 570 mm and a maximum table load of 1000 kg. If you are looking to get high-quality machining capabilities, consider the DOOSAN DNM 5700 vertical machining centre we have for sale. Contact us for further details.

CNC vertical machining center Type: DEM 4000 Manufacturer: Doosan Year: 2020 Control: Fanuc i Series X: 550 mm Y: 400 mm Z: 450 mm Spindle taper: BT40 Max spindle speed: 8000 rpm Table: 650 x 400 mm Max table load: 400 kg Machine weight: 3100 kg Tool probe Renishaw Work probe Chip conveyor In January, a general overhaul of the spindle plus the table of all axes was carried out. The machine is fully equipped Vices-clamping from the company LANG Boring heads, a large number of carbide drills, cutters and tools. Clamping milling magnet Grip cutter plus a powerful table Top-notch hydraulic-collet clamping of which there are about 50pcs Plus top-notch gauges and measuring devices The machine also includes a snow compressor with a refrigerator. Machine in good condition, fully functional, under power Find more here - / Contact us at -

x-travel: 1300 mm y-travel: 670 mm z-travel: 625 mm control: Siemens Sinumerik 828D total power requirement: kW weight of the machine ca.: 8500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1300 mm y-travel: 670 mm z-travel: 625 mm control: Siemens Sinumerik 828D total power requirement: kW weight of the machine ca.: 8500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 376 mm turning length: 1245 mm control: FANUC i-Series turning diameter over bed: 376 mm x-travel: 230 mm z - travel: 1350 mm rapid travel x/y/z: 24/30 m/min main spindle speeds:: 2800 spindle motor: 35 / 26 kW max. torque on the spindle: 1613 Nm spindle passage: 102 mm total power requirement: 33,91 Kva weight of the machine ca.: 7 t dimensions of the machine ca.: 4,6 x 2,11 x 2,3 m Equipped with: - Fanuc i-Series CNC control - C-axis - 3-jaw chuck, 304 mm diameter - 12-station tool turret - Tailstock - Chip conveyor - CE Only 2,300 spindle hours The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

A Doosan CNC lathe is available. Turning diameter: 300mm, turning diameter over bed/face slide: 550mm/390mm, max. turning length: 510mm, travel path X/Z: 205mm/580mm, rapid traverse: 24m/min, C-axis: 360°, bar capacity: 65mm, spindle bore: 76mm, speed: 4500rpm, tool stations: 12. Machine dimensions X/Y/Z: approx. 3500mm/1650mm/1800mm, weight: approx. 4250kg, control: Fanuc Series 18i-TB. Documentation vorhanden. An on-site inspection is possible.

This 3-axis DOOSAN Puma 2600 SY II was manufactured in 2018, designed for precision in horizontal turning. Ideal for complex machining tasks, this machine ensures robust performance and durability. If you are looking to get high quality turning capabilities consider the DOOSAN Puma 2600 SY II machine we have for sale. Contact us for more information.

This 4-axis DOOSAN Puma 2600 LYB II was manufactured in 2021. It features a maximum turning diameter of 376 mm and a turning length of 1,350 mm. The machine includes a 12-station turret, a live tailstock, and a steady rest with a diameter range from 40 mm to 200 mm. If you are looking to get high-quality turning capabilities, consider the DOOSAN Puma 2600 LYB II horizontal turning machine we have for sale. Contact us for further details.
