DOOSAN dnm used machines

This 3-axis DOOSAN DNM 500 was manufactured in 2011. It features a robust table size of 1200 × 540 mm and axis travels of 1020 × 540 × 510 mm. Equipped with through-spindle cooling and preparation for a 4th axis, it offers enhanced machining capabilities. Consider the opportunity to buy this DOOSAN DNM 500 vertical machining centre. Contact us for more information.

This 4-axis DOOSAN DNM 6700 vertical machining center was manufactured in 2017. Ideal for precision machining, it offers robust construction and reliability. Consider the opportunity to buy this DOOSAN DNM 6700 vertical machining center. Contact us for more information.

This 3-axis DOOSAN DNM 500 vertical machining center was manufactured in 2010. It features a large table size of 1200x540mm, capable of handling loads up to 800 kg. The machine operates with a speed of 36 m/min and includes a BT40 tool holder. Ideal for robust milling operations, the DOOSAN DNM 500 machine we have for sale represents a significant opportunity. Contact us for more information.

This 4s DOOSAN DNM 500II was manufactured in 2016, featuring a table size of 1200 × 540 mm and a maximum table load of 800 kg. With an X-axis travel of 1020 mm and a spindle speed of 12,000 rpm, this vertical machining center offers efficient machining capabilities. Consider the opportunity to buy this DOOSAN DNM 500II vertical machining center. Contact us for further details.

Key data: 800 mm, 450 mm, 510 mm

Doosan DNM 4500 Vertical Machining Center (VMC) Year of construction: 2016 Condition: Used – in very good working condition Well-maintained Doosan DNM 4500 vertical machining center, ideal for precision milling and general machining. Technical specifications: X-axis travel: 800 mm Y-axis travel: 450 mm Z-axis travel: 510 mm Rapid traverse (X/Y/Z): 36 / 36 / 30 m/min Spindle speed: up to 8,000 rpm Spindle power: 18.5 kW Spindle torque: 117.8 Nm Tool changer: 30 positions Table size: 1,000 mm Max. workpiece weight: 600 kg Machine weight: approx. 5,000 kg The machine has been regularly maintained and is in good condition. Inspection under power is possible.

This 3-axis DOOSAN DNM 400 II was manufactured in 2014. It features an X-axis travel of 762 mm, Y-axis travel of 435 mm, and Z-axis travel of 510 mm. The machine includes a worktable with dimensions of 920 mm x 435 mm and a maximum table load of 600 kg. If you are looking to get high-quality machining capabilities, consider the DOOSAN DNM 400 II vertical machining centre we have for sale. Contact us for further details.

This 3-axis DOOSAN DNM 5700 was manufactured in 2017. It features an X-axis travel of 1050 mm, Y-axis travel of 570 mm, and Z-axis travel of 510 mm. The machine is equipped with a powerful 18.5 kW spindle and a table size of 1300 × 570 mm, allowing for efficient machining operations. If you are looking to get high-quality machining capabilities, consider the DOOSAN DNM 5700 vertical machining centre we have for sale. Contact us for further details.

travel -x axis: 1.050 mm travel -y axis: 570 mm travel -z axis: 510 mm control: HEIDENHAIN - TNC620 number of spindle speeds: 12.000 U/min tool taper: BT 40 table dimension (L x W): 1300 x 570 mm numbers of positions in the tool changer: 30 Milling machining centers - vertical | DOOSAN - DNM 5700 equipped with 30-way tool changer, ITC cooling system and chip conveyor. The machine only has 13.600 spindle hours. The machine is in a well-maintained condition and has exclusively worked on Aluminum and Plastics. The machine video from the production plant will be shared on request. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: DNM5700 | DNM-5700 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Machine Details Stock number 1105-03821 Machine type machining center - vertical Make DOOSAN Type DNM 650 II Year of construction 2015 Control type CNC Storage location FRANCE Country of origin Korea Delivery time ON REQUEST Freight base from stock HAGUENAU FRANCE Technical details x-travel 1270 mm y-travel 670 mm z-travel 625 mm CNC control SIEMENS 840 D Table size 1300 x 670 mm table load 1000 kg Spindle holder ISO SK 40 Spindle speeds 8000 rpm Feed infinitely variable 8000 mm/min Rapid traverse 36 / 36 / 30 m/min Drive power - spindle motor 18,5 (15 min) kW Tool changing device 30 items. Operating voltage 380 V Total power requirement 40 kVA Machine weight ca. 8,5 t Space requirement approx. 3.20 x 2.45 x 2.40 m Chip conveyor 4.10 x 0.65 x 1.50 Coolant device 3.60 x 2.20 x 0.80 m Information Excellent condition! LIKE NEW with internal coolant supp ...

Doosan DNM 750 II Machining center - vertical - new in 2016 - control system: FANUC

Vertical machining center DOOSAN DNM 650, control system FANUC

This 3-axis DOOSAN DNM 415 vertical machining center was manufactured in 2015. It features a 765 x 450 x 510 mm travel range, a 920 x 435 mm table size, and a 24-station tool changer. The spindle operates at 10,000 RPM with a 15 KW motor. Includes a Fanuc Series 01-MC controller and a chip conveyor. Ideal for precision machining. Contact us for further details regarding this vertical machining center.

achine-Details Stock-No. 1105-03801 Type of machine Machining Center - Vertical Make DOOSAN DAEWOO Type DNM 5700 Year of manufacture 2021 Type of control CNC Storage location HAGUENAU FRANCE Country of origin KORREA Delivery time IMMEDIATELY Freight basis Ex works Technical details longitudinal 1020 mm cross 570 mm vertical 510 mm Tool Changer 30 Pos. max. tool length 300 mm max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm Rapid Traverse 36 m/min Weight of the machine approx. 7 t power capacity at 100 % load 11 kW power capacity at 40 % load 12000 kW turning speed range 8000 1/min tool taper BT 40 table surface area 1200 x 500 mm groove width 18 mm Additional information direct measuring system, El. handwheel, internal coolant supply package (chipconveyor, cooling trought the spindle, 12000rpm spindle) SIEMENS 828D CONTROL LIKE NEW ONL ...

Table dimensions: 1.300 x 570 mm Courses (X/Y/Z) 1.050 X 570 X 510 mm - Number of tool stations: 30 - Rapid Traverse (X x Y x Z): 36 x 36 x 30 mm/min - Max. spindle speed: 12.000 rpm - Operating hours: 5.456 - Axes: 3

Including: - Coolant Tray - Chip conveyor - Number of tool stations: 20 - Spindle power : 15 kW - Backgauge speed (X x Y x Z ): 24 x 24 x 20 mm/s - Travel (X x Y x Z): 762 x 435 x 510 mm - Working area (X x Y x Z): 920 x 436 mm - Max. workpiece weight: 600 kg - Max. spindle speed: 8.000 rpm - Operating hours: 6.700 - Axes: 3 - Weight: 500 - Dimensions (long x wide x high): 2.093 ? 1.962 ? 2.509 mm

x-travel: 1270 mm y-travel: 670 mm z-travel: 625 mm CNC-control: SIEMENS 828 D table-size: 1300 x 670 mm max. table load: 1000 kg spindle taper ISO: SK 40 spindle turning speed range: 12000 U/min feed stepless: 8000 mm/min rapid traverse: 36 / 36 / 30 m/min drive capacity - spindle motor: 18,5 kW tool change unit: 30 Pos. total power requirement: 40 kVA weight of the machine ca.: 8,5 t dimensions of the machine ca.: 3,20 x 2,45 x 2,40 m chip conveyor: 4,10 x 0,65 x 1,50 coolant: 3,60 x 2,20 x 0,80 m - Siemens 828D CNC control - Direct drive spindle: 12,000 rpm - Two-contact clamping system in the BIG-PLUS spindle (SK40 spindle taper) - Oil cooling of the spindle head - Thermal compensation system (software) - Tool magazine: 30 tools - RENISHAW tool and workpiece probe - Internal cooling via the spindle centre: 12 bar - External cooling with air and cooling lubricant - Internal thread spi ...

x-travel: 1300 mm y-travel: 670 mm z-travel: 625 mm control: Siemens Sinumerik 828D total power requirement: kW weight of the machine ca.: 8500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CNC vertical machining center Type: DNM 400 Manufacturer: Doosan Year: 2010 Control: Fanuc i Series X: 635 mm Y: 435 mm Z: 510 mm Table size: 790 × 435 mm Max. table load: 400 kg Tool magazine: 20 positions Max. spindle speed: 8000 rpm Spindle power: 15 kW Spindle taper: ISO 40 Machine weight: 5000 kg Dimensions: 1962 × 2093 × 2509 mm Chip conveyor Machine in good condition, fully functional, under power Find more here - / Contact us at -

The machine is in good technical condition, testing is possible after prior agreement. The machine is offered without a divider.

x-travel: 1050 mm y-travel: 570 mm z-travel: 510 mm Control: Siemens 828D Main spindle:: turning speed range - main spindle: 12000 min/-1 power capacity - main spindel: 16,5 / 11 kW max. Torque: 141 Nm tool taper: BT 40 distance spindle /table: 150 - 775 mm work table:: table surface area: 1300 x 570 mm max. table load: 1000 kg tool magazin:: number of toolpositions: 40 pos. tool taper: BT 40 max. tool diameter: 80 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,2 sec change-time chip to chip: 3,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 30 m/min workpiece height max.: 590 mm total power requirement: 40,9 kVA weight of the machine ca.: 6,5 t dimensions of the machine ca.: 2,5 x 3,1 x 2,98 m 3-axis vertical CNC machining center - Siemens 828D CNC control and workshop-oriented programming support Shop Mill - 40-tool tool changer (BT 40) - Bas ...

Model L126TI No. of Cyl. L6 Aspiration TI Displacement (Liter) 11.1 Bore x Stroke (mm) 123x155 Output (ISO 3046, 8528 kW(ps)/rpm) 265(360) / 2000 - Dimension (L×W×H) 1235x855x1073 Dry Weight (kg) 1,060 Emission TIER-2

Specifications Classification L136 Cylinder L6 Aspiration NA Displacement (Liter) 8.1 Bore x Stroke (mm) 111 x 139 kW(ps)/rpm Heavy Duty* 118(160) @ 2200 kW(ps)/rpm Medium Duty* - kW(ps)/rpm Light Duty* - Dimension (L×W×H) (mm) 1266 x 875 x 937 Dry Weight (kg) 743 Emissions Tier 1 Power Range (kW) 118 Speed Range (rpm) 2200 * The value is based on Output (ISO 3046, 8528).

Classification L136TI Cylinder L6 Aspiration TI Displacement (Liter) 8.1 Bore x Stroke (mm) 111 x 139 kW(ps)/rpm Heavy Duty* 169(230) @ 2200 Dimension (L×W×H) (mm) 1364 x 911 x 937 Dry Weight (kg) 773 Emissions Tier 2 Power Range (kW) 169 Speed Range (rpm) 2200 * The value is based on Output (ISO 3046, 8528).

X-AXIS STROKE MM 2,400 Y-AXIS STROKE MM 960 AXLE STROKE Z MM 800 TABLE SIZE MM 2600X900 ATTACK: BT50 SPEED ROTATION REVOLUTIONS/MIN 12,000 TOOLS N ° 30 FANUC 31I MODEL A CONTROL YEAR: 2012

MAX DIAMETER OF ROTATION: 750 MM MAX DIAMETER SWITCHABLE: 680 MM SWITCHABLE LENGTH: 1195 MM CNC: FANUC 18i-TB MAIN SPINDLE: MAX SPEED. OF ROTATION: 2800 RPM DIN 55026 8 ' ' CHUCK NOSE BAR PASS: 95 MM MOTOR POWER: 30 KW SELF-CENTRING DIAMETER: 315 MM Tailstock: POSITIONING STROKE: 1310 MM RACEWAY: 150 MM TUBE DIAMETER: 115 MM TORRETA TOOLHOLDER: MOTOR POWER: 10-17.5 KW TOOL DIMENSIONS: 25X25 MM BARENI DIA DIMENSIONS: 32-40 MM
