used Hole Punches for sale

sheet width: 500 mmplate length: 1000 mmplate thickness: max. 6,0 mmpressure: 28,0 tthroat: 500 mmheight of stroke: 0 - 40 mmworking area: X = 1200 mmworking area: Y = 570 mmno. of strokes: max. 180 Hub/minpunch diameter: max. 105 mmwork height max.: 900 mmoil volume: 50 ltotal power requirement: 4,0 kWweight of the machine ca.: 2500 kgrange L-W-H: 2400 x 1580 x 1540 mm New price including accessories approx. 30.000 euros Special price on requestThe hydraulic punching machine ECCO LINE is specially designed for processingSheet metal and profile parts have been optimized. She stands out for herFlexibility and manufacturing precision. The machines in the ECCO seriesLINE are equipped with 28 t punching force in conjunction with the provenTrumpf tool system. Tool change time approx. 15 seconds (manually)How it works: After installing the tool, the stops are in X and Ypositioned accordingly a ...

Offer here a post Cewe stand units partly still packed in all paper and unused partly already used or not quite complete anymore the tools have not been used for a bit longer but still in the functional state retail sale possible

Paneling Finn-Power Bending Automation Mod. Bending Cell Type BC 2550 200 year 1999 Hours: 27.800 This machine is in good condition and worked for few hours. I point out to you that there is an oil leak wich comes from a cylinder. The machine is functioning and in case of your visit, it can be connected again.

throat: 750 mmpunch diameter: max. 75 mmmax. sheet metal thickness: 4 mmweight of the machine ca.: 250 kgdimensions of machine L x W x H: 1,41 x 0,75 x 1,47 mmax. punch cap. in steel ø 75 in 2,0 mm,in aluminium ø 75 in 3,2 mm resp. ø 55 in 4,0 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 110 tpunching cross-cut in cmm: Ø 40x20 mmstroke: 80 mmstrokes per minute: 28 throat: 500 mmtotal power requirement: 9 kWweight of the machine ca.: 3,3 tHole punch / automatic punching machine GEKA with multiple tools (triple punching)Punching performance:Ø 40 x 20 mmØ 28 x 28 mm- 28x20mmAccesories:- Roller conveyor with stop (feed unit PAX)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 55 tpunching cross-cut in cmm: 0stroke: 37 Min./20 mmthroat: 500 mmstroke: max. 60 mmwork height max.: 1060 mmtotal power requirement: 5 kWThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 11 tpunching cross-cut in cmm: diverse stroke: 50 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mhydraulic punching pressWith 3 punching tools.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

offer 22273 Specifications: - Stroke 30 mm - Air consumption per stroke 5 l - Pneumatic connection 8 bar - Space requirement approx. W 500 x H 550 x D 500 mm - Weight approx. 70 kg - with: - Foot switch - Machine base mobile W 600 x H 830 mm - Various tools HUECK

Offer 23035 Technical data approx.: - Pressure capacity 30 t. - max. sheet thickness 10 mm - max. punching diameter 105 mm - Punching performance - e.g. Sheet steel : 105 mm in 1.5 mm ; 45 mm in 5 mm - e.g. VA sheet metal : 90 mm in 1.5 mm ; 45 mm in 4 mm - Stroke 7 - 70 mm - Projection 560 mm - Maximum stroke rate 120 h/min - Single stroke / continuous stroke - Drive 400 V / 4 kW - Space requirement approx. W 8000 x H 1850 x D 1700 mm - Weight approx. 1900 kg - with: - Notice table with stops - Foot switch; - Emergency stop button - Punch quick-change device - various receptacles, punches and matrices

Offer 23481 Specifications: - Printing capacity 30 t - max. sheet thickness 6 mm - Max. punching diameter 105 mm - Stroke 42 mm - Projection 700 mm - Maximum stroke rate 200 H/min - Table dimensions W 1500 x D 1100 mm - Table height 1000 mm - Drive 400 V / 4 kW - Space requirement approx. W 1600 x H 2000 x D 2200 mm - Weight approx. 3400 kg - With: - Bulletin table with adjustable stops - Quick-change punch device - Foot switches; - Emergency stop button - Various punches + dies in separate workbench

MUBEA BFL 350 - Profile steel shears technical data see pictures Dimension: LxWxH 1.1x0.7x1.8 meters Coizilgunw Weight 1100Kg

: 100 tdiameter: 40 mmthroat: 760 mmtotal power requirement: 8,5 kWweight: 3.600 kgAccessories / equipment:- punching tableThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Specifications: - Pressure capacity 450 KN - perforates e.B. up to 25 mm Ø in steel 15 mm - Stroke infinitely adjustable 0 to 60 mm - Stroke rate approx. 16 to 47 1/min - Projection 760 mm - Installation height 215 mm - Working height 1150 mm - Drive 400 V / 7.5 kW - Space requirement approx. W 850 x H 1850 x D 1650 mm - Weight approx. 1350 kg - with: - E. foot switch - 20 pieces of various punches + dies

Punching force: 300 kN For example, punches a 20 mm hole in 12 mm steel Stroke release via foot switch Support table with stop Assortment of tools is included in the price

Punching force: 350 kN For example, punches a 23 mm hole in 12 mm steel Stroke release via foot switch Assortment of tools is included in the price

Max. punching force: 750 kN Stroke triggering via foot switch For example, punches a 30 mm hole in 20 mm thick steel With assortment of tools as desired

pressure: 30.0 tpunching cross-cut in cmm: 30 in 9.0 mmstroke: 0 - 28.0 mmcolumn arm: 610 mmwork height max.: 1010 mmno. of strokes: ca. 35 Hub/minoil volume: 35.0 lpunching cross-cut in cmm: 270 mm²total power requirement: 4.0 kWweight of the machine ca.: 1200 kg.range L-W-H: 1400 x 700 x 1600 mm good condition () with a lot of application tools (stamps/dies)Furnishing:- electro-hydraulic hole punch, with large throat- Material/sheet metal scrapers including scraper plates- Large material support table, with adjustable depth stops- continuous stroke adjustment- freely movable foot switch including protective cover- Forklift pockets for easy transport- side storage area- lots of accessories + tools - including tool cabinet- Matrix base (for special size matrices)- Stamp holders (for special size stamps)- original user manuel Machine link:https://mhp.logotech.de/hpm/v7/Datenblatt/datenbl ...

Offer 23293 Specifications: - Printing capacity 300 KN - punches e.g. up to 30 mm Ø in steel 9 mm - or with special punching device up to 100 mm Ø in steel 2.5 mm - Infinitely adjustable stroke 0 to 28 mm - Stroke rate 26 to 36 1/min - Projection 610 mm - Installation height 240 mm - Drive 400 V / 4 kW - Space requirement approx. W 750 x H 1650 x D 1350 mm - Weight approx. 1300 kg - With: - Foot switch - Grain detection device, - Support table with foldable stops W 1100 x D 850mm - Sliding paths of the stops from the center of the punch - Width between Li and Re approx. 470 mm x D 510 mm

pressure: 50 tthroat: 610 mmhole diameter in sheet thickness: 30 / 15 mmconnected load: 5,5 kWstroke: 60 mm: 1510 x 660 mmweight of the machine ca.: 1,9 tdimensions of the machine ca.: 1,5 x 1,55 x 1,9 mith a wide range of accessoriesSee picturesThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Maximum punching force: 650 kN More performance data see nameplate or on request Inclusive range of punches and matrices

offer 20366 Specifications: - Printing capacity 100 t - Stroke infinitely adjustable 10 - 100 mm - stroke rate 34 - 80 1/min - Projection 510 mm - Installation height 500 mm - Drive 380 V / 15 kW - punches e.g. up to 31 mm Ø in steel 25 mm - with special punching caliper e.g. up to 58 mm Ø in steel 13 mm - e.g. up to 90 mm Ø in steel 8.5 mm - Space requirement approx. W 1200 x H 2550 x D 2100 mm - Weight approx. 3700 kg - No tools or punching saddles available

Specifications: - Pressure capacity 1000 KN - Stroke infinitely adjustable 10 - 100 mm - Stroke rate 34 - 80 1/min - Projection approx. 510 mm - Installation height approx. 450 mm - Drive 400 V / 15 kW - punches e.B. up to 31 mm Ø in steel 25 mm - with special punch saddle z.B. up to 58 mm Ø in steel 13 mm - e.B. up to 90 mm Ø in steel 8.5 mm - Space requirement approx. W 1200 x H 2400 x D 2300 mm - Weight approx. 3600 kg - with: - Hydr. Low Pressure Grain Detection Device - various punches + matrices - Emergency stop button

Punching force: 1000 kN Weight: 2400 kg For example, punches a 40 mm hole in 20 mm steel Stroke release via foot switch Includes viewfinder for graining and setup Assortment of tools is included in the price

pressure: 125 tpunching cross-cut in cmm: Ø 39 in 24 mmstroke: 10 - 50 mmcolumn arm: 510 mmwork height max.: 1100 mmno. of strokes: 29 Hub/minpunch diameter: max. Ø 130 x 7.0 mmoil volume: 103 ltotal power requirement: 11.0 kWweight of the machine ca.: 2350 kg.range L-W-H: 1750 x 1100 x 1910 mm good condition () New price without accessories approx. 27.500 euros Special price on requestFurnishing:- heavy / robust electro-hydraulic hole punch, with large throat- Punching station with material/sheet metal scraper- stepless stroke adjustment .. 10-50 mm- freely movable foot switch including protective cover- hydraulic low pressure finder for foot switch operation- Crane hanging eye for easy transport- side storage area- Hydraulic unit, integrated- Three-phase motor, 400 volts, 50 Hz- User manual (PDF) Special accessories included:- NC controlled stop system - WITHOUT function- the stop sy ...

Specifications: - Printing capacity 50 T - Outreach approx. 360 mm - Installation height approx. 240 mm - Drive 400 V / 7.5 kW - punches in ST 40 e.g. up to 25 mm Ø in 16 mm - up to 20 mm Ø in 19 mm - Space requirement approx. W 1000 x H 1900 x D 1000 mm - Weight approx. 1800 kg

Punching force: 500 kN For example, punches a 20 mm hole in 18 mm steel Stroke release via foot switch Assortment of tools is included in the price

Punching force: 500 kN For example, punches a 20 mm hole in 18 mm steel Stroke triggering via foot switch Large support table WBL Assortment of tools is included in the price

Punching force: 500 kN For example, punch a 20 mm hole in 18 mm steel Stroke release via foot switch Assortment of tools is included in the price

pressure: 100 tpunching cross-cut in cmm: -- stroke: 100 mmthroat: 510 mmwork height max.: 1100 mmTwist power: 31 Durchm. in 25 mmchannels - flange: 100-400 mmNumber of ventilators: 80-400 mm: 100-400 mm: 100-550 mmpunch stroke: bei 20 mm Hub: 60 p.Minsheet thickness max.: bei Luftbiegung: 10 mmtotal power requirement: 7,5 kWweight of the machine ca.: 2,4 tdimensions of the machine ca.: 1,7 x 0,9 x 2,3 mElectric 380 Volt: Diverse punches and dies: Foot pedal: Machinefeets: Machine dealer with own stock of 2500 m².The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 50,0 tpunching cross-cut in cmm: 31 in 12 mmstroke: max. 32,0 mmcolumn arm: 510 mmwork height max.: 1070 mmstroke - stepless adjustable: 10 - 32 mmno. of strokes: max. 45 Hub/minoil volume: 45,0 ltotal power requirement: 4,0 kWweight of the machine ca.: 1120 kg.range L-W-H: 1118 x 650 x 1680 mm good condition () from a maintenance workshopFurnishing:- hydraulic punch, with large overhang- Sheet metal wipers with wiper plates- stepless stroke adjustment- Various application tools- Die base- free-moving footswitch- Operation manualThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Punching force: 200 kN For example, punches a 13 mm hole in 12 mm steel Viewfinder via handwheel Assortment of tools is included in the price

Specifications Model No.: PM-55T Serial No.: 94713 Punching pressure max: 55 tons Punching capacity max.: Ø 22 x 18 mm Diameter x thickness: Ø 50 x 8 mm Engine power (kW): 3.7 Working height: 1050 mm Projection: 310 mm Table size (LxW): 700 x 500 mm Weight: 1620 kg Year of manufacture: 9/1999 Country of origin:Taiwan

TRUMPF TRUMATIC 600L Work area: 3000 x 1600 mm. Hours: 29.000
