Horizontal Bandsaws used for sale (25)

Horizontal Band Saw PROMAC SX 818 DV-M Year of construction: 2016 Blades dimensions: 20 x 0,9 x 2080 mm Max cutting capacity: Ø 180 mm Max vise opening: 220 mm Cutting speeds: from 30 to 80 m/min. Motor power: 2 KW Machine in very good condition Blade Speed by variable speed drive Automatic or manual descent Lubricant pump Voltage: 220 V mono Width: 800 mm Depth: 1200 mm Height in low position: 1500 mm Weight: approx 200 KG

Power 250 W - 220V, never used Overall dimensions: 500 x 500 x 800 mm Weight: 20 kg Auction-ID: A7-50796-372

Cutting range round 0°: 150 mm Cutting area square 0°: 150 x 150 mm Cutting area flat 0°: 150 x 165 mm Cutting range round 45°: 115 mm Cutting area flat 45°: 115 x 130 mm Cutting range round 60°: 60 mm Cutting area flat 60°: 70 x 70 mm Working height approx.: 700 mm Band saw blade dimensions: 1735 x 13 x 0.65 mm Cutting speeds : 40 / 80 m/min Motor output power S1 100%: 0.75 kW Voltage : 400 V Machine dimensions : 1200 x 750 x 1250 mm Weight approx.: 85 kg Characteristics: • For cutting profiles, tubes, solid materials made of VA, iron and non-ferrous materials • For miter cuts, the saw bracket can be swivelled by up to 60° • Infinitely variable lowering via hydraulic lowering cylinder • Torsion-free, strongly dimensioned saw arm made of grey cast iron • 2 cutting speeds for optimal cutting results • Robust construction, therefore smooth and vi ...

Power 250 W - 220V, never used Overall dimensions: 500 x 500 x 800 mm Weight: 20 kg Auction-ID: A7-50799-372

Cutting range round 0°: 150 mm Cutting area square 0°: 150 x 150 mm Cutting area flat 0°: 150 x 165 mm Cutting range round 45°: 115 mm Cutting area flat 45°: 115 x 130 mm Cutting range round 60°: 60 mm Cutting area flat 60°: 70 x 70 mm Working height: 700 mm Band saw blade dimensions: 1735 x 13 x 0.65 mm Cutting speeds: 40 - 80 m/min Motor output power S1 100%: 0.75 kW Voltage: 400 V Machine dimensions: 1200 x 750 x 1250 mm Weight approx.: 85 kg Characteristics: • For cutting profiles, tubes, solid materials made of VA, iron and non-ferrous materials • For miter cuts, the saw bracket can be swivelled by up to 60° • Infinitely variable lowering via hydraulic lowering cylinder • Torsion-free, strongly dimensioned saw arm made of grey cast iron • 2 cutting speeds for optimal cutting results • Robust construction, therefore smooth and vibration-fre ...

iron saw with guide working Auction-ID: A1-47366-90

Cutting range round 0°: 127 mm Cutting area flat 0°: 125 x 130 mm Cutting range round 45° right: 90 mm Cutting area square 45° right: 90 x 90 mm Cutting range approx. 60° right: 45 mm Cutting area square 60° right: 45 x 45 mm Vice opening: 130 mm Band saw blade dimensions: 1440 x 13 x 0.65 mm Cutting speeds: 30 - 80 m/min Motor power: 0.55 kW Voltage: 230 V Weight approx.: 25 kg Characteristics: - Two cutting speed levels for optimal adaptation to the workpiece - For miter cuts, the saw bracket can be swivelled up to 60° - Including workpiece stop for rational work - Optimum cutting results thanks to band saw blade guide with ball bearings - High-torque engine, even under continuous load - Under load, the motor electronics keep the cutting speed largely constant - Environmentally friendly, as there is no need for lubricating and coolant fluids - Smooth, low ...

Controllo touch KASTO BASIC CONTROL Auction-ID: A7-51034-18

Technical data: - Cutting range at 90° around 260 mm - flat 450 x 240 mm - Cutting range at 45° around 230 mm - flat 240 x 200 mm - Machine is mounted on original turnstile - Saw band dimension 3660 x 25 x 0.9 mm - Cutting speeds 20 / 35 / 50 / 70 m/min - Hydr. lifting + lowering the saw frame - Cutting pressure infinitely adjustable 0 - 10 m/min - Total drive power 400 V / 0.8 kW - Coolant device - Space requirement approx. W 2100 x H 1200 x D 1000 mm - Weight approx. 500 kg

Power 250 W - 220V, never used Overall dimensions: 500 x 500 x 800 mm Weight: 20 kg Auction-ID: A7-50798-121

Cutting capacity round 90°: 170 mm cutting capacity flat 90°: 140 x 210 mm cutting capacity around 45°: 125 mm section flat 45°: 100 x 125 mm working height: 890 mm band saw blade dimensions: 2080 x 20 x 0,9 mm cutting speed: 20-90 m / min coolant pump S1 100%: 100 W power: 0.75 of kW machine dimensions (L x D x H): 1250 x 540 x 1600 mm weight approx.: 157 kg

With extra saw blade Auction-ID: A3-46137-2887

Power 250 W - 220V, never used Overall dimensions: 500 x 500 x 800 mm Weight: 20 kg Auction-ID: A7-50798-216

Mitre adjustment and roller conveyor. Cutting range up to Ø 230 mm or 310 × 200 mm. For more details, see photo The machines are generally offered without documentation. If documents are available, they are attached to the respective machine. Auction-ID: A7-50868-7

Auction-ID: A1-50750-33

Saw adjustable in degrees Auction-ID: A1-50750-10

Variable snelheid____ with additional saws ____ conveyor 1 Auction-ID: A3-46133-2835

Auction-ID: A3-46133-2836

In fully functional condition with additional parts. Auction-ID: A3-46133-17280

Technical details Type: Horizontal metal band saw Configuration: - Hydraulic saw bow - Continuous metal-cutting band saw blade - Hydraulic feed cylinder - Dual hydraulic workpiece clamping system - Adjustable material feed carriage - Feed screw adjustment - Coolant lubrication system with flexible nozzle - Coolant collection tray - Separate electrical control pedestal - Heavy-duty cast-iron frame Application: - Cutting steel bars - Cutting tubes and pipes - Cutting structural profiles - Cutting solid stock - General metal fabrication Construction: - Hydraulic gravity-feed operation - Automatic cutting cycle - Integrated hydraulic power unit Dimensions: - Length: Approx. 2400 mm - Width: Approx. 1600 mm - Height: Approx. 1700 mm Weight: Approx. 1400 kg Condition: Used Observed condition: - Machine appears structurally complete - Saw head and hydraulic cylinders installed - Dual hydraulic  ...

Saw blade length: approx. 2.65 m Saw band width: approx. 10 mm Connection: 220 V Frequency: 50/60 Hz For more details, see photos. Auction-ID: A7-50677-69

Flatbed trailer mounted Auction-ID: A1-50076-452

including: infeed and outfeed roller conveyors: dimensions: 1x L4640 mm, 1x 5370mm, 4x L2160 mm, roller length: 495mm. including 1 roller conveyor segment in hall 1 and parts Auction-ID: A1-49889-20

Power 250 W - 220V, never used Overall dimensions: 500 x 500 x 800 mm Weight: 20 kg Auction-ID: A7-50066-372

cutting diameter: 360 mmsaw band length: 6.300 mmcutting width: 700 mmtable height: 800 mmtotal power requirement: 14 kWweight of the machine ca.: 5,8 tdimensions of the machine ca.: mAutomatic Horizontal Band SawCutting Capacity at 90° (Round): Ø 360 mmCutting Capacity at 90° (Rectangular): 700 x 340 mmCutting Capacity at 75° Mitre (Left & Right):Ø 340 mm / 650 x 340 mmCutting Capacity at 60° Mitre (Left & Right):Ø 340 mm / 600 x 340 mmCutting Capacity at 45° Mitre (Left & Right):Ø 340 mm / 400 x 340 mmMaximum Cutting Diameter: 360 mmMaximum Cutting Width: 700 mmMaximum Cutting Height: 340 mmMinimum Cut-Off Length: 35 mmMinimum Workpiece Size: 10 x 10 x 10 mmRemnant Length (Manual): from 10 mmRemnant Length (Automatic): from 160 mmBlade Tension: 85 barCoolant Tank Capacity: 150 lBlade Speed: 19 – 130 m/minMain Drive Motor: 5.5 kWHydraulic Pump Motor: 5.5 kWCoolant Pump Motor ...
