Horizontal Flat Grinding Machines ELB OPTIMAL 6375 ND
metal working machines / grinding machines / Horizontal Flat Grinding Machines
grinding length: 600 mmgrinding width: 375 mmworkpiece height: 325 mmgrinding height: 325 mmtable load: max. 300 kgtable longitudinal travel: max. 650 mmtable speeds: 1 - 30 m/mingrinding spindle speed: 1440 / 2900 U/mingrinding wheel size: 300 x 50 x 76,2 mmgrinding spindle drive: 3,7 / 4,7 ...
Manufacturer: ELB
Model:OPTIMAL 6375 ND
Type of machine: Horizontal Flat Grinding Machines
item-No.: 170304303
Quantity: 1
Date: 10.10.2026
Year of manufacture: 1990
Location: D - 77815 Bühl
Price:
Machine in stock:Yes
Seller-item-No.:1052-10006
grinding length: 600 mm
grinding width: 375 mm
workpiece height: 325 mm
grinding height: 325 mm
table load: max. 300 kg
table longitudinal travel: max. 650 mm
table speeds: 1 - 30 m/min
grinding spindle speed: 1440 / 2900 U/min
grinding wheel size: 300 x 50 x 76,2 mm
grinding spindle drive: 3,7 / 4,7 kW
vertical feed grinding spindle max.: 180 mm/min.
cross travel: 350 mm
cross adjustment: 1 - 40 mm
rapid traverse cross: 1200 mm/min
total power requirement: 9 kW
weight of the machine ca.: 3,3 t
dimensions of machine L x W x H: 2,75 x 2,10 x 2,05 m
- with autom. positioning -
Accessories: magnetic plate 600 x 350 mm, grinding wheel with flange,
wheel trueing attachment, DRO on Y-and Z-axis, 1 grinding wheel
and various flanges separate, balancing scale, wet grinding
attachment
