7 ERGOMAT used machine for sale

Ergomat TNG 32 + LNS Sprint 552 - Turning Center + Bar Feeder - FANUC 0i-TF CNC control - 60° inclined bed - Cross slides with linear guides - Parts separators - Coolant device -Conveyor - Switch-on time: 645 hours - Processing time: 390 hours - Year of construction 2022 LNS Sprint 552 - Bar Feeder - Rod Ø: 5 - 52 mm - Bar length: 3200 mm - Loading capacity: 11, 9, 8 bars Specifications Main spindle: - Bar passage Ø: 32 mm - Spindle speed max.: 5000 rpm - Collets DIN6343: 171-E A36 - Collets DIN6343: 161-E A25 Workspace: - Workpiece Ø/length: 32 / 75 mm - Travel in X: 300 mm - Travel in Y: 175 mm Cross slide "Gang Type": - Rapid traverse X: 12 m/min - Rapid traverse Z: 20 m/min - Number of tools: 7 - Tool shank Ø: 20 mm - Tool holder 4-point: 12 x 12 mm Coolant system: - Coolant pressure: 6 bar - Tank capacity: 100 l Performance data: - Po ...

Control Fanuc 18iTB Main spindle passage 42 mm 6 axes Front horizontal slide designed as cross slide (X1/Z1) Z2 turret slide including: 6-fold turret, IKZ, turret can be swivelled on both sides Rear horizontal slide x2 Two vertical slides X3 and X4 10 tool positions available Conveyor Bar Feeder SAMECA

Ergomat TBC 60 - Multi-slide turning center - as good as new exhibition machine - Rod passage: 60 mm - Tool holder: VDI 25 Compact multi-carriage turning center with eight CNC axes, two-channel control and backside machining. Developed for the ready-to-use production of complex turned parts. - Fanuc 31i-TB dual-channel control - 8 CNC-controlled axes - 2 vertical shaped slides and piercing slides - CNC cross slide at the front - Rear CNC cross slide with servo-driven Sauter turret and driven tools - Tapping spindle integrated in the turret - Astonishingly short cycle times - Backside processing - Coolant device - Generously dimensioned working area for unhindered chip fall - Chip collector - Year of construction: 2021 Specifications: Rod passage: - Round material: 60 mm - Hexagonal material: 52 mm - Square material: 42 mm Main drive: - max. spindle speed: ...

Location: Germany, Baden-Württemberg Southwest Condition: Used Model No.: TDA 26-36 CNC Year of Make: 1997 High-speed CNC automatic lathe (short lathe) Year of Make: 1997 Control: similar to Fanuc Technical data Max. rod diameter: 36 mm Standard rod passage: 26 mm Max. turning length: 100 mm Swing diameter over face slide: 120 mm Main spindle Speed range: 100 – 6,300 rpm (infinitely variable) Spindle power: 7.5 kW / 11 kW (continuous/peak) Spindle Nose: A2-5 C-axis: Resolution 0.001 Number of slides: 4 linear slides (X/Z) for

Location: Germany, Baden-Württemberg Southwest Condition: Used Model No.: TBA-60 CNC Year of Make: 2005 For sale is a CNC multi-slide automatic lathe ERGOMAT TBA-60, equipped with single bar feed. Technical data Type: TBA-60 Year of Make: 2005 Machine Type: CNC Multi-Slide Automatic Lathe Control: CNC (Fanuc-based control) Workspace Max. bar passage round: 60 mm Max. turning length: 100 mm Spindle Spindle power: 7.5 kW Max. spindle speed: up to 3,150 rpm Tool system Servo-driven 6-fold star turret Turret switching time: approx. 0.3–0.4

This 6-axis ERGOMAT TBC-42 Swiss Turning Machine was manufactured in 2012. It features a maximum material diameter of 42 mm and a spindle speed up to 5000 rpm. Equipped with a Fanuc 18i-TB Dual Path control, it offers precision and versatility with 8 tool positions and rapid feed rates up to 30 m/min. If you are looking to get high-quality turning capabilities consider the ERGOMAT TBC-42 machine we have for sale.Contact us for more information.

This ERGOMAT TNG 32 was manufactured in 2022. It features a spindle with a bar capacity of Ø 32 mm and a maximum speed of 5000 rpm. The horizontal turning machine includes a Fanuc Oi-TF control and an LNS bar loader with a 3m capacity. Consider the opportunity to buy this ERGOMAT TNG 32 horizontal turning machine. Contact us for more information.
