15 GEMINIS used machine for sale

Manufacturer GEMINI Model GHT 6 G2 1,300 x 3,000 Year 2007 CNC FAGOR 8055 TC/C Capabilities Max. turning on bed 1,300 mm. Maximum turntable diameter 1,300 mm. Ø Max. Turning on Transverse Carriage 940 mm. Distance between points 3,000 mm. Axles Fast Forward X-Axis, Z 8 m/min C-axis and motorized tools INCLUDED Head Speed 0-800 rpm No. of automatic ranges 4 Main engine power 46 kW Nose Type DIN-55026-B11 Head shank pitch 104 mm. Turret Turret Positions 8 Turret type VDI 50 (Ø 470 mm) Power of motorized tools 5.5 kW Counterpoint Tailstock shank diameter 180 mm Tailstock shaft course 300 mm Additional equipment Universal 3-jaw plate Ø 900 mm. INCLUDED 3-point bezel Ø 750 mm INCLUDED 3 Point Bezel Ø 400 mm INCLUDED 2 Pcs. Axial motorized tool holder INCLUDED 1 Pc. radial motorized tool holder INCLUDED 20 VDI 50 TOOL HOLDERS INCLUDED Air conditi ...

Manufacturer GEMINI Model GHT-4 720 x 3000 Year 1999 CNC FAGOR 8055 TC/B Capabilities Max turning. On bench/carriage 720 / 470 mm. Stitch height from guide 366 mm. Distance between points 3,000 mm. Progress Axis Fast Forward (X/Z) 8,000 mm/min Axle work advance (X/Z) 8,000 mm/min Head Main shaft hole diameter 92 mm. Nose Head DIN-55027-11 Axle diameter in the front bearing 150 mm. Head revolutions 0-1600 No. of automatic head ranges 2 Main engine power 17 / 20.5 kW Maximum torque main engine 1590 / 1920 Nm Counterpoint Tailstock shank diameter 100 mm Tailstock rod travel 200 mm Morse rod housing 6 Bench Width 430 mm. Height to the flat guide 775 mm. Turret Turret type Duplomatic VDI 40 No. Motorized positions turret 8 Additional equipment 3 Claws Self-centering Ø 315 mm. INCLUDED Plate protection INCLUDED Fixed Steady Rest Cap. 20/200 INCLUDED Ful ...

Key data: 870 mm, 3000 mm

Turning length: 3000 mm Turning diameter: 870 mm above bed 560 mm over cross slide Weight between tips: 3,600 kg without bezel 4,400 kg with 1 bezel 5,600 kg with 2 bezels Spindle speed: 0 - 900 rpm Spindle bore: 162 mm Control: Fagor Equipped with: - Extra jaw chuck on the rear side of the main spindle - 1 fixed bezel Ø420 mm - 1 rotating bezel - 4-jaw chuck Ø800 mm - 3-jaw chuck Ø 400 mm - 10 tool containers - Coolant and chip container at the rear - Machine documents Country of origin: Spain Motor power: 30 kW Machine weight: 9,000 kg Machine LxWxH: 5.1 x 2.4 x 2.0 mtr.

Geminis GE870 used lathe. Distance between centers: 2.000mm. Swing: 870mm. Swing in carriage: 580mm. Swing in gap: 1.100mm. Bore: 82mm. 18 speeds (16-1250rpm) Equipped with universal chuck. Equipped with 4 jaws chuck. Equipped with steady rest Equipped with follow steady rest. CE for used european machinery.

Parallel lathe Geminis GE650S to be rebuilt. Distance between points: 1000mm. Flip on bench: 680mm. Flip on cart: 410mm. Flip over neckline: 850mm. Main hole: 84mm. Motorized trolley and charriot. Speeds: 18 (13-1000rpm). Main engine: 15hp. Plate and trolley protections and CE RD1215/97 certificate. Quick-change plate and turret.

turning diameter over bed:1450 mm turning diameter over slide rest:1000 mm turning length:8000 mm spindle bore:160 mm turning speed range:2,8 - 560 U/min bed width:850 mm faceplate diameter max.:1400 mm turning diameter in the gap:1800 mm length of gap:600 mm dimensions of the machine ca.:12 x 2 x 2,5 m with Digital Readout 2 fixed steadies dia 1070 mm chip conveyor

control: FAGOR 8055 TC workpiece weight: 10.000 kg handwheel: inkl. Chip coveyor: inkl. centre height: 500 mm greates pass round over bed: 1300 mm Swing diameter face slide: 1000 mm centre distance: 5000 mm travel of cross-slide: 680 mm rapid traverse x + z axis: 8 m/min bed width: 900 mm spindle nose: DIN 55026-11 number of spindle speeds: 0-800 U/min/rpm spindle bore: 104 mm spindle diameter in front bearing: 180 mm turning speed range:: Anzahl 4 main drive: 37 kW Torque: 10.000 Nm : Sauter 300 x 300 diameter of quill: 180 mm quill stroke: 300 mm Height: BIS ZUR FLACHFÜHRUNG 805 mm total power requirement: 45 kW weight of the machine ca.: 8,5 t dimensions of the machine ca.: m Equipment -4-jaw faceplate (independent jaws) Ø 800 mm -3-jaw faceplate (independent jaws) Ø 400 mm -Steady rest (4-point support) Ø 750 mm -Chuck guard -Full rear enclosure The data for this ad was ...

engine lathe, year 2007, CNC 8055 TC. Used machine. More info & price on IndustrialBuyer.

Horizontal turning machine manufactured in 2014. This Geminis GT5 G2-1000x2000 features a maximum swing over bed of 1000 mm and a spindle speed of up to 1400 rpm. It also has a distance between centers of 2000 mm and a main spindle hole diameter of 104 mm. If you are looking to get high-quality turning capabilities, consider the Geminis GT5 G2-1000x2000 machine we have for sale. Contact us for further details.

turning diameter: 1.300 mm turning length: 3.000 mm control: FAGOR 8055 TC/C swing diameter over slide transversal: 940 mm feeds: X /Z 8.000 mm/min c-axis: Inkl. speeds:: 0 - 800 u/min transmission ratio: 4 spindle nose: DIN-55026-B11 : 46 kw spindle passage: 104 mm max. workpiece weight between centres: 13.000 kg chip conveyor: Inkl. total power requirement: 50 kW weight of the machine ca.: 16 t dimensions of the machine ca.: 7.925 x 2980 x 2585 m Turret positions 8 Turret type VDI 50 (Ø 470 mm) Driven tool power 5.5 kW Tailstock Tailstock quill diameter 180 mm Tailstock quill stroke 300 mm Additional equipment 3-jaw universal chuck Ø 900 mm 3-point steady rest Ø 750 mm 3-point steady rest Ø 400 mm 2 axial driven tool holders 1 radial driven tool holder 20 VDI 50 tool holders Air-conditioning unit for electrical cabinet Portable handwheel High-pressure coolant  ...

turning diameter over bed: 1450 mm turning diameter over slide rest: 1000 mm turning length: 8000 mm spindle bore: 160 mm turning speeds: 2,8-560 U/min faceplate: 1400 mm 3-jaw chuck: mm bed width: 850 mm turning diameter in the gap: 1800 mm length of gap: 600 mm steady: 1070 mm steady: 1070 mm steady: 650 mm Rapid travel: chip conveyor: kW digital readout: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Multifix steel holder with inserts The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business ...

turning diameter: 870 mm turning length: 3000 mm control: Siemens type: 810 mm bed width: 620 mm turning diameter over slide: 560 mm 3 jaw chuck Forckrath: 630 mm type: 3KTN 630 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software ...

turning diameter: 720 mm turning length: 3.000 mm control: FAGOR 8055 TC/B turning diameter over bed: 470 mm spindle bore: 92 mm spindle nose: DIN-55027-11 spindle diameter: 150 mm spindle drive: 17 / 20,5 kW total power requirement: 28 kW weight of the machine ca.: 5,7 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 880 mm turning length: 6000 mm swing diameter over bed slide: 540 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Brand: Geminis Type: GE870 Distance between centers: 6.000 mm Centre height: 440 mm Swing over bed: 880 mm ø Swing over support: 540 mm ø Swing in the gap: 1.100 mm ø Spindle boring: 85 mm ø Steadys: 400 mm ø + 600 mm ø 3 jaw chuck Digital read-out The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
