GILDEMEISTER gld used machines

CNC slot machine Gildemeister GLD 25 with counter spindle Technical data: Manufacturer: Gildemeister Type: GLD 25 Built: 1999 Control: FANUC Series O-T Main spindle: - max. turning diameter: 25 mm - max. speed: 8,000 rpm - maximum stroke (Z-axis): 160 mm Counter spindle: - max. turning diameter: 25 mm - max. speed: 8,000 rpm - maximum stroke (C-axis): 265 mm - Rapid speed C-axis 15 m/min Sled: - Slide: X= 30 mm, Y= 220 mm - Rapid x-axis 10 m/min - Rapid y-axis 15 m/min - Number of WZ on the sled: 5 + 3 (driven) - Speed WZ (driven) : 6,000 rpm Accessories: - Chip conveyor -Bar loader: IEMCA MINI BOSS 325/32 Dimensions LxWxH: - Machine with chip conveyor 3150 x 1100 x 1700 mm - Bar loader 3900 x 800 x 1400 mm Weight: - Machine: approx.2000 Kg - Bar loader: approx. 1000 kg. - Total weight: approx. 3,000 kg

Gildemeister 6-spindle rotary machine, curve controlled max. rod passage: 32.0 mm for rods up to 3.30 m - incl. rod guide, - Steel processing, run with cutting oel - easily equipped with tools Cmvlgfoyc - 1 set of clamping and feed pliers - Alternating wheels (on machine) - 1 set of curves for cross slides - 1 set of curves for main slide

Gildemeister 6 Spindle Lathe AS 32-6 - Spindle stop set-up - Pneum pick-up device. - Zubehoer at an extra cost - Cross hole drilling - Thread cutting gears - Thread cutting device - wahlw. Fraeseinrichtung Querschl. - Spaenefoerderer

Gildemeister 6-spindle rotary machine, curve controlled max. rod passage: 32.0 mm for rods up to 3.30 m - incl. rod guide, - Steel processing, run with cutting oel - easily equipped with tools Sowiabeb - 1 set of clamping and feed pliers - Alternating wheels (on machine) - 1 set of curves for cross slides - 1 set of curves for main slide

Gildemeister Multispindle Slot machine 6- Spindler Type: AS 25-6 Pick-up device back-valued processing pneumatic stop Balluff cam switch IEMCA PRA Bar loader Oil mist separator (electrostat.) Conveyor Machine has been retrofitted in the past

Tailstock for Gildemeister CTX 600

Note: We have 6 pieces of this machine in stock! Manufacturer: Gildemeister Type: GS 36 – 6 A/C Machine no.: 7.0176 Year of construction: 1987 Weight: 11t General / technical data: Portal-6spindle automatic lathe with measuring device and automatic feeding Spindle dividing circuit: 300mm Number of longitudinal slides: 6 Number of cross slides: 2 gr. cross slide stroke: 60mm gr. longitudinal slide stroke: 125mm Spindle speeds: Infinitely variable 562 – 3373 rpm Main time range: Stepless 1.95 – 78 sec. Low time range: 0.79 – 2.13 sec. Drive power: DC motor spindles 20kW; Feed rates 8kW Installation area: approx. 1720 x 4700mm Remark: The machine cannot be converted for bar work. Equipment: – 1 creep gear drive for set-up operation – 1 automatic central lubrication device – 1 coolant device with lines and pu ...

4x compound slide - Pos.1; Pos.2; Pos.4; Pos.5 4x indipenden feed - Pos.1; Pos.2; Pos.4; Pos.5 threading device 1x threading spindle pick-up spindle broaching device set of cams set of collets bar-loader Cucchi Giovanni (YOM 2004)

Multi-spindle lathe (8 spindles) max. rod diameter 16 mm Guide tubes 4,000 mm Conveyor

turn - diameter over facing slide: 450 mm turning diameter over bed: 830 mm turning diameter: mm turning length: 3000 mm control: Siemens total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control: SIEMENS 840D Max.turning length: 450 mm Max swing diametr over bed/Slide: 500 mm/375mm Workpiece diametr: 246 mm Material passage through the spindle: 0 mm Rotation speed(max.) 6000 rpm Quick Change Toolposts:12 Taper ? VDI30 Coolant tank:175l M

Control: Heidenhain Max.turning length: 450 mm Max swing diameter over bed/slide: 500 mm/375mm Workpiece diametr: 246 mm Material passage through the spindle: 0 mm Rotation speed(max.) 6000 rpm Quick Change Toolposts:12 Taper ? VDI30 Coolant tank:175l Ma

CNC lathe GILDEMEISTER CTX ALPHA 300 with bar feeder and parts pick-up device Built in 2010 in good condition. Duty Cycle: 22930 Hours: 7326 Control Heidenhain CNC-Pilot 640 Circulation over bed: 380 mm Circulation via face slide: 290 mm Spindle bore: 73 mm Flat travel ( X ) : 190 mm Longitudinal travel ( Z ) : 335 mm Speed max. 6000 rpm C-axis 360° Number of driven tool stations 12 pos. Tool holder VDI 30 Accessories: 3 jaw chuck hydraulic 170 mm Conveyor Coolant system Hydraulic hollow clamping device Tool drive C-axis Parts pick-up device Bar Feeder Irco RBK10012 Tailstock

Key data: 320 mm, 750 mm

Manufacturer: Gildemeister Model N.E.F. 320 K Year of construction 2004 Condition Used Siemens control system Specifications Circulation diameter 320 mm Turning length 750 mm Speed range - main spindle 3500 rpm Drive power - main spindle 9 kW Bar diameter 50 mm Tool holder Multifix size B Tailstock mount MK 5 Rapid traverse X / Z 8 / 10 m/min Machine weight approx. 2.5 t Space requirement approx. 2500 x 1800 x 1885 mm Accessories: 3 Jaw chuck Forkardt 200 Tool package Documentation

Turning diameter 80 mm Bar diameter 20 mm Spindle speed 10000 rpm X1, Y1, Z1, X2,Z2 axes Controller Fanuc FANUC 160iB LNS barfeeder

Gildemeister Sprint 65 Linear CNC lathe (with 2nd spindle, 3 turrets and Y-axis) Diameter of spindle bore 65 mm Spindle speed 5,000 rpm Spindle motor 25/20 kW Spindle speed counter spindle 5,000 rpm X-axis movement 165 / 165 / 165 Movement Y-axis 80 mm Z-axis travel 220 / 150 / 650 mm Movement of the W-axis (counter spindle to the main spindle) 690 mm C-axis indexing 0.0001° Number of towers 3 Number of tools on turret 12 (3x 12) Tool cone VDI 30 Bar Feeder LNS Quick Load Servo 65 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other listings for a full overview of our stock.

Gildemeister Sprint 65 Linear CNC lathe (with 2nd spindle, 3 turrets and Y-axis) Diameter of spindle bore 65 mm Spindle speed 5,000 rpm Spindle motor 25/20 kW Spindle speed counter spindle 5,000 rpm X-axis movement 165 / 165 / 165 Movement Y-axis 80 mm Z-axis travel 220 / 150 / 650 mm Movement of the W-axis (counter spindle to the main spindle) 690 mm C-axis indexing 0.0001° Number of towers 3 Number of tools on turret 12 (3x 12) Tool cone VDI 30 Bar Feeder LNS Quick Load Servo 65 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other listings for a full overview of our stock.

DMG GILDEMEISTER CTX ALPHA 300 CNC turning center was built in 2008. The machine, designed for machining workpieces with a maximum diameter of 500 mm, is equipped with state-of-the-art technical solutions that guarantee extraordinary accuracy and precision. Machining is performed inside a large, fully illuminated workspace by a reliable spindle and high-quality cutting tools taken from a 12-position turret. In turn, the operator is provided with a state-of-the-art touchscreen control panel with a perfectly optimised FANUC CNC controller. High reliability, precision and structural stability make the GILDEMEISTER CTX ALPHA 300 CNC lathe the perfect choice for even the most intensive production work. The total weight of the machine is approximately 4350 kg. Technical data of the DMG GILDEMEISTER CTX ALPHA 300 lathe - maximum turning diameter: 500 mm - maximum cutting diameter: 200 mm  ...

DMG GILDEMEISTER CTX 510 CNC turning center was built in 2008. Designed for machining workpieces with a maximum diameter of 465 mm, the machine features a fully illuminated workspace, a high-speed spindle and high-end cutting tools. The extremely stable design combined with the perfectly optimised SIEMENS CNC control ensures maximum process efficiency, even during the most intensive production work. The DMG CTX 510 CNC lathe weighs 7500 kg. Technical specifications of the DMG GILDEMEISTER CTX 510 lathe - maximum turning diameter: 465 mm - maximum swing diameter: 680 mm - maximum swing diameter above cross guideway: 465 mm - maximum external diameter of clamped workpiece: 400 mm - feed in the X/Z axis: 300/1050 mm - rapid traverse in X,Z axis: 30 m/min - maximum spindle rotational speed: 3500 rpm - spindle passage: 97 mm - spindle drive power (40%/100% DC): 42/31 kW - chuck s ...

DMG GILDEMEISTER CTX 410 CNC lathe built in 2006 is an extremely powerful machine designed for precision machining of workpieces with a maximum diameter of 320 mm. The machining process is performed inside a large, fully illuminated workspace using reliable components in the form of cutting tools and a high-speed spindle. The specially designed inclined bed effectively dampens all vibrations and oscillations, resulting in better quality of the machined surface and increased tool life. The offered DMG CTX 410 CNC turning center is also equipped with an integrated chip conveyor and a perfectly optimised, intuitive HEIDENHAIN CNC control. The total weight of the machine is approximately 6000 kg. Technical specifications of the DMG GILDEMEISTER CTX 410 turning center - CNC controller: HEIDENHAIN - turning diameter: 320 mm - turning length: 600 mm - feed in the X/Z axis: 250/635 mm -  ...

GILDEMEISTER NEF Plus 500 CNC lathe was manufactured in 1997. The machine, designed for precision machining of workpieces with a maximum diameter of 500 mm, has two spindles (main spindle and sub-spindle) of high speed and power, which will improve even the most intensive machining. The installed GRUNDING CNC controller with colour screen and control panel also allows for cycles to control. The total weight of the machine is approximately 3000 kg. Technical specifications of the GILDEMEISTER NEF Plus 500 lathe - CNC control: GRUNDIG - maximum turning diameter (over bed): 500 mm - maximum turning diameter (over saddle): 290 mm - maximum turning length: 1500 mm - main spindle rotational speed range: 80-2800 rpm - main spindle passage: 70 mm - main spindle drive power: 11 kW - maximum sub-spindle rotational speed: 5000 rpm - sub-spindle drive power: 7.5 kW - total power require ...

General: Year of construction 2006 Management Heidenhain plus IT Travel X 150 mm Z 650 mm Y 80 mm Program duration 10,600 h Spindle: Spindle speed 5,000 rpm Spindle bore 65 mm Turning diameter over face slide 375 mm Turning length 635 mm Revolver: Tool holder VDI30 Number of stations 12-fold with AGW Dimensions and weight: Dimensions 5,000 mm x 2,500 mm x 2,800 mm Weight approx. 5,800 kg

Control: Siemens 840 D powerline Accessories: Tool holder bar loading magazine Fully functional and still under power, can be visited at any time

Key data: 500 mm, 450 mm, 6000 1/min

1 used CNC lathe Make Gildemeister Model CTX 320 V5 Linear Year of manufacture 2004 Control Siemens 840 D ( ShopTurn ) Workspace: Max. circulation diameter over bed 500 mm Circumferential diameter via X-carriage 300 mm Turning length 450 mm Bar passage 60 mm Chuck diameter 170 mm Chuck diameter sub-spindle 165 mm Plane stroke 160 mm Rapid traverse X/Z axis 60/45 m/min Power main drive (100% ED) 16 kW Speed range 6000 rpm Power sub-spindle (100% ED) 7.5 kW Speed range 6000 rpm Number of tool stations 12 Cylindrical shank diameter 30 mm Number of driven tools 12 Drive power (40% ED) 10 kW RPM, max. 5000 min-1 C-axis speed range 0 - 200 min-1 C-axis positioning 0.001 degrees Connected load, total approx. 32 kVA Net weight with chip conveyor approx. 4300 kg Machine with chip conveyor L x W x H 3890 x 1555 x 1890 mm Accessories: Conveyor Pa ...

Specifications: Main spindle: Max. turning diameter: 33 mm Max. speed: 8000 1/min Drive power: 5.5 kW Drive power at 60% ED: 7.5 kW Slide 1: Carriage path Z1: 320 mm Slide path X1: 50 mm Carriage path Y1: 255 mm Rapid traverse speed: 30 m/min Ball screw diameter: 25 mm Tool holder slide 1: Number of tools fixed with tool shank 16 x 16: 5 pieces Slide 2: Slide path X2: 165 mm Carriage path Z2: 200 mm Rapid traverse speed: 30 m/min Ball screw diameter: 30 mm Tool holder slide 2: Number of stations for turret with integrated spindle: 8 pieces Number of axially driven tools (integrated): 8 pieces Coolant pan, approx.: 400l Coolant pump, max. capacity: 80 l/min Dimensions (LxWxH), approx.: 2460 x 1510 x 1750 mm Equipment: - CNC control Fanuc iT - Workpiece unloading system - IEMCA bar loading magazine - 5-item tool carrier plate for carriage 1 - Elec ...
